The special inclined dual fan design effectively minimizes the flow of turbulence between two fans & enhances heat dissipation of hot area right underneath each fan. By unique design, WINDFORCE 2X even enlarges air channel on the graphics card vents & creates a more effective air flow system in chassis. This special design helps heat dissipate quickly from GPU. In addition, WINDFORCE 2X is equipped with 2 copper heat-pipes which strengthen the speed of heat dissipation. Chipset
- Radeon R9 270 Memory Clock
- 5600 MHz Process Technology
- 28 nm Memory Size
- 2048MB Memory Bus
- 256 bit Core Clock
- Base / Boost clockï14;š950 / 975 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 3 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=254mm W=141mm H=43mm Power requirement
- 500W (with two 6-pin external power connectors)
















...

Gigabyte R9 270X 2G GDDR5 Dual DVI HDMI Display Port PCI-e Graphics Card Features & Benefits: Lower GPU Temperature: Ultra Durable VGA board provides dramatic cooling effect on lowering both GPU & memory temperature by doubling the copper inner layer of PCB. Better Overclocking Capability: Ultra Durable VGA board reduces voltage ripples in normal & transient state, thus effectively lowers noises & ensures higher overclocking capability. Decrease Power Switching Loss: Ultra Durable VGA board allows more bandwidth for electron passage & reduces circuit impedance. The less circuit impedance, the more stable flow of current & can effectively improve power efficiency. Chipset Radeon
- R9 270X Core Clock
- Base / Boost clock:1050 / 1100 MHz Memory Clock
- 5600 MHz Process Technology
- 28 nm Memory Size
- 2048MB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 3 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=297mm W=132mm H=43mm Power requirement
- 500W (with two 6-pin external power connectors)
















...

WINDFORCE 3X Cooling system Powered by AMD Radeon R9 270X GPU Integrated with 2GB GDDR5 memory, 256-bit memory interface Features Dual-link DVI-I/ DVI-D / HDMI / Display Port BASE:1050 M Hz / BOOST:1100 MHz System power supply requirement: 500W Specifications Chipset
- Radeon R9 270X Core Clock
- Base / Boost clock:1050 / 1100 MHz Memory Clock
- 5600 MHz Process Technology
- 28 nm Memory Size
- 2048 MB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=297mm W=132mm H=43mm Power requirement
- 500W (with two 6-pin external power connectors)















...

Gigabyte R9 270X OC 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card

Includes:: Battelfield 4 Download

...

WINDFORCE 3X Cooling system with Triangle Cool technology Powered by AMD Radeon™ R9 280 GPU Integrated with 3GB GDDR5 memory, 384-bit memory interface Features DVI-I / HDMI / mini Display Port*2 BASE:950 M Hz / BOOST:1072 MHz System power supply requirement: 600W GIGABYTE introduces the latest exclusive " Triangle Cool" Technology to reach a better cooling performance. The latest patented technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the new triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. Therefore, the " Triangle Cool" Technology provides a more efficient air flow for the cooling system. Chipset
- Radeon R9 280 Memory Clock
- 5000 MHz Process Technology
- 28 nm Memory Size
- 3072 MB Memory Bus
- 384 bit Core Clock
- Base / Boost clock:950 / 1072 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 I/O
- DVI-I / mini Display Port*2 / HDMI*1 Card size
- L=285mm W=126mm H=38mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)















...

Gigabyte R9 290 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but also enables higher performance due to a lower temperature. Memory Clock
- 5000 MHz Chipset Radeon
- R9 290 Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 512 bit Core Clock
- 1040 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- DVI-D*2 / Display Port / HDMI Card size
- L=294mm, W=141mm, H=41mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)
















...

Gigabyte R9 290 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card
Includes: Battelfield 4 Download Br&-new instinctive
...

NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but also enables higher performance due to a lower temperature. Chipset Radeon
- R9 290X Memory Clock
- 5000 MHz Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 512 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 Core Clock
- 1040 MHz I/O
- DVI-D*2 / Display Port / HDMI Card size
- L=294mm, W=141mm, H=41mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)
















...

Gigabyte R9 380 G1 GAMING 4GB GDDR5 Dual-Link DVI-I DVI-D HDMI Display Port PCI-E Graphics Card GV-R938G1 GAMING-4GD Main Features Super overclocking up to 990 M Hz by GPU Gauntlet sorting technology WINDFORCE 2X cooling system & Fan Stop mode with Intuitive Fan Indicators Stylish Metal Back-Plate for better cooling & PCB reinforcement 6-Phase GPU power design (reference: 5) Ultra Durable graphics card components Chipset Radeon R9 380 Core Clock 990 MHz (standard: 970 MHz) Process Technology 28 nm Memory Clock 5700 MHz Memory Size 4GB Memory Bus 256-bit Memory Type GDDR5 Card Bus PCI-E 3.0 Direct X 12 Open GL 4.4 PCB Form ATX Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 4 I/O Dual-link DVI-I*1/DVI-D*1/HDMI*1/ Display Port*1 Card size H=42 mm, L=234 mm, W=129 mm Power requirement 500W (with one 8-pin external power connector) GPU Gauntlet Sorting With GPU Gauntlet Sorting, the Gigabyte SOC graphics card guarantees the higher overclocking capability in terms of excellent power switching WINDFORCE 2X --- Dual 90mm Unique blade fan design The air flow is split through the triangle design at the fan edge, & is guided smoothly through the fan by the special 3D stripe curve design, effectively enhancing the air flow by 23% over traditional fans, whilst reducing air turbulence. WINDFORCE 2X --- Direct Heat Pipe Touch Three 6mm pure cooper heat pipes contact GPU directly by DHT (Direct Heat Pipe Touch) technology ...

Gigabyte R9 390 G1 GAMING 8GB GDDR5 DVI-D HDMI 3x Display Port PCI-E Graphics Card OC up to 1025 M Hz core clock by GPU Gauntlet sorting technology WINDFORCE 2X with dual 90mm unique blade fan 8192MB high capacity memory fulfill the multi-screen & high definition gaming 0d B Semi-Passive Fan with LED indicators. Stylish Metal Back-Plate 6-Phase GPU power design Ultra Durable graphics card components GIGABYTE OC GURU II Supported Specifications GPU Radeon R9 390 Core Clock 1025 MHz Memory Clock 6000 MHz Memory Size 8192MB GDDR5 Bus Type PCI Express 3.0 Memory Bus 512-bit Stream Processors 2816 Memory type 64 Mx 32 Direct X 11 Yes DVI Port DVI-D Display Port 3 HDMI 1 3D’ 11 P: 15573 / X: 4998 3D’ FS Default: 10725 / Extreme: 5311 GPU Gauntlet Sorting With GPU Gauntlet Sorting, the Gigabyte SOC graphics card guarantees the higher overclocking capability in terms of excellent power switching WINDFORCE 2X --- Dual 90mm Unique blade fan design The air flow is split through the triangle design at the fan edge, & is guided smoothly through the fan by the special 3D stripe curve design, effectively enhancing the air flow by 23% over traditional fans, whilst reducing air turbulence. WINDFORCE 2X --- Fan Stop with Intuitive Fan Indicators Equipped with the latest 0d B Semi-passive fan technology, the fans stop spinning when the GPU is under a set temperature for complete silence. Featuring LED indicators on the top of the graphics card to provide an instant display of whether the fans are spinning or not. WINDFORCE 2X --- Stylish Metal Back Plate Glorious black metal back plate engraved with G1 GAMING logo inspires passion for gaming. ...
