Vigor AP 903 is a high-performance Mesh Wireless solution, designed to expand the wireless coverage, eliminate Wi-Fi dead zones & significantly reduce the cost of network deployments. It can also be used as a traditional access point either managed or stand alone so has the flexibility to be used how you need it. The Vigor AP 903 is a dual-band 802.11ac Wave 2 Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal & Wi-Fi dead zones. One access point acts as the controller (Mesh root) & in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling. Dray Tek Mesh Wireless Mesh Wireless links Vigor AP access points across both Wi-Fi & Wired links to cover a large area with a single Wireless network, spanning multiple Wireless Access Points & easily managed from the Mesh Root Vigor AP or with the Dray Tek Wireless app. The Mesh Root Vigor AP links up to your existing Internet router, such as the Dray Tek Vigor 2862 & additional Vigor A Ps join up as Mesh Nodes, which connect wirelessly to the Mesh Root. Your devices see a single Wi-Fi network (SSID) & connect to the nearest Vigor AP in the Mesh, instead of a distant Wi-Fi network with low signal. Internet connectivity relays through the Mesh, using the up to 866 Mbps 5 G Hz wireless as the backhaul link, to relay between Mesh Nodes & avoid long waits for downloads. New Interface with Dashboard View The Vigor AP 903 features a new web interface designed for use with tablets, phones & PCs, adapting to suit any device. Dashboard view gives a detailed overview of the Vigor A Ps status at a glance, see individual connected clients & their traffic usage, ports in use & the utilisation of the Vigor AP. Easy Setup with the Dray Tek Wireless app The new Dray Tek Wireless app assists you with setting up the Vigor AP 903 access points & Mesh Wireless network. Once installed on your Smartphone or Tablet, use the Quick Start Wizard to adopt & set up your Vigor AP 903 as an Access Point, Range Extender, or a group of Vigor A Ps in a Mesh Wireless network. Simply scan the access point&128;&153;s QR code to detect it, or manually input the Vigor A Ps default SSID & password, then configure your wireless network with step-by-step guidance. When it&128;&153;s all set up, view the Mesh Wireless status & connected wireless clients from the app. Central Management with Dray Tek Vigor ACS The Dray Tek Vigor AP 903 can be managed by the Dray Tek vigor ACS central management system
- a cloud platform which can manage most Dray Tek products
- routers, wireless access points & Ethernet switches, giving you complete visibility & control of your Dray Tek product estate, even without a Dray Tek Vigor router on site. The Dray Tek Vigor ACS management system can be used to configure & provision Dray Tek Vigor AP access points, similarly to performing these actions through the Vigor A Ps web interface, with a familiar menu layout in the Configuration section of Vigor ACS. Profiles for groups of access points can be provisioned in Vigor ACS by selecting a Vigor ACS network, then accessing Configuration > AP Profile to configure profiles & apply them selectively. Dray Teks Vigor ACS management monitors the Vigor AP 903, with a Dashboard view giving a central overview of the most important information from the Vigor A Ps current status. Central Management with a Dray Tek Router The Vigor AP 903 can operate in standalone autonomous mode, but can also form part of a centrally managed wireless installation by adding a compatible Dray Tek wireless controller such as the Vigor 2862 router. This enables you to centrally control, manage & administer multiple AP devices installed around your building/campus. Management also enables efficient usage of your wireless access point through load-balancing, whereby wireless clients are distributed across several access points to reduce congestion. The Dray Tek router operating as the wireless controller can provision Dray Tek Vigor AP access points using the Central AP Management profiles configured on the router, with an option to Auto Provision
- auto configuring newly installed Vigor AP access points with the Auto Provisioning profile, upon initial connection to the Dray Tek Vigor routers network.


...

Vigor AP 906 is 11ax wall-mount/desktop wireless access point with a 5-port LAN switch. With wire-liked link rate up to 2402 Mbps in 5 G Hz band & up to 574 Mbps in 2.4 G Hz b&, it’s suitable for high density environments. It can be cloud-managed by Vigor ACS*, & also act as the mesh Root AP to manage up to 7 mesh node APs in LA. Po E Power Supply Simplify the infrastructure by getting data & power through a single cable Multiple SSID Mapping Wi-Fi clients to different VLANs & have a different set of security standards Wi-Fi Scheduling Schedule Wi-Fi On & Off to control wireless access & save energy. Local RADIUS Server User profile database for local & external 802.1x authentication. Airtime Fairness Equalize the transmission time of each client so the legacy devices wont slow everyone down. Hotspot Web Portal Market your business & communicate with the guests while offering hospitality WLAN Band Steering Redirect 5 G Hz-capable devices to the 5 G Hz radio to get a faster speed. Central AP Management Manage, maintain, & monitor Vigor AP 906 from the Dray Tek routers Assisted Wi-Fi Roaming Solve the sticky client problem & improve Wi-Fi roaming experience. Mesh (Wireless model only) Easily link to other Vigor AP to expand the wireless network Utilize Transmission Opportunity with OFDMA OFDMA has been used in LTE for many years, & is now available in 802.11ax for multi-user mode. Traditionally with OFDM, each frame is transmitted across the entire channel width. With low-rate transmission still using the whole channel, it brings latency & jitter to others & lower the overall efficiency. OFDMA splits a single transmission into groups of subcarriers, & each subcarrier can be used by different client. With multiple clients transmitting simultaneously in the same channel, it improves efficiency of every single transmission opportunity & thus increases the wireless experiences in high density environment. Making Transmission Effective Disassociate the Wireless clients who are out of the effective transmission range defined by custom Basic Rate or/and RSSI threshold, & force them to pick up another access point with a stronger signal. Resource Saving Proactively kick out the clients with a low basic rate or low RSSI can prevent the access points trying to do ineffective transmission but saving the airtime, which will results in better WLAN experience for all. No Controller Required Assisted Roaming is a feature built in all Vigor Access Points & selected Wireless routers. They operate without a wireless controller, providing an ideal solution for simple network deployment. Stronger Signal Guaranteed By using the " Minimum RSSI with Adjacent AP" option, the AP/ Router on the same local subnet will exchange client information with each other, providing the choice to disassociate the client only when other AP detecting a stronger signal. Thus to keep the client stayed when there is no other AP nearby. Three Modes in One AP Mode The mode mostly used Vigor AP acts as a bridge between wireless devices & wired Ethernet network, & exchanges data between them. Pros Limited wireless coverage Require physical wire to connect to the Ethernet Cons Limited wireless coverage Require physical wire to connect to the Ethernet Range Extender Vigor AP act as a wireless repeater It can be a Station & an AP at the same time Pros Compatibility among different brands Extend wireless coverage Cons No self-healing uplinks Need to install & check manually Performance decay Mesh Wirelessly connect 1~8 APs, & form a Mesh Group A mesh network creates a set of links automatically & calculate the most optimal wireless path through the wireless network back to a wired Mesh Root. Pros Easy installation Self-healing uplinks Extend wireless coverage Cons No compatibility among different brands Performance decay Manage from Dray Tek Wireless App Set up a Mesh network from scratch Monitoring all Mesh nodes & get an overview of the topology Check all the Wi-Fi clients Change SSID Configuration for all the nodes Add TR-069 Settings to all the nodes ...

Ceiling Mesh Wireless 802.11ac Range Extender & Access Point Vigor AP 912C is a high-performance Mesh Wireless solution, designed to expand the wireless coverage, eliminate Wi-Fi dead zones & significantly reduce the cost of network deployments. It can also be used as a traditional access point either managed or stand alone so has the flexibility to be used how you need it. The Vigor AP 912C is a dual-band 802.11ac Wave 2 Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal & Wi-Fi dead zones. One access point acts as the controller (Mesh root) & in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling. Initial setup of the Vigor AP 912C is easy with the Dray Tek Wireless app, whether its creating a new Mesh network or being set up in AP & Range Extender modes, the Quick Start Wizard assists throughout. Manage the Vigor AP 912C centrally through the Vigor ACS central management platform, Vigor Connect, Router AP Management, or simply on its own as a st&-alone access point. The Vigor AP 912C has the flexibility to be used how you need it. ...

Outdoor 802.11ac Mesh Wireless Access Point Vigor AP 918R is a wireless access point designed for outdoor environments. It is ideal for providing wireless access to users & devices in any outdoor scenario, including restaurants, gardens, marinas, educational premises or, really, anywhere where outdoor access is needed. The Vigor AP 918R is a dual-band 802.11ac Wave 2 wireless access point & range extender that can be used a part of a Dray Tek Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal & Wi-Fi dead zones. One access point acts as the controller (Mesh root) & in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling. Initial setup of the Vigor AP 918R is easy with the Dray Tek Wireless app, whether it's creating a new Mesh network or being set up in AP & Range Extender modes, the Quick Start Wizard assists throughout. Manage the Vigor AP 918R centrally through the Vigor ACS central management platform, Vigor Connect, Router AP Management, or simply on its own as a st&-alone access point. The Vigor AP 918R has the flexibility to be used how you need it, in any environment. ...

Outdoor 802.11ac Mesh Wireless Access Point Vigor AP 918R is a wireless access point designed for outdoor environments. It is ideal for providing wireless access to users & devices in any outdoor scenario, including restaurants, gardens, marinas, educational premises or, really, anywhere where outdoor access is needed. The Vigor AP 918R is a dual-band 802.11ac Wave 2 wireless access point & range extender that can be used a part of a Dray Tek Mesh Wireless solution, designed to eliminate wireless drop outs, stuttering videos, slow download speeds, poor signal & Wi-Fi dead zones. One access point acts as the controller (Mesh root) & in total up to 8 access points create an easy to manage wireless mesh. Extend coverage without running expensive cabling. Initial setup of the Vigor AP 918R is easy with the Dray Tek Wireless app, whether it's creating a new Mesh network or being set up in AP & Range Extender modes, the Quick Start Wizard assists throughout. Manage the Vigor AP 918R centrally through the Vigor ACS central management platform, Vigor Connect, Router AP Management, or simply on its own as a st&-alone access point. The Vigor AP 918R has the flexibility to be used how you need it, in any environment. ...

Key Features 8 Port Gigabit Managed Switch Ultra compact form factor Wall Mountable Fanless (Silent) Operation Ultra-low power consumption The Vigor Switch G1080 is a small, high-performance Gigabit smart switch designed for small & medium business networks that require simple network management, with support for VLANs, Qo S & Link Aggregation (increases uplink speed for high data volume applications). The G1080 is an ulta-low power device, consuming under 1A, even when fully loaded. It is powered by an AC/DC adaptor (included). Its a low cost device, ideal for adding additional Ethernet ports to your router with a small footprint. The Vigor Switch G1080 can be managed directly through its web interface, or can be installed in conjunction with a compatible Vigor router to expand the routers network, with the Vigor Switch G1080 managed & monitored through the Dray Tek Vigor routers web interface. Power from USB (Universal Serial Bus) If you have limited space or power sockets, the Vigor Switch G1080 can also be powered by USB (Universal Serial Bus)
- perhaps the USB (Universal Serial Bus) port on PC or one on your Dray Tek Vigor router**. Requires optional USB (Universal Serial Bus)-DC cable (part no. HVUSB1). Otherwise you can just power the device with the supplied AC/DC power supply. Central Management The Dray Tek Vigor Switch G1080 can operate in standalone mode & be managed through its web interface or, if you need to manage & monitor the switch remotely, or have several Dray Tek Vigor Switches to administer, you can centrally manage Vigor Switches on a site from the Dray Tek router which they are physically connected to. With Dray Tek Central Switch Management, connected Vigor Switches can be monitored, managed & provisioned simply by accessing the routers web interface, either locally or from across the Internet.
...

24+4 Port Gigabit Managed Switch 802.3az Power Saving 802.1q VLANs (Tag, Port & MAC-based) Qo S for Application traffic prioritisation Voice VLAN for Qo S (OUI Mode) The Vigor Switch G1280 is a high-performance, Gigabit smart switch with 24 RJ-45 ports (plus 4 additional Gigabit ports) The Vigor Switch G1280 features our latest generation of Dray Tek's own switch operating system which is used across our range of enhanced switches. This enables a consistent user-experience & look-&-feel so that once you're familiar with one model, the others feel the same. The new UI is designed to be intuitive & efficient, whilst providing access to all of the product's advanced features. Enhanced Feature Set The G1280's

Specification is packed with advanced features to aid reliability & switching performance to your network & is ready for the next generation with both IPv 4 & IPv 6 support. The G1280 has 24 standard (RJ45/copper) Gigabit Ethernet Ports, & four selectable ports (which can be set to either RJ-45 or SFP slots). Features for Quality of Service (Qo S), VLANs & network/switch security provide additional flexibility.

...

Key Features 24+4 Port Gigabit Managed Switch 802.3az Power Saving 802.1q VLANs (Tag, Port & MAC-based) Qo S for Application traffic prioritisation Voice VLAN for Qo S (OUI Mode) The Vigor Switch G1280 is a high-performance, Gigabit smart switch with 24 RJ-45 ports (plus 4 additional Gigabit ports) The Vigor Switch G1280 features our latest generation of Dray Teks own switch operating system which is used across our range of enhanced switches. This enables a consistent user-experience & look-&-feel so that once youre familiar with one model, the others feel the same. The new UI is designed to be intuitive & efficient, whilst providing access to all of the products advanced features. Enhanced Feature Set The G1280s

Specification is packed with advanced features to aid reliability & switching performance to your network & is ready for the next generation with both IPv 4 & IPv 6 support. The G1280 has 24 standard (RJ45/copper) Gigabit Ethernet Ports, & four selectable ports (which can be set to either RJ-45 or SFP slots). Features for Quality of Service (Qo S), VLANs & network/switch security provide additional flexibility.

...

Product Description Draytek Vigor Switch G2100
- switch
- 8 ports
- Managed
- rack-mountable Device Type Switch
- 8




...

Key Features 802.3az Power Saving 802.1q VLANs (Tag, Port & MAC-based) Qo S for Application traffic prioritisation Voice VLAN for Qo S (OUI Mode) Access Control List (ACL) The Vigor Switch G2280 is a high-performance, Gigabit smart switch with 24 RJ-45 ports (plus 4 additional Gigabit ports). The Vigor Switch G2280 features our latest generation of Dray Teks own switch operating system which is used across our range of enhanced switches. This enables a consistent user-experience & look-&-feel so that once youre familiar with one model, the others feel the same. The new UI is designed to be intuitive & efficient, whilst providing access to all of the products advanced features. Enhanced Feature Set The G2280s

Specification is packed with advanced features to aid reliability & switching performance to your network & is ready for the next generation with both IPv 4 & IPv 6 support. The G2280 has 24 standard (RJ45/copper) Gigabit Ethernet Ports, & four selectable ports (which can be set to either RJ-45 or SFP slots). Features for Quality of Service (Qo S), VLANs & network/switch security provide additional flexibility.

...
