Overview
- Gigabyte Radeon HD 7850 1GB Graphics Card PCI-E Mini-Display Port DVI HDMI Features
- Powered by AMD Radeon HD 7850

...

GIGABYTE HD Experience Series Powered by AMD Radeon HD 7850 GPU Integrated with the first 1GB GDDR5 memory & 256-bit memory interface Features Dual-link DVI-I / HDMI / mini Display Port * 2 Overclock to 900 MHz Support AMD Eyefinity Technology & Avivo™HD System power supply requirement: 500W

Specification
- Chipset
- Radeon HD 7850 Core Clock
- 900 MHz Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Memory Clock
- 4800 MHz Memory Size
- 1 GB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.2 Multi-view
- 4 I/O
- HDMIx 1, DVI-Ix 1, Mini Display Portx 2 Card size
- H= 42.5mm, L=241 mm, W= 137mm Power requirement
- 500 W



















...

Gigabyte HD 7850 DVI HDMI Display Port PCI-E Graphics Card Using high quality components on graphics cards is the key factor for having a long lasting, stable & reliable product. GIGABYTE is again setting a new standard by using Ferrite Core Chokes, Low RDS (on) MOSFET & Lower ESR Solid Capacitors, providing the stability & reliability from their high-end graphics solution. In addition, GIGABYTE Ultra Durable 2 Edition graphics cards now feature a sophisticated layout topology. This state-of-the-art power design from GIGABYTE delivers the ideal integration of thermal, electric characteristics, digital signals, power circuitry & optimum placement of components for enhanced graphics performance. Chipset
- Radeon HD 7850 Core Clock
- 975 MHz Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Memory Clock
- 4800 MHz Memory Size
- 2 GB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.2 Multi-view
- 4 I/O HDMI * 1 DVI-I * 1 Mini Display Port * 2 Card size
- H= 42.5mm, L=241 mm, W= 137mm Power requirement
- 500 W















...

Using high quality components on graphics cards is the key factor for having a long lasting, stable & reliable product. GIGABYTE Ultra Durable 2 Edition graphics cards now feature a sophisticated layout topology. This state-of-the-art power design from GIGABYTE delivers the ideal integration of thermal, electric characteristics, digital signals, power circuitry & optimum placement of components for enhanced graphics performance. ...

Free Never Settle Reloaded games download coupon bundle with selected purchases from 2nd May 2013 whilst stocks last.



...

Gigabyte HD 7950 3GB GDDR5 DVI HDMI Display Port PCI-E Graphics Card Features & Benefits: Lower GPU Temperature: Ultra Durable VGA board provides dramatic cooling effect on lowering both GPU & memory temperature by doubling the copper inner layer of PCB. Better Overclocking Capability: Ultra Durable VGA board reduces voltage ripples in normal & transient state, thus effectively lowers noises & ensures higher overclocking capability. Decrease Power Switching Loss: Ultra Durable VGA board allows more bandwidth for electron passage & reduces circuit impedance. The less circuit impedance, the more stable flow of current & can effectively improve power efficiency. Chipset
- Radeon HD 7950 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Core Clock
- Base 900/ Boost 1000 MHz Memory Clock
- 5000 MHz Memory Size
- 3072 MB Memory Bus
- 384 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL
- 4.2 Multi-view
- 4 I/O HDMI * 1 DVI-I * 1 Mini Display Port *2 Card size
- H=38 mm, L=285 mm, W=126 mm Power requirement
- 500 W















...

WINDFORCE 3X " Triangle Cool" Technology Compared to traditional linear heat transfer solution, GIGABYTE introduces the latest exclusive “ Triangle Cool” Technology that combines fin with clip module in a special triangle shape. This anti-turbulence structure enhances the efficiency of heat dissipation dramatically. Furthermore, the triangle design minimizes the flow of turbulence between fans & provides the system with more efficient air flow. Main Features AMD RADEON HD 7950 GPU (Tahiti PRO) OC to 900 M Hz (std: 800 MHz) GIGABYTE WINDFORCE 3X cooling design with “ Triangle Cool” technology&65289; Temperature: 35% cooler than stock fan 9.7% Performance better than stock HD 7950 19% Performance better than stock GTX 580 35% Performance better than stock GTX 570 PCI Express 3.0 x 16 bus interface World’s first 28nm GPU 3072MB of GDDR5 memory 384-bit memory interface Supports Open GL 4.2 / Shader Model 5.0 AMD Eyefinity 2.0 Technology AMD Cross Fire X Support Native HDMI 1.4a (with 3D over HDMI) Support mini Displayport 1.2 Specifications GPU
- Radeon HD 7950 (Tahiti PRO) Core Clock
- 900 MHz (Std 800 MHz) Memory Clock
- 5000 MHz Memory Size
- 3072MB GDDR5 Bus Type
- PCI Express 3.0 Memory Bus
- 384-bit Stream Processors
- 1792 Memory type
- 64 Mx 32 Direct X 11
- Yes Outputs
- DVI Port DVI-I, Display Port Yes (Mini Displayport*2), HDMI Yes HDCP
- Yes










...

Gigabyte HD 7970 3GB GDDR5 DVI HDMI Displayport PCI-E Graphics Card GIGABYTE introduces the latest exclusive " Triangle Cool" Technology to reach a better cooling performance. The latest patented technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the new triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. Therefore, the " Triangle Cool" Technology provides a more efficient air flow for the cooling system. Chipset
- Radeon HD 7970 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Core Clock
- 1000 MHz Memory Clock
- 5500 MHz Memory Size
- 3072 MB Memory Bus
- 384 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.1 Open GL- 4.2 Multi-view
- 4 I/O HDMI * 1 DVI-I * 1 Mini Display Port *2 Card size
- H=38 mm, L=285 mm, W=126 mm Power requirement
- 550 W














...

Specifications Chipset
- Radeon HD 7970 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Process


...

GIGABYTE HD Experience Series GIGABYTE HD Experience Series Powered by AMD Radeon HD 6670 GPU Integrated with the first 1GB DDR3 memory & 128-bit memory interface Features Dual-link DVI-D / D-sub / HDMI Support Cross Fire X™ & Avivo™HD System power supply requirement: 400W

Specification
- Chipset
- Radeon HD 6670 Core Clock
- 800 MHz Shader Clock
- N/A Memory Clock
- 1600 MHz Process Technology
- 40 nm Memory Size
- 1 GB Memory Bus
- 128 bit Card Bus
- PCI-E 2.1 Memory Type
- DDR3 Direct X
- 11 Open GL
- 4.1 PCB Form
- ATX I/O
- HDMIx 1, DVI-Dx 1, D-subx 1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Card size
- H=37.7 mm, L=211.8 mm, W=136.8 mm Power requirement
- 400 W




















...
