TRENDnet’s 48-Port Gigabit Web Smart Po E+ Switch, model TPE-4840WS, offers 12 x Gigabit Po E+ ports (ports 1-12 802.3at), 12 x Gigabit Po E ports (ports 13-24 802.3af), 24 x Gigabit ports (ports 25-48), 4 x shared SFP slots (shared with ports 45-48), & a Po E Power budget of 370 Watts. This IPv 6 ready switch offers advanced traffic management, troubleshooting, access control, energy saving GREENnet, & monitoring features at a reduced cost. Hardware Design Provides 12 x Gigabit Po E+ ports (ports 1-12 802.3at), 12 x Gigabit Po E ports (ports 13-24 802.3af), 24 x Gigabit ports (ports 25-48), 4 x shared SFP slots (shared with ports 45-48), a Po E Power budget of 370 Watts, &

Includes:: rackmount brackets. Smart Fan Smart fan saves energy by varying fan speed & use based on cooling needs. IPv 6 Ready This switch supports IPv 6 configuration & IPv 6 neighbor discovery. Traffic Management A broad range of network configurations are supported by: 802.3ad link aggregation, Asymmetric VLAN, 802.1Q VLAN, Voice VLAN, Private VLAN, Bandwidth Controls, GVRP, IGMP v 1-v 3, 802.1p Class of Service (Co S), Spanning Tree (STP, RSTP, & MSTP), & Qo S queue scheduling. Troubleshooting Real time traffic comparison charts, error group charts, & a convenient cable diagnostic test aid in rapid troubleshooting. Access Controls Features such as ACL, SSL, MAC/port filtering, Denial of Service controls, 802.1X, TACACS+, & RADIUS are compatible with layered network access controls. Monitoring RMON, SNMP, SNMP Trap, & Port Mirroring support administrator monitoring solutions. Features 12 x Gigabit Po E+ ports 12 x Gigabit Po E ports 24 x Gigabit ports & 4 shared SFP slots 370 Watt Po E budget 96 Gbps switching capacity Private/ Voice VLAN, Qo S, & bandwidth controls Smart fans reduce energy consumption Rack mount brackets included Please note: networking components such as switches, routers & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com.

...

TRENDnet’s Gigabit Po E+ Repeater, model TPE-E100, extends a Gigabit Po E/ Po E+ network connection to a remote location. It auto-detects a Po E (15.4 Watts) or Po E+ (30 Watts) signal & extends it an additional 100 meters (328 ft.) for a total distance of up to 200 meters (656 ft.) from the Po E device. Daisy chain two TPE-E100s for a total Po E network extension of 300 m (980 ft.)*. Handy mounting points & no external power adapter facilitate remote installations. Extension Distance Extends a Po E/ Po E+ network connection an additional 100 (328 ft.) meters for a total distance of up to 200 meters (656 ft.) from the Po E device Po E/ Po E+ Auto detects a 15.4 Watt Po E (IEEE 802.3af class 1-4) or 30 Watt Po E+ (IEEE 802.3at) network connection Gigabit Ports Gigabit ports extend a high performance wired connection Daisy Chain Daisy chain two TPE-E100s for a total Po E network extension of 300 m (980 ft.) Plug & Play Plug & play Po E/ Po E+ network cables Po E Powered No external power required—saves installation time & cost Mounting Wall mounting points for remote installations LED indicators LED indicators confirm Po E & network connectivity Housing Rugged metal enclosure Features Extends 100 meters for a total distance of up to 200 meters (656 ft.) Daisy chain two TPE-E100s for a total Po E+ network extension of 300 m (980 ft.) Plug & play installation No external power required Wall mountable LED indicators Rugged metal housing ...

TRENDnet’s Gigabit Po E+ Repeater, model TPE-E100, extends a Gigabit Po E/ Po E+ network connection to a remote location. It auto-detects a Po E (15.4 Watts) or Po E+ (30 Watts) signal & extends it an additional 100 meters (328 ft.) for a total distance of up to 200 meters (656 ft.) from the Po E device. Daisy chain two TPE-E100s for a total Po E network extension of 300 m (980 ft.)*. Handy mounting points & no external power adapter facilitate remote installations. Extension Distance Extends a Po E/ Po E+ network connection an additional 100 meters for a total distance of up to 200 meters (656 ft.) from the Po E device Po E/ Po E+ Auto detects a 15.4 Watt Po E (IEEE 802.3af class 1-4) or 30 Watt Po E+ (IEEE 802.3at) network connection Gigabit Ports Gigabit ports extend a high performance wired connection Daisy Chain Up to 7 units for a Po E+ (802.3at) network connection Up to 4 units for a Po E (802.3af) network connection Plug & Play Plug & play Po E/ Po E+ network cables Po E Powered No external power required—saves installation time & cost Mounting Wall mounting points for remote installations LED indicator LED indicator confirms power Housing Rugged metal enclosure Features Extends 100 meters for a total distance of up to 200 meters (656 ft.) Daisy chain up to 7 units for a total Po E+ network extension of 800 m (2, 600 ft.) * Plug & play installation No external power required Wall mountable Rugged metal housing ...

TRENDnet’s 16-Port 30 Watt 10/100 Mbps Po E+ Switch, model TPE-T160, reduces equipment & installation costs by delivering data & power over existing Ethernet cables. The IEEE 802.3at Po E+ standard supplies up to 30 watts of power per port for devices such as high power wireless access points, PTZ (Pan Tilt Zoom) Network Cameras, & Vo IP telephony systems. Auto sensing technology delivers up to 30 watts to 802.3at Po E+, 15 watts to 802.3af Po E, & only data to non-Po E devices. GREENnet technology reduces energy costs by up to 75% when the switch is not in use. Boost office efficiency & reduce network congestion with a total switching capacity of 3.2 Gbps. LED indicators display device status for easy power management & troubleshooting. An internal power supply reduces clutter & a convenient on/off button is located on the back of the switch. Use this switch with TRENDnet Po E Splitters to install non-Po E devices in remote locations. Features IEEE 802.3at & IEEE 802.3af Power over Ethernet (Po E) compliant Support Po E class 2 (7 watts), 3 (15.4 watts), & 4 (30 watts) 16 x 10/100 Mbps Auto-MDIX Po E+ ports Provides 30 watts per Po E port 3.2 Gbps switching fabric On/off power switch Full wire-speed non-blocking switching Store-&-forward switching method Back pressure Flow Control for half-duplex mode IEEE 802.3x Flow Control for full-duplex mode 1.25 Mbits RAM Data Buffer 4K MAC address entries 500 watt Internal Power supply: AC input (90~260V/AC, 50~60 Hz) Plug & Play Sturdy 1U 19” rack mountable metal enclosure 3-year limited warranty Please note: networking components such as switches, routers & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

The 16-Port 10/100 Mbps Po E+ Switch, model TPE-T160H, delivers data & power over existing Ethernet cables to Power over Ethernet (Po E) devices such as Access Points & IP Cameras. It supplies up to 30 Watts of power per port with a 250 Watt power budget. A convenient on/off button is located on the back of the switch & a rack mount kit is included. Hardware Po E+ Supplies up to 30 Watts of Po E power per port with a 250 Watt power budget Ports 16 x 10/100 Mbps Po E+ ports Switching Capacity 3.2 Gbps switching capacity Rack Mountable Rack mountable metal enclosure with included mounting kit On/ Off Convenient on/off switch LED Indicators LED indicators convey port status ...

The 8-Port 10/100 Mbps Po E+ Switch, model TPE-T80H, delivers data & power over existing Ethernet cables to Power over Ethernet (Po E) devices such as Access Points & IP Cameras. It supplies up to 30 Watts of power per port with a 125 Watt power budget. A convenient on/off button is located on the back of the switch & a rack mount kit is included. Hardware Po E+ Supplies up to 30 Watts of Po E power per port with a 125 Watt power budget Ports 8 x 10/100 Mbps Po E+ ports Switching Capacity 1.6 Gbps switching capacity Rack Mountable Rack mountable metal enclosure with included mounting kit On/ Off Convenient on/off switch LED Indicators LED indicators convey port status ...

. rpd-row { overflow:hidden; padding:30px 0; border-bottom: 1px solid eee; }. rpd-row img { max-
Width:100%; }. rpd-left
...

TRENDnet’s 8-Port Gigabit Po E+ Switch, model TPE-TG80g, offers 8 x Gigabit Po E+ ports (30 Watts/port), a 16 Gbps switching capacity, & a Po E power budget of 123 Watts. Plug & Play this sturdy metal switch for reliable high speed Po E networking. Features Po E+ Supplies up to 30 Watts of Po E power per port with a 123 Watt power budget Ports 8 x Gigabit Po E+ Ethernet ports Switching Capacity 16 Gbps switching capacity Jumbo Frame Sends Jumbo Frames (up to 9 Kbytes) for increased performance Energy Savings Embedded GREENnet technology reduces power consumption Housing Rugged metal enclosure LED Indicators LED indicators convey port status ...

TRENDnet’s 8-Port Gigabit GREENnet Po E+ Switch, model TPE-TG81g, reduces equipment & installation costs by delivering data & power over existing Ethernet cables. This unmanaged switch offers eight Gigabit Po E+ ports which supply up to 30 watts of power per port for devices such as high power wireless access points, PTZ (Pan / Tilt / Zoom) Network Cameras, & Vo IP telephony systems. This rack mountable switch features an internal power supply. Auto sensing technology delivers 30 watts to 802.3at Po E+ devices (up to 3 devices), 15 watts to 802.3af Po E devices, & only data to non-Po E devices. GREENnet technology reduces energy consumption by up to 75% when the switch is not in use. Boost office efficiency & reduce network congestion with a total switching capacity of 16 Gbps. LED indicators display device status for efficient troubleshooting. This switch comes in a sturdy metal case & quickly adds Po E+, Po E, & non-Po E devices to your network. Features IEEE 802.3at & IEEE 802.3af Power over Ethernet (Po E) compliant Supports Po E Class 2 (7 watts), 3 (15.4 watts), & 4 (30 watts) 8 x Gigabit Auto-MDIX Po E / Po E+ ports Internal power supply Up to 75% GREENnet energy savings Provides up to 30 watts for Po E+ (3 ports max.) Provides up to 15.4 watts for Po E Automatically detects the Po E class level of a Powered Device 16 Gbps switching fabric Forwarding rate: 1000 Mbps / 1, 488, 000pps; 100 Mbps / 148, 800 pps; 10 Mbps / 14, 880 pps Status LEDs: System Power, Po E, 1000 Mbps, & Link / Activity 2K Mac address entries 96 Kbyte memory buffer Full wire-speed non-blocking reception & transmission Store-&-forward switching method Back pressure Flow Control for Half-Duplex mode IEEE 802.3x Flow Control for Full-Duplex mode Power saving technology powers down unused ports & when a connected device is in standby mode Jumbo Frame support up to 9 Kbytes Plug & Play Sturdy rack mountable metal case 3-year limited warranty Please note: networking components such as switches, routers & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

The Powerline 200 AV Nano Adapter, model TPL-308E, uses an electrical outlet to create a secure high speed network. Two adapters are needed to start a network. Connect one adapter to your router & plug another adapter into an outlet on your electrical system for instant high speed network access. The compact form factor saves space around crowded electrical outlets. This adapter automatically connects to other TRENDnet Powerline AV adapters with no installation required —TRENDnet recommends pressing the ‘ Sync’ button to automatically change default encryption keys. Use up to 4 adapters to network devices in different rooms without running new cabling. Power Save mode reduces power consumption by up to 70%. Quality of Service technology prioritizes video, audio, & online gaming. LED displays convey device status for easy troubleshooting. Advanced 128-bit AES encryption secures your network. This adapter is ideal to be used in buildings that interfere with wireless networking signals. ...
