Supporting multiple independent display outputs simultaneously, AMD Eyefinity technology delivers innovative graphics display capabilities enabling massive desktop workspaces & ultra-immersive visual environments for the ultimate panoramic computing experience. Chipset
- AMD Radeon HD 7790 Memory Clock
- 6000 MHz Process Technology
- 28 nm PCB Form
- ATX Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 3 Memory Size
- 1 GB Memory Bus
- 128 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.2 Core Clock
- 1075 MHz













...

This new “ Triangle Cool” fansink integrates a patented triangle-shaped aluminum block into the aluminum extrusion module. The triangle design maximizes the efficiency of the wind flow to enhance heat dissipation, & also minimizes the turbulence between extruded aluminum fins, which can improve cooling performance for the whole fansink. Chipset Radeon
- HD 7790 Memory Clock
- 6000 MHz Core Clock
- 1075 MHz PCB Form
- ATX Process Technology
- 28 nm Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 3 Memory Size
- 1 GB Memory Bus
- 128 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.2 Card size
- H=42, L=203, W=136 I/O HDMI * 1 DVI-I * 1 DVI-D * 1 Display Port Power requirement
- 450W















...

Overview
- Gigabyte Radeon HD 7850 1GB Graphics Card PCI-E Mini-Display Port DVI HDMI Features
- Powered by AMD Radeon HD 7850

...

GIGABYTE HD Experience Series Powered by AMD Radeon HD 7850 GPU Integrated with the first 1GB GDDR5 memory & 256-bit memory interface Features Dual-link DVI-I / HDMI / mini Display Port * 2 Overclock to 900 MHz Support AMD Eyefinity Technology & Avivo™HD System power supply requirement: 500W

Specification
- Chipset
- Radeon HD 7850 Core Clock
- 900 MHz Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Memory Clock
- 4800 MHz Memory Size
- 1 GB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.2 Multi-view
- 4 I/O
- HDMIx 1, DVI-Ix 1, Mini Display Portx 2 Card size
- H= 42.5mm, L=241 mm, W= 137mm Power requirement
- 500 W



















...

Gigabyte HD 7850 DVI HDMI Display Port PCI-E Graphics Card Using high quality components on graphics cards is the key factor for having a long lasting, stable & reliable product. GIGABYTE is again setting a new standard by using Ferrite Core Chokes, Low RDS (on) MOSFET & Lower ESR Solid Capacitors, providing the stability & reliability from their high-end graphics solution. In addition, GIGABYTE Ultra Durable 2 Edition graphics cards now feature a sophisticated layout topology. This state-of-the-art power design from GIGABYTE delivers the ideal integration of thermal, electric characteristics, digital signals, power circuitry & optimum placement of components for enhanced graphics performance. Chipset
- Radeon HD 7850 Core Clock
- 975 MHz Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Memory Clock
- 4800 MHz Memory Size
- 2 GB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.2 Multi-view
- 4 I/O HDMI * 1 DVI-I * 1 Mini Display Port * 2 Card size
- H= 42.5mm, L=241 mm, W= 137mm Power requirement
- 500 W















...

Free Never Settle Reloaded games download coupon bundle with selected purchases from 2nd May 2013 whilst stocks last.



...

Chipset
- Radeon HD 7870 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
-



...

Gigabyte HD 7950 3GB GDDR5 DVI HDMI Display Port PCI-E Graphics Card Features & Benefits: Lower GPU Temperature: Ultra Durable VGA board provides dramatic cooling effect on lowering both GPU & memory temperature by doubling the copper inner layer of PCB. Better Overclocking Capability: Ultra Durable VGA board reduces voltage ripples in normal & transient state, thus effectively lowers noises & ensures higher overclocking capability. Decrease Power Switching Loss: Ultra Durable VGA board allows more bandwidth for electron passage & reduces circuit impedance. The less circuit impedance, the more stable flow of current & can effectively improve power efficiency. Chipset
- Radeon HD 7950 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Core Clock
- Base 900/ Boost 1000 MHz Memory Clock
- 5000 MHz Memory Size
- 3072 MB Memory Bus
- 384 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.2 Multi-view
- 4 I/O HDMI * 1 DVI-I * 1 Mini Display Port *2 Card size
- H=38 mm, L=285 mm, W=126 mm Power requirement
- 500 W















...

WINDFORCE 3X " Triangle Cool" Technology Compared to traditional linear heat transfer solution, GIGABYTE introduces the latest exclusive “ Triangle Cool” Technology that combines fin with clip module in a special triangle shape. This anti-turbulence structure enhances the efficiency of heat dissipation dramatically. Furthermore, the triangle design minimizes the flow of turbulence between fans & provides the system with more efficient air flow. Main Features AMD RADEON HD 7950 GPU (Tahiti PRO) OC to 900 M Hz (std: 800 MHz) GIGABYTE WINDFORCE 3X cooling design with “ Triangle Cool” technology&65289; Temperature: 35% cooler than stock fan 9.7% Performance better than stock HD 7950 19% Performance better than stock GTX 580 35% Performance better than stock GTX 570 PCI Express 3.0 x 16 bus interface World’s first 28nm GPU 3072MB of GDDR5 memory 384-bit memory interface Supports Open GL 4.2 / Shader Model 5.0 AMD Eyefinity 2.0 Technology AMD Cross Fire X Support Native HDMI 1.4a (with 3D over HDMI) Support mini Displayport 1.2 Specifications GPU
- Radeon HD 7950 (Tahiti PRO) Core Clock
- 900 MHz (Std 800 MHz) Memory Clock
- 5000 MHz Memory Size
- 3072MB GDDR5 Bus Type
- PCI Express 3.0 Memory Bus
- 384-bit Stream Processors
- 1792 Memory type
- 64 Mx 32 Direct X 11
- Yes Outputs
- DVI Port DVI-I, Display Port Yes (Mini Displayport*2), HDMI Yes HDCP
- Yes










...

Gigabyte HD 7970 3GB GDDR5 DVI HDMI Displayport PCI-E Graphics Card GIGABYTE introduces the latest exclusive " Triangle Cool" Technology to reach a better cooling performance. The latest patented technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the new triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. Therefore, the " Triangle Cool" Technology provides a more efficient air flow for the cooling system. Chipset
- Radeon HD 7970 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Core Clock
- 1000 MHz Memory Clock
- 5500 MHz Memory Size
- 3072 MB Memory Bus
- 384 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL- 4.2 Multi-view
- 4 I/O HDMI * 1 DVI-I * 1 Mini Display Port *2 Card size
- H=38 mm, L=285 mm, W=126 mm Power requirement
- 550 W














...
