The Techconnect range features an attractive architectural front surround system making it suitable for corporate & home-cinema applications, plus robust clip-in modules which make it super-quick to install & flexible. It allows seamless integration of connectivity, audio, & control. Plug-In Cables Modules feature plug-in connectors on the rear. Cables come pre-terminated with male connectors which are simply plugged into the rear of the module. Need to shorten or pull a cable? Just unscrew the captive-screw connector. Techconnect gives you the speed of a pre-terminated system with the flexibility you sometimes need. More Space By using multi-layer printed circuit boards we’ve created much more space behind each module for cables. The depth of the VGA module being just 38mm from the front of the module to the rear. Backboxes The Techconnect packages come with a surface-mounted ‘backbox’ & a ‘surround’ – the part the modules clip into. The range

Includes:: various flush & surface mounting backboxes, & all the surrounds conform to standard British sizes so they fit any locally sourced backboxes. Vision also offers Australian & American surrounds which conform to local standards. Backboxes are carefully designed with convenient easy-push-out sections for trunking & are made from flexible non-marking plastic so are not brittle like common backboxes. Quick & Easy Simple enough that even an inexperienced technician can install it. No soldering is necessary due to its captive screw connector design. The modules are interchangeable, so if in the future you require a different connector to be installed, you can simply buy just the module you want & swap it out. Plug-&-Play Connectivity Unlike cheap VGA cable, Vision’s quality cable has SDA & SCL data lines to support DDC2B (Display Data Channel) which allows the display device to communicate its supported display modes. Without these the user will not experience play-&-play connectivity & will have to manually setup resolution & color bit depth. Installation-Grade Cable When choosing cable don’t be fooled by a thick cable jacket. Does it have adequate copper? Is it shielded evenly to prevent ghosting? A major cost component of cables is copper, so cheap cables have less copper. Compromising can result in cable which doesn’t support high resolutions, & results in flagging or image jitter. The cross-sectional area of Techconnect cable conductors allows sufficient current-carrying capacity to support high resolution signal, & the shielding is evenly wound. Plus Ferrite Cores included on VGA cables to eliminate radio-frequency induction noise.

...

This adapter allows your camera to attach to select Vision projector mounts. Cable management Just drop the cables down through the pole to terminate to the camera for a professional look. Cables are out of sight. Camera tilt The bottom bracket is adjustable so you can direct the camera where you need to. ...

The TM-CAGE is obvious enough to serve as an effective visual deterrent, but is unobtrusive. Just because it needs to be seen, doesn't mean it needs to be ugly! The enclosure assembles like a puzzle making it deceptively difficult to take apart. The cage conforms as closely as possible to the size of the projector, which allows a more secure design & makes it more attractive. Security is enhanced because the projector can't be maneuvered within the enclosure to squeeze it out of an aperture, & also an attempt to cut the cage would almost certainly damage the projector. ...

The Techmount TM-CC is a universal projector ceiling bracket designed to secure 99% of data projectors safety & sturdily to ceilings. It is designed for applications where no ‘drop’ is required so no pole is included. It holds the projector 110mm away from the ceiling. Robust Construction High standard of finish & over-engineered for stability & safety. A rugged high-quality satin-white finish blends with ceiling tiles. Manoeuvrable The top & bottom parts can rotate 360 degrees, & the spider arms have a maximum span of 340mm. Sloping Ceilings? A tilting mechanism is built in allowing you to use the bracket with cathedral-type ceilings. Safety Approved As with all projector Techmounts a safety cable is included to attach to the projector. The TM-CC has a recommended maximum safe working load (SWL) of 10kg which is well within the limits of the product. Easy fit Fitting the bracket to the projector is simple; most projectors have threaded inserts in the bottom for attachment. Not all use the same diameter screws we provide a selection to suit almost all projectors. Simply adjust the arms on our bracket over the attachment holes, & insert a screw into the projector. Tools Included A spanner & pin-hex key are included. Secure Quick-release mechanisms make life easier for thieves so the TM-CC comes with secure pin-hex bolts. ...

VISION TECHCONNECT STEREO AMPLIFIER V2 LED display, 2x 20w (rms @ 8 ohms), 2 x stereo line-level inputs (Input 1 is duplicated on front & rear panel), low impedance digital amplifier. IR Remote control included. IR receiver duplicated on front & rear ...

Vision TM-1200 Universal Mounting Kit for Projectors 1.2m Ceiling Mount Satin White The Techmount is a universal projector ceiling bracket designed to secure most video data projectors safety & sturdily to your ceiling. Included: 1 x H50 Pin-Hex key 1 x 17mm Spanner 4 x M3 43mm screws 4 x M4 43mm screws 4 x M5 43mm screws 4 x M2.5 43mm pan slot for Optoma & Acer 4 x M8 50mm Ceiling fixtures with rawl plugs. 1 x Drilling Jig, 1 x Safety Tether, 1 x Ceiling Trim Disc ...

The TM-CAGE is obvious enough to serve as an effective visual deterrent, but is unobtrusive. Just because it needs to be seen, doesn't mean it needs to be ugly! The enclosure assembles like a puzzle making it deceptively difficult to take apart. The cage conforms as closely as possible to the size of the projector, which allows a more secure design & makes it more attractive. Security is enhanced because the projector can't be maneuvered within the enclosure to squeeze it out of an aperture, & also an attempt to cut the cage would almost certainly damage the projector. ...

Robust & simple, the Techmount for flat-panels fits any flat-panel LCD or LED screen which uses VESA mounting points up to 600 wide x 400 mm tall apart. In standard guise it fixes to the floor. Heavy duty floor mount for interactive flat-panels Motorized 500 mm up/down travel Fix to floor or add optional wheels ...

Smart design means the new Techmount LCD can fit anything from a 15” LCD, to 42& Prime; plasmas, to huge 65” LCD screens. A variety of thumb-screws are included for fitment. One-Tool Bracket The completely unique thumb-screw design cuts out the need for a screwdriver to attach the bracket to the back of the flat-screen – just use your hand! You just need one tool to attach the brackets to the wall. Fastest Installation Ever! Vision has done away with the plate which normally attaches to the back of the screen cutting down the parts you pay for, & dramatically reducing assembly time onsite. Strong Machined Parts High tolerance cast-alloy brackets & milled thumbscrews slot together neatly to give a secure fit. Paper Templates Included Mildly sticky paper templates with pre-printed VESA layouts assist with positioning of brackets on the wall. Spirit Level Included Vision

Includes:: a calibrated level to help make sure everything is level. Close to Wall Just a mere 10mm away from the wall & comes with wall attachment fixtures for large & small TVs. Specifications BOX

Dimensions 130 x 90 x 55mm PACKAGED WEIGHT 0.5kg SAFE WORKING LOAD 4 x 12.5kg = 50kg COLOUR Alluminium ACCESSORIES INCLUDED 4 x M4x 12 Thumb-screw Bolts 4 x M5x 12 Thumb-screw Bolts 4 x M6x 14 Thumb-screw Bolts 4 x M8x 16 Thumb-screw Bolts 4x ST8x 50 Screws with M8 square washers 4x RT expansion tube 6.5x 45 4x ST4x 25 Screws with M4 square washers 4x RT expansive tube 4x 30 1 x Large Paper Template 1 x Small Paper Template 1 x Spirit Level with plastic clip WARRANTY: 2-year return to base



...

The TM-TELE Techmount is a projector ceiling bracket for anchoring any data projector safely to a ceiling. The telescopic design allows fast deployment & adjustment without the need cut & drill the pole. It has a greater range than most other telescopic mounts & the pole can be removed for “flush-mounting” the projector as close to the ceiling as possible. Note: unlike the TM-1200 the length of this bracket cannot be extended. One-Man Installation Thoughtful design detail include a length adjustment clamp system which requires only one h&. Sloping Ceilings A tilting mechanism is included which tilts to a full 90 degrees, allowing you to use the bracket as a boom if need be. Safety Approved A back-up fall-arrest tether is included which secures the projector to your bracket, & the pole has a mechanical stop so that the two parts of the pole cannot be separated. Vision recommends a maximum safe working load of 10kg which is well within the limits of the product & meets the BSi installation standard

Specification (PAS122:2009). Easy fit Projectors have threaded inserts in the bottom for attachment – but not all use the same diameter screws so Vision

Includes:: a selection to suit most projectors. Simply locate the “spider” arms on our bracket over the attachment holes, & insert a screw into the projector. Obstruction-free Cable Management Vision’s unique ‘chute-through’ system leaves cable access clear – even for big VGA connectors. Tools Included A spanner & pin-hex key are included. Vision also

Includes:: a hex-key bit for a power drill to speed up installation. Secure Quick-release mechanisms make life easier for thieves, so the TM-TELE is secure & features security bolts.





...
