NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but also enables higher performance due to a lower temperature. Chipset Radeon
- R9 290X Memory Clock
- 5000 MHz Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 512 bit Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 Core Clock
- 1040 MHz I/O
- DVI-D*2 / Display Port / HDMI Card size
- L=294mm, W=141mm, H=41mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)
















...

Gigabyte R9 380 G1 GAMING 4GB GDDR5 Dual-Link DVI-I DVI-D HDMI Display Port PCI-E Graphics Card GV-R938G1 GAMING-4GD Main Features Super overclocking up to 990 M Hz by GPU Gauntlet sorting technology WINDFORCE 2X cooling system & Fan Stop mode with Intuitive Fan Indicators Stylish Metal Back-Plate for better cooling & PCB reinforcement 6-Phase GPU power design (reference: 5) Ultra Durable graphics card components Chipset Radeon R9 380 Core Clock 990 MHz (standard: 970 MHz) Process Technology 28 nm Memory Clock 5700 MHz Memory Size 4GB Memory Bus 256-bit Memory Type GDDR5 Card Bus PCI-E 3.0 Direct X 12 Open GL 4.4 PCB Form ATX Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 4 I/O Dual-link DVI-I*1/DVI-D*1/HDMI*1/ Display Port*1 Card size H=42 mm, L=234 mm, W=129 mm Power requirement 500W (with one 8-pin external power connector) GPU Gauntlet Sorting With GPU Gauntlet Sorting, the Gigabyte SOC graphics card guarantees the higher overclocking capability in terms of excellent power switching WINDFORCE 2X --- Dual 90mm Unique blade fan design The air flow is split through the triangle design at the fan edge, & is guided smoothly through the fan by the special 3D stripe curve design, effectively enhancing the air flow by 23% over traditional fans, whilst reducing air turbulence. WINDFORCE 2X --- Direct Heat Pipe Touch Three 6mm pure cooper heat pipes contact GPU directly by DHT (Direct Heat Pipe Touch) technology ...

Gigabyte R9 390 G1 GAMING 8GB GDDR5 DVI-D HDMI 3x Display Port PCI-E Graphics Card OC up to 1025 M Hz core clock by GPU Gauntlet sorting technology WINDFORCE 2X with dual 90mm unique blade fan 8192MB high capacity memory fulfill the multi-screen & high definition gaming 0d B Semi-Passive Fan with LED indicators. Stylish Metal Back-Plate 6-Phase GPU power design Ultra Durable graphics card components GIGABYTE OC GURU II Supported Specifications GPU Radeon R9 390 Core Clock 1025 MHz Memory Clock 6000 MHz Memory Size 8192MB GDDR5 Bus Type PCI Express 3.0 Memory Bus 512-bit Stream Processors 2816 Memory type 64 Mx 32 Direct X 11 Yes DVI Port DVI-D Display Port 3 HDMI 1 3D’ 11 P: 15573 / X: 4998 3D’ FS Default: 10725 / Extreme: 5311 GPU Gauntlet Sorting With GPU Gauntlet Sorting, the Gigabyte SOC graphics card guarantees the higher overclocking capability in terms of excellent power switching WINDFORCE 2X --- Dual 90mm Unique blade fan design The air flow is split through the triangle design at the fan edge, & is guided smoothly through the fan by the special 3D stripe curve design, effectively enhancing the air flow by 23% over traditional fans, whilst reducing air turbulence. WINDFORCE 2X --- Fan Stop with Intuitive Fan Indicators Equipped with the latest 0d B Semi-passive fan technology, the fans stop spinning when the GPU is under a set temperature for complete silence. Featuring LED indicators on the top of the graphics card to provide an instant display of whether the fans are spinning or not. WINDFORCE 2X --- Stylish Metal Back Plate Glorious black metal back plate engraved with G1 GAMING logo inspires passion for gaming. ...

Gigabyte R9 390X G1 GAMING 8GB GDDR5 DVI-D HDMI 3x Display Port PCI-E Graphics Card OC up to 1060 M Hz core clock by GPU Gauntlet sorting technology WINDFORCE 2X with dual 90mm unique blade fan 8192MB high capacity memory fulfill the multi-screen & high definition gaming 0d B Semi-Passive Fan with LED indicators. Stylish Metal Back-Plate 8-Phase GPU power design (reference: 6) Ultra Durable graphics card components GIGABYTE OC GURU II Supported Specifications GPU Radeon R9 390X Core Clock 1060 MHz Memory Clock 6000 MHz Memory Size 8192MB GDDR5 Bus Type PCI Express 3.0 Memory Bus 512-bit Stream Processors 2816 Memory type 64 Mx 32 Direct X 11 Yes DVI Port DVI-D Display Port 3 HDMI 1 3D’ 11 P: 15573 / X: 4998 3D’ FS Default: 10725 / Extreme: 5311 With GPU Gauntlet Sorting, the Gigabyte SOC graphics card guarantees the higher overclocking capability in terms of excellent power switching WINDFORCE 2X --- Dual 90mm Unique blade fan design The air flow is split through the triangle design at the fan edge, & is guided smoothly through the fan by the special 3D stripe curve design, effectively enhancing the air flow by 23% over traditional fans, whilst reducing air turbulence. WINDFORCE 2X --- Stylish Metal Back Plate Glorious black metal back plate engraved with G1 GAMING logo inspires passion for gaming. ...

Powered by AMD Radeon™ R9 FURY GPU Integrated with 4GB 4096-bit High Bandwidth Memory (HBM) Core Clock: Up to 1010 M Hz Features HDMI / Display Port*3/ Dual-Link DVI-D System power supply requirement: 600W WINDFORCE 3X cooling system is equipped with high performance pure copper heat-pipes which direct touch the GPU can strengthen the speed of heat dissipation. Besides, the air flow is effectively enhanced by the unique blade fan design, this not only increase the cooling capacity while reducing air turbulence but also results a lower noise level. Br&-new intuitive user interface helps you easily modify important settings & directly update driver & BIOS. Clock speeds, voltage, fan performance, & OSD setting can be monitored & tuned in real-time according to your own preference. HBM &9472; High Bandwidth Memory Achieve more than three times the bandwidth per watt over GDDR5 memory with smaller, faster, & more power-efficient High Bandwidth Memory on-chip, boosting gaming performance achieving high-framerates & smooth gameplay. Specifications Chipset
- Radeon R9 FURY Core Clock
- 1010 MHz Memory Clock
- 1000 MHz Process Technology
- 28 nm Memory Size
- 4 GB Memory Bus
- 4096 bit Card Bus
- PCI-E 3.0 Memory Type
- HBM Direct X
- 12 Open GL
- 4.4 PCB Form
- ATX Digital max resolution
- 4096 X 2160 Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- HDMI*1/ Display Port*3/ Dual-Link DVI-D Power requirement
- 600W (with two 8-pin external power connector)















...

Gigabyte Radeon R9 290 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics card NEW WINDFORCE 3X 2 SLOT 450W cooling system Keeping the same 450W Cooling capacity using only 2 slots, the New WINDFORCE 3X 450W cooling system is equipped with two 8mm & four 6mm cooper heat-pipes, inclined fans, & GIGABYTE Triangle Cool technology. This not only provides an effective heat dissipation capacity but also enables higher performance due to a lower temperature. Memory Clock
- 5000 MHz Chipset Radeon
- R9 290 Process Technology
- 28 nm Memory Size
- 4096 MB Memory Bus
- 512 bit Core Clock
- 1040 MHz Card Bus
- PCI-E 3.0 Memory Type
- GDDR5 Direct X
- 11.2 Open GL
- 4.3 PCB Form
- ATX Digital max resolution
- 4096 X 2160 (via a single HDMI connector or Display Port & not supported with two DVI connectors) Analog max resolution
- 2048 x 1536 Multi-view
- 4 I/O
- DVI-D*2 / Display Port / HDMI Card size
- L=294mm, W=141mm, H=41mm Power requirement
- 600W (with one 6-pin & one 8-pin external power connectors)
















...

Gigabyte GA-X99-Gaming 5P Socket LGA2011-3 E-ATX Motherboard CPU Support for Intel Core i 7 processors in the LGA2011-3 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel X99 Express Chipset Memory 8 x DDR4 DIMM sockets supporting up to 128 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. 4 channel memory architecture Support for DDR4 3333 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 (O.C.) / 2400 (O.C.) / 2133 MHz memory modules Support for non-ECC memory modules Support for Extreme Memory Profile (XMP) memory modules Support for RDIMM 1 Rx 8/2 Rx 8/1 Rx 4/2 Rx 4 memory modules (operates in non-ECC mode) (Please refer " Memory Support List" for more information.) Audio Creative Sound Core 3D chip Support for Sound Blaster Recon 3 Di TI Burr Brown OPA2134 operational amplifier High Definition Audio 2/5.1-channel Support for S/PDIF Out LAN Qualcomm Atheros Killer E2201 LAN chip (10/100/1000 Mbit) Expansion Slots 2 x PCI Express x 16 slots, running at x 16 (PCIE_1/PCIE_2) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIE_1 slot; if you are installing two PCI Express graphics cards, it is recommended that you install them in the PCIE_1 & PCIE_2 slots. 2 x PCI Express x 16 slots, running at x 8 (PCIE_3/PCIE_4) * The PCIE_4 slot shares bandwidth with the PCIE_1 slot. When the PCIE_4 slot is populated, the PCIE_1 slot will operate at up to x 8 mode. * When an i 7-5820K CPU is installed, the PCIE_2 slot operates at up to x 8 mode & the PCIE_3 operates at up to x 4 mode. (All PCI Express x 16 slots conform to PCI Express 3.0 standard.) 3 x PCI Express x 1 slots (The PCI Express x 1 slots conform to PCI Express 2.0 standard.) 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI) Multi-Graphics Technology Support for 4-Way/3-Way/2-Way AMD Cross Fire™/NVIDIA SLI™ technology * The 4-Way NVIDIA SLI™ configuration is not supported when an i 7-5820K CPU is installed. To set up a 3-Way SLI configuration, refer to "1-6 Setting up AMD Cross Fire™/NVIDIA SLI™ Configuration." Storage Interface Chipset: 1 x M.2 PCIe connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe x 2/x 1 SSD support) 1 x SATA Express connector 6 x SATA 6 Gb/s connectors (SATA3 0~5) Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Only AHCI mode is supported when an M.2 PCIe SSD or a SATA Express device is installed. (M2_10G, SATA Express, & SATA3 4/5 connectors can only be used one at a time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is installed in the M2_10G connector.) Chipset: 4 x SATA 6 Gb/s connectors (s SATA3 0~3), supporting IDE & AHCI modes only (An operating system installed on the SATA3 0~5 connectors cannot be used on the s SATA3 0~3 connectors.) USB (Universal Serial Bus) Chipset: 4 x USB (Universal Serial Bus) 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 8 x USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Chipset + Renesas u PD720210 USB (Universal Serial Bus) 3.0 Hub: 4 x USB (Universal Serial Bus) 3.0/2.0 ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector& Scaron; 1 x 8-pin ATX 12V power connector 1 x PCIe power connector 1 x I/O shield audio LED power connector 1 x heatsink LED power connector 1 x M.2 Socket 3 connector 1 x SATA Express connector 10 x SATA 6 Gb/s connectors 1 x CPU fan header 1 x water cooling fan header (CPU_OPT) 3 x system fan headers 1 x front panel header 1 x front panel audio header 1 x USB (Universal Serial Bus) 3.0/2.0 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Thunderbolt add-in card connector& Scaron; 1 x Clear CMOS jumper 1 x CPU mode switch 1 x audio gain control switch Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 6 x USB (Universal Serial Bus) 3.0/2.0 ports 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x optical S/PDIF Out connector 1 x RJ-45 port 5 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Line In/ Mic In, Line Out, Headphone) 2 x Wi-Fi antenna connector holes I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection CPU/ System/ Chipset temperature detection CPU/CPU OPT/ System fan speed detection CPU/ System/ Chipset overheating warning CPU/CPU OPT/ System fan fail warning CPU/CPU OPT/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Support for Q-Flash Plus Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. @BIOS Ambient LED Easy Tune EZ Setup Fast Boot Game Controller Cloud Station ON/OFF Charge Smart Time Lock Smart Recovery 2 System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Smart Switch Support for Xpress Install Bundle Software Norton Internet Security (OEM version) Intel Smart Response Technology Operating System Support for Windows 8.1/8/7 Form Factor E-ATX Form Factor; 30.5cm x 26.4cm ...

Gigabyte X99-Gaming 7 WIFI Socket 2011 5.1 channel E-ATX Motherboard Product A2:A40 Model Name GA-X99-Gaming 7 WIFI Version 1.0 Intel AC7260.NGWG.R 936135 WIFI+BT card onboard CPU Type Socket 2011-3 Vendor Intel Speed Support Core i 7 series/ Haswell-E QPI/FSB N/A L2/L3 Cache Size L3 cache varies with CPU Chipset North Bridge X99 South Bridge N/A Flash ROM others, 128 Mb x 2 Super IO ITE 8620 Heatsink/ Heatpipe Gaming heatpipe / sink Memory Socket 8 DIMM Frequency DDR4/2133 Type 4-CH DDR4 Parallel ATA Controller N/A Spec N/A Serial ATA Controller Integrated in main chip Spec SATA 6 Gb/s RAID or SCSI Controller Integrated in main chip Spec RAID 0/1/5/10 Graphics Interface PCI-E 3.0 x 16 Controller N/A VRAM size (optional) N/A Driect X support N/A Audio Controller (optional) N/A Codec Creative Sound Core 3D SPDIF Out/ In SPDIF Out Channel 5.1 channel Dolby/DTS N/A LAN Controller Big Foot Killer 2100, 2201 PHY Intel I217/218/218V Spec Gb E 1394 Controller N/A Spec N/A USB (Universal Serial Bus) Controller Integrated in main chip, X99/u PD720210 hub*2 Spec USB (Universal Serial Bus) 2.0/USB 3.0 TPM Controller N/A Spec N/A Others Key Component MOSFET IR Pow I Rstage Power Phase 8/ Digital Choke Ferrite Core Choke USB (Universal Serial Bus) Charge N/A PCB Form Factor E-ATX Layer 8-lay 2oz Copper PCB YES Size (D x W) 305x 258mm Color Black Expansion PCI N/A PCI Express x 1 slot YES, 3 PCI Express x 4 slot N/A PCI Express x 8 slot YES, 2 PCI Express x 16 slot YES, 2 Rear I/O PS2 YES, 1 USB2.0 YES, 2/for DAP-Up USB3.0 YES, 8 e SATA N/A e SATA/USB Combo N/A LAN (RJ45) YES, 2 Display port N/A HDMI N/A DVI N/A D-SUB N/A Audio 6 audio jacks 1394 N/A Optical SPDIF out YES, 1 Coaxial SPDIF out N/A COM port N/A LPT Port N/A Button & switch Fast Boost, OC button Front I/O Front Panel (2x 10) YES Front USB2.0 2-Port (2x 5) YES, 2/support 4 ports Front USB3.0 2-Port (2x 10) YES, 2/support 4 ports Front 1394 1 Port (Intel 2x 5) N/A Front Audio (Intel 2x 5) YES SPIDIF in (1x 3) N/A SPDIF out (1x 2) N/A Serial ATA (1x 7) SATA3, 10/2 port sw with M.2/SATA express x 1 COM Port (2x 5) N/A Printer Port (2x 10) N/A HDD (2x 20) N/A FDD (2x 17) N/A TPM pin header (2x 10) N/A SAS N/A Other Features Dual BIOS YES ...

Gigabyte X99-Gaming G1 WIFI Socket 2011 5.1 channel Audio E-ATX Motherboard Version 1.0 Intel AC7260.NGWG.R 936135 WIFI+BT card onboard CPU Type Socket 2011-3 Vendor Intel Speed Support Core i 7 series/ Haswell-E QPI/FSB N/A L2/L3 Cache Size L3 cache varies with CPU Chipset North Bridge X99 South Bridge N/A Flash ROM others, 128 Mb x 2 Super IO ITE 8620 Heatsink/ Heatpipe Gaming heatpipe / sink Memory Socket 8 DIMM Frequency DDR4/2133 Type 4-CH DDR4 Parallel ATA Controller N/A Spec N/A Serial ATA Controller Integrated in main chip Spec SATA 6 Gb/s RAID or SCSI Controller Integrated in main chip Spec RAID 0/1/5/10 Graphics Interface PCI-E 3.0 x 16 Controller N/A VRAM size (optional) N/A Driect X support N/A Audio Controller (optional) N/A Codec Creative Sound Core 3D SPDIF Out/ In SPDIF Out Channel 5.1 channel Dolby/DTS N/A LAN Controller Big Foot Killer 2100, 2201 PHY Intel I217/218/218V Spec Gb E 1394 Controller N/A Spec N/A USB (Universal Serial Bus) Controller Integrated in main chip, X99/u PD720210 hub*2 Spec USB 2.0/USB 3.0 TPM Controller N/A Spec N/A Others Key Component MOSFET IR Pow I Rstage Power Phase 8/ Digital Choke Ferrite Core Choke USB (Universal Serial Bus) Charge N/A Form Factor E-ATX Layer 8-lay 2oz Copper PCB YES Size (D x W) 305x 258mm Color Black Expansion PCI N/A PCI Express x 1 slot YES, 3 PCI Express x 4 slot N/A PCI Express x 8 slot YES, 2 PCI Express x 16 slot YES, 2 Rear I/O PS2 YES, 1 USB2.0 YES, 2/for DAP-Up USB3.0 YES, 8 e SATA N/A e SATA/USB Combo N/A LAN (RJ45) YES, 2 Display port N/A HDMI N/A DVI N/A D-SUB N/A Audio 6 audio jacks 1394 N/A Optical SPDIF out YES, 1 Coaxial SPDIF out N/A COM port N/A LPT Port N/A Button & switch Fast Boost AOC button Front I/O Front Panel (2x 10) YES Front USB2.0 2-Port (2x 5) YES, 2/support 4 ports Front USB3.0 2-Port (2x 10) YES, 2/support 4 ports Front 1394 1 Port (Intel 2x 5) N/A Front Audio (Intel 2x 5) YES SPIDIF in (1x 3) N/A SPDIF out (1x 2) N/A Serial ATA (1x 7) SATA3, 10/2 port sw with M.2/SATA express x 1 COM Port (2x 5) N/A Printer Port (2x 10) N/A HDD (2x 20) N/A FDD (2x 17) N/A TPM pin header (2x 10) N/A SAS N/A Other Features Dual BIOS YES ...

Gigabyte X99M-Gaming 5 Socket 2011-V3 Micro-ATX Motherboard CPU Support for Intel Core i 7 processors in the LGA2011-3 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel X99 Express Chipset Memory 4 x DDR4 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. 4 channel memory architecture Support for DDR4 2800 (O.C.) / 2666 (O.C.) / 2400 (O.C.) / 2133 MHz memory modules Support for non-ECC memory modules Support for Extreme Memory Profile (XMP) memory modules Support for RDIMM 1 Rx 8 memory modules (operate in non-ECC mode) (Please refer " Memory Support List" for more information.) Audio Realtek ALC1150 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Qualcomm Atheros Killer E2201 chip (10/100/1000 Mbit) Expansion Slots 2 x PCI Express x 16 slots, running at x 16 (PCIE_1/PCIE_2) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIE_1 slot; if you are installing two PCI Express graphics cards, it is recommended that you install them in the PCIE_1 & PCIE_2 slots. 1 x PCI Express x 16 slot, running at x 8 (PCIE_3) * When an i 7-5820K CPU is installed, the PCIE_2 slot operates at up to x 8 mode & the PCIE_3 operates at up to x 4 mode. (All PCI Express x 16 slots conform to PCI Express 3.0 standard.) 1 x PCI Express x 1 slot (The PCI Express x 1 slot conforms to PCI Express 2.0 standard.) 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI) Multi-Graphics Technology Support for 2-Way AMD Cross Fire/NVIDIA SLI technology Storage Interface Chipset: 1 x M.2 PCIe connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe x 2/x 1 SSD support) 1 x SATA Express connector 6 x SATA 6 Gb/s connectors (SATA3 0~5) Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Only AHCI mode is supported when an M.2 PCIe SSD or a SATA Express device is installed. (M2_10G, SATA Express, & SATA3 4/5 connectors can only be used one at a time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is installed in the M2_10G connector.) Chipset: 4 x SATA 6 Gb/s connectors (s SATA3 0~3), supporting IDE & AHCI modes only (An operating system installed on the SATA3 0~5 ports cannot be used on the s SATA3 0~3 ports.) USB (Universal Serial Bus) Chipset: 4 x USB (Universal Serial Bus) 3.0/2.0 ports (available through the internal USB (Universal Serial Bus) headers) 10 x USB (Universal Serial Bus) 2.0/1.1 ports (6 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Chipset + Renesas u PD720210 USB (Universal Serial Bus) 3.0 Hub: 4 x USB (Universal Serial Bus) 3.0/2.0 ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x M.2 Socket 3 connector 1 x SATA Express connector 10 x SATA 6 Gb/s connectors 1 x CPU fan header 1 x water cooling fan header (CPU_OPT) 3 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB (Universal Serial Bus) 3.0/2.0 headers 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Clear CMOS jumper 1 x power button 1 x reset button 1 x Clear CMOS button 1 x audio gain control switch 2 x BIOS switches Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 4 x USB (Universal Serial Bus) 3.0/2.0 ports 6 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 1 x optical S/PDIF Out connector 5 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In) 2 x Wi-Fi antenna connector holes I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection CPU/ System/ Chipset temperature detection CPU/CPU OPT/ System fan speed detection CPU/ System/ Chipset overheating warning CPU/CPU OPT/ System fan fail warning CPU/CPU OPT/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. @BIOS Ambient LED Easy Tune EZ Setup Fast Boot Game Controller Cloud Station ON/OFF Charge Smart Time Lock Smart Recovery 2 System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Smart Switch Support for Xpress Install Bundle Software Norton Internet Security (OEM version) Intel Smart Response Technology Operating System Support for Windows 8.1/8/7 Form Factor Micro-ATX Form Factor; 24.4cm x 24.4cm ...
