WINDFORCE 3X Cooling system with Triangle Cool technology Powered by AMD Radeon™ R9 280 GPU Integrated with 3GB GDDR5 memory, 384-bit memory interface Features DVI-I / HDMI / mini Display Port*2 BASE:950 M Hz / BOOST:1072 MHz System power supply requirement: 600W GIGABYTE introduces the latest exclusive " Triangle Cool" Technology to reach a better cooling performance. The latest patented technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the new triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. Therefore, the " Triangle Cool" Technology provides a more efficient air flow for the cooling system. Chipset
- Radeon R9 280 Memory Clock
- 5000 MHz Process Technology
- 28 nm Memory Size
- 3072 MB Memory Bus
- 384 bit Core Clock
- Base / Boost clock:950 / 1072 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 I/O
- DVI-I / mini Display Port*2 / HDMI*1 Card size
- L=285mm W=126mm H=38mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)















...

Gigabyte R9 280X 3GB GDDR5 DVI HDMI Display Port PCI-E Graphics Card GIGABYTE introduces the latest exclusive " Triangle Cool" Technology to reach a better cooling performance. The latest patented technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the new triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. Therefore, the " Triangle Cool" Technology provides a more efficient air flow for the cooling system. Chipset Radeon
- R9 280X Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Process Technology
- 28 nm PCB Form
- ATX Core Clock
- Base / Boost clock:1000 / 1100 MHz Memory Clock
- 6000 MHz Memory Size
- 3072 MB Memory Bus
- 384 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 Multi-view
- 3 I/O
- DVI-I / mini Display Port*2 / HDMI*1 Card size
- L=285mm W=126mm H=38mm Power requirement
- 600W (with one 6-pin & one 88-pin external power connectors)
















...

Gigabyte R9 290 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but also enables higher performance due to a lower temperature. Memory Clock
- 5000 MHz Chipset Radeon
- R9 290 Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 512 bit Core Clock
- 1040 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- DVI-D*2 / Display Port / HDMI Card size
- L=294mm, W=141mm, H=41mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)
















...

Gigabyte R9 290 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card
Includes: Battelfield 4 Download Br&-new instinctive
...

NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but also enables higher performance due to a lower temperature. Chipset Radeon
- R9 290X Memory Clock
- 5000 MHz Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 512 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 Core Clock
- 1040 MHz I/O
- DVI-D*2 / Display Port / HDMI Card size
- L=294mm, W=141mm, H=41mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)
















...

Gigabyte R9 390 G1 GAMING 8GB GDDR5 DVI-D HDMI 3x Display Port PCI-E Graphics Card OC up to 1025 M Hz core clock by GPU Gauntlet sorting technology WINDFORCE 2X with dual 90mm unique blade fan 8192MB high capacity memory fulfill the multi-screen & high definition gaming 0d B Semi-Passive Fan with LED indicators. Stylish Metal Back-Plate 6-Phase GPU power design Ultra Durable graphics card components GIGABYTE OC GURU II Supported Specifications GPU Radeon R9 390 Core Clock 1025 MHz Memory Clock 6000 MHz Memory Size 8192MB GDDR5 Bus Type PCI Express 3.0 Memory Bus 512-bit Stream Processors 2816 Memory type 64 Mx 32 Direct X 11 Yes DVI Port DVI-D Display Port 3 HDMI 1 3D’ 11 P: 15573 / X: 4998 3D’ FS Default: 10725 / Extreme: 5311 GPU Gauntlet Sorting With GPU Gauntlet Sorting, the Gigabyte SOC graphics card guarantees the higher overclocking capability in terms of excellent power switching WINDFORCE 2X --- Dual 90mm Unique blade fan design The air flow is split through the triangle design at the fan edge, & is guided smoothly through the fan by the special 3D stripe curve design, effectively enhancing the air flow by 23% over traditional fans, whilst reducing air turbulence. WINDFORCE 2X --- Fan Stop with Intuitive Fan Indicators Equipped with the latest 0d B Semi-passive fan technology, the fans stop spinning when the GPU is under a set temperature for complete silence. Featuring LED indicators on the top of the graphics card to provide an instant display of whether the fans are spinning or not. WINDFORCE 2X --- Stylish Metal Back Plate Glorious black metal back plate engraved with G1 GAMING logo inspires passion for gaming. ...

Gigabyte R9 390X G1 GAMING 8GB GDDR5 DVI-D HDMI 3x Display Port PCI-E Graphics Card OC up to 1060 M Hz core clock by GPU Gauntlet sorting technology WINDFORCE 2X with dual 90mm unique blade fan 8192MB high capacity memory fulfill the multi-screen & high definition gaming 0d B Semi-Passive Fan with LED indicators. Stylish Metal Back-Plate 8-Phase GPU power design (reference: 6) Ultra Durable graphics card components GIGABYTE OC GURU II Supported Specifications GPU Radeon R9 390X Core Clock 1060 MHz Memory Clock 6000 MHz Memory Size 8192MB GDDR5 Bus Type PCI Express 3.0 Memory Bus 512-bit Stream Processors 2816 Memory type 64 Mx 32 Direct X 11 Yes DVI Port DVI-D Display Port 3 HDMI 1 3D’ 11 P: 15573 / X: 4998 3D’ FS Default: 10725 / Extreme: 5311 With GPU Gauntlet Sorting, the Gigabyte SOC graphics card guarantees the higher overclocking capability in terms of excellent power switching WINDFORCE 2X --- Dual 90mm Unique blade fan design The air flow is split through the triangle design at the fan edge, & is guided smoothly through the fan by the special 3D stripe curve design, effectively enhancing the air flow by 23% over traditional fans, whilst reducing air turbulence. WINDFORCE 2X --- Stylish Metal Back Plate Glorious black metal back plate engraved with G1 GAMING logo inspires passion for gaming. ...

Powered by AMD Radeon™ R9 FURY GPU Integrated with 4GB 4096-bit High Bandwidth Memory (HBM) Core Clock: Up to 1010 M Hz Features HDMI / Display Port*3/ Dual-Link DVI-D System power supply requirement: 600W WINDFORCE 3X cooling system is equipped with high performance pure copper heat-pipes which direct touch the GPU can strengthen the speed of heat dissipation. Besides, the air flow is effectively enhanced by the unique blade fan design, this not only increase the cooling capacity while reducing air turbulence but also results a lower noise level. Br&-new intuitive user interface helps you easily modify important settings & directly update driver & BIOS. Clock speeds, voltage, fan performance, & OSD setting can be monitored & tuned in real-time according to your own preference. HBM &9472; High Bandwidth Memory Achieve more than three times the bandwidth per watt over GDDR5 memory with smaller, faster, & more power-efficient High Bandwidth Memory on-chip, boosting gaming performance achieving high-framerates & smooth gameplay. Specifications Chipset
- Radeon R9 FURY Core Clock
- 1010 MHz Memory Clock
- 1000 MHz Process Technology
- 28 nm Memory Size
- 4 GB Memory Bus
- 4096 bit Card Bus
- PCI-E 3.0 Memory Type
- HBM Direct X
- 12 Open GL
- 4.4 PCB Form
- ATX Digital max resolution
- 4096 X 2160 Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- HDMI*1/ Display Port*3/ Dual-Link DVI-D Power requirement
- 600W (with two 8-pin external power connector)















...

Gigabyte Radeon R9 270X 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Patented " Triangle Cool" Technology GIGABYTE introduces the latest exclusive " Triangle Cool" Technology to reach a better cooling performance. The latest patented technology combines fin with clip module in a special triangle shape. With the original anti-turbulence structure plus the new triangle cooling design, it enhances the efficiency of heat dissipation dramatically by minimizing the flow of turbulence between fans. Therefore, the " Triangle Cool" Technology provides a more efficient air flow for the cooling system. Chipset Radeon
- R9 270X Memory Clock
- 5600 MHz Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 256 bit Core Clock
- Base / Boost clockï14;š1050 / 1100 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- Dual-link DVI-I*1 / DVI-D*1 / Display Port*1 / HDMI*1 Card size
- L=297mm, W=132mm, H=43mm Power requirement
- 500W (with two 6-pin external power connectors)
















...

Gigabyte Radeon R9 290 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics card NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but also enables higher performance due to a lower temperature. Memory Clock
- 5000 MHz Chipset Radeon
- R9 290 Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 512 bit Core Clock
- 1040 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- DVI-D*2 / Display Port / HDMI Card size
- L=294mm, W=141mm, H=41mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)
















...
