Asus R7 240 2GB DDR3 VGA DVI HDMI PCI-E Graphics Card Graphics Engine AMD Radeon R7 240 Bus Standard PCI Express 3.0 Video Memory DDR3 2GB Engine Clock GPU Boost Clock: 780 MHz GPU Base Clock: 730 MHz Memory Clock 900 MHz (1800 MHz DDR3 ) Memory Interface 128-bit Resolution DVI Max Resolution: 1920x 1200 Interface D-Sub Output: Yes x 1 DVI Output: Yes x 1 (DVI-D) HDMI Output: Yes x 1 HDCP Support: Yes Power Consumption up to 75 Wno additional PCIe power required Software ASUS GPU Tweak & Driver ASUS Features Super Alloy Power

Dimensions 15.9 x 11.1 x 2 Centimeter

...

Asus Radeon R7 240 4GB DDR3 VGA DVI HDMI PCI-E Graphics Card Graphics Engine AMD Radeon R7 240 Bus Standard PCI Express 3.0 Video Memory DDR3 4GB Engine Clock GPU Boost Clock: 820 MHz GPU Base Clock: 770 MHz Memory Clock 900 MHz (1800 MHz DDR3 ) Memory Interface 128-bit Resolution DVI Max Resolution: 1920x 1200 Interface D-Sub Output: Yes x 1 DVI Output: Yes x 1 (DVI-D) HDMI Output: Yes x 1 HDCP Support: Yes Power Consumption up to 75 Wno additional PCIe power required Software ASUS GPU Tweak & Driver

Dimensions 6.26 " x 4.37 " x 0.79 " Inch 15.9 x 11.1 x 2 Centimeter

...

Raging Cool For the Win! Super Alloy Power durability & cooling Exclusively-formulated alloy components boost performance by reducing power loss, enhancing durability, & achieving cooler operation. Choke concrete cores eliminate buzzing sound under full load while capacitors assure a 50, 000-hour lifespan: equivalent to 2.5 times longer than traditional capacitors. Dust-Proof Fan 25% longer graphics card lifespan Unique fan design dissipates heat efficiently while extending a graphic card's lifespan by 25% through increased dust & particle resistance. GPU tweak Real-time intuitive graphics tuning Shows detailed specs & actual card status with GPU-Z Sync GPU clocks & voltages for easier overclocking Monitoring widget provides real-time detailed multi-parameter info 2D/3D switcher locks cards in 3D mode for higher benchmarks Automatically checks & updates drivers & BIOS versions Stream on-screen action to the web in full HD, with just a click Set your own headline for the streaming window 1GB GDDR5 Memory On-board memory for the best gaming experience & the best resolution Raging Cool For the Win! by AMD Radeon R7 250 AMD App Acceleration Speeds up daily applications such as web browsing & video playback. Also the first to provide support for both Open CL, C++ AMP, & Direct Compute 11. AMD Power Tune technology Intelligent power monitoring in the AMD Radeon graphics to enable higher clock better performance in your favorite games. AMD Zero Core Power technology Allows your AMD Radeon graphic to consume virtually no power when in idle state. It even shuts down additional GPUs in AMD Cross Fire. technology mode to consume less when they are not in use. Microsoft Direct X 11.2 API Brings new levels of visual realism to gaming on the PC & get top-notch performance. Microsoft R Windows 8.1 compatible Gives you access to advanced computing experiences with the latest operating system so you get more done with your PC I/O Ports Highlight 1 X Single-link DVI-D 1 X Native HDMI 1 X Native VGA Graphics Engine AMD Radeon R7 250 Bus Standard PCI Express 3.0 Video Memory GDDR5 1024MB Engine Clock 1000 MHz Memory Clock 1150 MHz (4600 MHz GDDR5 ) Memory Interface 128-bit Resolution DVI Max Resolution: 1920x 1200 Interface DVI Output: Yes x 1 (DVI-D) HDMI Output: Yes x 1 HDCP Support: Yes Software ASUS GPU Tweak & Driver

Dimensions 16 x 11.1 x 3.4 Centimeter Ports 4 x RJ45 for 10/100/1000/ Gigabits Base T for LAN, 1 x RJ45 for 10/100/1000/ Gigabits Base T for WAN USB (Universal Serial Bus) 2.0 x 1 USB (Universal Serial Bus) 3.0 x 1 Button WPS Button, Reset Button, Power Button, Wireless on/off Button Note Specifications are subject to change without notice. PCB color & bundled software versions are change without notice. Brand & product names mentioned are trademarks of their respective company.

...

ASUS Radeon R7 250X 1GB GDDR5 DVI HDMI Display Port PCI-E Graphics card Dust-proof Fan design increases particle resistance & extends card lifespan by up to 25% longer than reference. DIGI+ VRM with Super Alloy Power delivers precise digital power for superior efficiency, reliability, & performance. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. GPU Tweak Streaming let you share on-screen action in real time “ so others can watch live as games are played. Graphics Engine AMD Radeon R7 250X Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 1GB Engine Clock
- 1000 MHz Memory Clock
- 4500 MHz (1125 MHz GDDR5 ) RAMDAC
- 400 MHz Memory Interface
- 128-bit Resolution D-Sub Max Resolution: 2048x 1536 DVI Max Resolution: 2560x 1600 Interface D-Sub Output: Yes x 1 (via DVI to D-Sub adaptor x 1) DVI Output: Yes x 1 (DVI-I) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Power Consumption up to 150W1 additional 6 pin PCIe power required Accessories 1 x DVI to D-Sub adaptor 1 x Cross Fire cable Software
- ASUS GPU Tweak & Driver ASUS Features
- Super Alloy Power

Dimensions 7.5 " x 5.3 " x 1.5 " Inch 19.05 x 13.462 x 3.81 Centimeter









...

Asus Radeon R7 250X 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics card Dual fan design provides 2X greater air flow & 3X quieter performance. Acclaimed DIGI+ VRM with Super Alloy Power technology delivers precise digital power & enhanced durability for stable overclocking GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface GPU Tweak Streaming let you share on-screen action in real time “ so others can watch live as games are played Graphics Engine: AMD Radeon R7 250X Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 2GB Engine Clock
- 1020 MHz Memory Clock
- 4600 MHz (1150 MHz GDDR5 ) RAMDAC
- 400 MHz Memory Interface
- 128-bit Resolution D-Sub Max Resolution: 2048x 1536 DVI Max Resolution: 2560x 1600 Interface D-Sub Output: Yes x 1 (via DVI to D-Sub adaptor x 1) DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Accessories 1 x DVI to D-Sub adaptor 1 x Cross Fire cable Power Consumption
- up to 150W1 additional 6 pin PCIe power required Software
- ASUS GPU Tweak & Driver ASUS Features
- Super Alloy Power

Dimensions 8.3 " x 4.4 " x 1.4 " Inch 21.08 x 11.17 x 3.55 Centimeter










...

Asus Radeon R7 260X 1GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Graphics Engine AMD Radeon R7 260X Bus Standard PCI Express 3.0 Video Memory GDDR5 1024MB Engine Clock 1075 MHz Memory Clock 6400 MHz (1600 MHz GDDR5 ) Memory Interface 128-bit Resolution DVI Max Resolution: 2560x 1600 Digital Max Resolution:4096x 2160 Interface DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Software ASUS GPU Tweak & Driver ASUS Features Direct CU Series OC Series Super Alloy Power

Dimensions 8.5 " x 5.1 " x 1.5 " Inch 21.59 x 12.954 x 3.81 Centimeter

...

Perfect balance of 28nm power with cool & quiet performance Direct CU II achieves 20% lower temps with twice the dissipation area & 6X greater airflow then reference design. OC-selected 1188 MHz core, 88 M Hz higher than reference for smoother gaming. DIGI+ VRM with 6-phase Super Alloy Power delivers precise digital power for superior efficiency, reliability, & performance. GPU Tweak helps you modify clock speeds, voltages, fan performance & more, all via an intuitive interface. Specifications Graphics Engine
- AMD Radeon R7 260X Bus Standard
- PCI Express 3.0 Video Memory
- GDDR5 2GB Engine Clock
- 1188 MHz Memory Clock
- 7000 MHz (1750 MHz GDDR5) Memory Interface
- 128-bit Resolution
- DVI Max Resolution: 2560x 1600 Interface DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes ASUS Features Direct CU Series OC Series Super Alloy Power

Dimensions 8.5 " x 5.1 " x 1.5 " Inch








...

Asus R9 270 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Exclusive Direct CU II cooling technology delivers 20%-cooler & 3X-quieter operation & Super Alloy Power components provide 2.5X-longer lifespan The ASUS R9 270 Direct CU II is a new graphics card powered by the latest AMD Radeon™ R9 270 graphics-processing unit (GPU). R9 270 is equipped with loads of exclusive ASUS technologies & tools including Direct CU II for 20%-cooler & three-times (3X) quieter gaming performance, Super Alloy Power components for vastly enhanced longevity & GPU Tweak, an easy-to-use software tool that allows users to squeeze more performance out of the GPU. As an ASUS overclocked-edition card, R9 270 is overclocked to perform faster than reference — notching up a remarkable a 975 M Hz core speed & reaching the 104% level in 3 D Mark. SPECIFICATIONS: R9 270-DC2OC-2GD5 AMD Radeon R9 270 PCI Express 3.0 2048MB GDDR5 memory 975 M Hz core speed 1280 stream processors 5600 M Hz (1400 M Hz GDDR5) memory clock DVI-/DVI-D output HDMI output Display Port output ...

Asus R9 270X 2GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Asus Exclusive Innovations 20% cooler & vastly quieter preformance with exclusive Direct CU II thermal solution. Top-selected 1120 Mhz core performance 70mhz higher than reference for smoother gamplay. DIGI+VRM with Super Alloy Power Graphics Engine AMD Radeon R9 270X Bus standard PCI Express 3.0 Open GL
- Open GL 4.3 Video Memory
- 2048MB GDDR5 GPU Clock 1120 MHz Steam Processor 1280 Memory clock 5600 MHz (1400 MHz GDDR5) Memory Interface 256 bit DVI Max. Resolution 2560*1600 DVI Output 1x Native DVI-I 1x Native Dvi-D HDMI Output 1x Native HDMI HDCP Compliant Yes Display Port 1x Native Display Port Adapter/ Cable Bundled 1x Crossfire Cable 1x DVI to D-Sub Software Bundled Asus GPU Tweak & Driver Dimension The card size is 10.7 x 5.24 x 1.578 inches

...

Asus R9 270X Direct CU II 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card Graphics Engine AMD Radeon R9 270X Bus Standard PCI Express 3.0 Video Memory GDDR5 4GB Engine Clock 1120 MHz Memory Clock 5600 MHz (1400 MHz GDDR5 ) Memory Interface 256-bit Resolution DVI Max Resolution: 2560x 1600 Interface DVI Output: Yes x 1 (DVI-I), Yes x 1 (DVI-D) HDMI Output: Yes x 1 Display Port: Yes x 1 (Regular DP) HDCP Support: Yes Power Consumption up to 225W2 additional 6 pin PCIe power required Software ASUS GPU Tweak & Driver ASUS Features Direct CU Series TOP Series Super Alloy Power

Dimensions 10.7 " x 5.24 " x 1.578 " Inch 27.17 x 13.3 x 4 Centimeter

...
