Gigabyte R7 360 OC 2GB GDDR5 Dual-Link DVI-I DVI-D HDMI Display Port PCI-E Graphics Card GIGABYTE custom-designed 90 mm cooler, with air flow optimized cover & aluminum base. The cooler can dissipate heat effectively from the GPU while keeping the fan at lower speed & noise. Unique Blade Fan Design The airflow is spilt through the triangle design at the fan edge, & is guided smoothly through the fan by special 3D stripe curve design. At the same time, it effectively enhanced the cooling capacity while reducing air turbulence. Chipset Radeon R7 360 Core Clock 1200 MHz (standard: 1050 MHz) Memory Clock 6500 MHz Process Technology 28 nm Memory Size 2 GB Memory Bus 128 bit Card Bus PCI-E 3.0 Memory Type GDDR5 Direct X 12 Open GL 4.4 PCB Form ATX Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 4 I/O Dual-link DVI-I*1/DVI-D*1/HDMI*1/ Display Port*1 Card size H=42 mm, L=159 mm, W=127 mm Power requirement 500W (with one 6-pin external power connector) ...

Gigabyte R7 370 Windforce OC 2GB GDDR5 Dual-Link DVI-I DVI-D HDMI Display Port PCI-E Graphics Card GV-R737WF2OC-2GD Main Features WINDFORCE 2X with Dual 80mm unique blade fan & Heat pipe direct touch technology OC Edition with Core Clock of 1015 M Hz (Std: 975 M Hz) 2GB GDDR5 memory & 256-bit memory interface Stylish Metal Back-Plate for better cooling & PCB reinforcement Ultra Durable 2 technology delivers lower temperature & longer system lifespan Specifications Chipset Radeon R7 370 Core Clock 1015 MHz (standard: 975 MHz) Process Technology 28 nm Memory Clock 5600 MHz Memory Size 2GB Memory Bus 256-bit Memory Type GDDR5 Card Bus PCI-E 3.0 Direct X 12 Open GL 4.4 PCB Form ATX Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 4 I/O Dual-link DVI-I*1/DVI-D*1/HDMI*1/ Display Port*1 Card size H=43mm, L=263mm, W=142 mm Power requirement 500W (with two 6-pin external power connectors) WINDFORCE 2X --- Dual 80mm Unique blade fan design The air flow is split through the triangle design at the fan edge, & is guided smoothly through the fan by the special 3D stripe curve design, effectively enhancing the air flow by 23% over traditional fans, whilst reducing air turbulence. WINDFORCE 2X --- Direct Heat Pipe Touch Heat pipes contact GPU directly by DHT (Direct Heat Pipe Touch) technology. WINDFORCE 2X --- Stylish Metal Back Plate Glorious black metal back plate engraved with GIGABYTE logo inspires passion for gaming. ...

“ Free AMD Radeon Rewards download coupon Silver from 30th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” WINDFORCE Cooling system Powered by AMD Radeon R9 270 GPU Integrated with 2GB GDDR5 memory, 256-bit memory interface Features Dual-link DVI-I/ DVI-D / HDMI / Display Port BASE:950 M Hz / BOOST:975 MHz System power supply requirement: 500W The special inclined dual fan design effectively minimizes the flow of turbulence between two fans & enhances heat dissipation of hot area right underneath each fan. By unique design, WINDFORCETM 2X even enlarges air channel on the graphics card vents & creates a more effective air flow system in chassis. This special design helps heat dissipate quickly from GPU. In addition, WINDFORCETM 2X is equipped with 2 copper heat-pipes which strengthen the speed of heat dissipation. Specifications Chipset
- Radeon R9 270 Memory Clock
- 5600 MHz Process Technology
- 28 nm Memory Size
- 2048 MB Memory Bus
- 256 bit Core Clock
- Base / Boost clock:950 / 975 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=254mm W=141mm H=43mm Power requirement
- 500W (with two 6-pin external power connectors)















...

The special inclined dual fan design effectively minimizes the flow of turbulence between two fans & enhances heat dissipation of hot area right underneath each fan. By unique design, WINDFORCE 2X even enlarges air channel on the graphics card vents & creates a more effective air flow system in chassis. This special design helps heat dissipate quickly from GPU. In addition, WINDFORCE 2X is equipped with 2 copper heat-pipes which strengthen the speed of heat dissipation. Chipset
- Radeon R9 270 Memory Clock
- 5600 MHz Process Technology
- 28 nm Memory Size
- 2048MB Memory Bus
- 256 bit Core Clock
- Base / Boost clockï14;š950 / 975 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 3 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=254mm W=141mm H=43mm Power requirement
- 500W (with two 6-pin external power connectors)
















...

Gigabyte R9 270X 2G GDDR5 Dual DVI HDMI Display Port PCI-e Graphics Card Features & Benefits: Lower GPU Temperature: Ultra Durable VGA board provides dramatic cooling effect on lowering both GPU & memory temperature by doubling the copper inner layer of PCB. Better Overclocking Capability: Ultra Durable VGA board reduces voltage ripples in normal & transient state, thus effectively lowers noises & ensures higher overclocking capability. Decrease Power Switching Loss: Ultra Durable VGA board allows more bandwidth for electron passage & reduces circuit impedance. The less circuit impedance, the more stable flow of current & can effectively improve power efficiency. Chipset Radeon
- R9 270X Core Clock
- Base / Boost clock:1050 / 1100 MHz Memory Clock
- 5600 MHz Process Technology
- 28 nm Memory Size
- 2048MB Memory Bus
- 256 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 3 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=297mm W=132mm H=43mm Power requirement
- 500W (with two 6-pin external power connectors)
















...

Gigabyte R9 270X OC 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card

Includes:: Battelfield 4 Download

...

WINDFORCE 3X Cooling system with Triangle Cool technology Powered by AMD Radeon™ R9 280 GPU Integrated with 3GB GDDR5 memory, 384-bit memory interface Features DVI-I / HDMI / mini Display Port*2 BASE:950 M Hz / BOOST:1072 MHz System power supply requirement: 600W GIGABYTE introduces the latest exclusive " Triangle Cool" Technology to reach a better cooling performance. The latest patented technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the new triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. Therefore, the " Triangle Cool" Technology provides a more efficient air flow for the cooling system. Chipset
- Radeon R9 280 Memory Clock
- 5000 MHz Process Technology
- 28 nm Memory Size
- 3072 MB Memory Bus
- 384 bit Core Clock
- Base / Boost clock:950 / 1072 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 I/O
- DVI-I / mini Display Port*2 / HDMI*1 Card size
- L=285mm W=126mm H=38mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)















...

Gigabyte R9 280X 3GB GDDR5 DVI HDMI Display Port PCI-E Graphics Card GIGABYTE introduces the latest exclusive " Triangle Cool" Technology to reach a better cooling performance. The latest patented technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the new triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. Therefore, the " Triangle Cool" Technology provides a more efficient air flow for the cooling system. Chipset Radeon
- R9 280X Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Core Clock
- Base / Boost clock:1000 / 1100 MHz Memory Clock
- 6000 MHz Memory Size
- 3072 MB Memory Bus
- 384 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 Multi-view
- 3 I/O
- DVI-I / mini Display Port*2 / HDMI*1 Card size
- L=285mm W=126mm H=38mm Power requirement
- 600W (with one 6-pin & one 88-pin external power connectors)
















...

Gigabyte R9 290 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but also enables higher performance due to a lower temperature. Memory Clock
- 5000 MHz Chipset Radeon
- R9 290 Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 512 bit Core Clock
- 1040 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- DVI-D*2 / Display Port / HDMI Card size
- L=294mm, W=141mm, H=41mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)
















...

Gigabyte R9 290 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card
Includes: Battelfield 4 Download Br&-new instinctive
...
