Ceiling or Wall Mounted AX 3600 Mesh Wireless Po E Access Point Vigor AP 1060C is a high-performance ceiling mounted Mesh Wireless solution, offering up to 3.6 Gbps Dual-Band wireless performance, & up to 2.5 Gb Ethernet connectivity. Its third dedicated radio helps with auto channel selection, & Wireless Intrusion Detection Systems (WIDS). Wi-Fi 6
- Fast & Efficient A high performance Wi Fi 6 product with combined speeds up to 3600 Mbps. The Vigor AP 1060C raw power & Wi Fi 6's improvements in lag, efficiency & interference compared to Wi Fi 5 give speed benefits for both 2.4 G Hz & 5 G Hz connected Wi Fi 6 clients. Mesh Wireless & Root AP Management Dray Tek's Mesh system intelligently manages & links wireless Vigor A Ps, with guest network & VLAN support. Root AP allows to add further Vigor APs with a total number of 50. Easy to Configure & Manage The Dray Tek Wireless app simplifies setting up your network. Optionally configure & monitor through one of Dray Tek's management platforms
- Vigor ACS cloud, Vigor Connect, Router AP Management, or directly via the AP's Web Interface. 2.5 Gigabit Power Over Ethernet The Vigor AP-1060C can be powered through its 2.5 Gb Ethernet boosting performance interface with standard IEEE 802.3af Po E, for a tidier & more convenient installation Third Radio for RF Analytics & Security The AP-1060C third radio is dedicated to assist with rogue AP detection, auto channel & power management. It assists with Zero-Wait DFS feature reducing the time needed scan DFS channels. Ceiling Mounting The Vigor AP 1060C with its matte finish blends well with most home & office interiors. Ceiling & wall mounting capable (mounting base included) Features • Wi Fi 6 Mesh Ceiling-mount Mesh Wireless Access Point & Range Extender • AX3600
- 11ax Dual Band Wireless • Third Radio for RF Analytics & Security • WPA3
- Stronger Security with WPA3 Personal & Enterprise • Self-Healing Wireless Mesh with VLAN support • Power through 802.3af Po E or DC power adapter • 2.5 Gb Ethernet Uplink • Centrally Managed or Standalone operation • Advanced Access Control with Mobile Device Management & Station Control • Root AP for AP Management



...

The plug design makes the Vigor AP 802 easy to install & tidy once in place. With a Gigabit LAN port on the underside to connect Wired Ethernet devices into your Mesh network. Initial setup of the Vigor AP 802 is easy with the Dray Tek Wireless app, whether it's joining an existing Mesh network or being set up in AP & Range Extender modes, the Quick Start Wizard assists throughout. Manage the Vigor AP 802 centrally through the Vigor ACS central management platform, Vigor Connect, Router AP Management, or simply on its own as a st&-alone access point. The Vigor AP 802 has the flexibility to be used how you need it. Vigor AP 802 is a high-performance Mesh Wireless Access Point & Range Extender. With a Mesh network, you can easily expand wireless coverage, eliminate Wi-Fi dead zones & significantly reduce the cost of network deployments. Dray Tek's Mesh wireless solution supports VLAN tags, allowing you to provide two distint & separate wireless networks, such as an internal & a guest network, without any cable installation required. The Vigor AP 802 is a Mesh Node to be used in conjunction with a Mesh Root, such as the Vigor AP 903 Mesh Wireless Access Point. It can also be used as a traditional Access Point to provide wireless connectivity for your network. Extend wireless coverage for regular wireless networks without Mesh with the Range Extender mode. This joins the Vigor AP 802 to an existing wireless network, expanding its coverage. The plug design makes the Vigor AP 802 easy to install & tidy once in place. With a Gigabit LAN port on the underside to connect Wired Ethernet devices into your Mesh network. Initial setup of the Vigor AP 802 is easy with the Dray Tek Wireless app, whether it's joining an existing Mesh network or being set up in AP & Range Extender modes, the Quick Start Wizard assists throughout. Manage the Vigor AP 802 centrally through the Vigor ACS central management platform, Vigor Connect, Router AP Management, or simply on its own as a st&-alone access point. The Vigor AP 802 has the flexibility to be used how you need it. Small & Tidy Design The Vigor AP 802 is designed to fit into a power socket, mounting it securely & providing power with an absolute minimum of space required. You can expand wireless coverage quickly & easily with the Vigor AP 802, just plug it into a UK power socket & it's powered with its integrated power supply, no additional cables required. The dual band antennas are hidden within the Vigor AP & its small size makes it inconspicuous in any room. The indicator LEDs of the Vigor AP that normally show the Vigor AP's status, can be disabled or scheduled to avoid them lighting up a room. To check the Vigor AP's status with the LEDs turned off, just press the button on the front for 3 seconds to wake up the LED Gigabit LAN Port The Vigor AP 802 has one wired Ethernet port on the underside of the AP. This is a Gigabit port operating at 1000 Mb/s, backwards compatible with 10/100 devices. Using the Gigabit LAN port is optional, you can use the Vigor AP 802 as a purely wireless Mesh Node, connecting wirelessly to the Mesh network, without the need to use the RJ-45 for connectivity. When operating in AP mode, this ensures that the Vigor AP 802 is fed at the maximum speed in order to fully satisfy the full speed of both 2.4 G Hz & 5 Ghz bands simultaneously. When the Vigor AP 802 is used as a Mesh Node or Range Extender / Wireless Repeater, anything connected to the LAN port is bridged to your wireless network. Dual Band AC1200 Access Point The Vigor AP 802 is an 802.11ac access point, providing wireless coverage for both 2.4 G Hz & 5 G Hz clients simultaneously. This means that devices on the compatible 2.4 G Hz band can communicate with up to 300 Mb/s bandwidth to 802.11b/g/n clients, while the faster 5 G Hz band can provide up to 866 Mb/s to 802.11ac/n capable devices. The Vigor AP can connect up to 32 clients to each wireless radio, up to 64 wireless clients per Vigor AP 802 access point. When used with other Vigor A Ps being managed by a Dray Tek Vigor router, Central AP Management's AP Load Balancing can ensure that wireless clients are shared equally between the access points, giving better overall bandwidth by avoiding overloading of a single access point. Wireless Security & VLANs The Vigor AP 802 features multiple levels of wireless security. Encryption using WPA2 is available & you can also use the access control list (ACL) to specify the hardware addresses of clients which are permitted to connect (by MAC hardware address). Any unauthorised hardware is refused access. For additional user authentication, you can have the Vigor AP 802 authenticate clients with an 802.1x RADIUS (Remote Authentication Dial-in User Service) server. The Vigor AP 802 supports the 802.1q VLAN protocol so that if it is connected to an 802.1q enabled LAN, it can split tagged data (whether it's different subnets or intended for different users) & broadcast each on its own SSID. This means, for example, that your guest Wi Fi access is provided on a separate isolated SSID with no access to your company data. Multi-SSID over Mesh Dray Tek's Mesh system supports 802.1q VLAN tagging for its multiple Wireless networks (or SSIDs), over both wireless & wired Mesh links between Vigor A Ps. Each SSID provided by the Mesh network can have a VLAN tag assigned to it. VLAN tags are interpreted by the network's router & switch (es) to segregate one network from another. For instance keeping devices connecting to a guest network separate from resources on the private, internal network. Setting up a Mesh network to work with VLANs only requires setting up the Mesh Root with the VLAN tags on its SSIDs. This change propagates to Mesh Nodes when syncing the configuration between access points & Multi-SSID over Mesh can be used just like a cabled network of access points. AP & Repeater Modes The Vigor AP 802 can be used as a st&-alone Wireless Access Point, to provide wireless connectivity for a router or network that doesn't currently have wireless. Plug the Vigor AP 802's RJ-45 port into any Ethernet network & plug the AP itself into a wall socket for a tidy & space-efficient wireless solution. Access Point mode can create up to 2 separate Wireless networks (or SSIDs). The Vigor AP 802 can provide completely separate private & guest wireless networks through the use of 802.1q VLAN tags with a router or network that supports VLAN tagging, such as the Dray Tek Vigor 2862 router. Range Extender (or Universal Repeater) mode allows the Vigor AP 802 to extend the wireless coverage of any existing wireless network. In this mode, the Vigor AP 802 connects to a remote wireless network, allowing it to provide Internet & Network access to wireless clients that connect to the Vigor AP 802's wireless network. ...

The Dray Tek Vigor AP 902 is a wireless access point which can be operated in standalone or centrally managed/monitored mode (with the use of a central Dray Tek management product
- see later). The Vigor AP 902 is a high

Specification professional access point providing reliable & flexible coverage to all manner of applications. A vast array of security & management features helps the AP to improve & protect flexibility & integrity of your wireless LAN. The Vigor AP 902 is ideal for adding wireless connectivity to an existing LAN, or for expanding the range of an existing wireless LAN by using the WDS repeater features. Simultaneous Dual-Band Operation & Extended 5 Ghz Bands The Vigor AP 902 supports simultaneous operation of the common 2.4 Ghz band & faster 5 Ghz b&. The 5 Ghz band is far less congested so if your PCs or other devices support the 5 Ghz b&, you can use that. The 5 Ghz band is used for 802.11ac (or optionally 802.11n & 802.11a). The Vigor AP 902 operates both bands at the same time, allowing your devices to use either band & each has its own bandwidth so overall wireless capacity is also increased. The 5 Ghz interface supports the full range of extended domestic 5 Ghz channels, thank to its support for DFS/TPC; you can select all 5 Ghz channels up to channel 140, as opposed to just the 4 Band A-Lower channels (which provides only two non-overlapping channels). It has support for Band Steering which can be configured to guide clients that are able to connect to 5 G Hz wireless networks onto this band instead of the more congested 2.4 G Hz b&, which results in client connections being shared between the two frequencies more evenly, potentially increasing the number of wireless clients that can be connected to each Vigor Access Point. Gigabit Ethernet Ports The Vigor AP 902 has five wired Ethernet ports (separated into two distinct separated LANs). LAN A & LAN B can be fed separately & in turn broadcast on independent & isolated SSIDs. As the ports are all Gigabit, you can be sure that the AP is fed at the maximum speed in order to fully satisfy the full speed of both 2.4 G Hz & 5 Ghz bands simultaneously. The four ports on LAN A are particularly of use if you are using the AP as a wireless bridge as you can then connect wired PCs or devices to it. LAN Port 3 on LAN-A is also used as the Po E input if youre powering the AP by Po E.


...

Vigor AP 903 is a high-performance Mesh Wireless solution, designed to expand the wireless coverage, eliminate Wi-Fi dead zones & significantly reduce the cost of network deployments. It can also be used as a traditional access point either managed or stand alone so has the flexibility to be used how you need it. The Vigor AP 903 is a dual-band 802.11ac Wave 2 Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal & Wi-Fi dead zones. One access point acts as the controller (Mesh root) & in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling. Dray Tek Mesh Wireless Mesh Wireless links Vigor AP access points across both Wi-Fi & Wired links to cover a large area with a single Wireless network, spanning multiple Wireless Access Points & easily managed from the Mesh Root Vigor AP or with the Dray Tek Wireless app. The Mesh Root Vigor AP links up to your existing Internet router, such as the Dray Tek Vigor 2862 & additional Vigor A Ps join up as Mesh Nodes, which connect wirelessly to the Mesh Root. Your devices see a single Wi-Fi network (SSID) & connect to the nearest Vigor AP in the Mesh, instead of a distant Wi-Fi network with low signal. Internet connectivity relays through the Mesh, using the up to 866 Mbps 5 G Hz wireless as the backhaul link, to relay between Mesh Nodes & avoid long waits for downloads. New Interface with Dashboard View The Vigor AP 903 features a new web interface designed for use with tablets, phones & PCs, adapting to suit any device. Dashboard view gives a detailed overview of the Vigor A Ps status at a glance, see individual connected clients & their traffic usage, ports in use & the utilisation of the Vigor AP. Easy Setup with the Dray Tek Wireless app The new Dray Tek Wireless app assists you with setting up the Vigor AP 903 access points & Mesh Wireless network. Once installed on your Smartphone or Tablet, use the Quick Start Wizard to adopt & set up your Vigor AP 903 as an Access Point, Range Extender, or a group of Vigor A Ps in a Mesh Wireless network. Simply scan the access point&128;&153;s QR code to detect it, or manually input the Vigor A Ps default SSID & password, then configure your wireless network with step-by-step guidance. When it&128;&153;s all set up, view the Mesh Wireless status & connected wireless clients from the app. Central Management with Dray Tek Vigor ACS The Dray Tek Vigor AP 903 can be managed by the Dray Tek vigor ACS central management system
- a cloud platform which can manage most Dray Tek products
- routers, wireless access points & Ethernet switches, giving you complete visibility & control of your Dray Tek product estate, even without a Dray Tek Vigor router on site. The Dray Tek Vigor ACS management system can be used to configure & provision Dray Tek Vigor AP access points, similarly to performing these actions through the Vigor A Ps web interface, with a familiar menu layout in the Configuration section of Vigor ACS. Profiles for groups of access points can be provisioned in Vigor ACS by selecting a Vigor ACS network, then accessing Configuration > AP Profile to configure profiles & apply them selectively. Dray Teks Vigor ACS management monitors the Vigor AP 903, with a Dashboard view giving a central overview of the most important information from the Vigor A Ps current status. Central Management with a Dray Tek Router The Vigor AP 903 can operate in standalone autonomous mode, but can also form part of a centrally managed wireless installation by adding a compatible Dray Tek wireless controller such as the Vigor 2862 router. This enables you to centrally control, manage & administer multiple AP devices installed around your building/campus. Management also enables efficient usage of your wireless access point through load-balancing, whereby wireless clients are distributed across several access points to reduce congestion. The Dray Tek router operating as the wireless controller can provision Dray Tek Vigor AP access points using the Central AP Management profiles configured on the router, with an option to Auto Provision
- auto configuring newly installed Vigor AP access points with the Auto Provisioning profile, upon initial connection to the Dray Tek Vigor routers network.


...

Vigor AP 906 is 11ax wall-mount/desktop wireless access point with a 5-port LAN switch. With wire-liked link rate up to 2402 Mbps in 5 G Hz band & up to 574 Mbps in 2.4 G Hz b&, it’s suitable for high density environments. It can be cloud-managed by Vigor ACS*, & also act as the mesh Root AP to manage up to 7 mesh node APs in LA. Po E Power Supply Simplify the infrastructure by getting data & power through a single cable Multiple SSID Mapping Wi-Fi clients to different VLANs & have a different set of security standards Wi-Fi Scheduling Schedule Wi-Fi On & Off to control wireless access & save energy. Local RADIUS Server User profile database for local & external 802.1x authentication. Airtime Fairness Equalize the transmission time of each client so the legacy devices wont slow everyone down. Hotspot Web Portal Market your business & communicate with the guests while offering hospitality WLAN Band Steering Redirect 5 G Hz-capable devices to the 5 G Hz radio to get a faster speed. Central AP Management Manage, maintain, & monitor Vigor AP 906 from the Dray Tek routers Assisted Wi-Fi Roaming Solve the sticky client problem & improve Wi-Fi roaming experience. Mesh (Wireless model only) Easily link to other Vigor AP to expand the wireless network Utilize Transmission Opportunity with OFDMA OFDMA has been used in LTE for many years, & is now available in 802.11ax for multi-user mode. Traditionally with OFDM, each frame is transmitted across the entire channel width. With low-rate transmission still using the whole channel, it brings latency & jitter to others & lower the overall efficiency. OFDMA splits a single transmission into groups of subcarriers, & each subcarrier can be used by different client. With multiple clients transmitting simultaneously in the same channel, it improves efficiency of every single transmission opportunity & thus increases the wireless experiences in high density environment. Making Transmission Effective Disassociate the Wireless clients who are out of the effective transmission range defined by custom Basic Rate or/and RSSI threshold, & force them to pick up another access point with a stronger signal. Resource Saving Proactively kick out the clients with a low basic rate or low RSSI can prevent the access points trying to do ineffective transmission but saving the airtime, which will results in better WLAN experience for all. No Controller Required Assisted Roaming is a feature built in all Vigor Access Points & selected Wireless routers. They operate without a wireless controller, providing an ideal solution for simple network deployment. Stronger Signal Guaranteed By using the " Minimum RSSI with Adjacent AP" option, the AP/ Router on the same local subnet will exchange client information with each other, providing the choice to disassociate the client only when other AP detecting a stronger signal. Thus to keep the client stayed when there is no other AP nearby. Three Modes in One AP Mode The mode mostly used Vigor AP acts as a bridge between wireless devices & wired Ethernet network, & exchanges data between them. Pros Limited wireless coverage Require physical wire to connect to the Ethernet Cons Limited wireless coverage Require physical wire to connect to the Ethernet Range Extender Vigor AP act as a wireless repeater It can be a Station & an AP at the same time Pros Compatibility among different brands Extend wireless coverage Cons No self-healing uplinks Need to install & check manually Performance decay Mesh Wirelessly connect 1~8 APs, & form a Mesh Group A mesh network creates a set of links automatically & calculate the most optimal wireless path through the wireless network back to a wired Mesh Root. Pros Easy installation Self-healing uplinks Extend wireless coverage Cons No compatibility among different brands Performance decay Manage from Dray Tek Wireless App Set up a Mesh network from scratch Monitoring all Mesh nodes & get an overview of the topology Check all the Wi-Fi clients Change SSID Configuration for all the nodes Add TR-069 Settings to all the nodes ...

Outdoor 802.11ac Mesh Wireless Access Point Vigor AP 918R is a wireless access point designed for outdoor environments. It is ideal for providing wireless access to users & devices in any outdoor scenario, including restaurants, gardens, marinas, educational premises or, really, anywhere where outdoor access is needed. The Vigor AP 918R is a dual-band 802.11ac Wave 2 wireless access point & range extender that can be used a part of a Dray Tek Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal & Wi-Fi dead zones. One access point acts as the controller (Mesh root) & in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling. Initial setup of the Vigor AP 918R is easy with the Dray Tek Wireless app, whether it's creating a new Mesh network or being set up in AP & Range Extender modes, the Quick Start Wizard assists throughout. Manage the Vigor AP 918R centrally through the Vigor ACS central management platform, Vigor Connect, Router AP Management, or simply on its own as a st&-alone access point. The Vigor AP 918R has the flexibility to be used how you need it, in any environment. ...

Outdoor 802.11ac Mesh Wireless Access Point Vigor AP 918R is a wireless access point designed for outdoor environments. It is ideal for providing wireless access to users & devices in any outdoor scenario, including restaurants, gardens, marinas, educational premises or, really, anywhere where outdoor access is needed. The Vigor AP 918R is a dual-band 802.11ac Wave 2 wireless access point & range extender that can be used a part of a Dray Tek Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal & Wi-Fi dead zones. One access point acts as the controller (Mesh root) & in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling. Initial setup of the Vigor AP 918R is easy with the Dray Tek Wireless app, whether it's creating a new Mesh network or being set up in AP & Range Extender modes, the Quick Start Wizard assists throughout. Manage the Vigor AP 918R centrally through the Vigor ACS central management platform, Vigor Connect, Router AP Management, or simply on its own as a st&-alone access point. The Vigor AP 918R has the flexibility to be used how you need it, in any environment. ...

Wi-Fi 6 Mesh wireless access point, offering up to 1.8 Gbps dual-band total wireless capacity. Significantly boosts real world performance for both 2.4 & 5 G Hz Wi-Fi 6 clients. Dray Tek’s Mesh with VLAN capability can significantly reduce the cost of network deployments, improves coverage & eliminates Wi-Fi dead zones for homes & businesses. Quick to install & change configuration. The Dray Tek Wireless app simplifies setting up your network. Optionally configure & monitor through one of Dray Tek’s management platforms. High Speed connections even in locations without mains power. The AP 960C can be powered through its Gigabit Ethernet interface with standard IEEE 802.3af Po E or power the Vigor AP with an AC adapter. Suitable for ceiling & wall mounting. With a new matte finish, the AP 960C blends well with home & office interiors. Flexible & discrete installation, with option to disable status LED. The Dray Tek Vigor AP 960C is a Wi-Fi 6 access point with mesh facilities, offering up to 1.8 Gbps dual-band total wireless capacity. Wi-Fi 6 brings significantly enhanced efficiency, not only through its higher speed but by better allocating bandwidth, allowing more client capacity – especially useful with the huge increase in Wi-Fi clients within homes & offices. Improvements in reliability add to better overall performance compared to all previous standards. Dray Tek’s Mesh with VLAN capability can signifi cantly reduce the cost of network deployments, improves coverage & eliminates Wi-Fi dead zones for homes & businesses. ...

Key Features 8 Port Gigabit Managed Switch Ultra compact form factor Wall Mountable Fanless (Silent) Operation Ultra-low power consumption The Vigor Switch G1080 is a small, high-performance Gigabit smart switch designed for small & medium business networks that require simple network management, with support for VLANs, Qo S & Link Aggregation (increases uplink speed for high data volume applications). The G1080 is an ulta-low power device, consuming under 1A, even when fully loaded. It is powered by an AC/DC adaptor (included). Its a low cost device, ideal for adding additional Ethernet ports to your router with a small footprint. The Vigor Switch G1080 can be managed directly through its web interface, or can be installed in conjunction with a compatible Vigor router to expand the routers network, with the Vigor Switch G1080 managed & monitored through the Dray Tek Vigor routers web interface. Power from USB (Universal Serial Bus) If you have limited space or power sockets, the Vigor Switch G1080 can also be powered by USB (Universal Serial Bus)
- perhaps the USB (Universal Serial Bus) port on PC or one on your Dray Tek Vigor router**. Requires optional USB (Universal Serial Bus)-DC cable (part no. HVUSB1). Otherwise you can just power the device with the supplied AC/DC power supply. Central Management The Dray Tek Vigor Switch G1080 can operate in standalone mode & be managed through its web interface or, if you need to manage & monitor the switch remotely, or have several Dray Tek Vigor Switches to administer, you can centrally manage Vigor Switches on a site from the Dray Tek router which they are physically connected to. With Dray Tek Central Switch Management, connected Vigor Switches can be monitored, managed & provisioned simply by accessing the routers web interface, either locally or from across the Internet.
...

24+4 Port Gigabit Managed Switch 802.3az Power Saving 802.1q VLANs (Tag, Port & MAC-based) Qo S for Application traffic prioritisation Voice VLAN for Qo S (OUI Mode) The Vigor Switch G1280 is a high-performance, Gigabit smart switch with 24 RJ-45 ports (plus 4 additional Gigabit ports) The Vigor Switch G1280 features our latest generation of Dray Tek's own switch operating system which is used across our range of enhanced switches. This enables a consistent user-experience & look-&-feel so that once you're familiar with one model, the others feel the same. The new UI is designed to be intuitive & efficient, whilst providing access to all of the product's advanced features. Enhanced Feature Set The G1280's

Specification is packed with advanced features to aid reliability & switching performance to your network & is ready for the next generation with both IPv 4 & IPv 6 support. The G1280 has 24 standard (RJ45/copper) Gigabit Ethernet Ports, & four selectable ports (which can be set to either RJ-45 or SFP slots). Features for Quality of Service (Qo S), VLANs & network/switch security provide additional flexibility.

...
