Compatible with: Vigor 2760 Vigor 2832 Vigor 2860 Vigor 2862 Vigor 2925 Vigor 2926 Vigor AP 810 Vigor AP 900 Vigor AP 902 Vigor BX 2000 Vigor 2952 Vigor 2960 Vigor 3220 Vigor 3900 Web Interface: 24-hour graph Current temperature Min/ Max 24 Hours Alarm Max/ Min Thresholds Continuous Reporting to syslog Syslog Reporting Email & SMS Reporting on threshold breach USB (Universal Serial Bus) Extension cable included (1M) Mounting hole (for fixing or hanging) With the installation of this USB (Universal Serial Bus) thermometer, compatible Vigor routers can take continuous temperature readings from the vicinity of the router. This USB (Universal Serial Bus) thermometer connects to the router's USB (Universal Serial Bus) port either directly or placed nearby using the supplied 1 Metre USB (Universal Serial Bus) extension cable. You can log into the router at any time & see the current temperature & the previous 24-hour's high/low as well as graphs. You can set thresholds so that if it gets too hot or too cold at the sensor, you'll receive an email or SMS (text message). Typical applications will be to report the temperature in your comms/IT cabinet or room, but also the general office temperature, depending on the placement of the temperature 'dongle'. USB (Universal Serial Bus) typically allows a maximum cable length of up to 3M. Note: Exact facilities vary by router model. ...

The Dray Tek Vigor 2620 Ln is a unique product with VDSL & LTE modems in one box, with 2 embedded SIM card slots for 4G/LTE failover & versatile Multi-WAN Failover for guaranteed ultra-resilient service. Key Features Multi-WAN Router with Failover 4G/LTE with dual-SIMs for second backup telco VDSL/ADSL Port for wired broadband Ethernet (RJ45) IPv 4/IPv 6 Dual-Stack 2 Gigabit LAN Ports Removable LTE/4G Antenna Built-in Wireless LAN (802.11n) Quality of Service Assurance Dial-out LAN-to-LAN VPN Incoming SSL VPN VLANs (Port, 802.1q & Wireless) Optional Vigor Care Available Can be centrally Managed by Vigor ACS LTE 4G/3G Modem
- Up to 150 Mbps Integrated LTE 4G/3G (Category 4) modem, with speeds up to 150 Mbps Downstream & 50 Mbps Upstream. Compatible with EE, Vodafone, O2 & Three mobile networks & any MVNOs on those networks. High speed Mobile Broadb&. Versatile Connectivity. VDSL2 & ADSL2+ Modem Connect the Vigor 2620 Ln to Fiber to the Cabinet (FTTC) VDSL2 or ADSL, with support for VDSL2 Vectoring. Openreach MCT approved & SIN498 compliant. Compatible with all ISPs in the UK & Ireland Constant Connectivity
- Dual-SIM LTE For primary & backup mobile broadband connections. Automatically switches to the backup SIM if the main SIM’s connection drops, or experiences significant delays. Safeguard against mobile network outages. Ensures high availability Virtual Private Networking Create a secure LAN-to-LAN VPN tunnel your remote office to the main office. Supports Ipsec IKEv 1, IKEv 2, Dray Tek SSL Tunnel & L2TP with Ipsec. Dial-In to the Vigor 2620 Ln’s network with Dray Tek SSL VPN. Securely encrypted network access. Versatile Multi-WAN Failover Connect the Vigor 2620 to 4G mobile broadb&, ADSL2+, VDSL2 or Ethernet. If the primary connection fails, the Vigor 2620 Ln automatically resumes connectivity with its Failover connections. Highly adaptable. Ensures high availability. SMS Monitoring & Control SMS text messages through the web interface that will help you check the connection status, its current Internet IP, uptime & data usage. Easily manage the Vigor 2620 Ln & its SIMs remotely. Gigabit LAN Ports & VLANs Attach Computers, Servers & Network Attached Storage to the Vigor 2620 Ln, with 2 Gigabit (10/100/1000 Mbps) LAN ports. Use VLANs to supply broadband & VPN connectivity to 2 networks. Separate private & guest networks. Make full use of LTE 4G bandwidth Designed for Centralised Management Configure & manage the Vigor 2620 Ln remotely through the Vigor ACS central management platform. saves your valuable time & money Specifications LAN Ports (Switch) 2 x Gigabit Ethernet (1000 Mb/s) Ports (P2 switchable to WAN2 port) WAN Ports (one as primary, others as failover) WAN1: ADSL/VDSL
- RJ-11 WAN2: Gigabit Ethernet
- RJ-45 LTE: 3G/4G/LTE modem
- Dual-SIM Slot 2 x Removable LTE Wireless antennas Wireless On / Off / WPS button Recessed Factory Reset button Performance Firewall: Up to 300 Mb/s NAT Sessions: 30, 000 Wireless LAN: Up to 300 Mb/s (2 Spatial Streams @ 40 M Hz) Wireless LAN: Up to 300 Mb/s (2 Spatial Streams @ 40 M Hz) SSL VPN: Up to 25 Mb/s 4G LTE Modem Features Dual SIM LTE Category 4 Unlocked to any network (BT, EE, 3, O2, Vodafone, Eircom) LTE FDD Supported Frequency Bands: 1, 3, 7, 8, 20 Max Data Rates: 150 Mbps Downlink 50 Mbps Uplink 2 Standard-Size SIM Slots (primary & backup) Removable SIM slot cover 2 Removable LTE Wireless Antennas (SMA connector fitting) SMS Inbox
- Send & Receive SMS text messages SMS Router Commands
- Status Report, Reboot via text message Wireless LAN Features 2.4 G Hz
- 802.11b/g/n Wireless Wireless LAN On/ Off button 2 Internal Wireless Antennas Up to 4 SSIDs Whitelist / Blacklist individual wireless clients per SSID (by MAC address) Time Scheduling for Wireless radio and/or individual SSIDs Active Client list in Web Interface Station Control, limit wireless client access time per day Wireless Rate-Control Wireless Client Isolation per SSID WPA/WPA2 Encryption Access Point Discovery WDS (Wireless Distribution system) for WLAN Bridging & Repeating WMM (Wi-Fi Multimedia) support Firewall & NAT Features 40 Port Redirection rules 40 Open Port rules (10 port ranges per rule) DMZ Host Configurable SIP (Vo IP) & RTSP Application Layer Gateway (ALG) services Policy-Based Firewall MAC Address Filter SPI (Stateful Packet Inspection ) with Flow Track Mechanism Do S / DDo S Protection IP Address Anti-spoofing E-Mail Alert & Logging via Syslog Bind IP to MAC Address Object-based Firewall to apply rules to Objects / Groups as well as subnet/network addresses Content Security Management (CSM)

Features: Part of the Dray OS Object based Firewall system Apply Content Filtering to specific IP ranges & subnets Apply different Content Filter profiles to different groups Schedule restrictions to specific times of day URL Keyword Filtering: Whitelist or Blacklist specific sites or keywords in URLs Prevent accessing of web sites by using their direct IP address (thus URLs only) Web Content Filtering: Block Web sites by category e.g. Adult, Gambling etc.

Includes:: free 30-day trial App Enforcement: Block access to services & applications passing through the router Block popular P2P (Peer-to-Peer) file sharing programs Control access to Instant Messaging programs such as Skype, Whatsapp & Facebook Messenger Block VPN connections & other Tunneling services being established through the router Control access to Streaming services such as Youtube Bandwidth Management Temporary (5 minute) Quick Blocking of any LAN Client Bandwidth Limit (Shared or individual limit) Smart Bandwidth Limitation (Triggered by Traffic / Session) Session Limit Quality of Service (Qo S) Guaranteed Bandwidth for Vo IP Class-based Bandwidth guarantee by User-Defined Traffic Categories Layer 2&3 (802.1p & TOS/DCSP) Diff Serv Code Point Classifying 4-level Priority for each Direction (Inbound / Outbound) Bandwidth Borrowing Dial-in (Host) VPN Facilities SSL VPN (TLS) connections 2 Concurrent active Remote Dial-In User VPN Tunnels LAN-to-LAN Dial-Out VPN Facilities 2 Concurrent active dial out VPN Tunnels VPN Pass-Through Tunnelling Protocols: PPTP IPSec L2TP L2TP over IPSec Dray Tek SSL IPSec

Features: Internet Key Exchange: IKEv 1 (Main & Aggressive mode) & IKEv 2 Security Protocols: AH mode, ESP mode IKE Authentication: Pre-shared Key or X.509 Digital Signature DHCP over IPSec NAT-Traversal (NAT-T) Dead Peer Detection (DPD) Virtual IP Mapping, map a remote IP subnet/range to another range to resolve IP subnet/range conflicts Diffie Helman (DH) Groups IKEv 1: 1, 2, 5, 14 IKEv 2: 1, 2, 5, 14, 19, 20, 21 Encryption DES / 3DES (168bits) AES (128/192/256bits)
- Hardware-Accelerated Authentication
- Hardware-Accelerated: MD5 SHA-1 SHA-256 Network Features 2 LAN Subnets with NAT/ Routing modes (IPv 4) IPv 6 Subnet (as provided by your ISP) LAN Clients: Up to 253 per subnet Multi Subnet DHCP Servers with DHCP Relay Port-Based VLAN (Inclusive/ Exclusive Groups) 802.1q VLAN Tagging Custom DHCP Option support Port Mirroring Dynamic DNS Dray Tek Dray DDNS Support DNS Transparent Proxy DNS Caching NTP Client (Synchronise Router Time) Maximum MTU 1534 Router Management Web-Based User Interface (HTTP / HTTPS) CLI (Command Line Interface ) via Web Console, Telnet or SSH Administration Access Control SMS Alert Service Brute Force Protection Configuration Backup / Restore Built-in Diagnostic Function (ping, traceroute) Firmware Upgrade via Web Interface, TFTP, Vigor ACS Logging via Syslog SNMP v 2 & v 3 Management with MIB-II TR-069 TR-104 Access Point Management: Centrally Manage 2 Dray Tek Vigor AP wireless access points WAN Features WAN Connection Fail-over WAN1 Service & Customer (double-tag) VLAN support IGMP Proxy
- for compatibility with IPTV services Multi-PVC/VLAN virtual WAN interfaces for Management / IPTV services WAN Protocols DHCP Client Static IP PPPo E PPTP/L2TP (Ethernet WAN only ADSL & VDSL Compatibility BT Infinity Option 1 & Option 2 Compatible BT SIN 498 MCT Approved Support for G.INP & Vectoring ADSL Standards ANSI T1.413 Issue 2 ITU-T G.992.1 G.dmt (ADSL) ITU-T G.992.2 G.lite ITU-T G.992.3 ADSL2 ITU-T G.992.5 ADSL2+ Annex L (READSL) Annex A Annex M ANFP Issue 3 Compliant/ Certified (for Annex A & Annex M) DSL Forum: TR-048/67 & TR-100 VDSL Standards ITU-T VDSL2 G.993.2 ITU-T G.993.1, G.997.1 Band Plan: G.998, G.997 Annex A, Annex B, Annex C VDSL2 Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a OLR, UPBO, DPBO Supported US0 Supported Loop Diagnostic Mode DSL Forum WT-114 ATM Protocols RFC-2684/RFC-1483 Multiple Protocol over AAL5 RFC-2516 PPP over Ethernet RFC-2364 PPP over AAL5 PPPo E pass through LAN/WLAN PPPo E/PPPo A Relay Transparent bridge for MPo A Multiple PVC support for Triple Play Applications (up to 8 simultaneous) Support for RFC4638 for MTU up to 1500 Operating Requirements Wall Mountable Operating Temperature: 0 °C ~ 45 °C Storage Temperature: -25 °C ~ 70 °C Humidity 10% ~ 90% (non-condensing) Power Consumption: 12 Watt Max Dimensions: Length: 207mm,

Width: 131mm,

Height: 39mm Weight: 440g (without antenna) Operating Power: DC 12V 1A (via external PSU, supplied) Warranty: Two (2) Years RTB Power Requirements: 220-240VAC




















...

VDSL & Ethernet Load Balancer The Vigor 2865ax is a VDSL & Ethernet WAN router featuring VPN, advanced routing features, firewall, content filtering, bandwidth management & more. Connect the Vigor 2865 to Superfast Fibre with its integrated VDSL modem. Or connect to Virgin Media Cable & Ultrafast FTTP with Ethernet WAN. Featuring high throughput with Load Balancing & Failover connectivity, suitable for handling Fibre to the Premises (FTTP) & Gigabit Internet connections. Offering up to 950 Mbps per-WAN of Hardware Accelerated throughput while retaining its full feature set. With Wi-Fi 6 AX3000 wireless, it provides ultra fast & efficient wireless coverage, to your networks computers & devices. In addition, the router can connect to Wireless networks for Internet access, allowing it to make use of Mobile Hotspot wireless connections & nearby wireless networks, where for instance a neighbours wireless network could provide an emergency backup connection. For cabled wireless networks, the routers Central AP Management greatly reduces installation time & provides an easy way to manage Vigor A Ps, including auto-provisioning, so new Vigor A Ps are configured by the router when theyre plugged into the routers network. Wi-Fi 6
- AX3000 Performance The Vigor 2865ax features ultra-fast & highly efficient Wi-Fi 6, or 802.11ax. OFDMA allows the router to send to more than one device at a time, splitting up wireless frequency into blocks, assigning more to users that need more e.g. video data, less to users that need less e.g. Vo IP calls, then sending all at once. Which ensures all users have less of a wait, greatly improving efficiency. It allows the router to effectively & responsively, serve more wireless clients. Ideal VPN Router for SMB A feature central to Dray Tek routers is its VPN (Virtual Private Networking) capabilities. A VPN enables you to link remote offices & branch offices back to HQ, or home-based/mobile teleworkers back to your office. The Vigor 2865 is an ideal VPN router, with 300 Mbps standard IPsec VPN throughput & up to 50 concurrently active VPN tunnels. IPsec Hardware Acceleration boosts performance, up to 800 Mbps for 16 VPN tunnels, allowing securely encrypted tunnels between sites to make full use of high speed Internet connections. It supports all common industry standard VPN protocols, for it to connect to VPN services, link remote offices & handle connections from all types of VPN clients. Supporting IPsec IKEv 1 & IKEv 2 protocols with EAP & XAuth authentication, Dray Teks SSL VPN & L2TP for both LAN to LAN & Dial-In teleworker VPNs. In addition, teleworkers can connect to the router with Open VPN. User management for Dial-In Teleworkers is managed through the routers web interface, with m OTP 2-factor authentication available for IPsec, L2TP & SSL VPN Teleworker connections. Alternatively, authentication for Dial-In Teleworker connections can be forwarded to your Active Directory (LDAP) or RADIUS or TACACS+ server. Connect VPNs from Behind NAT with Dray Teks VPN Matcher A typical requirement for connecting a VPN tunnel between two points is that the VPN server must be directly accessible on the public Internet. Sometimes this can be achieved with NAT Port Forwarding if the router is located behind another router, but if the router is connected to 4G Mobile Broadband or is behind Carrier-Grade NAT (CG-NAT), connecting to that VPN server may be impossible. Dray Teks new VPN Matcher service helps Dray Tek routers behind NAT to allow Dial-In Teleworkers to connect, or connect two Dray Tek VPN routers that are behind NAT & could not normally establish a VPN tunnel. Connecting Remote Sites with LAN to LAN VPN Supporting up to 32 concurrently active VPN tunnels, the Vigor 2865 series is ideal for connecting multiple sites or home offices together with fast & secure IPsec VPN tunnels. Once connected, they have access to your office/remote resources through a secure encrypted tunnel allowing remote desktop, file sharing & seamless access to other resources & devices. Dray Tek SSL VPN for Dial-In Teleworkers & LAN to LAN The Vigor 2865 supports up to 16 active Dray Tek SSL VPN tunnel connections. These are encrypted tunnels linking your teleworkers or remote Dray Tek Vigor routers back to your main office using SSL/TLS technology
- the same encryption that you use for secure web sites such as your bank. Teleworkers can easily create a secure SSL VPN tunnel to the Dray Tek Vigor 2865 using the free Dray Tek Smart VPN Client app. Available for Windows, mac OS, Apple i OS (iPad, iPhone) & Android devices. 5+1 Gigabit LAN Ports with VLANs The Vigor 2865 series provides up to 6 Gigabit LAN ports for wired links to Computers, Servers & Network Attached Storage. With 5 dedicated LAN ports & one flexible LAN/WAN port, the Vigor 2865 can connect up to 6 devices directly with a single Ethernet WAN configuration, or 5 devices with a dual Ethernet WAN configuration. With Multiple LAN subnets & VLANs, the Vigor 2865 can manage up to 8 separate networks. For instance, an internal network with a separate network for Guests to use, completely separate from the private network. Each network with its own Content Filtering, Firewall, Quality of Service & Route Policy applied. The router has full support for 802.1Q VLAN tagging, so that these subnets can be passed to other devices that support VLAN tags, such as the Dray Tek Vigor Switch G1080 8-port switch, for additional network ports. The Wireless LAN also links to these VLANs, making the same Guest & Private networks possible simply using different wireless SSIDs. Or connect up a Dray Tek Vigor AP wireless access point, such as the Vigor AP 903 to do the same, spanning the routers own wireless & any connected wireless APs. Designed for Central Management The Vigor 2865 series (along with most other Dray Tek routers, Access points & switches) can be centrally managed by our Vigor ACS central management platform. This scalable solution provides visibility, control & reporting of your entire Dray Tek product estate, ideal for dealers/SIs managing customers devices or any user who wants to know whats going on with their devices. Vigor ACS also provides features like automated/bulk firmware updates, VPN management & alarms for connectivity or other issues. Robust & Comprehensive IPv 4 / IPv 6 Firewall Security is always taken seriously with Dray Tek routers. The firewall protects against attacks including Do S (Denial of Service) attacks, IP-based attacks & access by unauthorised remote systems. Wireless, Ethernet & VPN are also protected by various protection systems. The Dray Tek object-based firewall enables you to create combinations of Firewall rules & Content Filtering to suit a home or small office environment, applying Content Filtering to the whole network, only specified devices or just the network that guests can connect to. The Vigor 2865 supports both IPv 4 & IPv 6 with Dual-Stack IPv 4/IPv 6. Advanced networking features, such as the object-based Firewall, Quality of Service, Content Filtering & VLANs support both IPv 4 & IPv 6 networks. Web Content Filtering with DNS Filter The content control features of the Vigor 2865 allow you to set restrictions on web site access, blocking download of certain file or data types, blocking specific web sites with whitelists or blacklists, blocking IM/P2P applications or other potentially harmful or wasteful content. Restrictions can be per user, per PC or universal & according to time schedules. Content filtering can also block sites using HTTPS/SSL where URLs are encrypted (and normal routers cannot block). Using the Global View service, you can block whole categories of web sites (e.g. gambling, adult sites etc.), subject to an annual subscription, which is continuously updated with new or changed site categorisations or sites which have become compromised (such as infected with Malware). A free 30-day trial is included with your new router. High Availability
- Hardware Failover For even greater resilience, the Vigor 2865 series provides High Availability (HA), with both a primary & secondary router able to provide connectivity to your network & subnets. In the event of the primary unit failing, the secondary unit will take its place on the network, automatically switching over to resume Internet, routing & VPN connectivity with no intervention required. This can remove the possibility of a single point of failure within your routers. With Config Sync, the two routers are managed as a single unit, so that any changes made to the primary router will automatically propagate to the secondary router, ensuring it’s ready to take over at any time. Dray DDNS
- Dray Tek Dynamic DNS Address Dray Tek provides a free Dynamic DNS address to each Vigor 2865 router, allowing you to link the routers current IP address to a memorable "drayddns.com" hostname, such as "myrouter.drayddns.com". This address automatically updates whenever the Internet connections IP changes, so if one WAN’s IP address allocation is dynamic, or the IP changes when switching from the primary WAN connection to a backup, you can easily locate & access your Vigor 2865 router. Just use the hostname to access the routers VPN services, management & any other services you have made accessible through the router. The Vigor 2865 can also authenticate your Dray DDNS hostname with free SSL/TLS certificates provided by Lets Encrypt, the router manages & automates the certificate process. Keeping the certificate up to date & ready for use with SSL VPN & other services. Manage Guest Wi Fi with Hotspot Web Portal Dray Tek routers make it easy to manage Guest Wireless with Hotspot Web Portal. The fully customisable captive portal can apply to both the routers wireless networks & LAN interfaces, for use with wireless access points. Authentication can be handled by Google/ Facebook or an external web Portal service such as violet Wi Fi with RADIUS. Upon connecting to the wireless network, users are presented with your companys branding & information. From there, depending on what youve set, they can simply click-through, provide their details or enter a PIN with Voucher generated by the router. Once connected, the router can allow access until a user reaches their"a limit of time connected or bandwidth used. Quality of Service & Bandwidth Control Prioritise latency-sensitive applications on your network with Quality of Service. App Qo S simplifies setting up Quality of Service significantly, simply select which applications or services to prioritise, such as Zoom & Skype. Use 4 separate queues to give priority to servers & PCs (IP address), services such as Vo IP or DNS, or packet tagging used by IP phones with 802.1p & DSCP support Auto Voice VLAN allows the router to automatically prioritise Vo IP calls as they pass through the router without additional configuration. Control throughput with Bandwidth Limit, by setting speed limits for all clients individually, groups of IPs, or a shared bandwidth limit for a whole subnet, such as a Guest network. Central AP & Switch Management The Vigor 2865 manages Dray Tek Vigor AP access points & Vigor Switch switches connected locally to the router. This enables you to centrally control, manage & administer multiple AP & Switch devices installed around your building/campus from just the one router.



...

Draytek
- As Vigor 2865 with built in 3G/4G (LTE) SIM slot
- Plus 802.11ac Wi Fi ...

The Dray Tek Vigor 130 is an ADSL & VDSL modem with an Ethernet connection; it is not a router but a true ADSL/VDSL Ethernet Modem (bridge). The Vigor 130 provides compatibility with all current UK VDSL/ADSL technologies; it has been extensively tested & tuned to provide a robust & reliable DSL connection. By providing a PPPo E bridge, the connected device (firewall, router or PC) can log into the Internet (your ISP) directly & have full control over the Internet connection
- that makes the Vigor 130 a unique product. You can connect any device to the Vigor 130 which has a PPPo E client facility, which

Includes:: PCs, most Ethernet-WAN routers & the Apple Airport/ Time Capsule products. Other Ethernet modems may use workarounds to get a public IP address through to your secondary device/client, requiring non-standard operation & complicated dual-stage setup (modem logs in, router routes) but the Vigor 130 provides the secondary device with a real routed IP connection & the ability to fully manage the connection, making setup easy. In most cases, the Vigor 130 needs no setup or configuration
- just plug it in & set up your PC or router. All login/ISP details are entered on the connected client device, not the Vigor 130. The actual connection to your ISP is still PPPo A or PPPo E (depending on your ISP & line type). This transparent bridging method also differs from using a normal ADSL/VDSL router which logs in itself & then uses NAT or multiple public IP addresses to create an onward client connection for your secondary device; that is not IP Address thrifty & can introduce secondary NAT compromises or interference with various protocols/traffic. With the Vigor 130 bridge/modem, you get a true single public IP address (or multiple, if you have them) straight through to your firewall/router. Key Features ADSL & VDSL2 (FTTC/BT Infinity) Ethernet Modem Bridge (pass) a single IP address or a whole public subnet IPv 6 & IPv 4 Compatible Ethernet Connection for client device (router, PC etc.) Ideal for Apple Airport devices



...

Vigor 2130 Series Router/ Firewall The Dray Tek Vigor 2130 Series routers are intended for the new generation of very-high speed, Ethernet-connected broadband services, such as connection to broadband modems from Virginmedia or BTs Infinity modem* (VDSL/FTTC). It is an ideal router firewall for So Ho users wanting very high speed access with control & a wealth of other usability features. Your PCs, consoles or other devices can plug into the 4-Port gigabit switch & the Wireless versions can provide Wi Fi access to your laptops, tablet computers, mobile phones or any other device which can access the internet over Wi Fi Up to 500 Mb/s WAN Throughput
- ideal for ultra high-speed Internet services Gigabit Ethernet WAN Port 4-Port Gigabit Ethernet Switch Bandwidth/session control (prevent specific PCs from using too much) Web URL Blocking (block access to specific sites) Optional web content filtering by category (Globalview) Username/ Password controlled access Support for IPv 6 Networks Support for 15, 000 simultaneous NAT sessions 802.11n Wi Fi (V2130n/ Vn only) Twin Vo IP Phone ports (V2130 Vn only)
...

The Vigor 2762 is an ADSL/VDSL2, Ethernet or 3G/4G router, thats ideal for your small office or home business/office. It provides connectivity to your PCs or other Internet-connected devices (laptops, tablets, games consoles, smartphones) via its 4 built-in Gigabit Ethernet ports, or using Wireless LAN (on n & ac models). The firewall helps protect your network from external threats, as well as the Vigor 2762s built-in Content Filtering which gives you control over what & when your local users can access or download. The Vigor 2762 series can alternatively connect to an Ethernet Internet connection, such as a cable/fiber modem (e.g. Virgin Media) instead of connecting to a ADSL/VDSL line. Compatible 3G & 4G (LTE) modems can also optionally be added to the USB (Universal Serial Bus) port to provide backup or main Internet connectivity without any fixed line. The Dray Tek Vigor 2762ac adds 802.11ac Dual-Band Wireless to your network, with up to 866 Mbps on the 5 G Hz 11ac b&, & up to 300 Mbps on the 2.4 G Hz b&, allowing devices access to the Internet from around the property. The Vigor 2762ac operates simultaneiously in both the 2.4 Ghz & less congested 5 Ghz band so your devices can connect to either, with Band Steering to ensure that each wireless device connecting is guided to its most suitable wireless b&. The Vigor 2762 Vac variant integrates a Vo IP ATA (Analogue Telephone Adapter), which provides two analogue phone ports to provide Vo IP integration via the Internet (Vo IP). You can connect 1 or 2 regular telephones, which can be used independently & simultaneously for both incoming & outgoing calls. An Ideal firewall router for Fibre Broadband Many broadband connections offered by ISPs are referred to as Fibre Broadb&, although technically in many cases theyre actually VDSL based connections which run over your phone line. The phone lines twisted pair telephone cable runs from the premise to a street cabinet (these are typically 4ft green boxes with a Openreach logo on) which contain a VDSL MSAN (multi-service access node) that connects to fibre infrastructure which runs to the local exchange & then on to the ISPs core network. The Vigor 2762s built-in DSL interface (WAN1) is ideal for connecting this type of VDSL based connection. Cable Modem & Ethernet WAN Compatible As well as being able to connect to ADSL/VDSL lines directly through the Vigor 2762s RJ11 DSL socket, the Vigor 2762 series can instead connect to Ethernet-fed Internet connections, such as that provided by cable modems (e.g. Virgin Media). When Ethernet WAN is enabled, LAN Port 4 switches to become your WAN port into which you can connect to your cable modem or other Ethernet feed. The other 3 Gigabit LAN ports (1-3) remain available for normal LAN connectivity. Note, you cannot have Ethernet WAN & ADSL/VDSL enabled at the same time; if Ethernet WAN is enabled, the ADSL/VDSL port is disabled (and vice versa). The photo on the right shows the Vigor 2762 connected to a fiber modem using the Ethernet WAN Port. IPv 6
- Next Generation Internet Routing The Vigor 2762 supports IPv 6
- the successor to the current IPv 4 addressing system that has been used since the Internet was first created. IPv 4 address space is full up & IPv 6 allows for much more efficient routing & a larger address space. IPv 6 is supported directly from your own ISP, but if your ISP does not (yet) support IPv 6, the Vigor 2762 also supports IPv 6 broker/tunnel services to provide IPv 6 access using either TSPC or AICCU via 3rd party IPv 6 providers. The advanced networking features of the Vigor 2762, such as the object-based Firewall, Quality of Service, Content Filtering & VLANs support both IPv 4 & IPv 6 networks.

...

The Vigor 2762 is an ADSL/VDSL2, Ethernet or 3G/4G router, thats ideal for your small office or home business/office. It provides connectivity to your PCs or other Internet-connected devices (laptops, tablets, games consoles, smartphones) via its 4 built-in Gigabit Ethernet ports, or using Wireless LAN (on n & ac models). The firewall helps protect your network from external threats, as well as the Vigor 2762s built-in Content Filtering which gives you control over what & when your local users can access or download. The Vigor 2762 series can alternatively connect to an Ethernet Internet connection, such as a cable/fiber modem (e.g. Virgin Media) instead of connecting to a ADSL/VDSL line. Compatible 3G & 4G (LTE) modems can also optionally be added to the USB (Universal Serial Bus) port to provide backup or main Internet connectivity without any fixed line. The Dray Tek Vigor 2762ac adds 802.11ac Dual-Band Wireless to your network, with up to 866 Mbps on the 5 G Hz 11ac b&, & up to 300 Mbps on the 2.4 G Hz b&, allowing devices access to the Internet from around the property. The Vigor 2762ac operates simultaneiously in both the 2.4 Ghz & less congested 5 Ghz band so your devices can connect to either, with Band Steering to ensure that each wireless device connecting is guided to its most suitable wireless b&. The Vigor 2762 Vac variant integrates a Vo IP ATA (Analogue Telephone Adapter), which provides two analogue phone ports to provide Vo IP integration via the Internet (Vo IP). You can connect 1 or 2 regular telephones, which can be used independently & simultaneously for both incoming & outgoing calls. An Ideal firewall router for Fibre Broadband Many broadband connections offered by ISPs are referred to as Fibre Broadb&, although technically in many cases theyre actually VDSL based connections which run over your phone line. The phone lines twisted pair telephone cable runs from the premise to a street cabinet (these are typically 4ft green boxes with a Openreach logo on) which contain a VDSL MSAN (multi-service access node) that connects to fibre infrastructure which runs to the local exchange & then on to the ISPs core network. The Vigor 2762s built-in DSL interface (WAN1) is ideal for connecting this type of VDSL based connection. Cable Modem & Ethernet WAN Compatible As well as being able to connect to ADSL/VDSL lines directly through the Vigor 2762s RJ11 DSL socket, the Vigor 2762 series can instead connect to Ethernet-fed Internet connections, such as that provided by cable modems (e.g. Virgin Media). When Ethernet WAN is enabled, LAN Port 4 switches to become your WAN port into which you can connect to your cable modem or other Ethernet feed. The other 3 Gigabit LAN ports (1-3) remain available for normal LAN connectivity. Note, you cannot have Ethernet WAN & ADSL/VDSL enabled at the same time; if Ethernet WAN is enabled, the ADSL/VDSL port is disabled (and vice versa). The photo on the right shows the Vigor 2762 connected to a fiber modem using the Ethernet WAN Port. IPv 6
- Next Generation Internet Routing The Vigor 2762 supports IPv 6
- the successor to the current IPv 4 addressing system that has been used since the Internet was first created. IPv 4 address space is full up & IPv 6 allows for much more efficient routing & a larger address space. IPv 6 is supported directly from your own ISP, but if your ISP does not (yet) support IPv 6, the Vigor 2762 also supports IPv 6 broker/tunnel services to provide IPv 6 access using either TSPC or AICCU via 3rd party IPv 6 providers. The advanced networking features of the Vigor 2762, such as the object-based Firewall, Quality of Service, Content Filtering & VLANs support both IPv 4 & IPv 6 networks.

...

The Vigor 2762 is an ADSL/VDSL2, Ethernet or 3G/4G router, thats ideal for your small office or home business/office. It provides connectivity to your PCs or other Internet-connected devices (laptops, tablets, games consoles, smartphones) via its 4 built-in Gigabit Ethernet ports, or using Wireless LAN (on n & ac models). The firewall helps protect your network from external threats, as well as the Vigor 2762s built-in Content Filtering which gives you control over what & when your local users can access or download. The Vigor 2762 series can alternatively connect to an Ethernet Internet connection, such as a cable/fiber modem (e.g. Virgin Media) instead of connecting to a ADSL/VDSL line. Compatible 3G & 4G (LTE) modems can also optionally be added to the USB (Universal Serial Bus) port to provide backup or main Internet connectivity without any fixed line. The Dray Tek Vigor 2762ac adds 802.11ac Dual-Band Wireless to your network, with up to 866 Mbps on the 5 G Hz 11ac b&, & up to 300 Mbps on the 2.4 G Hz b&, allowing devices access to the Internet from around the property. The Vigor 2762ac operates simultaneiously in both the 2.4 Ghz & less congested 5 Ghz band so your devices can connect to either, with Band Steering to ensure that each wireless device connecting is guided to its most suitable wireless b&. The Vigor 2762 Vac variant integrates a Vo IP ATA (Analogue Telephone Adapter), which provides two analogue phone ports to provide Vo IP integration via the Internet (Vo IP). You can connect 1 or 2 regular telephones, which can be used independently & simultaneously for both incoming & outgoing calls. An Ideal firewall router for Fibre Broadband Many broadband connections offered by ISPs are referred to as Fibre Broadb&, although technically in many cases theyre actually VDSL based connections which run over your phone line. The phone lines twisted pair telephone cable runs from the premise to a street cabinet (these are typically 4ft green boxes with a Openreach logo on) which contain a VDSL MSAN (multi-service access node) that connects to fibre infrastructure which runs to the local exchange & then on to the ISPs core network. The Vigor 2762s built-in DSL interface (WAN1) is ideal for connecting this type of VDSL based connection. Cable Modem & Ethernet WAN Compatible As well as being able to connect to ADSL/VDSL lines directly through the Vigor 2762s RJ11 DSL socket, the Vigor 2762 series can instead connect to Ethernet-fed Internet connections, such as that provided by cable modems (e.g. Virgin Media). When Ethernet WAN is enabled, LAN Port 4 switches to become your WAN port into which you can connect to your cable modem or other Ethernet feed. The other 3 Gigabit LAN ports (1-3) remain available for normal LAN connectivity. Note, you cannot have Ethernet WAN & ADSL/VDSL enabled at the same time; if Ethernet WAN is enabled, the ADSL/VDSL port is disabled (and vice versa). The photo on the right shows the Vigor 2762 connected to a fiber modem using the Ethernet WAN Port. IPv 6
- Next Generation Internet Routing The Vigor 2762 supports IPv 6
- the successor to the current IPv 4 addressing system that has been used since the Internet was first created. IPv 4 address space is full up & IPv 6 allows for much more efficient routing & a larger address space. IPv 6 is supported directly from your own ISP, but if your ISP does not (yet) support IPv 6, the Vigor 2762 also supports IPv 6 broker/tunnel services to provide IPv 6 access using either TSPC or AICCU via 3rd party IPv 6 providers. The advanced networking features of the Vigor 2762, such as the object-based Firewall, Quality of Service, Content Filtering & VLANs support both IPv 4 & IPv 6 networks.

...

Key Features Integrated Vo IP Telephone Adapter (SIP ATA) 2 PSTN Telephone (FXS) ports Phone Book & Digit Map Call Barring (with schedule) Support for SRTP & ZRTP encryption The Vigor 2762 Vac features the same

Specification as the standard Vigor 2762 series router models, with the addition of two phone ports for Vo IP services Standard Analogue telephone handsets or DECT phone bases can be connected to the Phone 1/2 ports & each of the phones can then be used to make & receive calls using Vo IP services (over the Internet) as opposed to using your traditional landline. The two phone ports are independent so you can make two calls at once. Its like having two extra phone lines, but without the monthly rental of additional l&-lines. Vo IP calls are typically much lower cost that fixed-line calls, or if youre calling another Vo IP user (who is also using the same Vo IP provider, or SIP compatible) the calls are free. There are many SIP Vo IP providers who can provide pay-as-you-go or monthly calling plans, such as Dray TEL. You can also have your Vo IP accounts registered in more than one location so that the phone rings at home or work, & providers can also provide geographic (or non-geographic) phone numbers for incoming calls. Click on the Vo IP Features tab for more detail. A 4-port Gigabit Ethernet switch on the LAN side provides high speed connectivity for your computers, Network Attached Storage (NAS), Wireless Access Points, or for uplink to a larger Ethernet switch. The Vigor 2762 Vac has ADSL/VDSL support through the DSL (WAN1) port; alternative WAN ports can instead provide connectivity to Ethernet feeds 1, or a 3G/4G modem using a supported USB (Universal Serial Bus) 3G/4G Modem.

...
