Use this adapter to connect four independent displays to a single m DP 1.2 port\n\n This MST hub lets you connect four monitors to your Mini Display Port (m DP) 1.2 equipped Windows tablet, laptop or desktop.\n\n Increase productivity with multiple screens\n\n The newest generations of computers are more portable than ever, which often means that you&153;re left with fewer video outputs & smaller integrated screens. This MST hub solves both of these problems by letting you connect four additional displays to your computer, which makes multitasking much easier. \n\n Connect to any display\n\n With the MST hub, you can use Mini Display Port video adapters & cable adapters that enable you to connect HDMI, VGA or DVI displays. This ensures that your MST hub will be compatible with virtually any television, monitor or projector. The hub is VESA & Display Port certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment.\n\n Configure your displays for any environment\n\n Using the MST hub, you can extend your desktop onto additional monitors & stream independent content to each display, giving you the freedom to multitask & increase your productivity. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage.\n\n Enjoy amazing video quality, without draining system resources\n\n MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. This unprecedented performance makes MST perfect for high-resolution applications such as graphic design, gaming & medical imaging.\n\n Note: When using a Display Port 1.1 video card the MSTMDP124DP will act as a splitter, automatically mirroring your video source across all displays. Resolution limitations apply.\n\n The MSTMDP124DP supports plug-&-play installation for a hassle-free setup, & is backed by a Star Tech.com 3-year warranty & free lifetime technical support.\n\n Notes: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup. Certain graphics adapters have limited MST support & will only output to three displays in total. If more than three monitors are attached, the fourth will be disabled.\n\n The Surface Pro 3, Surface Pro 4, & Surface Book only support the use of three displays in total. If this device is used with the Surface Pro 3, & three external monitors, the built-in touch screen on your Surface will be disabled. \n\n Average resolution bandwidth allocation\n\n 1920x 1080 (High-definition 1080p) @60hz
- 22%\n\n 1920x 1200 @60hz
- 30%\n\n 2560x 1440 @60hz
- 35%\n\n 2560x 1600 @60hz
- 38%\n\n 3840 x 2160 (Ultra HD 4K) @30hz
- 38%\n\n Note: Exceeding 100% will reduce functionality.\n\n Examples of supported resolution configurations\n\n Screen 1 Resolution\n\n Screen 2 Resolution\n\n Screen 3 Resolution\n\n Screen 4 Resolution\n\n Total % of Bandwidth\n\n 1920x 1080 @60hz (22%)\n\n 1920x 1080 @60hz (22%)\n\n 1920x 1080 @60hz (22%)\n\n 1920x 1080 @60hz (22%)\n\n 88%\n\n 1920x 1200 @60hz (30%)\n\n 1920x 1080 @60hz (22%)\n\n 1920x 1080 @60hz (22%)\n\n 1920x 1080 @60hz (22%)\n\n 96%\n\n 3840x 2160 @30hz (38%)\n\n 1920x 1080 @60hz (22%)\n\n 1920x 1080 @60hz (22%)\n\n off\n\n 82%\n\n 3840x 2160 @30hz (38%)\n\n 1920x 1200 @60hz (30%)\n\n 1920x 1080 @60hz (22%)\n\n off\n\n 90%\n\n Examples of unsupported resolution configurations\n\n Screen 1 Resolution\n\n Screen 2 Resolution\n\n Screen 3 Resolution\n\n Screen 4 Resolution\n\n Total % of Bandwidth\n\n 2560x 1600 @60hz (38%)\n\n 2560x 1600 @60hz (38%)\n\n 1920x 1200 @60hz (30%)\n\n 1920x 1200 @60hz (30%)\n\n 136%\n\n 3840x 2160 @30hz (38%)\n\n 2560x 1600 @60hz (38%)\n\n 1920x 1200 @60hz (30%)\n\n 1920x 1200 @60hz (30%)\n\n 136%\n\n 3840x 2160 @30hz (38%)\n\n 2560x 1600 @60hz (38%)\n\n 2560x 1440 @60hz (35%)\n\n 1920x 1200 @60hz (30%)\n\n 141%\n\n 3840x 2160 @30hz (38%)\n\n 3840x 2160 @30hz (38%)\n\n 3840x 2160 @30hz (38%)\n\n off\n\n 114%\n\n The Star Tech.com Advantage\n\n- Maximize your productivity by connecting four independent displays to your computer using the MST hub\n- Connect to almost any television, monitor or projector with support for low-cost adapters\n- Newly engineered chipset for increased compatibility with Microsoft Surface Pro 4 Feature Feature Value Video ports quantity 4 Video port type Mini Display Port Video out 4x Display Port Maximum resolution 3840 x 2160 pixels Product colour Black Maximum refresh rate 30 Hz Supported graphics resolutions 1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160 Plug & Play Y Ro HS compliance Y Certification CE, FCC, Ro HSWindows operating systems supported Windows 10 Education, Windows 10 Education x 64, Windows 10 Enterprise, Windows 10 Enterprise x 64, Windows 10 Home, Windows 10 Home x 64, Windows 10 Pro, Windows 10 Pro x 64, Windows 7 Enterprise, Windows 7 Enterprise x 64, Windows 7 Home Basic, Windows 7 Home Basic x 64, Windows 7 Home Premium, Windows 7 Home Premium x 64, Windows 7 Professional, Windows 7 Professional x 64, Windows 7 Starter, Windows 7 Starter x 64, Windows 7 Ultimate, Windows 7 Ultimate x 64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x 64, Windows 8 Pro, Windows 8 Pro x 64, Windows 8 x 64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x 64, Windows 8.1 Pro, Windows 8.1 Pro x 64, Windows 8.1 x 64 Input voltage 100
- 240 VInput current 0.5 AOutput voltage 5 VOutput current 3 APower consumption (typical)15 WWidth 65 mm Depth 386 mm Height 15 mm Weight 127 g Package width 153 mm Package depth 244 mm Package height 64 mm Package weight 118 g Manual YAC adapter included Y Included power plug types AU, EU, NA, UKOperating temperature (T-T)0
- 45 &176;CStorage temperature (T-T)-20
- 70 &176;C







...

Connect a DVI monitor to a single-mode Display Port output from your computer The MDP2DVIS Mini Display Port to DVI Active Adapter (single-link) lets you connect your Mini-Display Port video source to a DVI-D display, including televisions & Apple Cinema Display HD, eliminating the expense of having to upgrade to a Display Port capable monitor. Unlike passive video adapters, this Mini Display Port to DVI adapter offers an active conversion for use with any Mini Display Port output
- ideal for graphics cards that are not capable of outputting multi-mode DP++ signals (e.g. ATI Eyefinity). Supporting resolutions up to 1920x 1200, this compact device provides a simple solution for adapting PC or Mac Mini-Display Port output for DVI monitors, televisions or projectors. Compatible with Intel Thunderbolt™, when connected directly to a supporting Display Port over Thunderbolt™ I/O port. Backed by a Star Tech.com 2-year warranty & free lifetime technical support. * This Mini Display Port to DVI adapter offers active signal conversion, which helps overcome the limitation of some Mini Display Port video cards not being able to output a DP++ (multimode) signal * Simple to use, small form-factor converter makes Mini-Display Port backwards compatible with your DVI-D single link display
...

Connect a DVI monitor to a single-mode Display Port output from your computer\n\n The MDP2DVIS Mini Display Port to DVI Active Adapter (single-link) let's you connect your Mini Display Port video source (such as any of your Mac Book or Microsoft Surface Pro devices with m DP) to a DVI-D display, including televisions & Apple Cinema Display HD, eliminating the expense of having to upgrade to a Display Port capable monitor.\n\n Unlike passive video adapters, this Mini Display Port to DVI adapter offers an active conversion for use with any Mini Display Port output
- ideal for graphics cards that are not capable of outputting multi-mode DP++ signals (e.g. ATI Eyefinity).\n\n Supporting resolutions up to 1920x 1200, this compact device provides a simple solution for adapting PC or Mac Mini-Display Port output for DVI monitors, televisions or projectors.\n\n The Mini DP to DVI adapter is compatible with Intel Thunderbolt, when connected directly to a supporting Display Port over Thunderbolt I/O port.\n\n Backed by a Star Tech.com 3-year warranty & free lifetime technical support.\n\n The Star Tech.com Advantage\n\n- This Mini Display Port to DVI adapter offers active signal conversion, which helps overcome the limitation of some Mini Display Port video cards not being able to output a DP++ (multimode) signal\n- Simple to use, small form-factor converter makes Mini-Display Port backwards compatible with your DVI-D single link display\n\n\n\n Product ID: MDP2DVIS\n\n\n\n\n\n Model: Mini Display Port to DVI Active Adapter\n\n Datasheet: http://objects.icecat.biz/objects/mmo_8545546_1578484168_7332_20904.pdf\n\n\n\n Manual: http://objects.icecat.biz/objects/mmo_8545546_1557499837_3569_17539.pdf\n\n\n\n\n\n\n\n
...

Connect a DVI monitor to a single-mode Display Port output from your computer\n\n The MDP2DVIS Mini Display Port to DVI Active Adapter (single-link) let's you connect your Mini Display Port video source (such as any of your Mac Book or Microsoft Surface Pro devices with m DP) to a DVI-D display, including televisions & Apple Cinema Display HD, eliminating the expense of having to upgrade to a Display Port capable monitor.\n\n Unlike passive video adapters, this Mini Display Port to DVI adapter offers an active conversion for use with any Mini Display Port output
- ideal for graphics cards that are not capable of outputting multi-mode DP++ signals (e.g. ATI Eyefinity).\n\n Supporting resolutions up to 1920x 1200, this compact device provides a simple solution for adapting PC or Mac Mini-Display Port output for DVI monitors, televisions or projectors.\n\n The Mini DP to DVI adapter is compatible with Intel Thunderbolt, when connected directly to a supporting Display Port over Thunderbolt I/O port.\n\n Backed by a Star Tech.com 3-year warranty & free lifetime technical support.\n\n The Star Tech.com Advantage\n\n- This Mini Display Port to DVI adapter offers active signal conversion, which helps overcome the limitation of some Mini Display Port video cards not being able to output a DP++ (multimode) signal\n- Simple to use, small form-factor converter makes Mini-Display Port backwards compatible with your DVI-D single link display\n\n\n\n Product ID: MDP2DVIS\n\n\n\n\n\n Model: Mini Display Port to DVI Active Adapter\n\n Datasheet: http://objects.icecat.biz/objects/mmo_8545546_1578484168_7332_20904.pdf\n\n\n\n Manual: http://objects.icecat.biz/objects/mmo_8545546_1557499837_3569_17539.pdf\n\n\n\n\n\n\n\n
...

Connect your Mini Display Port video source to a DVI-D display The MDP2DVID Mini Display Port to DVI-D Dual-Link adapter lets you connect your Mini Display Port video source (Macbook, Macbook Pro, Macbook Air, etc.) to any DVI-D display, including televisions & Apple Cinema Display HD, eliminating the expense of having to upgrade to a Mini Display Port-capable monitor. The Mini Display Port adapter offers an active conversion, which is powered by a single USB (Universal Serial Bus) port & is able to handle full dual-link resolutions (up to 2560x 1600). Use it to mirror your display to another monitor, or extend your desktop to increase your workspace. Backed by a Star Tech.com 2-year warranty & free lifetime technical support. " * USB (Universal Serial Bus)-Powered operation means no wall outlet or bulky external power adapter is required * Active conversion allows full dual-link DVI resolution (2560x 1600)" ...

The MDP2DVIW passive Mini Display Port to DVI Adapter (White) offers an easy-to-use DVI/ Mini-Display Port link that enables you to connect a DVI computer monitor to a device with a Mini-Display Port output (such as a laptop video out port) or video card. The adapter supports high resolution output up to 1900x 1200, offering a cost-effective solution for mirroring or extending a computer desktop onto a second display. Plus, because the adapter functions passively, it can be used with a DVI to HDMI adapter, to connect an HDMI-equipped monitor to a Mini Display Port output. This versatile Mini Display Port to DVI adapter requires a multimode Display Port port (Display Port ++) connection to function, & is compatible with Intel Thunderbolt™ output when directly connected to a supporting Display Port over Thunderbolt I/O port. ...

Connect a DVI display to a Mini Display Port equipped PC or MAC\n\n The Star Tech.com MDP2DVI Mini Display Port DVI Adapter Cable offers a cost-effective DVI/ Mini Display Port link, letting you connect a DVI computer monitor to a device with a Mini Display Port output while saving the expense of upgrading the monitor for compatibility. This Mini Display Port adapter is the perfect accessory for any of your Mac Book or Microsoft Surface Pro devices with m DP.\n\n MDP2DVI is a passive adapter that requires a DP++ port (Display Port++), meaning that DVI & HDMI signals can also be passed through the port.\n\n Compatible with Intel Thunderbolt, when connected directly to a supporting Display Port over Thunderbolt I/O port.\n\n Backed by a Star Tech.com 3-year warranty & free lifetime technical support.\n\n The Star Tech.com Advantage\n\n- Simple to use, small form factor converter makes Mini Display Port backwards compatible with your existing DVI display or projector\n- No installation software or drivers required providing a simple plug & play solution Feature Feature Value Maximum video resolution 1920 x 1200 pixels Supported video modes 1080p Converter type Passive video converter Maximum resolution 1920 x 1200 pixels Product colour Black Cable length 0.13 m Ro HS compliance Y Certification CE, FCC, REACHHost interface Mini Display Port Output interface DVI-IWidth 35 mm Depth 185 mm Height 11 mm Weight 31 g Package width 200 mm Package depth 220 mm Package height 18 mm Package weight 40 g Audio support N ...

Connect a DVI display to a Mini Display Port equipped PC or MAC\n\n The Star Tech.com MDP2DVI Mini Display Port DVI Adapter Cable offers a cost-effective DVI/ Mini Display Port link, letting you connect a DVI computer monitor to a device with a Mini Display Port output while saving the expense of upgrading the monitor for compatibility. This Mini Display Port adapter is the perfect accessory for any of your Mac Book or Microsoft Surface Pro devices with m DP.\n\n MDP2DVI is a passive adapter that requires a DP++ port (Display Port++), meaning that DVI & HDMI signals can also be passed through the port.\n\n Compatible with Intel Thunderbolt, when connected directly to a supporting Display Port over Thunderbolt I/O port.\n\n Backed by a Star Tech.com 3-year warranty & free lifetime technical support.\n\n The Star Tech.com Advantage\n\n- Simple to use, small form factor converter makes Mini Display Port backwards compatible with your existing DVI display or projector\n- No installation software or drivers required providing a simple plug & play solution Feature Feature Value Maximum video resolution 1920 x 1200 pixels Supported video modes 1080p Converter type Passive video converter Maximum resolution 1920 x 1200 pixels Product colour Black Cable length 0.13 m Ro HS compliance Y Certification CE, FCC, REACHHost interface Mini Display Port Output interface DVI-IWidth 35 mm Depth 185 mm Height 11 mm Weight 31 g Package width 200 mm Package depth 220 mm Package height 18 mm Package weight 40 g Audio support N ...

Connect a DVI display to a Mini Display Port equipped PC or MAC\n\n The Star Tech.com MDP2DVI Mini Display Port DVI Adapter Cable offers a cost-effective DVI/ Mini Display Port link, letting you connect a DVI computer monitor to a device with a Mini Display Port output while saving the expense of upgrading the monitor for compatibility. This Mini Display Port adapter is the perfect accessory for any of your Mac Book or Microsoft Surface Pro devices with m DP.\n\n MDP2DVI is a passive adapter that requires a DP++ port (Display Port++), meaning that DVI & HDMI signals can also be passed through the port.\n\n Compatible with Intel Thunderbolt, when connected directly to a supporting Display Port over Thunderbolt I/O port.\n\n Backed by a Star Tech.com 3-year warranty & free lifetime technical support.\n\n The Star Tech.com Advantage\n\n- Simple to use, small form factor converter makes Mini Display Port backwards compatible with your existing DVI display or projector\n- No installation software or drivers required providing a simple plug & play solution Feature Feature Value Maximum video resolution 1920 x 1200 pixels Supported video modes 1080p Converter type Passive video converter Maximum resolution 1920 x 1200 pixels Product colour Black Cable length 0.13 m Ro HS compliance Y Certification CE, FCC, REACHHost interface Mini Display Port Output interface DVI-IWidth 35 mm Depth 185 mm Height 11 mm Weight 31 g Package width 200 mm Package depth 220 mm Package height 18 mm Package weight 40 g Audio support N ...

Connect a DVI Display to a Mini Display Port Video Source\n\n The MDP2DVI3 Mini Display Port to DVI Adapter lets you connect your Mini Display Port video source (such as any of your Mac Book or Microsoft Surface Pro devices with m DP) to a DVI monitor, projector, or display, eliminating the expense of having to upgrade to a Mini Display Port-capable monitor.\n\n Compatible with Intel Thunderbolt, when connected directly to a supporting Display Port over Thunderbolt I/O port, the adapter supports display or projector resolutions up to 1920x 1200 (WUXGA) & is compliant with HDCP standards.\n\n MDP2DVI3 is a passive adapter that requires a DP++ port (Display Port++), meaning that DVI & HDMI signals can also be passed through the port.\n\n Backed by a Star Tech.com 3-year warranty & free lifetime technical support.\n\n The Star Tech.com Advantage\n\n- Simple to use converter makes Mini Display Port output backward compatible with your existing DVI display or projector\n- Save time with a simple plug-&-play solution; no software or driver installation required\n\n\n\n Product ID: MDP2DVI3\n\n\n\n\n\n Model: Mini Display Port to DVI Video Adapter Converter
- Black Mini DP to DVI
- 1920x 1200\n\n Datasheet: http://objects.icecat.biz/objects/mmo_18139468_1557497412_873_14925.pdf\n\n\n\n\n\n\n\n\n\n\n\n

...
