The Draper 81645 is a semi automatic tyre changer, capable of removing & replacing tyres on wheels up to 23”. The fully motorised turntable, pneumatically operated clamping jaws & powerful pneumatic bead breaker enables the changing of conventional tyres quickly & easily. The self centring four-jaw chuck, controlled by two clamping cylinders, always ensures wheel rims are correctly clamped. Alloy rims are treated particularly gently as the mounting head is provided with plastic protectors. The bead breaker is attached with a large anti-skid rubber pad, which preserves the tyres & rims. The machine is operated by a standard 13amp 3 pin plug enabling self installation, & the mounting arm swings to the side allowing the machine to be installed directly near a wall, perfect for those with limited working space. Supplied with the following accessories: tyre lever, filter regulator lubricator to connect your compressed air supply, alloy rim protectors, head tongue protectors & inflation gun & air hose. Price now

Includes:: professional installation. UK Mainland only.

...

A comprehensive wheel servicing kit, consisting of a semi-automatic tyre changer & wheel balancer. The tyre changer is capable of removing & replacing tyres on wheels up to 23” & is powered by a fully motorised turntable & fitted with pneumatically operated clamping jaws & bead breaker. This enables the changing of conventional tyres quickly & easily & the bead breaker is attached with a large anti-skid rubber pad, which preserves the tyres & rims. Each machine is attached with a self-centring four-jaw chuck guaranteeing that wheel rims are correctly clamped, & alloy rims are treated particularly gently as the mounting head is provided with plastic protectors. The semi-automatic wheel balancer is supplied with a calibration weight for easy setup & is able to balance wheels up to 65kg & 24” in diameter all with an accuracy of 1 gram. This tool is also suitable for passenger & LGV wheel/tyre combinations. Both machines are fitted with a standard 13 amp plugs for easy installation & assembly & supplied with the following accessories: 4 x centering cones, centering shaft, wheel weight pliers, hub nut & rim width calipers, tyre lever, filter regulator lubricator to connect your compressed air supply, alloy rim protectors, head tongue protectors & inflation gun & air hose. Full self-assembly & self-installation is required. Pricing now

Includes:: delivery & installation. Wheel Balancer Specifications Balance speed 200RPM Power supply 230V Balance accuracy 1 Gram Cycle Time 8-10 seconds Max tyre diameter 43" Max tyre width 35" Rim capacity 10"
- 20" Rim width capacity 1.5"
- 20" Max weight capacity 65kg

Dimensions (guard open) 13208mm x 1016mm x 1651mm

Dimensions (guard closed) 13208mm x 965mm x 1270mm Tyre Changer Specifications Motor 0.75KW Power supply 230V Bead breaker force 2100kg Pneumatic supply 90-115psi (6-8BAR) Suitable for use on wheel width 3" to 14" For rim dia. (internal locking) 13" to 23" For rim dia. (external locking) 11" to 21" Max tyre outside diameter 40" (1000mm)

Dimensions 1740mm x 950mm x 760mm Weight 180kg









...

A comprehensive wheel servicing kit, consisting of a semi-automatic tyre changer with assist arm & wheel balancer. The semi-automatic tyre changer, capable of removing & replacing tyres on wheels up to 26” is fitted with an assist arm (also known as a third arm) to aid the user when changing low profile & run-flat tyres. The fully motorised turntable, which is pneumatically operated with clamping jaws, has a powerful pneumatic bead breaker & tilt column which enables the changing of low profile, & run flat tyres quickly & easily. The self-centering four-jaw chuck, controlled by two clamping cylinders, always ensures wheel rims are correctly clamped for added peace of mind. Alloy rims are treated particularly gently as the mounting head is provided with plastic protectors. The bead breaker is attached with a large anti-skid rubber pad, which preserves the tyres & rims. The semi automatic wheel balancer is supplied with a calibration weight for easy set up & is able to balance wheels up to 65kg, 24” in diameter & with an accuracy of 1 gram. This product is also suitable for passenger & LGV wheel/tyre combinations. Both machines are operated with standard 13 amp plugs for easy installation & supplied with the following accessories: 4 x centering cones, centering shaft, wheel weight pliers, hub nut & rim width calipers, tyre lever, filter regulator lubricator to connect your compressed air supply, alloy rim protectors, head tongue protectors & inflation gun & air hose. Optional installation & instruction service available from Draper Tools. Please call us for a"e. Tyre Changer Specifications • Motor: 1.1KW • Power supply: 230V • Bead breaker force: 2100kg • Pneumatic supply: 80 -115psi (6
- 8bar) • Suitable for use on wheel

Width: 3” to 18” • For rim dia. (internal locking): 13” to 26” • For rim dia. (external locking): 12” to 25” • Max tyre outside diameter: 45” • Dimensions: 1900mm H x 1950mm D x 1650mm W • Weight: 350kg Wheel Balancer Specifications • Balance speed: 200RPM • Power supply: 230V • Balance accuracy: 1gram • Cycle Time: 8-10 seconds • Max wheel & tyre diameter capacity: 43” • Max wheel & tyre width capacity: 35” • Min/max rim diameter capacity: 10”
- 39” • Min/max rim width capacity: 1.2”
- 35” • Max tyre/rim weight capacity: 65kg •

Dimensions (guard open): 1321mm x 1016mm x 1651mm •

Dimensions (guard closed): 1321mm x 965mm x 1276mm








...

Expert Quality, four drawer top tool chest. Manufactured from thick sheet steel with a protective powder coated finish. Drawers are fitted with an aluminium trim, 3mm EVA foam linings, heavy duty auto retention ball bearing runners delivering a smoother operation & a secure locking system supplied with two keys. The reinforced lid is fitted with supportive gas struts & two soft grip handles. Each tool chest is also supplied with a 6mm EVA top mat. ...

Expert Quality, four drawer top tool chest. Manufactured from thick sheet steel with a protective powder coated finish. Drawers are fitted with an aluminium trim, 3mm EVA foam linings, heavy duty auto retention ball bearing runners delivering a smoother operation & a secure locking system supplied with two keys. The reinforced lid is fitted with supportive gas struts, a plastic document holder & two soft grip handles. Each tool chest is also supplied with a 6mm EVA top mat. ...

Expert Quality, four drawer locker top tool chest. Manufactured from thick sheet steel with a protective powder coated finish. Drawers are fitted with an aluminium trim, 3mm EVA foam linings, heavy duty auto retention ball bearing runners delivering a smoother operation & a secure locking system supplied with two keys. The reinforced lid is fitted with supportive gas struts & two soft grip handles. Each tool chest is also supplied with a 6mm EVA top mat. ...

Expert Quality, five drawer top tool chest. Manufactured from thick sheet steel with a protective powder coated finish. Drawers are fitted with an aluminium trim, 3mm EVA foam linings, heavy duty auto retention ball bearing runners delivering a smoother operation & a secure locking system supplied with two keys. The reinforced lid is fitted with supportive gas struts & two soft grip handles. Each tool chest is also supplied with a 6mm EVA top mat. ...

An Expert Quality, sixteen drawer, professional combined roller cabinet & tool chest. Attached with spring loaded suspension fixed to braked & swiveling castors & soft grip pulling handles for easy manoeuvrability. The reinforced lid is fitted with supportive gas struts & two soft grip handles. Manufactured from thick sheet steel with a protective powder coated finish. Drawers are fitted with an aluminium trim, 3mm EVA foam linings, heavy duty auto retention ball bearing runners delivering a smoother operation & a secure locking system with two keys. Each tool cabinet is also supplied with a EVA top mat. ...

A 5 drawer tool chest manufactured from sheet steel with a powder coated finish & aluminium effect trim. The drawers are fitted with ball bearing runners for smoother operation & a protective foam liner. Each tool chest is fitted with heavy-duty carry handles & a secure integral locking system supplied with two keys. ...

Expert Quality, six drawer top tool chest. Manufactured from thick sheet steel with a protective powder coated finish. Drawers are fitted with an aluminium trim, 3mm EVA foam linings, heavy duty auto retention ball bearing runners delivering a smoother operation & a secure locking system supplied with two keys. The reinforced lid is fitted with supportive gas struts, plastic document holder & two soft grip handles. Each tool chest is also supplied with a 6mm EVA top mat. ...
