High quality 1m brown network patch cable CAT5e

Specification constructed from full copper 26AWG cable.





...

1m C14 to C15 power cable designed to allow you to connect equipment that has a C16 socket (C15 on cable) such as servers & rack-mount switches to UPS or PDUs with C13 outputs (C14 on cable). The C15 connector although similar in appearance to the C13 has a higher temperature rating of 170 degrees rather than 70 degrees. You can tell the difference between a C13 & a C15 connector by the notch in the connector; this means a C15 plug will work with a C14 & a C16 socket. A C13 plug however will only work in a C14 socket.

Specification IEC C14 to IEC C15 3G 0.75mm Cable (H05RR-F) Length 1 metre Rubberized Power Cable VDE Approved C14 Connector VDE Approved C15 Connector VDE Approved C14 Cable

...

Crossover cables are designed for connecting two computers together without a switch (or linking switches together) Specification 1 Meter violet cable with black boots UTP (Unshielded Twisted Pair) Cat 5e Moulded 26 AWGX4P ETL VERIFIED ISO/IEC 11801 & TIA/EIA 568B.2 E213738 CM (UL) C (UL) ...

Category 5e cable is a twisted pair high signal integrity cable type often referred to as Cat 5e. Most cables are unshielded relying on the twisted pair design for noise rejection some are shielded. Often used in computer networks such as Ethernet.

Specification 1 Meter Red cable with Black boots UTP (Unshielded Twisted Pair) Cat 5e Moulded 26 AWGX4P ETL VERIFIED ISO/IEC 11801 & TIA/EIA 568B.2 E213738 CM (UL) C (UL)

...

Category 5e cable is a twisted pair high signal integrity cable type often referred to as Cat 5e. Most cables are unshielded relying on the twisted pair design for noise rejection some are shielded. Often used in computer networks such as Ethernet.

Specification 1 Meter Grey cable with Black boots UTP (Unshielded Twisted Pair) Cat 5e Moulded 26 AWGX4P ETL VERIFIED ISO/IEC 11801 & TIA/EIA 568B.2 E213738 CM (UL) C (UL)

...

Crossover cables are designed for connecting two computers together without a switch (or linking switches together) Specification 1 Meter Grey cable with black boots FULL DUPLEX Crossover wiring spec UTP (Unshielded Twisted Pair) ...

Crossover cables are designed for connecting two computers together without a switch (or linking switches together) Specification 1 Meter Yellow cable with black boots UTP (Unshielded Twisted Pair) Cat 5e Moulded 26 AWGX4P ETL VERIFIED ISO/IEC 11801 & TIA/EIA 568B.2 E213738 CM (UL) C (UL) ...

Category 5e cable is a twisted pair high signal integrity cable type often referred to as Cat 5e. Most cables are unshielded relying on the twisted pair design for noise rejection some are shielded. Often used in computer networks such as Ethernet. Specification 1 Metre Grey UTP (Unshielded Twisted Pair)CAT5e Moulded Verified for Gigabit Ethernet 24AWG x 4P Type CM (UL) CMH E164469-F3ISO/IEC 11801 & EN 50288 & TIA/EIA-568-B.2 3 P Full copper cable ...

Category 6 cable commonly referred to as Cat-6 is a cable standard for Gigabit Ethernet & other network protocols that are backward compatible with the Category 5/5e & Category 3 cable standards. Compared with Cat-5 & Cat-5e Cat-6 features more stringent specifications for crosstalk & system noise. The cable standard provides performance of up to 250 MHz.

Specification 1 Meter Moulded boots (black) with blue cable Cat 6 UTP (Unshielded Twisted Pair) Low Smoke Zero Halogen 24AWG x 4P IEC 332.3.C-TIA/EIA-568-B.2 ISO/IEC 11801

...

1m CAT6A Patch Cable Black 10 G Base-T Pure Copper Category 6A Ethernet cable commonly referred to as Cat 6A is a cable standard for 10 Gigabit Ethernet. The cable standard provides performance of up to 600 M Hz & is suitable for 10BASE-T 100BASE-TX (Fast Ethernet) 1000BASE-T / 1000BASE-TX (Gigabit Ethernet) & 10GBASE-T (10 Gigabit Ethernet). It is backwards compatible with previous standards such as Cat 6 Cat 5e & Cat 5. LSZH: low Smoke Zero Halogen cable reduces the amount of toxic & corrosive gas emitted during a fire. Supports 10 Gigabit Ethernet / 10GBASE-T: 10 Times faster than Gigabit Ethernet 10GE (also called 10 Gb E or 10 Gig E) supports a data rate of 10 Gbits/s (billion bits per second). S/FTP (or S/STP): Screened & Foil (Shielded) Twisted Pair. Each individual pair is screened by foil & features an overall outer sheath. This shielding protects the cable from EMI (Electro-Magnetic Interference). Snagless Connectors: The connectors feature a “bubble” which protects the locking clip on the RJ45 from damage or being snapped off during transport or installation. Flush Moulded Strain Relief: The flush moulded design allows the patch cables to be installed side by side in high-density network switches. The strain relief allows the cables to move without damaging the cable or breaking away from the connector while it is plugged in a device. This product has been tested & found to comply with the applicable electrical transmission characteristics specified in: ISO/IEC 11801 ED.2 & ANSI/TIA-568-C.2 IEC 60332-1-2 Ro HS Compliant & 3P Verified Available in 0.5 1 2 3 5 & 10 metre lengths All lengths are available in grey yellow red blue green & black. ...
