“ Free AMD Radeon Rewards download coupon Silver from 30th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” WINDFORCE Cooling system Powered by AMD Radeon R9 270 GPU Integrated with 2GB GDDR5 memory, 256-bit memory interface Features Dual-link DVI-I/ DVI-D / HDMI / Display Port BASE:950 M Hz / BOOST:975 MHz System power supply requirement: 500W The special inclined dual fan design effectively minimizes the flow of turbulence between two fans & enhances heat dissipation of hot area right underneath each fan. By unique design, WINDFORCETM 2X even enlarges air channel on the graphics card vents & creates a more effective air flow system in chassis. This special design helps heat dissipate quickly from GPU. In addition, WINDFORCETM 2X is equipped with 2 copper heat-pipes which strengthen the speed of heat dissipation. Specifications Chipset
- Radeon R9 270 Memory Clock
- 5600 MHz Process Technology
- 28 nm Memory Size
- 2048 MB Memory Bus
- 256 bit Core Clock
- Base / Boost clock:950 / 975 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=254mm W=141mm H=43mm Power requirement
- 500W (with two 6-pin external power connectors)
