Supports 10th Gen Intel Core™ Processors (Socket 1200). 7 Power Phase Design. Supports DDR4 2933 MHz. 1 PCIe 3.0 x 16, 1 PCIe 3.0 x 1. Graphics Output Options: HDMI. 7.1 CH HD Audio (Realtek ALC887 Audio Codec). 4 SATA3, 1 Ultra M.2 (PCIe Gen 3 x 4 & SATA3). 4 USB (Universal Serial Bus) 3.2 Gen 1 (2 Front, 2 Rear). Intel Gigabit LAN. Intel 802.11ac Wi Fi + BT 4.2. 7 Power Phase Design Featuring sturdy components & completely smooth power delivery to the CPU. Plus, it enhanced performance with the lowest temperature for advanced gamers. Premium 50A Power Choke Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced & enhanced Vcore voltage to the motherboard. Dual Band 802.11ac Wi Fi No one has time for weak Wi Fi signals & sluggish internet! Thats why this motherboard comes with a 802.11ac Wi Fi (2.4G / 5G Wi Fi) module which supports wireless networks & Bluetooth v 4.2. Intel LAN Intel LAN provides the best throughput performance, lower CPU utilisation, enhanced stability & is able to deliver ultimate network experience to users! Ultra M.2 32 Gb/s (PCIe Gen 3 x 4 & SATA3) The PCIe Gen 3 x 4 Ultra M.2 interface pushes data transfer speeds up to 32 Gb/s. In addition, it also supports SATA3 6 Gb/s M.2 modules, & is compatible with ASRock’s U.2 Kit for installing some of the world’s fastest U.2 PCIe Gen 3 x 4 SSDs. Water Pump Header This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 2A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise. ...

Features Supports 10th Gen Intel Core Processors & 11th Gen Intel Core Processors. Supports DDR4 3200 M Hz (OC). 1x PCIe 4.0 x 16, 1x PCIe 3.0 x 1. Graphics Output Options: HDMI, D-Sub. 7.1 CH HD Audio (Realtek ALC897 Audio Codec). 4x SATA3 ports. 4x USB (Universal Serial Bus) 3.2 Gen 1 (2x Rear, 2x Front). Realtek Gigabit LAN. PCIe 4.0 Technology H510 platform is able to support PCIe 4.0 technology that delivers higher performance, bandwidth & speed. DUAL Graphics Outputs Packed with a HDMI & D-Sub combo to support the most used connectors. Plus, HDMI port supports 4K resolution. 4K x 2K @60 Hz Supports the most recent HDMI 4K 60 Hz graphics output

Specification. With the larger bandwidth & increased frame rate, the motion on your screen becomes more fluid & less blurry. USB (Universal Serial Bus) 3.2 Gen 1 Ports Packed with luxurious USB (Universal Serial Bus) 3.2 Gen 1 ports to give ultimate expansion capability for high speed devices.

...

Everything You Need For Computing Introducing the ASRock Intel Z490 PRO4 ATX motherboard, which supports 10th Gen & future generation Intel Core™ Processors & AMD Quad Cross Fire X™ & Cross Fire X™. The Z490 PRO4 boasts rapid transfer speed with Dual Ultra M.2 sockets which supports PCIe M.2 SSDs. Improve your networking capabilities with Intel LAN, users can choose wireless connections by an M.2 (Key E) slot. The I/O offers Dual USB (Universal Serial Bus) 3.2 Gen 2 & various connectivity ports for super speedy transfer rates. ASRock Boost Frequency Boost Technology, allows users to install their non K series CPUs to ASRock’s 400 series motherboards (even non Z models) & enjoy the base frequency boost with the hidden power of processors immediately. Enjoy stunning customization with Polychrome RGB Sync lighting, plus incredible Nahimic 3D audio has been optimized to satisfy gamers, movie goers, or anyone who is looking for an outstanding sound experience in high definition. RULE YOUR OWN LIGHTING WAY WITH POLYCHROME RGB SYNC ASRock Intel Z490 PRO4 provides an outstanding performance & superior aesthetics that let you rule your own way, utilizing the comprehensive control to perform the built-in RGB LEDs or the connected LED strips, CPU fans, coolers, chassis & any RGB devices smoothly.

Includes:: two Addressable RGB LED Headers & two RGB LED Headers. Devices can be synchronized across the Polychrome RGB Sync-certified accessories as well. ASRock Z490 PRO4 features Gigabit Intel LAN which provides the best throughput performance, lower CPU utilization, enhanced stability & is able to deliver ultimate network experience to users. This motherboard has Dual onboard Type-A & Type-C USB (Universal Serial Bus) 3.2 Gen 2 ports, built on the rear I/O for supporting next generation USB (Universal Serial Bus) 3.2 Gen 2 devices & to deliver up to 10 Gbps data transfer rates. In total six USB (Universal Serial Bus) 3.2 Gen 1, 4 on the front, 2 on the rear side. Whether you are using headphones, a headset, external or internal speakers, via USB (Universal Serial Bus), Wi-Fi, analog output or even HDMI, Nahimic Audio offers you the most engaging listening experience, vibrant & rich with details. The Z490 Series motherboard offers completely immersive audio & with gold audio jacks you get stable sound transmission. Heat Dissipating PCB gives the motherboard a more mysterious touch & this design effectively takes the heat away from PCB & lower down the temperature up to 4.1 degrees. Ready for higher capacity & even faster Type 22110 M.2 NVMe SSD to fulfill the need of performance. Two Ultra M.2 sockets that support both SATA3 6 Gb/s & PCIe Gen 3 x 4 modes, pushing data transfer speeds up to 32 Gb/s. ASRock provides an M.2 armor solution that makes SSDs run in a certain low temperature Heat Dissipating PCB gives the motherboard a more mysterious touch & this design effectively takes the heat away from PCB & lower down the temperature up to 4.1 degrees.

...

TOUGH AS STEEL, TRUE TO LEGEND Introducing the ASRock Intel Z490 Steel Legend ATX motherboard, which supports 10th Gen & future generation Intel Core™ Processors. The Z490 Steel Legend boasts rapid transfer speed with Dual Ultra M.2 sockets which supports PCIe M.2 SSDs while the full coverage heatsink ensures the SSDs are working at their best. Improve your networking capabilities with LAN up to 2.5X the bandwidth & besides the onboard LAN port, users can choose wireless connections by an M.2 (Key E) slot. The flexible I/O shield features Dual USB (Universal Serial Bus) 3.2 Gen 2 & various connectivity ports & if you look on the Z490 Steel Legend ATX motherboard youll find a Front USB (Universal Serial Bus) Type-C header which is a reversible USB (Universal Serial Bus) design. Whoever said that only K series CPUs & the Z-family platform are capable of being performed with maximum power? Via ASRock BFB (Boost Frequency Boost) Technology, users may install their non K series CPUs to ASRock’s 400 series motherboards (even non Z models) & enjoy the base frequency boost with the hidden power of processors immediately. Enjoy stunning customization with Polychrome RGB Sync lighting, plus incredible Nahimic 3D audio has been optimized to satisfy gamers, movie goers, or anyone who is looking for an outstanding sound experience in high definition. RULE YOUR OWN LIGHTING WAY WITH POLYCHROME RGB SYNC ASRock Z490 Steel Legend provides an outstanding performance & superior aesthetics that let you rule your own way, utilizing the comprehensive control to perform the built-in RGB LEDs or the connected LED strips, CPU fans, coolers, chassis & any RGB devices smoothly.

Includes:: two Addressable RGB LED Headers & two RGB LED Headers. Devices can be synchronized across the Polychrome RGB Sync-certified accessories as well. Featuring the flexible integrated I/O shield that reserves tolerance for fitting perfectly without fuss. Boost your networking performance for the demanding requirements of home networking, content creators, online gamers & high-quality streaming media with intelligent 2.5 Gb/s LAN up to 2.5X than standard Gigabit LAN. This motherboard has a pair of onboard Type-A & Type-C USB (Universal Serial Bus) 3.2 Gen 2 ports built on the rear I/O for supporting next generation USB (Universal Serial Bus) 3.2 Gen 2 devices & to deliver up to 10 Gbps data transfer rates. in addition, a Front USB (Universal Serial Bus) 3.2 Gen 1 Type-C header delivers up to 5 Gbps data transfer rate & next generation reversible USB (Universal Serial Bus) design to the front panel of computer case. Whether you are using headphones, a headset, external or internal speakers, via USB (Universal Serial Bus), Wi-Fi, analog output or even HDMI, Nahimic Audio offers you the most engaging listening experience, vibrant & rich with details. The Z490 Series motherboard offers completely immersive audio & which gold audio jacks this provides stable sound transmission. Ready for higher capacity & even faster Type 22110 M.2 NVMe SSD to fulfill the need of performance. Two Ultra M.2 sockets that support both SATA3 6 Gb/s & PCIe Gen 3 x 4 modes, pushing data transfer speeds up to 32 Gb/s. ASRock provides an M.2 armor solution that makes SSDs run in a certain low temperature Heat Dissipating PCB gives the motherboard a more mysterious touch & this design effectively takes the heat away from PCB & lower down the temperature up to 4.1 degrees. 2 ounce copper inner layers that provide stable signal traces & power shapes! Delivering lower temperature & higher energy efficiency for overclocking, its able to support the latest DDR4 memory modules with most extreme memory performance.

...

IT’S TIME FOR EXTREME, PROFESSIONAL PERFORMANCE. The ASRock Intel Z490M PRO4 is a Micro ATX motherboard, which supports 10th Gen & future generation Intel Core™ Processors & supports AMD Quad Cross Fire X™ & Cross Fire X™. The Z490M PRO4 boasts rapid transfer speed with Dual Ultra M.2 sockets which supports PCIe M.2 SSDs. Improve your networking capabilities with Intel LAN, users can choose wireless connections by an M.2 (Key E) slot. The I/O offers Dual USB (Universal Serial Bus) 3.2 Gen 2 & various connectivity ports for super speedy transfer rates. Enjoy stunning customization with Polychrome RGB Sync lighting, plus incredible Nahimic 3D audio has been optimized to satisfy gamers, movie goers, or anyone who is looking for an outstanding sound experience in high definition. ASRock Boost Frequency Boost Technology, allows users to install their non K series CPUs to ASRock’s 400 series motherboards (even non Z models) & enjoy the base frequency boost with the hidden power of processors immediately. RULE YOUR OWN LIGHTING WAY WITH POLYCHROME RGB SYNC ASRock Intel Z490M PRO4 provides an outstanding performance & superior aesthetics that let you rule your own way, utilizing the comprehensive control to perform the built-in RGB LEDs or the connected LED strips, CPU fans, coolers, chassis & any RGB devices smoothly.

Includes:: two Addressable RGB LED Headers & two RGB LED Headers. Devices can be synchronized across the Polychrome RGB Sync-certified accessories as well. ASRock Z490M PRO4 features Gigabit Intel LAN which provides the best throughput performance, lower CPU utilization, enhanced stability & is able to deliver ultimate network experience to users. This motherboard has Dual onboard Type-A & Type-C USB (Universal Serial Bus) 3.2 Gen 2 ports, built on the rear I/O for supporting next generation USB (Universal Serial Bus) 3.2 Gen 2 devices & to deliver up to 10 Gbps data transfer rates. In total eight (USB 3.2 Gen 1 4 on the front), 2 on the rear side. NAHIMIC AUDIO TAKES YOU TO ANOTHER DIMENSION Whether you are using headphones, a headset, external or internal speakers, via USB (Universal Serial Bus), Wi-Fi, analog output or even HDMI, Nahimic Audio offers you the most engaging listening experience, vibrant & rich with details. The Z490M Series motherboard offers completely immersive audio & with gold audio jacks you get stable sound transmission. Ready for higher capacity & even faster Type 22110 M.2 NVMe SSD to fulfill the need of performance. Two Ultra M.2 sockets that support both SATA3 6 Gb/s & PCIe Gen 3 x 4 modes, pushing data transfer speeds up to 32 Gb/s, & is compatible with ASRock’s U.2 Kit for installing some of the world’s fastest U.2 PCIe Gen 3 x 4 SSD Heat Dissipating PCB gives the motherboard a more mysterious touch & this design effectively takes the heat away from PCB & lower down the temperature up to 4.1 degrees.

...

Features Supports 10th Gen Intel Core™ Processors & 11th Gen Intel Core™ Processors 12 Phase Dr.MOS Power Design Supports DDR4 4800 M Hz (OC) 1 x PCIe 4.0 x 16, 1 x PCIe 3.0 x 16, 2 x PCIe 3.0 x 1 1 x M.2 Key-E for Wi Fi Graphics Output Options: HDMI, Display Port 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio 4 SATA3, 1 x Hyper M.2 (PCIe Gen 4 x 4 & SATA3) 1 x Ultra M.2 (PCIe Gen 3 x 4 & SATA3) 2 x Rear USB (Universal Serial Bus) 3.2 Gen 2 (10 Gb/s) Dr. MOS Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Compared to traditional discrete MOSFETs, it intelligently delivers higher current for each phase, thus providing enhanced thermal result & superior performance. Premium 50A Power Choke Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced & enhanced Vcore voltage to the motherboard. Clever Access Memory Conventional PC systems processor can only access a fraction of graphics memory & limits system performance. With Clever Access Memory, the data channel gets expanded to harness the full potential of GPU memory, removes the bottleneck & increase performance. PCIe 4.0 High Speed M.2 Solution This motherboard is capable of accomadating multiple M.2 storage devices, one of which can even support next generation PCI Express 4.0 M.2 SSD, it is capable of performing twice the speed compared to previous 3rd generation, giving a lightning fast data transferring experience. 6 Layer PCB The 6 Layer PCB comes with 3 sets of copper inner layers, providing stable signal traces & power shapes delivering lower temperature & higher energy efficiency for memory overclocking! Thus, its able to support the latest DDR4 memory modules with most extreme memory performance! ...

Features ASRock Super Alloy Intel Quad-Core Processor J3455 (up to 2.3 GHz) Supports DDR3/DDR3L 1866 SO-DIMM 1 PCIe 2.0 x 16 (x 2 mode) Graphics Output Options: D-Sub, HDMI 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 2 SATA3 5 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 3 Rear) Supports Full Spike Protection, ASRock Live Update & APP Shop Overview D-Sub, HDMI, Parallel, COM Packed with a COM port + Printer port + D-Sub + HDMI combo. Plus the HDMI port supports Full HD 1080p Blu-ray (BD) playback. HEVC 10-bit Decoding Supports HEVC 10-bit decoding to provide substantially enhanced video quality & higher bit depth video experience. The 10-bit content supports up to 1.07 billion color palette, it can have more detail of image, & greater range between the brightest & darkest part of the image Intel Quad-Core Processor J3455 (Up to 2.3 GHz) enhanced performance, lower power consumption, & new multimedia capabilities. Supports Standard & Low Voltage SO-DIMMs Capable of supporting both standard & low-voltage SO-DIMMs.

Specification Unique Feature ASRock Super Alloy
- High Density Glass Fabric PCB ASRock Full Spike Protection ASRock Live Update & APP Shop CPU
- Intel Quad-Core Processor J3455 (up to 2.3 GHz) Memory
- Dual Channel DDR3/DDR3L Memory Technology
- 2 x DDR3/DDR3L SO-DIMM Slots*
- Supports DDR3/DDR3L 1866/1600/1333 non-ECC, un-buffered memory
- Max. capacity of system memory: 16GB** *2GB DRAM per module is not supported. ** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 64 Mb AMI UEFI Legal BIOS with GUI support
- Supports Plug & Play
- ACPI 5.0 compliant wake up events
- Supports jumperfree
- SMBIOS 3.0 support Audio, Video & Networking Graphics
- Integrated Intel HD Graphics 500: 12 EUs inside (Up to 750 M Hz)
- Direct X 12, Pixel Shader 5.0
- Dual graphics output: support D-Sub & HDMI ports by independent display controllers
- Supports HDMI with max. resolution up to 4K x 2K (3840x 2160) @ 30 Hz or 2560x 1600 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HW Accelerated Decoders: H.264 @ level 5.2, HEVC (H.265) 10b @MP level 5.1 (GPU accelerated), JPEG, VP8, VP9
- Supports HDCP with HDMI Port
- Supports Full HD 1080p Blu-ray (BD) playback with HDMI Port Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection (ASRock Full Spike Protection)
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111GR
- Supports Wake-On-WAN
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection (ASRock Full Spike Protection)
- Supports LAN Cable Detection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Expansion / Connectivity Slots
- 1 x PCI Express 2.0 x 16 Slot (PCIE1: x 2 mode) Storage
- 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug Connector
- 1 x COM Port Header
- 1 x Chassis Intrusion Header
- 1 x TPM Header
- 1 x CPU Fan Connector (3-pin)
- 1 x Chassis Fan Connector (3-pin)
- 1 x 24 pin ATX Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection (ASRock Full Spike Protection))* *USB3_1_2 is shared with USB2_3. Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Parallel Port (ECP/EPP Support)
- 1 x Serial Port: COM1
- 1 x D-Sub Port
- 1 x HDMI Port
- 1 x USB (Universal Serial Bus) 2.0 Port (Supports ESD Protection (ASRock Full Spike Protection))
- 3 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Other Features / Miscellaneous Software & BIOS Software
- ASRock Power Gear
- ASRock XFast LAN* UEFI
- ASRock Power Gear
- ASRock Instant Flash
- ASRock Internet Flash
- ASRock Crashless BIOS * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables Hardware Monitor
- CPU/ Chassis temperature sensing
- CPU/ Chassis Fan Tachometer
- CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
- CPU/ Chassis Fan multi-speed control
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor
- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit*
- Linux: Ubuntu 16.10 / Fedora 25 * For the updated Windows 10 driver, please visit ASRocks website for details. Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required) Caution: Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS or using the third-party overclocking tools. Overclocking may affect your system stability, or even cause damage to the components & devices of your system. It should be done at your own risk & expense. We are not responsible for possible damage caused by overclocking.









































































...

Features ASRock Super Alloy Intel Quad-Core Processor J4105 (up to 2.5 GHz) Supports DDR4 2133/2400 SO-DIMM 1 PCIe 2.0 x 1, 1 M.2 (Key E) Graphics Output Options: D-Sub, HDMI, DVI-D 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps 4 SATA3 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Supports Full Spike Protection, ASRock Live Update & APP Shop

Specification Unique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Intel Quad-Core Processor J4105 (up to 2.5 GHz) Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 SO-DIMM Slots*
- Supports DDR4 2400/2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB** *2GB DRAM per module is not supported. ** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with GUI support
- Supports Plug & Play
- ACPI 5.0 compliant wake up events
- Supports jumperfree
- SMBIOS 3.0 support Graphics
- Integrated Intel UHD Graphics 600: 12 EUs inside (Up to 750 M Hz)
- DX12, Open GL 4.3, OGL ES 3.0, Open CL 2.0
- HW Acceleration Decode: HEVC (H.265) 8 bit, HEVC (H.265)10 bit, H.264 @ Lvl 5.2 (AVC), JPEG/MJPEG, VP8, VP9 8bit, VP9 10 bit
- HW Acceleration Encode: HEVC (H.265) 8 bit, HEVC (H.265)10 bit, H.264 @ Lvl 5.2 (AVC), JPEG/MJPEG, VP8, VP9 8bit
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 60 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 2048x 1536 @ 60 Hz
- Supports Auto Lip Sync, xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
- Premium Blu-ray Audio support
- Supports Surge Protection
- ELNA Audio Caps LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111H
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 2.0 x 1 Slot
- 1 x M.2 Socket (Key E), supports type 2230 Wi Fi/BT module & Intel CNVi (Integrated Wi Fi/BT) Storage
- 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug
- 2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, support NCQ, AHCI & Hot Plug Connector
- 1 x COM Port Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (3-pin)
- 1 x Chassis Fan Connector (3-pin)
- 1 x 24 pin ATX Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 3 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection)* *USB3_0_1 is shared with USB_0_1. Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 2 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock XFast LAN UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket Hardware Monitor
- CPU/ Chassis temperature sensing
- CPU/ Chassis Fan Tachometer
- CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
- CPU/ Chassis Fan multi-speed control
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor
- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit* * Supports UEFI mode only Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)











































































...

The K7S41GX is ideal for the value market segment that requires a performance workstation on a cost effective budget. With ...

As Rock K7S41GX2 Socket 462 VGA 5.1 Channel Audio Micro ATX Motherboard Product Specifications General CPU:
- Socket 462 for AMD
...
