The Hornby Select unit is an ideal way to enter the digital age of controlling a model railway The following are some of the many features & benefits that the Hornby Select digital Control has to offer Controls up to 10 trains simultaneously provided the necessary power is available The 1 amp power supply included allows for up to three locomotives providing power is available to be running at any one time Supports a maximum four amp power supply 3 amps to the track 1amp to the accessory outlet available separately Incorporates 128 speed steps for smooth control of locomotives Can programme locomotives with up to 99 levels of acceleration deceleration The Select Unit supports up to nine functions per locomotive if required Able to programme up to 59 locomotives or other items containing a locomotive decoder & 40 points or other items that rely on a solenoid for operation Eg Electrically operated signals electrically operated uncouplers & point motors It should be noted that items containing a locomotive decoder should always be programmed between 1 59 This will ensure that the locomotive will function as expected All items connected to Accessory Decoders should be programmed between 60 99 The Select accommodates decoders that incorporate a functioning feed back system Supports Xpress Net protocol Uncontrolled 15V DC analogue accessory outlet 2 digit LCD display External boosters can be supported through the Xpress Net port A standard RJ12 sixway cable can be used to connect the Select to a booster which has an RJ12 socket Up to 9 Select units can be connected together for individual control of 9 locomotives providing power is available The Select can be used as a Walkabout Unit when connected to the Hornby Elite Digital Unit ...

Decoder scale NTT with Plu X12 connector DCC Multiprotocol decoder with load regulation for DC & Faulhaber motors With higher current capacity for small locos with High current demands N TT OOHO Features Regulated Multiprotocol decoder for DCC Motorola with automatic system recognition for analog DC Suitable for DC & Bell armature motors up to 07A 15A peak current Quiet motor running with 1875 K Hz control frequency 14 27 28 31 & 128 speed steps depending on the data format Short 1127 & long 1289999 addresses NMRA compatible Minimum maximum & middle speeds adjustable Speed step table for 14 28 & 31 speed steps Main line programming DCC Shunting speed half speed switched with F3 Direction dependent dimmable lighting switched via F0 Two additional function outputs With solder pads for connecting Uhlenbrock Intelli Sound modules or LISSY Mini transmitter Reacts to DCC brake signal eg from Power 3 Brake diode or braking section in DC operation All outputs have short circuit protection Conventional DC operation with automatic switching between DC & digital mode All CVs programmable by digital devices with DCC & Motorola formats Programmable via register direct CV or page mode in DCC operation Updatable using Flash memory

Dimensions 145 x 83 x 24mm

...

PIKO Multiprotocol Decoder For locomotives with DC motors on digital layouts operating in the DCC & Motorola data format Features Regulated multiprotocol decoder for DCC NMRA compliant & Motorola Suitable for DC & bell armature motors to 3 A Quiet motor running by using 1875 k Hz control frequency 14 27 28 128 speed steps depending on data format Short addresses 1127 & long addresses for 1289999 Adjustable minimum medium & maximum speeds Speed step tables for 14 & 28 speed step mode Main track programming DCC Shunting mode half speed toggled using f 3 Startingbrake inertia switched using f 4 Headlights switched using f 0 dimmable 8 special function outputs switched using f 1 & f 8 Function Mapping With SUSI sound interface 4 pole mini socket for the connection of the PIKO sound module 36190 or other modules controllable using auxiliary functions f 1 to f 12 Reacts to DCC conforming brake signal eg Power 3 or brake sections with DC voltage Overheating protection All outputs are short circuit protected Conventional DC or AC operation with automatic changeover on the respective operating mode All CVs are programmable with digital devices using DCC andor Motorola formats With DCC systems programmable using register CV direct or page programming All special functions also switchable with LGB controllers Connection of older LGB sound modules possible by outputting of LGB pulse trains via output A1 Shuttle train service & intermediate stop or INDUSI using a locomotive reed contact & track magnets Optional direction dependent or timelimited switching of the special functions f 1 to f 8 Updatable by Flash memory Description This locomotive decoder is an efficient multiprotocol decoder for large scale trains It can be used in DCCand Motorola Digital systems & also works in analog mode with DC or AC & direction of travel changeover using high voltage pulse Mrklin system The decoder works with a frequency of 1875 KHz & is suitable for DC motors as well as for bell armature motors eg Faulhaber Maxon Escap up to a continuous power of 3 A Short term higher switching on currents are tolerated well The motor characteristics are setup either by means of the minimum middle & maximum speed or by different CVs for the individual speed steps The load control can be individually adapted to different locomotive motors by setting these control parameters The decoder has two travel direction dependent lighting outputs as well as eight additional special function outputs which are switched using function keys f 1 to f 8 Function keys f 3 & f 4 can be used to switch a shunting mode with extended lowspeed operating range & the startingbrake inertia The allocation of the switching tasks such as lighting special function outputs shunting mode & adjustable startingbrake inertia can be freely assigned to the function keys of the digital center Function Mapping Special functions f 5 to f 8 have fixed outputs assigned All CVs can be programmed using the PIKO Digi Power Box Intellibox DCC or Mrklin controller In the factory condition the decoder automatically recognizes the DCC & Motorola data formats as well as analog DC or AC power The desired mode of operation can also be specified manually description Digital Set for GTaurus scale G ...
