This product is a magnetic base and extension cable compatible with the ANT-2520, ANT-1207 & ANT-1005 aerials used with any Dray Tek router or wireless access point. This allows your aerials to be positioned to avoid any obstructions or enclosures which are obscuring the router or wireless access point & find the optimum location. This is especially useful if the router is installed in a rack inside a comms cabinet because if the aerials are inside the cabinet their signal will be severely impeded. The 1M extension cable allows the aerials to be positioned outside of the cabinet & the magnetic base means that it can be attached to the side of a cabinet if the metal is magnetic. The magnetic antenna base is supplied singly; you can purchase 1, 2 or 3 to suit the number of aerials on your router or access point. The antenna base is compatible with dual-band aerials so can be used for both 2.4 Ghz & 5 Ghz operation. It is also suitable for use with 802.11ac operation (5 Ghz). The Dray Tek ANT-1250, ANT-1207 & ANT-1005 aerials twist & can tilt at their base, which allows for optimum positioning once connected to the ANT-BAS1 base. Features Magnetic Base 1M Extension Cable Allows aerial to be located in best position Compatible with ANT-2520, 1207 & 1005 Suitable for all Dray Tek routers & access Points Compatible with 802.11a, b, g, n & 802.11ac Dual-Band: 2.4 Ghz & 5 Ghz Available in black only Suitable for indoor use only ...

Dray Tek P1282 Vigor Switch 24-Port Smart Managed Gigabit Po E+ Switch The Dray Tek P1282 Vigor Switch 24-Port Smart Managed Rackmount Gigabit Po E+ Switch is a high-performance, Smart Managed Gigabit Ethernet switch with four (4) uplink ports. With twenty-four (24) Po E+ (Power over Ethernet) RJ45 LAN ports, it's ideal for powering connected IP phones, IP cameras & wireless access points. The 400 watt Po E power budget provides ample power through Ethernet, to each of its Po E / Po E+ enabled Gigabit LAN ports. Designed for centralised management, the Vigor Switch P1282 can be provisioned & monitored with the Vigor ACS management platform (licence required, sold separately), the free Vigor Connect single site management system, and/or with an existing Dray Tek Vigor router’s Central Switch Management. Easily provision VLAN configuration through a router (sold separately) & clone switch configurations. Drastically reduce the setup time required for a complex network & configure an entire Dray Tek network remotely. Key Features Po E (Power over Ethernet) Deliver power & data over one Ethernet cable, with up to 30 watts per port. Power up to twenty-four (24) devices. Cloud Management Manage the Vigor Switch P1282 from anywhere with Vigor ACS Cloud Management (licence required, sold separately). Dynamic MAC-based VLAN Network port changes are easier to manage with MAC-based VLANs automating port re-configuration. ONVIF IP Camera Management Manage & view ONVIF capable cameras, automatically detecting their topology on the network. IP Conflict Prevention Improve network stability by avoiding IP conflicts caused by a misconfigured or malicious host. Useful Security Features Protect your network against unauthorised access with Do S Defence, ACL port level Firewall & IP Source Guard. Po E Management Schedule Po E device power. Monitor Po E device status, automatically restarting devices if they stop responding. Central Site Management Easily configure switches remotely with a Dray Tek Vigor router or Vigor Connect. Surveillance & Voice Auto VLAN Auto configures VLANs for IP cameras & IP phones, recognises traffic & manages Qo S prioritisation. IP Camera Snapshot Alert Locate IP Camera problems quickly with Mail Alerts from the switch showing the IP Camera's last snapshot. Qo S (Quality of Service) Improve the performance of critical traffic by prioritising the traffic with Co S, DSCP, & IP Precedence tag. RJ45/SFP Uplink Ports Uplink to Fibre or direct-attach to additional switches with four (4) Gigabit RJ45/SFP Combo Ports. Power over Ethernet (Po E) The Vigor Switch P1282 is a 24-port Po E (Power over Ethernet) switch, providing power on all ports over the Ethernet cable to any Po E-enabled device, such as IP phones, wireless access points or IP cameras. As well as removing the need for local (at the desk) power supplies, making for tidier installations, Po E ensures power efficiency, providing only the power needed, as well as allowing for time schedules for powering up/down & remote rebooting. Power is provided only when required & allows for installation of devices where there is no mains power, which is particularly useful for wireless access points that can be ceiling mounted. The Vigor Switch P1282 has twenty-four (24) Po E ports with a power budget of up to 400 watts for all connected Po E devices, allowing for connection of both standard Po E (802.3af) & High-Power Po E (802.3at) devices at up to 30 watts per port. Power over Ethernet Management Device Check The Device Check feature can monitor connectivity to a device / remote IP. If it stops responding, for instance if an IP camera stops transmitting, the Vigor Switch will automatically power cycle the port it's connected to, allowing it to restart & work normally again. Scheduling Set time schedules to turn connected Po E devices on/off at certain times of the day, for instance turning off wireless access points overnight. Save power & prevent network access outside of the set operation times. Po E Priority In the event that the Po E power usage exceeds the power budget of the switch, important devices can be given priority so that they remain on. Less important devices can be turned off by the switch, to ensure constant operation of essential systems. Central Management The Dray Tek Vigor Switch P1282 can operate in standalone mode & be managed through its web interface or, if you need to manage & monitor the switch remotely, or have several Dray Tek Vigor Switches to administer, you can centrally manage & monitor them either with: Router
- Switch Management Manage Vigor Switches connected to a router & determine network topology at a glance. Dray Tek Vigor ACS Manage & Provision Dray Tek Vigor Switches on any network, from anywhere (licence required, sold separately). Dray Tek Vigor Connect Manage & Provision Vigor Switches & Vigor A Ps on a single site. Managing a Vigor Switch through Vigor ACS Dray Tek's Vigor ACS central management system (licence required, sold separately) provides a centralised way to manage & view the status of any Dray Tek Vigor router, Vigor AP access point & Vigor Switch connected to the Vigor ACS server. Dray Tek Vigor Switches that support TR-069 management can be managed through Dray Tek Vigor ACS 2 in the same way that a Dray Tek Vigor router or Vigor AP access point would be managed. Through Vigor ACS, you can view & manage a single Vigor Switch, all switches on a site, or all switches across an entire network spanning multiple sites in one place. Dray Tek Vigor Switches connected to Vigor ACS connect directly to the Vigor ACS server to be managed, so the router or network that they are connected to needs no additional configuration beyond the Vigor Switch having access to the internet (or if your Vigor ACS server is located across a private WAN / VPN connection, access to that network). Dashboard view View the state of a Vigor Switch through the Dashboard, with Po E usage, uptime & connected ports all visible in one place Switch Configuration View the configuration of a Vigor Switch & make changes to the configuration through Vigor ACS, then copy the settings from that switch to apply them to multiple Vigor Switches Central Switch Management with a Dray Tek Vigor Router Dray Tek Vigor router Central Switch Management provisions & monitors Vigor Switches through a Dray Tek Vigor router (sold separately), with profiles that can be applied to multiple switches & VLAN configuration all handled within the router. Central Switch Management requires firmware support on both the Vigor Switch & the Dray Tek Vigor router (requires 3.9.1 firmware update). This simplifies the setup of multiple subnets & VLANs without needing in-depth knowledge of VLAN tagging, & reduces setup time with the time-consuming step of configuring VLANs for each port handled by the router instead. Switch Hierarchy The Switch Hierarchy view provides a visual overview of interconnections between Dray Tek Vigor Switches with the devices connected to each LAN port Switch Management Profiles Switch Management profiles can be used configure schedules to enable or disable ports (including Po E) & set bandwidth limits for the ports. Descriptive names can be configured on the router which can be seen from the Switch Hierarchy view VLAN configuration of a Vigor Switch can be provisioned from the Dray Tek Vigor router, with the router automatically configuring the Uplink port & being aware of the VLAN tags that the Vigor router & the connected LAN port have available Dynamic MAC-based VLAN Assign VLAN access to individual devices instead of ports with MAC-based VLAN, to ensure that devices are assigned to the correct network regardless of which switch port they're plugged into. With MAC-based VLAN, users can move around the office & make use of the same network resources & access through any port on the switch, without requiring manual re-configuration of VLAN settings on individual ports. Surveillance & Voice Auto VLAN With Voice VLAN & Surveillance VLAN, the Vigor Swith P1282 simplifies the setup of connected IP Phones & IP Cameras. Move around ports on the switch without having to manually re-configure VLAN & Qo S settings each time. Instead, the switch will auto-assign VLAN tags & Quality of Service to IP Phones & IP Cameras, ensuring that each device remains on the correct network & that essential Voice & Video data is prioritised on the network. The switch identifies cameras & phones from their MAC address (Vendor OUI), so that when connecting up an IP Phone from Yealink for instance, the switch would configure the VLAN ID & set the Qo S tag for that port. Upon moving the phone to a different port, the switch will ensure that the VLAN settings follow the device rather than requiring a fixed VLAN & Qo S configuration per-port. ONVIF IP Camera Management The Vigor Switch P1282 can discover, manage & configure ONVIF (Open Network Video Interface Forum) compatible IP cameras & NVR systems, allowing for easy discovery, management & troubleshooting of your connected IP cameras. Device Management Use the Vigor Switch to configure & manage your IP camera network; configure network & security settings, restart cameras & have the switch monitor whether cameras are responding, alerting of any issues. Network Surveillance Topology Simply connect ONVIF capable devices to the Vigor Switch P1282, discover devices, & the Vigor Switch determines the network topology of connected cameras & NVR systems. View IP Camera Output Through the Vigor Switch web interface, you can view the video feed of connected IP cameras. Camera Offline Alerts with Snapshot The Vigor Switch P1282 can store a recent snapshot of each connected IP Camera that's ONVIF compliant. If a camera goes offline, the Vigor Switch sends out an email alert with the last-seen snapshot from the camera that's stopped responding. This means that you can locate the affected camera easily & troubleshoot any problems it may have, such as a disconnected cable or hardware fault. In addition, with Device Check on this Po E Vigor Switch, the switch can automatically power cycle the affected camera when problems occur, resolving issues with a freezing camera without requiring manual intervention. IP Conflict Detection & Prevention Conflict Detection The Vigor Switch can detect & notify an administrator when an IP conflict is detected on the network. Easily track down conflicts & take action to resolve them. Conflict Prevention Use Dray Tek's IP Conflict Prevention to allow the switch to automatically protect against IP conflicts & ARP spoofing. IP Conflict Prevention catalogues the current network layout, giving you the option to fix the IP address & MAC information for important network devices, such as Servers & Routers. If another device attempts to use an IP address that's in use, the Vigor Switch blocks the misconfigured or malicious device, communicating only with the known & correct device. Quality of Service & Bandwidth Control Prioritise mission-critical services such as Voice over IP & optimise traffic on your network with Quality of Service. 802.1p Class of Service allows the switch to identify essential traffic, moving it ahead in the queue at busy uplinks, ensuring that important data arrives on time when passing through the switch. Auto Voice & Surveillance VLAN allow the switch to automatically assign Vo IP Phones & IP Cameras to their specified VLAN & prioritise their traffic without manual port configuration. Control & manage throughput per-port with Rate Limiting & application specific Traffic Shaping. Network Security & Management Features Control port access for every port on your network with the Vigor Switch Access Control List, to specifically allow or deny specified traffic types moving between ports just like a Firewall. Protect against network issues arising from connection of unwanted devices with IP Source Guard. Access Control List Similar to a firewall, the ACL can control which packet types (IPv 4, IPv 6 & MAC) are allowed to pass between ports on the switch. IPv 6 Ready The Vigor Switch P1282 supports IPv 6, with IPv 6 DNS Resolution & IPv 6 Access Control List (ACL) for port & traffic level firewalling of IPv 6 data alongside IPv 4 traffic. IGMP Snooping & Querying Manage & control multicast IGMP traffic passing through the switch, with IGMP Snooping & Querying. With IGMP Snooping, the switch tracks IGMP traffic passing through its ports. This allows it to limit the broadcast of multicast/IGMP packets to only the ports that have subscribed, improving overall network performance & avoiding excess network traffic. The Vigor Switch's IGMP Querier allows it to manage IGMP subscriptions on its network ports, checking which ports are members of which multicast group, if the network's router does not support multicast. Management Account Control Control logins to the switch management with the switch's internal user accounts. Create multiple admin accounts & specify who can access what with 2-level admin privileges. IP Source Guard Protects against address spoofing by comparing packets received with either statically configured source IP addresses or addresses learned from DHCP snooping. Link Aggregation
- Port Trunking Use two or more network links to connect the Vigor Switch P1282 to another switch or server. Traffic can be shared between the two ports, effectively doubling the bandwidth of the uplink & providing resilience should one of the links fail. Jumbo Frame The Vigor Switch P1282 supports Ethernet packets up to 9 Kilobytes in size, to further improve throughput & increase the efficiency of packet transmission across your network. Do S (Denial of Service) Defence Protect your network against Denial of Service attacks & malformed network packets with Dray Tek's extensive switch-level Do S Defence. SFP Ports for Fibre Connectivity & Switch Uplinks The Dray Tek Vigor Switch P1282 has four (4) switchable Gigabit SFP ports for uplinks, which can be used instead of the corresponding RJ45 ports (nos. 25-28). SFP slots are typically used for fibre transceivers & interlinks between switches. In comparison to 'copper' (RJ45) cables, using fibre for connectivity provides longer range & resilience from electrical interference. The SFP ports provides compatibility with your choice of SFP modules (sold separately) & therefore the most appropriate medium for your application. Alternatively, use a passive Direct Attach SFP adapter (sold separately) to connect directly to the SFP module port of another switch, similarly to an RJ45 network connection.

...

The Vigor AP 918RPD & Vigor AP 920RPD outdoor access points have a secondary LAN port that provides Po E Output (Po E-PSE), to power an additional Po E device through a single cable run. Use the Dray Tek Vigor Po E-600 High-Power Po E Injector to power additional devices through the Vigor AP 918RPD's secondary LAN port. This powers the Vigor AP 918RPD & provides up to 16 watts power output to the device connected to the Vigor AP's Po E Out port, over a 100 meter CAT5e/CAT6 cable run. Connect a camera near to the Vigor AP, or daisy-chain an additional AP through the one cable. ...

The Dray Tek POEINj 1 is a Fast Ethernet Po E injector that is ideal if you need power for just one or two devices, you can use a single Po E injector to add Po E to one Ethernet network cable/device. Compared to a large Po E switch, a Po E injector is more economonical if you need only a small number of Po E devices in a particular location as it is mains powered & inserts Po E into the Ethernet cable. With the Dray Tek Po E Injector POEINJ1, both power & data can be transmitted up to 328 feet (100m) using standard CAT5e Ethernet cabling with virtually no reduction in data throughput. Use the Dray Tek Po E Injector with Ethernet-enabled devices where power outlets are not readily available. ...

The RM1 Rackmount Bracket enables you to fit any Vigor 2820, 2830, 2920, 3200, 2925 or 2860 series router into a standard 19" rack or cabinet. The bracket takes up one rack slot (1U). The front mounted sockets remain fully accessible. A cable retainer is fitted at the back to hold the power cord captive to avoid accidental disconnection. For wireless models, we then recommend extension aerials (or aerial extension cables
- see ANT-BAS1) as your rack will generally interfere with wireless signals if the aerials are mounted inside. The RM1 is supplied with four M5 screws (cage nuts are not supplied)
...

The Dray Tek Vigor 2620 Ln is a unique product with VDSL & LTE modems in one box, with 2 embedded SIM card slots for 4G/LTE failover & versatile Multi-WAN Failover for guaranteed ultra-resilient service. Key Features Multi-WAN Router with Failover 4G/LTE with dual-SIMs for second backup telco VDSL/ADSL Port for wired broadband Ethernet (RJ45) IPv 4/IPv 6 Dual-Stack 2 Gigabit LAN Ports Removable LTE/4G Antenna Built-in Wireless LAN (802.11n) Quality of Service Assurance Dial-out LAN-to-LAN VPN Incoming SSL VPN VLANs (Port, 802.1q & Wireless) Optional Vigor Care Available Can be centrally Managed by Vigor ACS LTE 4G/3G Modem
- Up to 150 Mbps Integrated LTE 4G/3G (Category 4) modem, with speeds up to 150 Mbps Downstream & 50 Mbps Upstream. Compatible with EE, Vodafone, O2 & Three mobile networks & any MVNOs on those networks. High speed Mobile Broadb&. Versatile Connectivity. VDSL2 & ADSL2+ Modem Connect the Vigor 2620 Ln to Fiber to the Cabinet (FTTC) VDSL2 or ADSL, with support for VDSL2 Vectoring. Openreach MCT approved & SIN498 compliant. Compatible with all ISPs in the UK & Ireland Constant Connectivity
- Dual-SIM LTE For primary & backup mobile broadband connections. Automatically switches to the backup SIM if the main SIM’s connection drops, or experiences significant delays. Safeguard against mobile network outages. Ensures high availability Virtual Private Networking Create a secure LAN-to-LAN VPN tunnel your remote office to the main office. Supports Ipsec IKEv 1, IKEv 2, Dray Tek SSL Tunnel & L2TP with Ipsec. Dial-In to the Vigor 2620 Ln’s network with Dray Tek SSL VPN. Securely encrypted network access. Versatile Multi-WAN Failover Connect the Vigor 2620 to 4G mobile broadb&, ADSL2+, VDSL2 or Ethernet. If the primary connection fails, the Vigor 2620 Ln automatically resumes connectivity with its Failover connections. Highly adaptable. Ensures high availability. SMS Monitoring & Control SMS text messages through the web interface that will help you check the connection status, its current Internet IP, uptime & data usage. Easily manage the Vigor 2620 Ln & its SIMs remotely. Gigabit LAN Ports & VLANs Attach Computers, Servers & Network Attached Storage to the Vigor 2620 Ln, with 2 Gigabit (10/100/1000 Mbps) LAN ports. Use VLANs to supply broadband & VPN connectivity to 2 networks. Separate private & guest networks. Make full use of LTE 4G bandwidth Designed for Centralised Management Configure & manage the Vigor 2620 Ln remotely through the Vigor ACS central management platform. saves your valuable time & money Specifications LAN Ports (Switch) 2 x Gigabit Ethernet (1000 Mb/s) Ports (P2 switchable to WAN2 port) WAN Ports (one as primary, others as failover) WAN1: ADSL/VDSL
- RJ-11 WAN2: Gigabit Ethernet
- RJ-45 LTE: 3G/4G/LTE modem
- Dual-SIM Slot 2 x Removable LTE Wireless antennas Wireless On / Off / WPS button Recessed Factory Reset button Performance Firewall: Up to 300 Mb/s NAT Sessions: 30, 000 Wireless LAN: Up to 300 Mb/s (2 Spatial Streams @ 40 M Hz) Wireless LAN: Up to 300 Mb/s (2 Spatial Streams @ 40 M Hz) SSL VPN: Up to 25 Mb/s 4G LTE Modem Features Dual SIM LTE Category 4 Unlocked to any network (BT, EE, 3, O2, Vodafone, Eircom) LTE FDD Supported Frequency Bands: 1, 3, 7, 8, 20 Max Data Rates: 150 Mbps Downlink 50 Mbps Uplink 2 Standard-Size SIM Slots (primary & backup) Removable SIM slot cover 2 Removable LTE Wireless Antennas (SMA connector fitting) SMS Inbox
- Send & Receive SMS text messages SMS Router Commands
- Status Report, Reboot via text message Wireless LAN Features 2.4 G Hz
- 802.11b/g/n Wireless Wireless LAN On/ Off button 2 Internal Wireless Antennas Up to 4 SSIDs Whitelist / Blacklist individual wireless clients per SSID (by MAC address) Time Scheduling for Wireless radio and/or individual SSIDs Active Client list in Web Interface Station Control, limit wireless client access time per day Wireless Rate-Control Wireless Client Isolation per SSID WPA/WPA2 Encryption Access Point Discovery WDS (Wireless Distribution system) for WLAN Bridging & Repeating WMM (Wi-Fi Multimedia) support Firewall & NAT Features 40 Port Redirection rules 40 Open Port rules (10 port ranges per rule) DMZ Host Configurable SIP (Vo IP) & RTSP Application Layer Gateway (ALG) services Policy-Based Firewall MAC Address Filter SPI (Stateful Packet Inspection ) with Flow Track Mechanism Do S / DDo S Protection IP Address Anti-spoofing E-Mail Alert & Logging via Syslog Bind IP to MAC Address Object-based Firewall to apply rules to Objects / Groups as well as subnet/network addresses Content Security Management (CSM)

Features: Part of the Dray OS Object based Firewall system Apply Content Filtering to specific IP ranges & subnets Apply different Content Filter profiles to different groups Schedule restrictions to specific times of day URL Keyword Filtering: Whitelist or Blacklist specific sites or keywords in URLs Prevent accessing of web sites by using their direct IP address (thus URLs only) Web Content Filtering: Block Web sites by category e.g. Adult, Gambling etc.

Includes:: free 30-day trial App Enforcement: Block access to services & applications passing through the router Block popular P2P (Peer-to-Peer) file sharing programs Control access to Instant Messaging programs such as Skype, Whatsapp & Facebook Messenger Block VPN connections & other Tunneling services being established through the router Control access to Streaming services such as Youtube Bandwidth Management Temporary (5 minute) Quick Blocking of any LAN Client Bandwidth Limit (Shared or individual limit) Smart Bandwidth Limitation (Triggered by Traffic / Session) Session Limit Quality of Service (Qo S) Guaranteed Bandwidth for Vo IP Class-based Bandwidth guarantee by User-Defined Traffic Categories Layer 2&3 (802.1p & TOS/DCSP) Diff Serv Code Point Classifying 4-level Priority for each Direction (Inbound / Outbound) Bandwidth Borrowing Dial-in (Host) VPN Facilities SSL VPN (TLS) connections 2 Concurrent active Remote Dial-In User VPN Tunnels LAN-to-LAN Dial-Out VPN Facilities 2 Concurrent active dial out VPN Tunnels VPN Pass-Through Tunnelling Protocols: PPTP IPSec L2TP L2TP over IPSec Dray Tek SSL IPSec

Features: Internet Key Exchange: IKEv 1 (Main & Aggressive mode) & IKEv 2 Security Protocols: AH mode, ESP mode IKE Authentication: Pre-shared Key or X.509 Digital Signature DHCP over IPSec NAT-Traversal (NAT-T) Dead Peer Detection (DPD) Virtual IP Mapping, map a remote IP subnet/range to another range to resolve IP subnet/range conflicts Diffie Helman (DH) Groups IKEv 1: 1, 2, 5, 14 IKEv 2: 1, 2, 5, 14, 19, 20, 21 Encryption DES / 3DES (168bits) AES (128/192/256bits)
- Hardware-Accelerated Authentication
- Hardware-Accelerated: MD5 SHA-1 SHA-256 Network Features 2 LAN Subnets with NAT/ Routing modes (IPv 4) IPv 6 Subnet (as provided by your ISP) LAN Clients: Up to 253 per subnet Multi Subnet DHCP Servers with DHCP Relay Port-Based VLAN (Inclusive/ Exclusive Groups) 802.1q VLAN Tagging Custom DHCP Option support Port Mirroring Dynamic DNS Dray Tek Dray DDNS Support DNS Transparent Proxy DNS Caching NTP Client (Synchronise Router Time) Maximum MTU 1534 Router Management Web-Based User Interface (HTTP / HTTPS) CLI (Command Line Interface ) via Web Console, Telnet or SSH Administration Access Control SMS Alert Service Brute Force Protection Configuration Backup / Restore Built-in Diagnostic Function (ping, traceroute) Firmware Upgrade via Web Interface, TFTP, Vigor ACS Logging via Syslog SNMP v 2 & v 3 Management with MIB-II TR-069 TR-104 Access Point Management: Centrally Manage 2 Dray Tek Vigor AP wireless access points WAN Features WAN Connection Fail-over WAN1 Service & Customer (double-tag) VLAN support IGMP Proxy
- for compatibility with IPTV services Multi-PVC/VLAN virtual WAN interfaces for Management / IPTV services WAN Protocols DHCP Client Static IP PPPo E PPTP/L2TP (Ethernet WAN only ADSL & VDSL Compatibility BT Infinity Option 1 & Option 2 Compatible BT SIN 498 MCT Approved Support for G.INP & Vectoring ADSL Standards ANSI T1.413 Issue 2 ITU-T G.992.1 G.dmt (ADSL) ITU-T G.992.2 G.lite ITU-T G.992.3 ADSL2 ITU-T G.992.5 ADSL2+ Annex L (READSL) Annex A Annex M ANFP Issue 3 Compliant/ Certified (for Annex A & Annex M) DSL Forum: TR-048/67 & TR-100 VDSL Standards ITU-T VDSL2 G.993.2 ITU-T G.993.1, G.997.1 Band Plan: G.998, G.997 Annex A, Annex B, Annex C VDSL2 Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a OLR, UPBO, DPBO Supported US0 Supported Loop Diagnostic Mode DSL Forum WT-114 ATM Protocols RFC-2684/RFC-1483 Multiple Protocol over AAL5 RFC-2516 PPP over Ethernet RFC-2364 PPP over AAL5 PPPo E pass through LAN/WLAN PPPo E/PPPo A Relay Transparent bridge for MPo A Multiple PVC support for Triple Play Applications (up to 8 simultaneous) Support for RFC4638 for MTU up to 1500 Operating Requirements Wall Mountable Operating Temperature: 0 °C ~ 45 °C Storage Temperature: -25 °C ~ 70 °C Humidity 10% ~ 90% (non-condensing) Power Consumption: 12 Watt Max Dimensions: Length: 207mm,

Width: 131mm,

Height: 39mm Weight: 440g (without antenna) Operating Power: DC 12V 1A (via external PSU, supplied) Warranty: Two (2) Years RTB Power Requirements: 220-240VAC




















...

VDSL & Ethernet Load Balancer The Vigor 2865ax is a VDSL & Ethernet WAN router featuring VPN, advanced routing features, firewall, content filtering, bandwidth management & more. Connect the Vigor 2865 to Superfast Fibre with its integrated VDSL modem. Or connect to Virgin Media Cable & Ultrafast FTTP with Ethernet WAN. Featuring high throughput with Load Balancing & Failover connectivity, suitable for handling Fibre to the Premises (FTTP) & Gigabit Internet connections. Offering up to 950 Mbps per-WAN of Hardware Accelerated throughput while retaining its full feature set. With Wi-Fi 6 AX3000 wireless, it provides ultra fast & efficient wireless coverage, to your networks computers & devices. In addition, the router can connect to Wireless networks for Internet access, allowing it to make use of Mobile Hotspot wireless connections & nearby wireless networks, where for instance a neighbours wireless network could provide an emergency backup connection. For cabled wireless networks, the routers Central AP Management greatly reduces installation time & provides an easy way to manage Vigor A Ps, including auto-provisioning, so new Vigor A Ps are configured by the router when theyre plugged into the routers network. Wi-Fi 6
- AX3000 Performance The Vigor 2865ax features ultra-fast & highly efficient Wi-Fi 6, or 802.11ax. OFDMA allows the router to send to more than one device at a time, splitting up wireless frequency into blocks, assigning more to users that need more e.g. video data, less to users that need less e.g. Vo IP calls, then sending all at once. Which ensures all users have less of a wait, greatly improving efficiency. It allows the router to effectively & responsively, serve more wireless clients. Ideal VPN Router for SMB A feature central to Dray Tek routers is its VPN (Virtual Private Networking) capabilities. A VPN enables you to link remote offices & branch offices back to HQ, or home-based/mobile teleworkers back to your office. The Vigor 2865 is an ideal VPN router, with 300 Mbps standard IPsec VPN throughput & up to 50 concurrently active VPN tunnels. IPsec Hardware Acceleration boosts performance, up to 800 Mbps for 16 VPN tunnels, allowing securely encrypted tunnels between sites to make full use of high speed Internet connections. It supports all common industry standard VPN protocols, for it to connect to VPN services, link remote offices & handle connections from all types of VPN clients. Supporting IPsec IKEv 1 & IKEv 2 protocols with EAP & XAuth authentication, Dray Teks SSL VPN & L2TP for both LAN to LAN & Dial-In teleworker VPNs. In addition, teleworkers can connect to the router with Open VPN. User management for Dial-In Teleworkers is managed through the routers web interface, with m OTP 2-factor authentication available for IPsec, L2TP & SSL VPN Teleworker connections. Alternatively, authentication for Dial-In Teleworker connections can be forwarded to your Active Directory (LDAP) or RADIUS or TACACS+ server. Connect VPNs from Behind NAT with Dray Teks VPN Matcher A typical requirement for connecting a VPN tunnel between two points is that the VPN server must be directly accessible on the public Internet. Sometimes this can be achieved with NAT Port Forwarding if the router is located behind another router, but if the router is connected to 4G Mobile Broadband or is behind Carrier-Grade NAT (CG-NAT), connecting to that VPN server may be impossible. Dray Teks new VPN Matcher service helps Dray Tek routers behind NAT to allow Dial-In Teleworkers to connect, or connect two Dray Tek VPN routers that are behind NAT & could not normally establish a VPN tunnel. Connecting Remote Sites with LAN to LAN VPN Supporting up to 32 concurrently active VPN tunnels, the Vigor 2865 series is ideal for connecting multiple sites or home offices together with fast & secure IPsec VPN tunnels. Once connected, they have access to your office/remote resources through a secure encrypted tunnel allowing remote desktop, file sharing & seamless access to other resources & devices. Dray Tek SSL VPN for Dial-In Teleworkers & LAN to LAN The Vigor 2865 supports up to 16 active Dray Tek SSL VPN tunnel connections. These are encrypted tunnels linking your teleworkers or remote Dray Tek Vigor routers back to your main office using SSL/TLS technology
- the same encryption that you use for secure web sites such as your bank. Teleworkers can easily create a secure SSL VPN tunnel to the Dray Tek Vigor 2865 using the free Dray Tek Smart VPN Client app. Available for Windows, mac OS, Apple i OS (iPad, iPhone) & Android devices. 5+1 Gigabit LAN Ports with VLANs The Vigor 2865 series provides up to 6 Gigabit LAN ports for wired links to Computers, Servers & Network Attached Storage. With 5 dedicated LAN ports & one flexible LAN/WAN port, the Vigor 2865 can connect up to 6 devices directly with a single Ethernet WAN configuration, or 5 devices with a dual Ethernet WAN configuration. With Multiple LAN subnets & VLANs, the Vigor 2865 can manage up to 8 separate networks. For instance, an internal network with a separate network for Guests to use, completely separate from the private network. Each network with its own Content Filtering, Firewall, Quality of Service & Route Policy applied. The router has full support for 802.1Q VLAN tagging, so that these subnets can be passed to other devices that support VLAN tags, such as the Dray Tek Vigor Switch G1080 8-port switch, for additional network ports. The Wireless LAN also links to these VLANs, making the same Guest & Private networks possible simply using different wireless SSIDs. Or connect up a Dray Tek Vigor AP wireless access point, such as the Vigor AP 903 to do the same, spanning the routers own wireless & any connected wireless APs. Designed for Central Management The Vigor 2865 series (along with most other Dray Tek routers, Access points & switches) can be centrally managed by our Vigor ACS central management platform. This scalable solution provides visibility, control & reporting of your entire Dray Tek product estate, ideal for dealers/SIs managing customers devices or any user who wants to know whats going on with their devices. Vigor ACS also provides features like automated/bulk firmware updates, VPN management & alarms for connectivity or other issues. Robust & Comprehensive IPv 4 / IPv 6 Firewall Security is always taken seriously with Dray Tek routers. The firewall protects against attacks including Do S (Denial of Service) attacks, IP-based attacks & access by unauthorised remote systems. Wireless, Ethernet & VPN are also protected by various protection systems. The Dray Tek object-based firewall enables you to create combinations of Firewall rules & Content Filtering to suit a home or small office environment, applying Content Filtering to the whole network, only specified devices or just the network that guests can connect to. The Vigor 2865 supports both IPv 4 & IPv 6 with Dual-Stack IPv 4/IPv 6. Advanced networking features, such as the object-based Firewall, Quality of Service, Content Filtering & VLANs support both IPv 4 & IPv 6 networks. Web Content Filtering with DNS Filter The content control features of the Vigor 2865 allow you to set restrictions on web site access, blocking download of certain file or data types, blocking specific web sites with whitelists or blacklists, blocking IM/P2P applications or other potentially harmful or wasteful content. Restrictions can be per user, per PC or universal & according to time schedules. Content filtering can also block sites using HTTPS/SSL where URLs are encrypted (and normal routers cannot block). Using the Global View service, you can block whole categories of web sites (e.g. gambling, adult sites etc.), subject to an annual subscription, which is continuously updated with new or changed site categorisations or sites which have become compromised (such as infected with Malware). A free 30-day trial is included with your new router. High Availability
- Hardware Failover For even greater resilience, the Vigor 2865 series provides High Availability (HA), with both a primary & secondary router able to provide connectivity to your network & subnets. In the event of the primary unit failing, the secondary unit will take its place on the network, automatically switching over to resume Internet, routing & VPN connectivity with no intervention required. This can remove the possibility of a single point of failure within your routers. With Config Sync, the two routers are managed as a single unit, so that any changes made to the primary router will automatically propagate to the secondary router, ensuring it’s ready to take over at any time. Dray DDNS
- Dray Tek Dynamic DNS Address Dray Tek provides a free Dynamic DNS address to each Vigor 2865 router, allowing you to link the routers current IP address to a memorable "drayddns.com" hostname, such as "myrouter.drayddns.com". This address automatically updates whenever the Internet connections IP changes, so if one WAN’s IP address allocation is dynamic, or the IP changes when switching from the primary WAN connection to a backup, you can easily locate & access your Vigor 2865 router. Just use the hostname to access the routers VPN services, management & any other services you have made accessible through the router. The Vigor 2865 can also authenticate your Dray DDNS hostname with free SSL/TLS certificates provided by Lets Encrypt, the router manages & automates the certificate process. Keeping the certificate up to date & ready for use with SSL VPN & other services. Manage Guest Wi Fi with Hotspot Web Portal Dray Tek routers make it easy to manage Guest Wireless with Hotspot Web Portal. The fully customisable captive portal can apply to both the routers wireless networks & LAN interfaces, for use with wireless access points. Authentication can be handled by Google/ Facebook or an external web Portal service such as violet Wi Fi with RADIUS. Upon connecting to the wireless network, users are presented with your companys branding & information. From there, depending on what youve set, they can simply click-through, provide their details or enter a PIN with Voucher generated by the router. Once connected, the router can allow access until a user reaches their"a limit of time connected or bandwidth used. Quality of Service & Bandwidth Control Prioritise latency-sensitive applications on your network with Quality of Service. App Qo S simplifies setting up Quality of Service significantly, simply select which applications or services to prioritise, such as Zoom & Skype. Use 4 separate queues to give priority to servers & PCs (IP address), services such as Vo IP or DNS, or packet tagging used by IP phones with 802.1p & DSCP support Auto Voice VLAN allows the router to automatically prioritise Vo IP calls as they pass through the router without additional configuration. Control throughput with Bandwidth Limit, by setting speed limits for all clients individually, groups of IPs, or a shared bandwidth limit for a whole subnet, such as a Guest network. Central AP & Switch Management The Vigor 2865 manages Dray Tek Vigor AP access points & Vigor Switch switches connected locally to the router. This enables you to centrally control, manage & administer multiple AP & Switch devices installed around your building/campus from just the one router.



...

Draytek
- As Vigor 2865 with built in 3G/4G (LTE) SIM slot
- Plus 802.11ac Wi Fi ...

The Dray Tek Vigor 130 is an ADSL & VDSL modem with an Ethernet connection; it is not a router but a true ADSL/VDSL Ethernet Modem (bridge). The Vigor 130 provides compatibility with all current UK VDSL/ADSL technologies; it has been extensively tested & tuned to provide a robust & reliable DSL connection. By providing a PPPo E bridge, the connected device (firewall, router or PC) can log into the Internet (your ISP) directly & have full control over the Internet connection
- that makes the Vigor 130 a unique product. You can connect any device to the Vigor 130 which has a PPPo E client facility, which

Includes:: PCs, most Ethernet-WAN routers & the Apple Airport/ Time Capsule products. Other Ethernet modems may use workarounds to get a public IP address through to your secondary device/client, requiring non-standard operation & complicated dual-stage setup (modem logs in, router routes) but the Vigor 130 provides the secondary device with a real routed IP connection & the ability to fully manage the connection, making setup easy. In most cases, the Vigor 130 needs no setup or configuration
- just plug it in & set up your PC or router. All login/ISP details are entered on the connected client device, not the Vigor 130. The actual connection to your ISP is still PPPo A or PPPo E (depending on your ISP & line type). This transparent bridging method also differs from using a normal ADSL/VDSL router which logs in itself & then uses NAT or multiple public IP addresses to create an onward client connection for your secondary device; that is not IP Address thrifty & can introduce secondary NAT compromises or interference with various protocols/traffic. With the Vigor 130 bridge/modem, you get a true single public IP address (or multiple, if you have them) straight through to your firewall/router. Key Features ADSL & VDSL2 (FTTC/BT Infinity) Ethernet Modem Bridge (pass) a single IP address or a whole public subnet IPv 6 & IPv 4 Compatible Ethernet Connection for client device (router, PC etc.) Ideal for Apple Airport devices



...

Key Features & Benefits Add DSL connectivity to any Router Ideal Partner device for Dray Tek dual-WAN products or any other vendors Ethernet WAN firewall. Reports DSL Line Status on Dray Tek Vigor routers. Benefits: Connect any Router or Firewall to VDSL & ADSL Two Gigabit LAN Ports Connect two devices to the Vigor 167 with 2 Gigabit (10/100/1000 Mbps) LAN ports. Implement High Availability more easily & manage the modem conveniently. Benefits: More convenient setup & remote management. No Setup Needed Works as a modem with most ISPs, straight out of the box. Pre-Configured to work with most UK ISPs. Just set the username & password on your router. Benefits: Quick & easy to install. Wall or Shelf Mountable Can be installed securely on a wall or shelf with screw fixings to hold it in place. Mounting kit included. Benefits: Convenient & tidy installation. Vigor 167
- VDSL2 35b & ADSL2+ Modem The Vigor 167 is VDSL2 35b & ADSL2+ modem to Ethernet bridge, connecting VDSL or ADSL to your Ethernet-based Router or Firewall. It provides proven compatibility with UK VDSL2 & ADSL2+ networks. Dray Teks Vigor 167 is an ideal modem to connect your Dray Tek Vigor router, or any Router & Firewall, to a DSL line.
...
