Features Easily support your professional software application base with comprehensive ISV certifications. Experience fluid interactions with your 3D models & datasets with 2 GB of DDR3 memory. Get low-profile, single-slot 3D performance that fits within your most compact workstation chassis, & the entire HP Z Workstation lineup, & doesn’t require external power. Drive displays with ultra-high resolutions like 4096 x 2160 @ 60 Hz with 30-bit color & easily manage them with NVIDIA Mosaic & NVIDIA n View technologies. The NVIDIA Quadro K620 2GB is supported on the following HP Z Workstations: Z230 CMT, Z440, Z640, Z840 Overview Enjoy impressive application performance for your more demanding 3D models & datasets with the NVIDIA Quadro K620 graphics card & its 2 GB dedicated memory.

Specification Compatibility The NVIDIA Quadro K620 2GB is supported on the following HP Z Workstations: Z230 CMT, Z440, Z640, Z840

Dimensions Out of Package: 6.89 x 16 cm

Dimensions (case or master carton, metric): 597 x 198 x 250 mm Case or master carton quantity: 10 Count of cartons per pallet layer: 10 Count of layers in pallet: 8 Quantity per Pallet: 800 Packed: 184 x 232 x 57.5 mm Weight Out of Package: 0.133kg Warranty The NVIDIA Quadro K620 has a one-year limited warranty or the remainder of the warranty of the HP product in which it is installed. Technical support is available seven days a week, 24 hours a day by phone, as well as online support forums. Parts & labor are available on-site within the next business day. Telephone support is available for parts diagnosis & installation. Certain restrictions & exclusions apply. Additional information P/N: J3G87AA UPC/EAN code: 888793835791 Country of Origin China Whats in the box NVIDIA Quadro K620 2GB Graphics Card; Low Profile bracket; DP to DVI-D adapter; Documentation





...

Nvidia Quadro M2000 4GB GDDR5 Display Port PCI-E Graphics Card he Quadro M2000 delivers an incredible creative experience across a broad range of professional 3D applications. This advanced graphics board features an NVIDIA Maxwell-based GPU, 4GB of ultra-fast on-board memory & the power to drive four 4K displays natively. This makes it an excellent choice for accelerating product development & content creation workflows that demand fluid interactivity with complex models & scenes. Creative professionals can tap into this increased performance – as well as hardware HEVC encode & decode engines—to accelerate both creation & playback of HEVC content. Designed & built specifically for professional workstations, NVIDIA Quadro GPUs power more than 100 professional applications across a broad range of industries including manufacturing, media & entertainment, sciences, & energy. Professionals trust them to realize their most ambitious visions— whether its product design, visualization & simulation, or spectacular visual storytelling—and get results to market faster. To learn how NVIDIA Quadro & Iray enabled interactive physically based rendering can dramatically transform design workflows click here to receive a complementary Desktop Engineering whitepaper (registration required). Product Specifications CUDA Cores 768 GPU Memory 4GB GDDR5 Memory Interface 128-bit Memory Bandwidth 106GB/s System Interface PCI Express 3.0 x 16 Maximum Power Consumption 75 W Energy Star Enabling Yes Thermal Solution Ultra-quiet active fansink Form Factor 4.376” H x 6.6” L, Single Slot Display Connectors DP 1.2 (4) Display Port 1.2 Yes Display Port with Audio Yes DVI-D Dual Link Connector Via optional 3rd party adapter DVI-D Single-Link Connector Via included adapter (1 only) Number of Displays Supported 4 Maximum DP 1.2 Resolution 4096 x 2160 at 60 Hz Maximum DVI-D DL Resolution 2560 x 1600 at 60 Hz Maximum DVI-D SL Resolution 1920 x 1200 at 60 Hz HDCP Support Yes Graphics APIs Shader Model 5.0, Open GL 4.5, Direct X 12 Compute APIs CUDA, Direct Compute, Open CL NVIEW Yes NVIDIA Mosaic Yes (Windows 10, 8.1, 8, 7, Vista, Linux) Warranty 3 Years PNY Part Number VCQM2000-PB Minimum System Requirements Microsoft Windows 10, 8.1, 8, 7, Vista, Linux, or Solaris PCIe x 16 Gen 3 (preferred) expansion slot 2 GB or more of system memory, 8 GB recommended 200MB of available disk space for full driver installation Blu-ray or DVD-ROM drive Internet connection (if preferred for driver installation) Display Port, DVI, or VGA compatible display (s) ...

Features Experience ultra-fast visualization & compute horsepower with 4GB ultra-fast GDDR5 memory & CUDA parallel processing. Drive up to four 4K or two 5k displays or one 8K projector with four Display Port 1.2 ports & managed them with included NVIDIA Mosaic™ & NVIDIA n View technologies. Enable immersive collaboration with optional 3D Vision™ & 3D Vision Pro. Boost application performance in real time while staying within the power & thermal envelope of the card with NVIDIA GPU Boost. Easily support your professional software application base with comprehensive ISV certifications. Compatible with Z240 CMT, Z440, Z640, Z840. Overview Get fast performance & work interactively with models & scenes across CAD, DCC, & medical applications with the new Maxwell GPU architecture features of the flexible, single-slot NVIDIA Quadro M2000 graphics card.

Specification Weight 8.43 oz (0.23 kg)

Dimensions (W x D x H) 4.37 x 6.6 in (110 x 167 mm) Whats in the box Graphics Card; Documentation Warranty The NVIDIA Quadro M2000 has a one-year limited warranty or the remainder of the warranty of the HP product in which it is installed. Technical support is available seven days a week, 24 hours a day by phone, as well as online support forums. Parts & labor are available on-site within the next business day. Telephone support is available for parts diagnosis & installation. Certain restrictions & exclusions apply.



...

Features NVIDIA Quadro M4000 with NVIDIA Quadro Sync— Ideal for Extreme Performance Single-Slot Form Factor Visualization Environments Get real interactive expression with NVIDIA Quadro—the world’s most powerful workstation graphics. Tackle your most demanding visualization workloads with ease using the advanced NVIDIA Maxwell™ GPU architecture & the flexibility of a single-slot form factor. 8 GB of ultra-fast memory enables the creation & rendering of large, complex models & the computation of massive datasets. A new display engine drives up to four 4K resolutions displays natively (4096 x 2160 at 60 Hz with 30-bit color), or pair up two or more outputs to drive displays greater than 4K. The NVIDIA Quadro Sync board included as part of this turnkey solution synchronizes up to four NVIDIA Maxwell architecture-based GPUs & up to 16 displays or projectors per system. Quadro Sync benefits include the ability to keep multi-projector systems or video walls free of imaging artifacts without impacting performance, the ability to align inputs for multi-input display devices like 4K projectors or panels, proper stereoscopic 3D display across multiple systems, & the ability to align displays or projectors to an external timing source. NVIDIA Mosaic™ technology support allows any application to scale across synchronized displays or projectors & offers features like projector overlap & an integrated geometry & intensity adjustment to enable pixel-accurate display surfaces. Designed & built specifically for professional workstations, NVIDIA Quadro GPUs power more than 200 professional applications across a broad range of industries including manufacturing, media & entertainment, sciences, & energy. Professionals trust them to realize their most ambitious visions— whether its product design, visualization & simulation, or spectacular visual storytelling—and get results to market faster. Overview CUDA Cores 1664 GPU Memory 8 GB GDDR5 Memory Interface 256-bit Memory Bandwidth 192 GB/s System Interface PCI Express 3.0 x 16 Display Connectors DP 1.2 (4) + Stereo Maximum Number of Displays Four Quadro Sync Connectors RJ-45 Framelock + RJ-45 Framelock + BNC Genlock Mosaic Technology Yes, Windows 10, 8.1, 8, 7, & Linux Warranty 3 Years PNY Part Number VCQM4000SYNC-PB Minimum System Requirements Microsoft Windows 10, 8.1, 8, 7, Vista, Linux, or Solaris PCIe x 16 Gen 3 (preferred) expansion slot 2 GB or more of system memory, 8 GB recommended 200MB of available disk space for full driver installation Blu-ray or DVD-ROM drive Internet connection (if preferred for driver installation) Display Port, DVI, or VGA compatible display (s) Package Contains NVIDIA Quadro M4000 professional graphics board Stereo connector bracket 6-pin auxiliary power cable NVIDIA Quadro Sync board Four ribbon connector cables Three cable retention clips Software installation disc for Windows 10, 8.1, 8, 7, & Vista (32- & 64-bit) Printed Quick Start Guide

Specification CUDA Cores 1664 GPU Memory 8 GB GDDR5 Memory Interface 256-bit Memory Bandwidth 192 GB/s System Interface PCI Express 3.0 x 16 Maximum Power Consumption 120 W Energy Star Enabling Yes Thermal Solution Ultra-quiet active fansink Form Factor 4.40” H x 9.50” L, Single Slot Display Connectors DP 1.2 (4) + Stereo Display Port 1.2 Yes Display Port with Audio Yes DVI-D Dual Link Connector Via optional adapter DVI-D Single-Link Connector Via optional adapter Number of Displays Supported 4 Maximum DP 1.2 Resolution 4096 x 2160 at 60 Hz HDCP Support Yes Professional 3D Support Yes, via included stereo connector bracket Quadro Sync Compatible Yes NVIDIA GPU Direct Compatible Yes Graphics APIs Shader Model 5.0, Open GL 4.5, Direct X 12 Compute APIs CUDA, Direct Compute, Open CL NVIEW Yes NVIDIA Mosaic Yes (Windows 10, 8.1, 8, 7, & Linux) NVIDIA 3D Vision & 3D Vision Pro Yes Quadro Sync Connectors RJ-45 Framelock + RJ-45 Framelock + BNC Genlock Quadro Sync Thermal Solution Passive heatsink Quadro Sync Power 6-pin PCIe or SATA power cable Warranty 3 Years PNY Part Number VCQM4000SYNC-PB

...

Featuring NVIDIA’s n View display management software, Quadro NVS business graphics solutions deliver maximum flexibility for single or multi-display options. With productivity enhancing features such as extended Windows Taskbar that spans across multiple displays, gridlines that divide a single large or a multiple display set up into smaller sub-displays, virtual desktops that seamlessly reduce desktop clutter, & profiles that assist with enterprise deployments – users are provided with unprecedented control of the desktop experience. Plus, Quadro NVS solutions are tested for compatibility with industry-leading business applications to meet the needs of today’s most demanding business users. ...

Features CUDA Cores 3840 Peak Single Precision FP32 Performance 12.0 TFLOPS GPU Memory 24 GB GDDR5X Memory Interface 384-bit Memory Bandwidth 432 GB/s System Interface PCI Express 3.0 x 16 Display Connectors DP 1.4 (4) + DVI-D DL (1) + Stereo Overview UNMATCHED POWER. UNMATCHED CREATIVE FREEDOM. NVIDIA QUADRO P6000—THE WORLD’S MOST POWERFUL WORKSTATION GRAPHICS SOLUTION. The NVIDIA Quadro P6000 is the most advanced pure professional graphics solution ever created, combining the latest GPU, memory & display technologies that result in unprecedented performance & breakthrough capabilities. Professionals across a range of industries can now create their most complex designs, solve the most challenging visualization problems & experience their creations within the most detailed, lifelike & immersive VR environments. in addition, you can create massive digital signage solutions by connecting multiple P6000s via Quadro Sync II. Designs become more complex over time. Visual effects grow in size, complexity, & scope. Scientific visualization & compute problems continue to push the boundaries of workstation capabilities. VR is changing all facets of entertainment, design, engineering, architecture, & medicine. As professional workflows grow in size & complexity, the demand for visual compute power grows with it. Quadro P6000’s Pascal architecture GPU implementation, GDDR5X memory & Display Port 1.4 support synergistically deliver the best overall single precision FP32 performance & professional graphics solutions. The P6000 enables users to create large, complex designs, interactively render photorealistic imagery, & create detailed, lifelike VR experiences.

Specification CUDA Cores 3840 Peak Single Precision FP32 Performance 12.0 TFLOPS Multi-GPU Scalability NVIDIA SLI HB GPU Memory 24 GB GDDR5X Memory Interface 384-bit Memory Bandwidth 432 GB/s System Interface PCI Express 3.0 x 16 Maximum Power Consumption 250 W Energy Star Enabling Yes Thermal Solution Ultra-quiet active fansink Form Factor 4.40” H x 10.50” L, Dual Slot Display Connectors DP 1.4 (4) + DVI-D DL + Stereo Display Port with Audio Yes DVI-D Single-Link Connector Via included adapter HDMI Support Via optional adapters VGA Support Via optional adapters Number of Displays Supported 4 Maximum DP 1.4 Resolution HDR 7680 x 4320 at 30 Hz (30-bit color) 5K Display Support HDR 5120 x 2880 at 60 Hz (30-bit color) 4K Display Support HDR 4096 x 2160 at 60 Hz or 3840 x 2160 at 60 Hz Maximum DVI-D DL Resolution 2560 x 1600 at 60 Hz via 3rd party adapter Maximum DVI-D SL Resolution 1920 x 1200 at 60 Hz via included adapter HDCP Support Yes Professional 3D Support Yes, via included stereo connector bracket Quadro Sync II Compatible Yes (Frame Lock & Genlock) NVIDIA GPU Direct Compatible Yes Graphics APIs Shader Model 5.1, Open GL 4.5, Direct X 12.0, Vulkan 1.0 Compute APIs CUDA, Direct Compute, Open CL NVIEW Yes NVIDIA MOSAIC Yes (Windows 10, 8.1, 8, 7, & Linux) Warranty 3 Years

...

NVIDIA QUADRO RTX 4000 Real Time Means Real Change Meet today’s demanding professional workflows with GPU accelerated ray tracing, deep learning, & advanced shading. The NVIDIA Quadro RTX™ 4000, powered by the NVIDIA Turing™ architecture & the NVIDIA RTX™ platform, delivers best in-class performance & features in a single-slot PCI-e form factor. Design & create like never before with faster time to insight & faster time to solution. BUILT FOR PROFESSIONALS The Quadro RTX 4000 is designed, built, & tested for demanding professional visual computing workflows. Validated in OEM workstations & certified for professional software applications, Quadro provides the performance, stability, & reliability required by professionals.

Specification RTX 4000 CUDA Parallel-Processing Cores 2, 304 NVIDIA Tensor Cores 288 NVIDIA RT Cores 36 GPU Memory 8 GB GDDR6 RTX-OPS 43T Rays Cast 6 Giga Rays/ Sec FP32 Performance 7.1 TFLOPS Max Power Consumption 160 W Graphics Bus PCI Express 3.0 x 16 Display Connectors DP 1.4 (3), Virtual Link (1) Form Factor 4.4" (H) x 9.5" (L) Single Slot

...

NVIDIA Quadro RTX 5000 The Worlds First Ray Tracing GPU Shatter the boundaries of whats possible with NVIDIA Quadro RTX 5000. Powered by the NVIDIA Turing architecture & the NVIDIA RTX platform, it fuses ray tracing, deep learning & advanced shading to supercharge next-generation workflows. Creative & technical professionals can make more informed decisions faster & tackle demanding design & visualization workloads with ease. New RT Cores & Tensor Cores bring the power of real-time ray tracing & AI-enhanced workflows to millions of design & creative professionals. Combined with NVIDIA NVLink„¢ technology, RTX 5000 scales graphics memory & performance to drive the most demanding rendering, AI, & visual computing workloads. & the all-new Virtual Link provides connectivity to next-generation, high-resolution VR HMDs to let you view your work in the most compelling virtual environments. Welcome to the future of professional visual computing. CUDA Cores 3072 NVIDIA RT Cores 48 NVIDIA Tensor Cores 384 GPU Memory 16 GB GDDR6 with ECC RTX-OPS 62T Rays Cast 8 Giga Rays/ Sec Peak Single Precision FP32 Performance 11.2 TFLOPS Peak Half Precision FP16 Performance 22.3 TFLOPS Peak Integer Operations INT8 Performance 178.4 TOPS Deep Learning TFLOPS 89.2 TFLOPS Memory Interface 4096-bit Memory Bandwidth 448 GB/ Sec System Interface PCI Express 3.0 x 16 Display Connectors DP 1.4 (4) + DVI-D DL (1) + Virtual Link (1) ...
