Features Scalable geometry architecture Hardware tessellation engine FXAA/TXAA dedicated anti-aliasing engine Shader Model 5.0 (Open GL 4.5 & Direct X 12) Up to 16K x 16K texture & render processing Transparent multisampling & super sampling 16x angle independent anisotropic filtering 32-bit per-component floating point texture filtering & blending Up to 64x full scene antialiasing (FSAA) Decode acceleration for MPEG-2, MPEG-4 Part 2 Advanced Simple Profile, H.264, MVC, VC1, Div X (version 3.11 & later), & Flash (10.1 & later) Dedicated H.264 Encoder NVIDIA GPU Boost (Automatically increases GPU engine throughput to maximize application performance.) Overview NVIDIA Unified Driver Architecture (UDA) Guarantees forward & backward compatibility with software drivers. This simplifies upgrading to a new NVIDIA solution because the latest driver supports all current NVIDIA products. Ultra-Quiet High Reliability Cooling Solution Built with a highly reliable, ultra-quiet fansink that efficiently cools the graphics without taxing the system fans resulting in a quieter desktop environment, as well as enabling multi-NVS 810 configurations in workstations & desktop systems Compatibility with Industry-Standard Architectures Compatible with x 86 32 & 64-bit microprocessor architectures & operating systems from Intel/AMD & Microsoft/ Linux. Tested & Certified across multiple platforms NVS 810 is tested on industry-leading business applications as well as certified to work in commercial desktop & workstations from multiple PC System Vendors to provide a highly reliable business environment.

Specification CUDA Cores 1, 024 (512 per GPU) GPU Memory 4GB DDR3 (2GB per GPU) Memory Interface 128-bit (64-bit per GPU) Memory Bandwidth 28.8GB/s System Interface PCI Express 3.0 x 16 Maximum Power Consumption 68W Energy Star Enabling Yes Thermal Solution Ultra-quiet active fansink Form Factor 4.40” H x 9.50” L, Single Slot Display Connectors 8 Mini-Display Port Display Port 1.2 Yes Display Port with Audio Yes Mini-DP to DP adapters None – order PN VCNVS810DP-PB if Display Port is required Mini-DP to DVI-D SL adapters 8 included with PN VCNVS810DVI-PB Number of Displays Supported 8 at 4, 096 x 2, 160 at 30 Hz (4 at 4, 096 x 2, 160 at 60 Hz) Maximum DP 1.2 Resolution 4, 096 x 2, 160 at 60 Hz (3, 840 x 2, 160 at 60 Hz also available) Maximum DVI-D SL Resolution 1, 920 x 1, 200 at 60 Hz HDCP Support Yes Graphics APIs Shader Model 5.0, Open GL 4.3, Direct X 11 Compute APIs CUDA, Direct Compute, Open CL NVIEW Yes NVIDIA Mosaic Yes (Windows 10, 8.1, 8, 7, & Linux) Bezel Correction Yes Warp & Blend Yes Synchronization Yes (8 displays hosted by a single NVS 810) Warranty 3 Years PNY Part Number VCNVS810DVI-PB Minimum System Requirements Microsoft Windows 10, 8.1, 8, Linux, or Solaris PCIe x 16 expansion slot 1GB or more of system memory, 2GB recommended 200MB of available disk space for full driver installation Blu-ray, DVD-ROM or CD-ROM drive DVI compatible displays (via included m DP to DVI-D SL adapters) Package Contains NVIDIA NVS 810 professional graphics board 8 locking mini-Display Port to DVI-D SL adapters Software Installation Disc for Windows 10, 8.1, 8, 7 (32- & 64-bit) Printed Quick Start Guide

...

Delivering the industry's best-in-class performance across leading professional ISV applications, the NVIDIA Quadro 2000D by PNY features two dual-link DVI connectors to drive two ultra-high-resolution panels & add flexibility for multi-monitor configurations. Professional applications can take advantage of the Quadro 2000D advanced feature set, including Scalable Geometry Engine technology, 192 NVIDIA CUDA parallel processing cores & 1GB of memory for fast processing of complex models & scenes. The NVIDIA Quadro 2000D by PNY also delivers the industry's most advanced diagnostic imaging graphics solution. Offering two dual-link DVI connectors for display flexibility, support for 10/12-bit grayscale monitors up to 10 Mpixels, & DICOM monitor calibration capabilities
- the Quadro 2000D enables more confident medical analysis. Based on NVIDIA's award-winning Fermi Architecture, the Quadro 2000D delivers advanced capabilities including 3D Vision Pro for high quality stereoscopic 3D environments & Mosaic Technology which enables any application to scale across up to eight displays using multiple Quadro graphics boards.
...

The NVIDIA Quadro 600 professional graphics solution delivers exceptional value to the entry level professional graphics market. ...

NVIDIA Quadro K1200 – Accelerate Your Creativity Now

Includes:: both Full-Height & Half-Height brackets.

...

NVIDIA Quadro K2200 4 GB GDDR5 Dual-Link DVI 2x Displayport PCI-E Graphics card Easily support your professional software application base with comprehensive ISV certifications Excellent performance from the ultra-efficient Kepler GPU architecture & ultra fast GDDR5 memory to zip through larger models & datasets Driving up to four digital displays from a single card & managing them with NVIDIA's Mosaic & n View technology Designed to the MXM type A

Specification for compatibility with the HP Z1 G2 workstation NVIDIA Quadro 3D workstation professional graphics solutions Designed & built specifically for professional workstations, NVIDIA Quadro GPUs power more than 150 professional applications across a broad range of industries. Professionals trust them to deliver the best possible experience in applications such as Adobe Creative Cloud, Avid Media Composer, Autodesk Inventor, and many more. NVIDIA Tesla co-processors NVIDIA Tesla GPU parallel processors provide the highest-performance NVIDIA CUDA acceleration for your workflow. Designed for professional systems & demanding professional applications, Tesla GPUs perform the complex calculations required for CAE/CFD calculations, seismic processing, ray-traced rendering, compositing, image processing, physics, and effects many times faster than a CPU. NVIDIA Maximums platform NVIDIA Maximums-powered workstations combine the industry-leading professional 3D graphics capability of NVIDIA Quadro GPUs with the high-performance computing power of NVIDIA Tesla GPUs. Tesla co-processors automatically perform the heavy lifting of rendering or CAE computations, freeing the Quadro GPUs to do what they do best
- enabling rich interactive graphics. With maxims, engineers, artists, designers, and scientists can now interact with high-performance visuals while also performing simulations or renderings on the same system. NVIDIA NVS commercial graphics solutions NVIDIA NVS graphics boards provide robust IT management tools for seamless enterprise deployment. This makes them the trusted solution of choice financial institutions, emergency call centers, digital signage systems, and other mission-critical environments. Product Description NVIDIA Quadro K2200 graphics card
- Quadro K2200
- 4 GB Device Type Graphics card Bus Type PCI Express 2.0 x 16 Graphics Engine NVIDIA Quadro K2200 Memory 4 GB
- GDDR5 CUDA Cores 640 Memory Interface 128-bit Max Resolution 4096 x 2160 Max Resolution Details DVI:2560 x 1600 at 60 Hz / Display Port:4096 x 2160 at 60 Hz / VGA:2048 x 1536 at 85 Hz Max Monitors Supported 3 Interfaces DVI-I (dual link) 2 x Display Port DVI
- with adapter VGA
- with adapter API Supported Open CL, Direct Compute, Direct X 11.1, Open GL 4.4

Dimensions (Wx Dx H) 20.2 cm x 11.1 cm Pricing Type Promo Designed For Workstation Z440, Z640, Z840









...

384 CUDA cores 2 GB of DDR3 GPU memory 128-bit memory interface 29 GB/s memory bandwidth PCI Express 2.0 x 16 system interface 45 Watt maximum power consumption Energy Star certified Ultra-quiet active fansink DVI-I DL + DP 1.2 + DP 1.2 display connectors Drives two directly attached displays Drives up to 4 displays via Display Port 1.2 multi-streaming technology Certified for use with over 200 professional applications Unmatched NVIDIA Quadro professional drivers NVIDIA Mosaic multi-display technology NVIDIA NVIEW desktop management technology NVIDIA multi-GPU compatible ...

NVIDIA Quadro K620 2GB DDR3 DVI-I DVI-D Display Port PCI-E Graphics Card The NVIDIA Quadro K620 offers impressive power-efficient 3D application performance & capability in a low profile design. 2 GB of DDR3 GPU memory with fast bandwidth enables you to create large, complex 3D models, and a flexible single-slot & low-profile form factor makes it compatible with even the most space & power-constrained chassis. Plus, display engine drives up to four displays with Display Port 1.2 support for ultra-high resolutions like 4096x 2160 @ 60 Hz with 30-bit color. The Quadro K620 is an excellent card for medium sized product development activities & media creation. Great performance for leading professional applications 2 GB of GPU memory All in a power efficient low-profile form factor for maximum usage flexibility Specifications: Device Type Graphics card
- low profile Bus Type PCI Express 2.0 x 16 Graphics Engine NVIDIA Quadro K620 CUDA Cores 384 Max Resolution 4096 x 2160 at 60 Hz Max Resolution Details DVI (Single-Link):1920 x 1200 / DVI (Dual-Link):2560 x 1600 / Display Port:4096 x 2160 Max Monitors Supported 2 Interfaces DVI-I (dual link) Display Port DVI-D (Single-Link)
- with adapter API Supported Direct X 11, Open CL, Direct Compute, Open GL 4.4 Features Nvidia n VIEW Multi-Display Technology, Nvidia CUDA technology, Nvidia 3D Vision technology, Shader Model 5.0, Nvidia Quadro Mosaic Technology, High Bit Rate 2, Maxwell architecture Memory Size 2 GB Technology DDR3 SDRAM Effective Clock Speed 900 MHz Bus Width 128-bit Bandwidth 29 GBps System Requirements OS Required Linux, Microsoft Windows 7, Windows 8, Windows 8.1 Miscellaneous Power Consumption Operational 45 Watt Included Accessories Full-height bracket Cables Included 1 x Display Port-DVI adapter Depth 16 cm Height 6.89 cm Weight 133 g Pricing Type Promo Manufacturer Warranty Service & Support 1 year warranty

...

Features Easily support your professional software application base with comprehensive ISV certifications. Experience fluid interactions with your 3D models & datasets with 2 GB of DDR3 memory. Get low-profile, single-slot 3D performance that fits within your most compact workstation chassis, & the entire HP Z Workstation lineup, & doesn’t require external power. Drive displays with ultra-high resolutions like 4096 x 2160 @ 60 Hz with 30-bit color & easily manage them with NVIDIA Mosaic & NVIDIA n View technologies. The NVIDIA Quadro K620 2GB is supported on the following HP Z Workstations: Z230 CMT, Z440, Z640, Z840 Overview Enjoy impressive application performance for your more demanding 3D models & datasets with the NVIDIA Quadro K620 graphics card & its 2 GB dedicated memory.

Specification Compatibility The NVIDIA Quadro K620 2GB is supported on the following HP Z Workstations: Z230 CMT, Z440, Z640, Z840

Dimensions Out of Package: 6.89 x 16 cm

Dimensions (case or master carton, metric): 597 x 198 x 250 mm Case or master carton quantity: 10 Count of cartons per pallet layer: 10 Count of layers in pallet: 8 Quantity per Pallet: 800 Packed: 184 x 232 x 57.5 mm Weight Out of Package: 0.133kg Warranty The NVIDIA Quadro K620 has a one-year limited warranty or the remainder of the warranty of the HP product in which it is installed. Technical support is available seven days a week, 24 hours a day by phone, as well as online support forums. Parts & labor are available on-site within the next business day. Telephone support is available for parts diagnosis & installation. Certain restrictions & exclusions apply. Additional information P/N: J3G87AA UPC/EAN code: 888793835791 Country of Origin China Whats in the box NVIDIA Quadro K620 2GB Graphics Card; Low Profile bracket; DP to DVI-D adapter; Documentation





...

Nvidia Quadro M2000 4GB GDDR5 Display Port PCI-E Graphics Card he Quadro M2000 delivers an incredible creative experience across a broad range of professional 3D applications. This advanced graphics board features an NVIDIA Maxwell-based GPU, 4GB of ultra-fast on-board memory & the power to drive four 4K displays natively. This makes it an excellent choice for accelerating product development & content creation workflows that demand fluid interactivity with complex models & scenes. Creative professionals can tap into this increased performance – as well as hardware HEVC encode & decode engines—to accelerate both creation & playback of HEVC content. Designed & built specifically for professional workstations, NVIDIA Quadro GPUs power more than 100 professional applications across a broad range of industries including manufacturing, media & entertainment, sciences, & energy. Professionals trust them to realize their most ambitious visions— whether its product design, visualization & simulation, or spectacular visual storytelling—and get results to market faster. To learn how NVIDIA Quadro & Iray enabled interactive physically based rendering can dramatically transform design workflows click here to receive a complementary Desktop Engineering whitepaper (registration required). Product Specifications CUDA Cores 768 GPU Memory 4GB GDDR5 Memory Interface 128-bit Memory Bandwidth 106GB/s System Interface PCI Express 3.0 x 16 Maximum Power Consumption 75 W Energy Star Enabling Yes Thermal Solution Ultra-quiet active fansink Form Factor 4.376” H x 6.6” L, Single Slot Display Connectors DP 1.2 (4) Display Port 1.2 Yes Display Port with Audio Yes DVI-D Dual Link Connector Via optional 3rd party adapter DVI-D Single-Link Connector Via included adapter (1 only) Number of Displays Supported 4 Maximum DP 1.2 Resolution 4096 x 2160 at 60 Hz Maximum DVI-D DL Resolution 2560 x 1600 at 60 Hz Maximum DVI-D SL Resolution 1920 x 1200 at 60 Hz HDCP Support Yes Graphics APIs Shader Model 5.0, Open GL 4.5, Direct X 12 Compute APIs CUDA, Direct Compute, Open CL NVIEW Yes NVIDIA Mosaic Yes (Windows 10, 8.1, 8, 7, Vista, Linux) Warranty 3 Years PNY Part Number VCQM2000-PB Minimum System Requirements Microsoft Windows 10, 8.1, 8, 7, Vista, Linux, or Solaris PCIe x 16 Gen 3 (preferred) expansion slot 2 GB or more of system memory, 8 GB recommended 200MB of available disk space for full driver installation Blu-ray or DVD-ROM drive Internet connection (if preferred for driver installation) Display Port, DVI, or VGA compatible display (s) ...

Features Experience ultra-fast visualization & compute horsepower with 4GB ultra-fast GDDR5 memory & CUDA parallel processing. Drive up to four 4K or two 5k displays or one 8K projector with four Display Port 1.2 ports & managed them with included NVIDIA Mosaic™ & NVIDIA n View technologies. Enable immersive collaboration with optional 3D Vision™ & 3D Vision Pro. Boost application performance in real time while staying within the power & thermal envelope of the card with NVIDIA GPU Boost. Easily support your professional software application base with comprehensive ISV certifications. Compatible with Z240 CMT, Z440, Z640, Z840. Overview Get fast performance & work interactively with models & scenes across CAD, DCC, & medical applications with the new Maxwell GPU architecture features of the flexible, single-slot NVIDIA Quadro M2000 graphics card.

Specification Weight 8.43 oz (0.23 kg)

Dimensions (W x D x H) 4.37 x 6.6 in (110 x 167 mm) Whats in the box Graphics Card; Documentation Warranty The NVIDIA Quadro M2000 has a one-year limited warranty or the remainder of the warranty of the HP product in which it is installed. Technical support is available seven days a week, 24 hours a day by phone, as well as online support forums. Parts & labor are available on-site within the next business day. Telephone support is available for parts diagnosis & installation. Certain restrictions & exclusions apply.



...
