Key Features 8 Port Gigabit Managed Switch Ultra compact form factor Wall Mountable Fanless (Silent) Operation Ultra-low power consumption The Vigor Switch G1080 is a small, high-performance Gigabit smart switch designed for small & medium business networks that require simple network management, with support for VLANs, Qo S & Link Aggregation (increases uplink speed for high data volume applications). The G1080 is an ulta-low power device, consuming under 1A, even when fully loaded. It is powered by an AC/DC adaptor (included). Its a low cost device, ideal for adding additional Ethernet ports to your router with a small footprint. The Vigor Switch G1080 can be managed directly through its web interface, or can be installed in conjunction with a compatible Vigor router to expand the routers network, with the Vigor Switch G1080 managed & monitored through the Dray Tek Vigor routers web interface. Power from USB (Universal Serial Bus) If you have limited space or power sockets, the Vigor Switch G1080 can also be powered by USB (Universal Serial Bus)
- perhaps the USB (Universal Serial Bus) port on PC or one on your Dray Tek Vigor router**. Requires optional USB (Universal Serial Bus)-DC cable (part no. HVUSB1). Otherwise you can just power the device with the supplied AC/DC power supply. Central Management The Dray Tek Vigor Switch G1080 can operate in standalone mode & be managed through its web interface or, if you need to manage & monitor the switch remotely, or have several Dray Tek Vigor Switches to administer, you can centrally manage Vigor Switches on a site from the Dray Tek router which they are physically connected to. With Dray Tek Central Switch Management, connected Vigor Switches can be monitored, managed & provisioned simply by accessing the routers web interface, either locally or from across the Internet.
...

24+4 Port Gigabit Managed Switch 802.3az Power Saving 802.1q VLANs (Tag, Port & MAC-based) Qo S for Application traffic prioritisation Voice VLAN for Qo S (OUI Mode) The Vigor Switch G1280 is a high-performance, Gigabit smart switch with 24 RJ-45 ports (plus 4 additional Gigabit ports) The Vigor Switch G1280 features our latest generation of Dray Tek's own switch operating system which is used across our range of enhanced switches. This enables a consistent user-experience & look-&-feel so that once you're familiar with one model, the others feel the same. The new UI is designed to be intuitive & efficient, whilst providing access to all of the product's advanced features. Enhanced Feature Set The G1280's

Specification is packed with advanced features to aid reliability & switching performance to your network & is ready for the next generation with both IPv 4 & IPv 6 support. The G1280 has 24 standard (RJ45/copper) Gigabit Ethernet Ports, & four selectable ports (which can be set to either RJ-45 or SFP slots). Features for Quality of Service (Qo S), VLANs & network/switch security provide additional flexibility.

...

Key Features 24+4 Port Gigabit Managed Switch 802.3az Power Saving 802.1q VLANs (Tag, Port & MAC-based) Qo S for Application traffic prioritisation Voice VLAN for Qo S (OUI Mode) The Vigor Switch G1280 is a high-performance, Gigabit smart switch with 24 RJ-45 ports (plus 4 additional Gigabit ports) The Vigor Switch G1280 features our latest generation of Dray Teks own switch operating system which is used across our range of enhanced switches. This enables a consistent user-experience & look-&-feel so that once youre familiar with one model, the others feel the same. The new UI is designed to be intuitive & efficient, whilst providing access to all of the products advanced features. Enhanced Feature Set The G1280s

Specification is packed with advanced features to aid reliability & switching performance to your network & is ready for the next generation with both IPv 4 & IPv 6 support. The G1280 has 24 standard (RJ45/copper) Gigabit Ethernet Ports, & four selectable ports (which can be set to either RJ-45 or SFP slots). Features for Quality of Service (Qo S), VLANs & network/switch security provide additional flexibility.

...

Product Description Draytek Vigor Switch G2100
- switch
- 8 ports
- Managed
- rack-mountable Device Type Switch
- 8




...

Key Features 802.3az Power Saving 802.1q VLANs (Tag, Port & MAC-based) Qo S for Application traffic prioritisation Voice VLAN for Qo S (OUI Mode) Access Control List (ACL) The Vigor Switch G2280 is a high-performance, Gigabit smart switch with 24 RJ-45 ports (plus 4 additional Gigabit ports). The Vigor Switch G2280 features our latest generation of Dray Teks own switch operating system which is used across our range of enhanced switches. This enables a consistent user-experience & look-&-feel so that once youre familiar with one model, the others feel the same. The new UI is designed to be intuitive & efficient, whilst providing access to all of the products advanced features. Enhanced Feature Set The G2280s

Specification is packed with advanced features to aid reliability & switching performance to your network & is ready for the next generation with both IPv 4 & IPv 6 support. The G2280 has 24 standard (RJ45/copper) Gigabit Ethernet Ports, & four selectable ports (which can be set to either RJ-45 or SFP slots). Features for Quality of Service (Qo S), VLANs & network/switch security provide additional flexibility.

...

Vigor Switch G2540x 10 Gb E Gigabit Switch with 48 Gigabit Ports & 6 10 Gb E SFP+ Uplink Ports Vigor Switch G2540x is a 54 port Gigabit L2+ Managed switch with a plethora of management options & enterprise-level features to improve network stability & security for businesses. Use the 4 switchable SFP/RJ-45 ports & 2 dedicated SFP module slots to link with additional switches using link aggregation, or plug in a suitable SFP module to use optical Fibre as an Ethernet uplink. Designed for centralised management, the Vigor Switch G2540x can be provisioned & monitored through both the Vigor ACS management platform and/or, a Dray Tek Vigor router’s Central Switch Management. Easily provision the VLAN configuration through the router & clone switch configurations. Drastically reduce the setup time required for a complex network, with VLANs spanning multiple switches. ...

The Vigor Switch P1092 is a high-performance, Gigabit smart switch with Po E+ (Power over Ethernet) on 8 RJ-45 ports (plus 2 additional SFP ports). All 8 ports are full speed Gigabit (1000 Mb/s) Ethernet; as well as ensuring that your wired Ethernet devices get maximum speed, Gigabit on Po E is is particularly useful on a network where your Po E devices are providing Gigabit devices to a secondary device, for example IP phone to desktop PC using their loop/passthrough support if it supports Gigabit Ethernet. Of course, regular, non-Po E devices can connect to the switch so will also still take advantage of the Gigabit speed so ideal for a mixed environment. The P1092

Includes:: the rack mounting bracket/kit as standard. Po E Devices The Vigor Switch P1092 is a Po E (Power over Ethernet) switch, providing power to any Po E-enabled device, most commonly IP phones, wireless access points or IP cameras over the Ethernet cable. As well as removing the need for local (at the desk) power supplies, making for tidier installations, Po E ensures power efficiency, providing only the power needed. Power is provided only when required. Po E also allows for installation of devices where there is no mains power (particularly useful for wireless access points). The P1092 supports both standard Po E (802.3af) & High-Power Po E (802.3at) devices. Central Management* The Dray Tek Vigor Switch P1092 can operate in standalone mode & be managed through its web interface or you need to manage & monitor the switch remotely, or have several Dray Tek Vigor Switches to administer, you can centrally manage them with a Dray Tek router which supports switch management*. This allows a Dray Tek router which is directly connected to the switch to manage it. For details on this click the tabs at the top of the page. The Dray Tek Vigor Switch P1092 has 2 Gigabit SFP module ports (labelled 9 & 10) which can be used in addition to the 8 RJ-45 ports. SFP slots are typically used for fibre transceivers. In comparison to copper (RJ-45) cables, using fibre for connectivity provides longer range & resilience from electrical interference. The SFP ports provide compatibility with your choice of SFP modules (not included) & therefore the most appropriate medium for your application.

...

The Vigor Switch P1280 is a high-performance, Gigabit switch with Po E+ (Power over Ethernet) on 24 RJ-45 ports (plus 4 additional Gigabit ports). With the increase in Po E powered devices requiring full power, notably wireless access points & IP cameras, the generous 340W power budget is much higher than many other products in its class. New Dray Tek OS & User Interface The Vigor Switch P1280 features our latest generation of Dray Teks own switch operating system which is used across our range of enhanced switches. This enables a consistent user-experience & look-&-feel so that once youre familiar with one model, the others feel the same. The new UI is designed to be intuitive & efficient, whilst providing access to all of the products advanced features. Enhanced Feature Set The P1280s

Specification is packed with advanced features to aid reliability & switching performance to your network & is ready for the next generation with both IPv 4 & IPv 6 support. The P1280 has 24 standard (RJ45/copper) Gigabit Ethernet Ports, all with Po E+ & four selectable ports (which can be set to either RJ-45 or SFP slots). Features for Quality of Service (Qo S), VLANs & network/switch security provide additional flexibility. Po E Devices The Vigor Switch P1280 is a Po E (Power over Ethernet) switch, providing power to any Po E-enabled device, most commonly IP phones, wireless access points or IP cameras over the Ethernet cable. As well as removing the need for local (at the desk) power supplies, making for tidier installations, Po E ensures power efficiency, providing only the power needed, as well as allowing for time schedules for powering up/down & remote rebooting. Power is provided only when required. Po E also allows for installation of devices where there is no mains power (particularly useful for wireless access points). The P1280 supports both standard Po E (802.3af) & High-Power Po E (802.3at) devices.

...

Po E (Power over Ethernet) Deliver power & data over one ethernet cable, turn on/off the Po E device periodically with Po E Schedule. Po E device check Enable Ping Watchdog for all Po E devices, if they lose their network connection, automatically restart them by a power cycle. Auto surveillance & Voice VLAN Recognize traffic from IP cameras & IP phones automatically & add Co S tag for Qo S prioritization. ONVIF-friendly Recognize the ONVIF devices, display surveillance topology, provide UI for video streaming & device maintenance. Learn more Wire-speed VLAN routing Improve overall network performance by using Vigor Switch P2100 to route the inter-VLAN traffic directly & offload the router. IP Conflict Prevention Improve network stability by avoiding IP conflicts caused by a misconfigured or malicious host. Access Control Vigor Switch P2100 supports ACL by IP/MAC & 802.1x port access control with RADIUS to filter unauthorized hosts. Qo S (Quality of Service) Improve the performance of critical traffic by prioritizing the traffic with Co S, DSCP, & IP Precedence tag. IPv 6 Ready Vigor Switch P2100 supports IPv 6 by offering MLD Snooping, IPv 6 ACL, & IPv 6 DNS Resolver. Web-based GUI Easily manage & monitor the network through the web-based console with graphics showing ports & hardware status. See demo Multiple Admin accounts Multiple Admin accounts with two levels of administrator privilege. Central switch management Set up VLAN easily from the router & get a centralized hierarchy view of the switches. Learn more Energy-efficient Ethernet Compliant with IEEE 802.3az to reduce power consumption. ...

8+4 Port Gigabit Managed Switch: 8 x RJ-45 Ethernet Ports with Po E+ 4 x Combo RJ-45 or SFP (Fibre Module) Ports Po E (Power-over-Ethernet) for IP phones, wireless access points, IP Cameras etc. Fanless for silent operation with generous 140w Po E Power budget 802.3af (Po E) & 802.3at (High Power Po E) 802.1q VLANs (Tag, Port & MAC-based) Access Control List (ACL) Secure Networking with 802.1x Port Security, IP Source Guard & DHCP Snooping Qo S for Application traffic prioritisation Voice & IP Camera VLANs for auto Qo S prioritisation via MAC address OUI Port Mirroring & Link Aggregation IGMP Snooping/ Querier & IPv 6 MLD Snooping IPv 4 & IPv 6 Support Centrally managed or standalone operation Console Port for CLI configuration Desktop, Wall or Rack mountable The Vigor Switch P2121 is a silent, high-performance, Gigabit smart switch with Po E+ (Power over Ethernet) on 8 RJ-45 ports. With the increase in Po E powered devices requiring full power, notably wireless access points & IP cameras, the generous 140W power budget is much higher than many other products in its class without fan cooling. The switch can be used simply on a desk, or securely fitted to a wall / shelf, or rack mounted (1u) with the included mounting brackets. The Dray Tek Vigor Switch P2121 has 4 Gigabit SFP module ports which can be used instead of the corresponding RJ-45 ports Nos. 9-12. SFP slots are typically used for fibre transceivers. In comparison to copper (RJ-45) cables, using fibre for connectivity provides longer range & resilience from electrical interference. The SFP ports provides compatibility with your choice of SFP modules (not included) & therefore the most appropriate medium for your application. If you use the SFP slots, then the corresponding copper port is not active but the others remain available. The Vigor Switch P2121s Serial (RS232) Console port & SSH server allow for full configuration & management of the Vigor Switch through its command line interface (CLI). ...
