This cost-effective graphics card brings the reliability, stability, & features of the proven Millennium G550 product line to PCI Express systems. The x 1 design of the card makes it compatible with all compliant PCI Express slots
- especially useful for systems with no available PCI Express x 16 slots. In addition to having Matrox display drivers for Windows, the Millennium G550 PCIe is the world's first PCI Express graphics card with open-source display drivers for Linux & other UNIX-like operating systems. With support for using 2 monitors at a time & reliable passive cooling (a heat sink with no fan), this product is ideal for a variety of mission-critical professional applications, including computer-aided dispatch, security monitoring, & process control. By helping to manage large amounts of information, Matrox multi-display technology can improve productivity & reduce errors.
...

The Matrox M9120 Plus LP PCIe x 16 low-profile, dual monitor graphics card renders pristine image quality on up to two displays, at resolutions up to 1920x 1200 (digital) or 2048x 1536 (analog) each. This card also supports up to four analog displays via an aftermarket quad-upgradeable cable, at resolutions of up to 1920x 1200 each. High-resolution two monitor support: Support resolutions up to 1920 x 1200 (Digital) & 2048 x 1536 (Analog) per output Native PCI express x 16 performance Maximum bandwidth to ensure best performance Upgrade option to four monitor Support four VGA displays via cable (CAB-L60-4XAF); enables up to 1920 x 1200 per output 512 MB of memory For enhanced performance in demanding multi-monitor applications Low-profile form factor To fit in a wide variety of systems;

Includes:: bracket for full-height ATX form factor Passive cooling & low power consumption Fanless design eliminates noise & increases product reliability Stretched & independent desktop modes Expand your desktop across multiple monitors or set each monitor independent of each other Edge Overlap Easily & intuitively adjust the number of overlapping pixels to create a seamless, unified image on up to eight edge blending projectors. M-Series multi-card support 1 Add an additional M-Series card into the same system to drive up to 12 displays from two cards Joined graphics card mode 2 Insert two M-Series cards into the same system to drive even more monitors across a stretched desktop Matrox Clone View a copy of one display on the other displays Wide enterprise flexibility Unified driver package compatible with other Matrox products Matrox Power Desk software Easily configure & manage program windows on multiple monitors Multiple operating system support Display drivers for Microsoft Windows 8 (32-bit, 64-bit), Windows Server 2012 (32-bit, 64-bit), Windows 7 (32-bit, 64-bit), Windows Embedded Standard 7 (32-bit), Windows Vista (32-bit, 64-bit), Windows Server 2008 R1 (32-bit, 64-bit), Windows Server 2008 R2, Windows XP (32-bit, 64-bit), Windows Server 2003 & Linux 3 Hardware Included Matrox M9120 Plus LP PCIe x 16 graphics card with factory-installed low-profile bracket (ATX bracket in the box) LFH60-to- 2 x DVI-I dual-monitor adapter cable (1 ft) Two DVI-I-to-HD15 connector adapters Part Number
- M9120-E512LPUF Bus Type
- PCIe x 16 Graphics Memory
- 512MB DDR2 Card Form Factor (PCB / bracket)
- LP / LP Extra bracket in the box
- ATX Card

Dimensions
- 6.6" (L) x 2.7" (H) Connectors
- LFH-60 Breakout / Splitter Cables included
- LFH-60 to 2 x DVI-I (same as current: F16123-00) DVI to Analog (HD15) Adapters
- 2 Max Display Outputs per Card
- 2 (4 with aftermarket analog upgrade cable) Supported Display Output Types
- DVI SL, Analog Max Digital Resolution per Output
- 1920x 1200 Max Analog Resolution per Output
- 2048x 1536 (1920x 1200 with quad analog upgrade cable) Independent Desktop Mode
- Yes Stretched Desktop Mode
- Yes Joined Adapter Mode - Yes 1 Matrox Clone
- Yes Pivot Support
- Yes Passive Cooling
- Yes Unified Driver Package
- Yes Power Desk Software
- Yes EMC Certifications
- Class B Aftermarket Cable Upgrades
- Quad analog output cable (Part CAB-L60-4XAF) Supported Operating Systems Microsoft Windows 8 (32-bit, 64-bit), Windows Server 2012 (32-bit, 64-bit), Windows 7 (32-bit, 64-bit), Windows Embedded Standard 7 (32-bit), Windows Vista (32-bit, 64-bit), Windows Server 2008 R1 (32-bit, 64-bit), Windows Server 2008 R2, Windows XP (32-bit, 64-bit), Windows Server 2003 & Linux 2 Open GL support
- 2.0


























...

Enables a dual monitor setup for your notebook or desktop computer Supports a maximum resolution of 3840x 1200 (2x 1920x 1200)1; displays attached to Dual Head 2 Go must run at the same resolution Uses your system's existing GPU to deliver a stable platform for office, 3D design, & multimedia applications Works with LCDs, CRTs & projectors 2 Quick & easy to install; there's no need to open the computer case or insert components Spans taskbar across monitors for easy access to all your open applications Matrox Dual Head 2 Go is an external multi-monitor upgrade that adds two monitors to your laptop or desktop computer. It connects to the video output of your system & uses its existing GPU to provide high-quality, uncompressed graphics & video across all monitors. Ideal for business & professional users looking to increase their productivity with a dual display setup, this small box lets you run different applications on each monitor or view one application across two monitors. Working with multiple monitors lets you organize your workspace more efficiently, multi-task more comfortably & make fewer errors. Dual Head 2 Go is available in Display Port, Digital, or Analog Editions. Maximum DVI Resolution 3840x 1200 (2x 1920x 1200) Maximum VGA Resolution 3360x 1050 (2x 1680x 1050) Input connectors 1 VGA input Output connectors 2 DVI-I outputs Power USB (Universal Serial Bus) for power

Dimensions 3.9" x 5.5" x 1.3" (10cm x 14cm x 3.2cm) Hardware included One one 2 foot HD 15-to-HD-15 (analog) monitor cable One USB (Universal Serial Bus) cable Software CD

...

The Matrox Dual Head 2 Go Digital SE external multi-display adapter adds up to two monitors to your laptop or desktop computer. It connects to the video output of your system & uses the system's existing GPU to provide high-quality, uncompressed graphics & video across all monitors. Ideal for business & professional users looking to increase their productivity with a dual display setup, this little black box lets you run different applications on each monitor or view one application across two monitors. Lets you connect up to two monitors to the single Display Port video output of your system Creates a stretched desktop of 3840x 1200 (2x 1920x 1200)1 across two displays Uses your system's existing GPU to deliver a solid platform for office, 3D design, & multimedia applications Open an application on each display or span one across the two HDCP compliance for protected content playback Works with displays & projectors Quick & easy to install—there's no need to open the computer case or insert components Spans taskbar across monitors for easy access to all your open applications Runs in clone mode & shows the same content on all displays

Includes:: Matrox Power Desk software to easily manage your desktop configuration External device that won't void your system warranty Expand your desktop further by connecting a second Dual Head 2 Go Digital SE to your graphics hardware to support up to four monitors at a time 2 Matrox part number
- D2G-DP2D-IF Maximum DVI Resolution 1 3840x 1200 (2x 1920x 1200) Input connector 1 x Display Port input Output connectors 2 x DVI-D outputs Power USB (Universal Serial Bus) for power

Dimensions 3.8” x 2.5” x 1.1 Clone Mode Yes Stretched Desktop Support Yes Power Desk Software Yes Hardware included One 3-foot USB (Universal Serial Bus) cable One Display Port to Display Port input cable “ Getting Started” CD Multi-unit support Yes – Available under Windows only System Requirements Single Display Port video output on a compatible system Powered USB (Universal Serial Bus) connector Display driver supporting 2048x 768 or higher resolution Verify your system compatibility Supported Operating Systems Microsoft Windows 8 (32/64bit), Windows 7 (32/64bit), Windows Vista (32/64bit), Windows XP (32/64bit), Windows Server 2012 (32/64bit), Windows Server 2003/2008 (32/64bit) & Linux 2 Optional Accessories (Sold Separately) Power Supply Kit (Part GXM-PSKIT-IF)




...

Matrox Dual Head 2 Go is an external multi-monitor upgrade for notebooks & desktop computers. Ideal for business & professional users looking to increase their productivity with a dual monitor setup, this small box lets you run different applications on each monitor or view one application across two monitors. Dual Head 2 Go is available in analog & digital editions. ...

The Matrox M9120 Plus LP x 1 low-profile, quad-upgradeable, dual monitor graphics card renders pristine images on either two displays (natively), or four displays (via an aftermarket upgrade cable) at resolutions up to 1920x 1200 (digital), or 2048x 1536 (analog). Armed with 512MB of graphics memory & advanced desktop management, the M9120 Plus drives business, government, & industrial applications with extraordinary performance on in both independent & stretched desktop modes. Its low-profile form factor makes it easy to integrate into a wide variety of systems, it offers optimal Windows Vista Aero support (WDDM mode), & it can be paired with another Matrox graphics card if additional outputs are required. The M9120 Plus card builds upon the reliability & stability of previous Matrox products & retains core Matrox benefits such as long life-cycles, top-to-bottom manufacturing, & unified display driver models for easy deployment across multiple systems. ...

The Matrox M9140 LP PCIe x 16 quad head graphics card renders pristine images across four monitors at resolutions up to 1920x 1200 per output (digital or analog) for an exceptional multi-display user experience. With 512 MB of memory & advanced desktop management features such extending the Windows Taskbar to span multiple displays & support of independent or stretched modes, the M9140 drives business, industrial, & government applications with extraordinary performance. Its low-profile form factor makes it easy to integrate into a wide variety of systems, it offers optimal Windows Vista Aero support (WDDM mode), & it can be paired with another M9140 graphics card to support up to eight displays from a single system. The M9140 graphics card builds upon the reliability & stability of previous Matrox products, & retains core Matrox benefits such as long life-cycles, top-to-bottom manufacturing & unified display driver models for easy deployment across multiple systems. ...

The Matrox M9148 LP PCIe x 16 four monitor graphics card renders pristine images across four Display Port monitors at resolutions up to 2560 x 1600 per output for an exceptional multi-monitor user experience. With 1 GB of memory & advanced desktop management features such extending the Windows Taskbar to span multiple displays & support of independent or stretched modes, the M9148 drives business, industrial, & government applications with extraordinary performance. Its low-profile form factor makes it easy to integrate into a wide variety of systems, it offers optimal Windows Vista Aero support (WDDM mode), & it can be paired with another M9148 graphics card to support up to eight Display Port monitors from a single system. Part Number
- M9148-E1024LAF Bus Type
- PCIe x 16 Graphics Memory
- 1024MB Card Form Factor (PCB / bracket)
- LP / ATX Extra bracket in the box
- LP Card

Dimensions
- 6.6" (L) x 2.7" (H) On-board Connectors
- 4 x Mini Display Port Adapters
- 4 x Mini Display Port to Display Port Connector Adapters
- 4 x Display Port to DVI Max Display Outputs per Card
- 4 Supported Display Output Types
- Display Port, DVI SL Max Display Port Resolution per Output
- 2560x 1600 Max DVI Resolution per Output
- 1920x 1200 Independent Desktop Mode
- Yes Stretched Desktop Mode
- Yes Joined Adapter Mode
- Yes (Not available under Microsoft Windows 7 & Vista when M9188 is the additional card, except under Windows 7 XDDM mode) Matrox Clone
- Yes Pivot Support
- Yes Passive Cooling
- Yes Unified Driver Package
- Yes Power Desk Software
- Yes EMC Certifications
- Class B Supported Operating Systems
- Windows 7 (32/64bit), Windows Vista (32/64bit), Windows XP (32/64bit), Windows Server 2003/2008 (32/64bit), & Linux Open GL support
- 2.0

























...

PRODUCT
Features: Matrox Dual Head to use 2 monitors at a time (in "independent" or "stretched" mode)PCI
...

Reliable, ultra-low power graphics solution with wide enterprise flexibility The Matrox P690 PCIe x 16 offers 128MB of graphics memory & full Dual Head support for using two digital or analog monitors at high resolution & pristine image quality. With ultra-low power consumption, fanless cooling & unified display drivers for easy deployment across multiple systems, the P690 PCIe x 16 is suitable for a wide range of professional applications. This graphics card builds upon the reliability, stability, & features of the proven P-Series product line, making it an ideal choice for use in long-life environments. Matrox Dual Head technology with support for two digital or analog monitors at a time Independent resolutions & stretched desktop both supported Native PCI Express x 16 support Passive cooling (heat sink with no fan) for silent operation & extra reliability Ultra low power consumption: 10 watts Unified driver package also compatible with other products in P-Series, G-Series, QID Series, MMS Series, Parhelia Series, & Extio Series Display drivers for Windows XP & XP x 64, Windows 2000, Windows Vista (XDDM) & Vista x 64 (XDDM), Windows Server 2003 & Server 2003 x 64* Easy-to-use Matrox Power Desk desktop management software Support for customizable unattended installation of drivers for multi-system set-up Compatible with Matrox Power Space for augmented multi-display desktop functionality including multiple workspace configuration support, program autostart, desktop recall, RDP recognition support, & multi-system workspace import/export Joined graphics card mode enables an additional Matrox Dual Head& Dagger; or Triple Head± graphics card to work in tandem in one system to drive up to four displays using advanced multi-card features† Widescreen resolution support & additional functionality via Matrox Power Res Display pivoting (rotation) support Global sales & technical support Ro HS & WEEE compliant 3-year warranty * Drivers for Windows Server 2003, Windows XP x 64 (64-bit) & Windows Vista XDDM available online. For other possible operating systems, contact Matrox. With Joined graphics card mode, some Dual Head graphics cards can be joined with a second compliant Dual Head or Triple Head graphics card to drive up to four displays. In Joined graphics card mode, compliant Triple Head graphics cards are supported in Dual Head mode only. Joined graphics card mode multi-display configurations can be obtained by downloading the Matrox Power Desk-SE version 2.04 display driver & above. Hardware included Matrox P690 PCIe x 16 graphics card Two DVI-I-to-HD15 connector adapters Software included Matrox display drivers for Microsoft Windows XP & Windows 2000* Matrox Power Desk desktop management software Part Number
- P69-MDDE128F Card type
- PCIe x 16 (PCI Express x 16) Graphics Memory
- 128 MB DDR2 Bracket connectors
- DVI x 2 Card form factor
- ATX Bracket form factor
- ATX EMC certifications
- Class B – ACA, CE, CSA, FCC, VCCI Card size
- 6.6" x 4.38" / 16.76 x 11.13 cm (Card size = length, not including bracket & bracket connectors x height, including slot connector. Card width is within specifications for a single card of the given type.) Maximum resolutions (per display) Digital, 1-2 monitors: 1920 x 1200 Analog, 1-2 monitor: 2048 x 1536







...
