“ Free AMD Radeon Rewards download coupon Silver from 30th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” Asus R7 260 1GB GDDR5 DVI HDMI Display Port PCI-E Graphics Card Dual fans increase thermal efficiency with 2X better cooling & 3X lower noise emissions. Premium alloys in power delivery components defeat heat for cards that run 15% faster & last 2.5 times longer than reference. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. GPU Tweak Streaming tool means that you can share on-screen action in real-time. Add scrolling text, pictures, & webcam images to the streaming window easily. Graphics Engine
- AMD Radeon R7 260 Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 1GB Engine Clock
- 1000 MHz Memory Clock
- 6000 MHz (1500 MHz GDDR5 ) Memory Interface
- 128-bit Resolution
- DVI Max Resolution: 2560x 1600 Interface DVI Output: Yes x 1 (DVI-I) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Power Consumption
- up to 150W1 additional 6 pin PCIe power required Accessories 1 x Cross Fire cable 1 x DVI to D-Sub adaptor Software
- ASUS GPU Tweak & Driver ASUS Features
- Super Alloy Power

Dimensions 8.7 " x 4.4 " x 1.6 " Inch 22.09 x 11.17 x 4.06 Centimeter











...

Asus Radeon R7 260X 1GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Graphics Engine AMD Radeon R7 260X Bus Standard PCI Express 3.0 Video Memory GDDR5 1024MB Engine Clock 1075 MHz Memory Clock 6400 MHz (1600 MHz GDDR5 ) Memory Interface 128-bit Resolution DVI Max Resolution: 2560x 1600 Digital Max Resolution:4096x 2160 Interface DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Software ASUS GPU Tweak & Driver ASUS Features Direct CU Series OC Series Super Alloy Power

Dimensions 8.5 " x 5.1 " x 1.5 " Inch 21.59 x 12.954 x 3.81 Centimeter

...

Perfect balance of 28nm power with cool & quiet performance Direct CU II achieves 20% lower temps with twice the dissipation area & 6X greater airflow then reference design. OC-selected 1188 MHz core, 88 M Hz higher than reference for smoother gaming. DIGI+ VRM with 6-phase Super Alloy Power delivers precise digital power for superior efficiency, reliability, & performance. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. Specifications Graphics Engine
- AMD Radeon R7 260X Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 2GB Engine Clock
- 1188 MHz Memory Clock
- 7000 MHz (1750 MHz GDDR5) Memory Interface
- 128-bit Resolution
- DVI Max Resolution: 2560x 1600 Interface DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes ASUS Features Direct CU Series OC Series Super Alloy Power

Dimensions 8.5 " x 5.1 " x 1.5 " Inch








...

Asus R9 270 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Exclusive Direct CU II cooling technology delivers 20%-cooler & 3X-quieter operation & Super Alloy Power components provide 2.5X-longer lifespan The ASUS R9 270 Direct CU II is a new graphics card powered by the latest AMD Radeon™ R9 270 graphics-processing unit (GPU). R9 270 is equipped with loads of exclusive ASUS technologies & tools including Direct CU II for 20%-cooler & three-times (3X) quieter gaming performance, Super Alloy Power components for vastly enhanced longevity & GPU Tweak, an easy-to-use software tool that allows users to squeeze more performance out of the GPU. As an ASUS overclocked-edition card, R9 270 is overclocked to perform faster than reference — notching up a remarkable a 975 M Hz core speed & reaching the 104% level in 3 D Mark. SPECIFICATIONS: R9 270-DC2OC-2GD5 AMD Radeon R9 270 PCI Express 3.0 2048MB GDDR5 memory 975 M Hz core speed 1280 stream processors 5600 M Hz (1400 M Hz GDDR5) memory clock DVI-/DVI-D output HDMI output Display Port output ...

Asus R9 270X 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Asus Exclusive Innovations 20% cooler & vastly quieter preformance with exclusive Direct CU II thermal solution. Top-selected 1120 Mhz core performance 70mhz higher than reference for smoother gamplay. DIGI+VRM with Super Alloy Power Graphics Engine AMD Radeon R9 270X Bus standard PCI Express 3.0 Open GL
- Open GL 4.3 Video Memory
- 2048MB GDDR5 GPU Clock 1120 MHz Steam Processor 1280 Memory clock 5600 MHz (1400 MHz GDDR5) Memory Interface 256 bit DVI Max. Resolution 2560*1600 DVI Output 1x Native DVI-I 1x Native Dvi-D HDMI Output 1x Native HDMI HDCP Compliant Yes Display Port 1x Native Display Port Adapter/ Cable Bundled 1x Crossfire Cable 1x DVI to D-Sub Software Bundled Asus GPU Tweak & Driver Dimension The card size is 10.7 x 5.24 x 1.578 inches

...

Asus AMD Radeon R9 270X 2GB GDDR5 VGA DVI HDMI Display Port PCI-E Graphics Card Graphics Engine AMD Radeon R9 270X Bus Standard PCI Express 3.0 Video Memory GDDR5 2GB Engine Clock GPU Boost Clock: 1120 MHz GPU Base Clock: 1050 MHz Memory Clock 5600 MHz (1400 MHz GDDR5 ) Memory Interface 256-bit Resolution D-Sub Max Resolution: 2048x 1536 DVI Max Resolution: 2560x 1600 Interface D-Sub Output: Yes x 1 (via DVI to D-Sub adaptor x 1) DVI Output: Yes x 2 HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Software ASUS Utilities & Driver ASUS Features Direct CU Series TOP Series Super Alloy Power

Dimensions 10.7 " x 5.24 " x 1.578 " Inch

...

Asus R9 280 Direct CU II 3GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Graphics Engine
- AMD Radeon R9 280 Bus Standard
-

...

“ Free AMD Radeon Rewards download coupon GOLD from 28th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” ASUS R9 280X Direct CU II 3GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics card Direct CU II achieves 20% lower temps with direct-contact copper heatpipes, plus 3X quieter & 6X more powerful twin 100mm fan operation. Exclusive Cool Tech Fan drives wider airflow to keep critical components cool. TOP-selected 1070 M Hz cores run 70 M Hz higher than reference for smoother gameplay. DIGI+ VRM with 12-phase Super Alloy Power delivers precise digital power for superior efficiency, reliability, & performance. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. Graphics Engine
- AMD Radeon R9 280X Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 3GB Engine Clock
- 1070 MHz Memory Clock
- 6400 MHz (1600 MHz GDDR5 ) Memory Interface
- 384-bit Resolution
- DVI Max Resolution: 2560x 1600 Interface DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Accessories 1 x Cross Fire cable 1 x DVI to D-Sub adaptor 1 x Power cable Software
- ASUS GPU Tweak & Driver

Dimensions
- 11.2 " x 5.7 " x 1.5 " Inch










...

“ Free AMD Radeon Rewards download coupon GOLD from 28th May 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” Direct CU II achieves 20% lower temps with direct-contact copper heatpipes, plus 3X quieter & 6X more powerful twin 100mm fan operation. Exclusive Cool Tech Fan drives wider airflow to keep critical components cool. DIGI+ VRM with 12-phase Super Alloy Power delivers precise digital power for superior efficiency, reliability, & performance. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. Specifications Graphics Engine
- AMD Radeon R9 280X Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 3GB Engine Clock
- GPU Boost Clock: 1000 MHz, GPU Base Clock: 850 MHz Memory Clock
- 6000 MHz (1500 MHz GDDR5 ) Memory Interface
- 384-bit Resolution
- DVI Max Resolution: 2560x 1600 Interface
- DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D), HDMI Output: Yes x 1, Display Port: Yes x 1 (Regular DP) Power Consumption
- up to 300W additional 6+8 pin PCIe power required

Dimensions
- 11.2 " x 5.7 " x 1.5 " Inch











...

ASUS Radeon R9 280X Direct CU II gives new edge to hardcore gamers Direct CU II achieves 20% lower temps with direct-contact copper heatpipes, plus 3X quieter & 6X more powerful twin 100mm fan operation Exclusive Cool Tech Fan drives wider airflow to keep critical components cool TOP-selected 1070 M Hz cores run 70 M Hz higher than reference for smoother gameplay DIGI+ VRM with 12-phase Super Alloy Power delivers precise digital power for superior efficiency, reliability, & performance GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface Graphics Engine
- AMD Radeon R9 280X Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 3GB Engine Clock
- GPU Boost Clock: 1070 MHz, GPU Base Clock: 970 MHz Memory Clock
- 6400 MHz (1600 MHz GDDR5 ) Memory Interface
- 384-bit Resolution
- DVI Max Resolution: 2560x 1600 Interface DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Power Consumption up to 300 Wadditional 6+8 pin PCIe power required ASUS Features Direct CU Series TOP Series Super Alloy Power

Dimensions 11.2 " x 5.7 " x 1.5 " Inch Note Specifications are subject to change without notice PCB color & bundled software versions are change without notice Brand & product names mentioned are trademarks of their respective company UEFI BIOS support








...
