Scythe have released some new 120mm case fans, the " Slipstream 120mm Case Fan". Their main aim with the new fans was to increase performance without compromising noise levels. The Slipstream 120mm Case Fans have been developed solely by Scythe engineers. They found out that by reducing the dimension of the centre hub & the wider surface area of the fan blade increased the airflow. There are a range of different fan speeds to choose from which meets the demand from a wide variety of users in the market. Silent users to power users now have more choice when it comes to choosing a suitable case fan. Features Model number SY1225SL12SH Quiet PC cooling fan Sleeve Bearings Very quiet only 37.0 d B (A) at 1900 RPM MTBF 30, 000 hours Specifications Fan size (edge to edge) 120 mm Manufacturer Scythe Model SY1225SL12SH Air volume at full speed (12V), CFM ±10% 110.3 Noise level at full speed (12V), d B (A) 37.0 Fan speed at full speed (12V), RPM ±10% 1900 Weight, g 115 Approximate cable length, cm 30 Life expectancy @ 25°C continuous use 3.5 years Power connector 3-pin with 3-pin to 4-pin Molex adaptor Bearing type Sleeve Mounting hardware included Screws Fan depth 25 mm Rated voltage 12 VDC Warranty 24 months ...

The update of Big Shuriken is equipped with an additional 6mm heatpipe as well as an additional row of fins. This significantly increased increased the cooling capabilities of the cooler. Scythe have done this & still kept the cooler under 58mm in height which provides compatibility especially with HTPCs (Home Theatre Personal Computers) & computer systems with limited space. In addition higher compatibility with new generation chipset motherboards was established by inventing F.S.M.B.4 (Flip Mount Super Back-Plate 4) mounting system, so now the Rev.B provides compatibility with the new Intel LGA2011 socket. Features Excellent low profile cooler, only 58mm tall Supplied with Scythe 120mm Slim PWM fan Suitable for Intels new LGA2011 CPUs New FSMB4 mounting system Compatible with Intel LGA2011/1366/1155/1156/775 & AMD FM1/AM3+/AM3/AM2+/AM2

Specification Model Number SCBSK-2100 Compatibility Intel LGA2011/1366/1155/1156/775 & AMD FM1/AM3+/AM3/AM2+/AM2 Max TDP All Installation Method Intel & AMD
- backplate, requires motherboard removal Combined

Dimensions 125 x 135 x 58 mm Weight 410 g Accessories Manual, Thermal Grease Fan specifications Shown below Model Name Slip Stream 120 Slim PWM Model No. SY1212SL12H-P Fan

Dimensions 120 x 120 x 12 mm Fan Speed 500 (±200 RPM)
- 2000 RPM (±10%)
- PWM controlled Noise Level 9.32 – 33.67 d BA Air Flow 12.13
- 45.47 CFM Static Pressure 0.11 – 1.35 mm H2O Input Current 0.19 A Bearing Type Sleeve Bearing Voltage 12 V Warranty 24 months EAN barcode 4571225049441









...

The largest Mini Kaze variant (60x 60x 20 mm) is characterised by high power at low operational sound. A large number of possible application areas make this fan the ideal choice for many users. By using a 2-pin to 3-pin adapter, one can use the Mini Kaze 60 cm fan for cooling the chip set in external hard disk casings or in a picture frame with a removeable back. The fan was set to an optimum speed of 2, 500 RPM, in order to generate the lowest possible volume. ...

Gentle Typhoon 120 mm High Speed Series are optimised for high speed as well as high airflow. An implemented ring connects the fan blades creating characteristics similar to 38mm thick fans, while running at a quieter noise level. By employing a large fan motor, little fluctuation in rotation torque has been achieved. Furthermore, a vibration absorbing structure has been integrated to further help reduce the noise level. Optimized for High Airflow Forceful airflow is created & guided in a linear fashion thanks to the implemented stabilising ring. By using this powerful design the fans are able to generate high pressure to overcome & handle high resistance such as when being used with a duct or coolers with dense fin structure. Vibration Reduction Structure By employing a large fan motor, little fluctuation in rotation torque has been achieved. Furthermore, an anti-vibration absorbing structure has been integrated to further reduce the noise level. This combination greatly reduces the transfer of vibration from the motor to the fan chassis. Weight 205 g Dimensions 120 x 120 x 25 mm Maximum air flow, CFM ±10% 83.0 Maximum noise level, d B (A) 36.5 Maximum fan speed, RPM ±10% 3000 Power Consumption 2.64 W Rated Current 0.22 A Starting Current 0.97 A Cable Length 30 cm Bearing Type Double Ball Bearing MTBF 100, 000 hour at 35°C or 60, 000 hours at 60°C Accessories 4-pin Molex Adapter, 4x Screws Warranty 24 months ...

Scythe Kaze Jyu SLIM 100mm 2000RPM Case/HDD Fan If you need a slim fan than the Kaze Jyu SLIM could be just what you are looking for. The fan is 100mm but it has 92mm fan screw holes so it could replace any existing 92mm fan. The fan is also supplied with a HDD mounting kit, allowing the fan to be mounted directly to any 312;" hard drive to aid cooling.

Features: Super slim
- only 12mm thick Supplied with HDD mounting kit, for HDD cooling Equipped with both 92mm & 100mm screw holes 3-Pin to 4-Pin adapter provided 27.6 CFM / 29.2 d BA / 2000 RPM Specifications Model number
- SY1012SL12M

Dimensions
- 100 x 100 x 12 mm Air volume at full speed (12V), CFM ±10%
- 27.6 Noise level at full speed (12V), d B (A)
- 29.2 Fan speed at full speed (12V), RPM ±10%
- 2000 Connector
- 3-pin (4-pin adaptor included) Cable Length
- 30cm / 11.81 inch Bearing Type
- Sleeve MTBF
- 30, 000 hours Warranty
- 24 months














...

Scythe Kaze Jyuni 500RPM Slip Stream 120mm Fan The Scythe Slip Stream 120mm fan
- designed to increase performance without compromising
...

If space is limited & you need a quiet, low profile CPU cooler then the Kozuti could be it! The Kozuti stands just 40mm tall which makes it an ideal CPU cooler where space is limited. Scythe have achieved this low height by placing the fan underneath the heatsink fins instead of on the top. This obviously reduces the height of the cooler but does not affect its performance. To generate airflow, Scythe have opted for a PWM 80 x 80 x 10mm fan, which also contributes to keeping down the height of the cooler. The fan produces enough airflow for it to be able to cool CPUs that have a Thermal Design Power (TDP) of 95W, but if you want to keep things as quiet as possible, Scythe recommends the Kozuti for CPUs that generate a maximum of 65W. Specifications
- Model No.
- SCKZT-1000 Compatibility
- Intel LGA1366/1155/1156/775 & AMD FM1/AM3+/AM3/AM2+/AM2 Max TDP
- 95W (for quiet operation 65W recommended) Installation Method
- Intel & AMD
- screws, requires motherboard removal Overall

Dimensions
- 110 x 103 x 40 mm Weight Included Fan
- 250 g Fan Model No
- SY8010SL12M-P, 4-pin PWM Fan

Dimensions
- 80 x 80 x 10 mm Fan Speed, RPM
- 800 ±30%
- 3300 ±10% Air Flow, CFM
- 6.0 to 24.8 Noise Level
- 8.2 to 32.5 d BA Input Power
- 2.4 W Input Current
- 0.20 A Voltage Range
- 12 V




















...

Scythe Mini Kaze, 40mm x 10mm Quiet Cooling Fan The Mini Kaze, an ideal replacement for any 40mm chipset, external HDD case cooling fan & removable case cooling fan. Introducing Scythe's quiet 40mm fan to help reduce the noise of your already quiet PC system. This fan is an ideal replacement for any 40mm chipset, external HDD case cooling fan & removable case cooling fan. Features 40 x 10mm quiet PC cooling fan Noise level 14.0 d B (A) 2-pin & 3-pin connectors Great value Perfect for Chipset/VGA Cooling Specifications: Fan size (edge to edge)
- 40 mm Screw hole spacings
- 32 mm Model
- SY124010L Air volume at full speed (12V), CFM ±10%
- 4.11 Noise level at full speed (12V), d B (A)
- 14 Fan speed at full speed (12V), RPM ±10%
- 3500 Weight, g
- 65 Approximate cable length
- 11cm 2-pin, 22cm with 3-pin adapter Life expectancy @ 25°C continuous product use
- 2 years Power connector
- 3-pin & 2-pin Bearing type
- Sleeve Accessories
- 2-pin to 3-pin converter Fan depth
- 10 mm












...

Scythe Mini Kaze 50mm Quiet Fan Scythe's 50mm Mini Kaze is designed to replace any 12V 50mm 2-pin or 3-pin fan, whilst making only a fraction of the noise. Scythe's 50mm Mini Kaze is designed to replace any other 12V 50mm fan, whilst making only a fraction of the noise. The Silent Mini Kaze 50mm fan uses by default a 2-pin connector. Included with the fan is an adapter to convert the 2-pin connector to a standard 3-pin connector, thus providing the best compatibility for both old & new hardware. Features Ideal replacement for very noisy 50mm fans 2-pin & 3-pin connectors Great value Specifications:

Dimensions
- 50 x 50 x 10 mm Distance between hole centres
- 40 mm Weight
- 21g Noise Level
- 26.09 d BA Air Flow
- 9.4 CFM Fan Speed
- 4, 500 rpm Starting Voltage
- 9 V Current
- 0.06A Operating Voltage
- 10.8 ~ 13.2 V MTBF
- 30, 000 h Accessories
- Mounting Screws, 2-pin to 3-pin adapter Warranty
- 24 months













...
