MSI AMD Radeon R7 260X 2GB GDDR5 Dual Link DVI-D DVI-I Display P Ort PCI-E Graphics Card Graphics Processing Unit AMD Radeon R7 260X Interface PCI Express x 16 3.0 Core Clock Speed (MHz) 1175 Memory Size (MB) 2048 Memory Type GDDR5 Memory Interface 128 bits Memory Clock Speed (MHz) 6500 Memory Bandwidth (GB/sec) 104 DVI Connectors DL-DVI-Ix 1, DL-DVI-Dx 1 Max Resolution: 2048x 1536 @60 Hz HDMI Connectors 1 (version 1.4a) Max Resolution: 3840x 2160 @30 Hz-30bpp 4096x 2160 @24 Hz-24bpp Display Port 1 (version 1.2) Max Resolution: 4096x 2160 @ 50 Hz Maximum Displays 3 with DVI/HDMI, 4 using Display Port, 6 with an MST hub HDCP Support Y RAMDAC speed (MHz) 400 Direct X Version Support 11.2 API (feature 11_0) Open GL Version Support 4.3 Multi-GPU Technology Cross Fire Card Dimension (mm) 203x 123x 36mm Card Weight 450 Power consumption (W) 105 Recommended Power Supply (W) 500 Power Connectors 1x 6-Pin ...

MSI Afterburner overclocking utility
- Supports advanced fan speed control.
- Supports burn-in stability test. Dual Fan Thermal

...

Features
- GPU Overvoltage Support Support GPU overvoltage adjustment by Afterburner. Unleash the potential of graphics card to
...

A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". That's why we bring you the best of the best. We don't want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Specifications GPU Graphics Processing Unit
- AMD Radeon™ R9 270 Core Clock Speed (MHz) 900 M Hz Core (Boost Clock:975 M Hz) (OC mode) 900 M Hz Core (Boost Clock:955 M Hz) (Gaming mode) 900 M Hz Core (Boost Clock:925 M Hz) (Silent mode) Memory Memory Size (MB)
- 2048 Memory Type
- GDDR5 Memory Interface
- 256 bits Memory Clock Speed (MHz)
- 5600 Memory Bandwidth (GB/sec)
- 179.2 Outputs DVI Connectors
- DL-DVI-Ix 1, DL-DVI-Dx 1 Max Resolution: 2048x 1536 @60 Hz HDMI Connectors
- 1 (version 1.4a) Max Resolution: 3840x 2160 @30 Hz-30bpp 4096x 2160 @24 Hz-24bpp Display Port
- 1 (version 1.2) Max Resolution: 4096x 2160 @ 50 Hz HDCP Support
- Y Features Direct X Version Support
- 11.2 API (feature 11_0) Open GL Version Support
- 4.3 Multi-GPU Technology
- Cross Fire, 2-ways Interface
- PCI Express x 16 3.0

Dimensions Card Dimension (mm)
- 256x 127x 34mm Power Requirements Power consumption (W)
- 147 Recommended Power Supply (W)
- 500 Power Connectors
- 1x 6-Pin



















...

A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". That's why we bring you the best of the best. We don't want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Specifications Product Name
- R9 270X Gaming 2G GPU
- AMD Radeon R9 270X Processor
- 1290 Units Core Clock
- Base:1030 MHz Boost:1120 MHz Memory Clock
- 5600 MHz Memory Size
- 2048MB GDDR5 Memory Bus
- 256 bits Output
- Display Port / HDMI / DL-DVI-D / DL-DVI-I Power Consumption
- 161W Card dimension
- 260x 129x 38mm Form Factor
- ATX










...

A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". That's why we bring you the best of the best. We don't want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Most MSI Gaming graphics cards come pre-overclocked out of the factory. This simply means you get more performance out of your card, without spending any time on checking for maximum clocks & stability. Pre-overclocked graphics cards simply give more performance & you don't have to worry about damaging your card, it is completely covered by our warranty! MSI's Twin Frozr has been the industry defining graphics card cooler. The first Twin Frozr kicked off the dual-fan trend & today MSI stays true to its dual-fan dual-slot design where others have to resort to less effective means. The other part that the Twin Frozr cooler uses is a large Aluminium fin grid array that provides a huge amount of surface area for cooling. Heat from the GPU is transferred to the fin grid array by virtue of heat pipes with MSI's special Super Pipe technology. Super Pipes transfer heat twice as fast as regular heat pipes enabling an MSI GAMING graphics card to stay cooler than the competition. Futhermore, MSI provide all new Airflow Control technology on Twin Frozr. This new thermal tech. is leading airflow to heat pipe by spcial deflector on heatsink, so it can deflect more airflow to heat pipes directly. In addtion, This exclusive heatsink design is increasing the area of heatsink so that enhancing the efficiency of dissipation much more. Specifications Graphics Engine- AMD Radeon R9 280 Core Clock Speed (MHz) 933 M Hz Core (Boost Clock:1000 M Hz) (OC mode) 933 M Hz Core (Boost Clock:972 M Hz) (Gaming mode) 933 M Hz Core (Boost Clock:933 M Hz) (Silent mode) Memory Type
- GDDR5 Memory Size (MB)
- 3072 Memory Interface
- 384 bits Memory Clock Speed (MHz)
- 5000 Bus Standard
- PCI Express x 16 3.0 DVI Output
- 1 (Dual-link DVI-I) HDMI-Output
- 1 (version 1.4a) Mini Display Port
- 2 HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11.2 Open GL Version Support
- 4.3 Cross Fire Support
- Y Card Dimension (mm)
- 269x 128x 37 mm Weight
- 849g

















...

MSI R9 280X 3GB GDDR5 DVI HDMI Display Port PCI-E Graphics Card NOW YOU'RE GAMING WITH MSI A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". That's why we bring you the best of the best. We don't want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Graphics Engine
- R9 280X Interface
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 3072 Memory Interface
- 384 bits Core Clock Speed (MHz) 1000 M Hz Core (Boost Clock:1050 M Hz) (OC mode) 1000 M Hz Core (Boost Clock:1020 M Hz) (Gaming mode) 1000 M Hz Core (Boost Clock:1000 M Hz) (Silent mode) Memory Clock Speed (MHz)
- 6000 DVI Output
- 1 (Dual-link DVI-I) HDMI-Output
- 1 (version 1.4a) Mini Display Port
- 2 HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output
- (Max Resolution)2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11.2 Open GL Version Support
- 4.3 Cross Fire Support
- Y Card Dimension (mm)
- 269x 128x 34 mm Weight
- 849g


















...

“ Free AMD Radeon Rewards download coupon GOLD from 28th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". That's why we bring you the best of the best. We don't want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Graphics Engine
- AMD Radeon R9 290 Interface
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 4096 Memory Interface
- 512 bits Core Clock Speed (MHz) 1007 M Hz Core (OC mode), 977 M Hz Core (Gaming mode), 947 M Hz Core (Silent mode) Memory Clock Speed (MHz)
- 5000 DVI Output
- 2 (Dual-link DVI-D) HDMI-Output
- 1 (version 1.4a) Display Port
- 1 HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11.2 Open GL Version Support
- 4.3 Cross Fire Support
- Y, 4-way (SW) Card

Dimensions (mm)
- 276x 127x 39mm



















...

A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". That's why we bring you the best of the best. We don't want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Specifications GPU Graphics Processing Unit
- AMD Radeon™ R9 290 Core Clock Speed (MHz) 1007 M Hz Core (OC mode) 977 M Hz Core (Gaming mode) 947 M Hz Core (Silent mode) Memory Memory Size (MB)
- 4096 Memory Type
- GDDR5 Memory Interface
- 512 bits Memory Clock Speed (MHz)
- 5000 Memory Bandwidth (GB/sec)
- 320 Display Details DVI Connectors
- DL-DVI-Dx 2 Max Resolution
- 2048x 1536 @60 Hz HDMI Connectors
- 1 (version 1.4a) Max Resolution
- 3840x 2160 @30 Hz-30bpp
- 4096x 2160 @24 Hz-24bpp Display Port
- 1 (version 1.2) Max Resolution
- 4096x 2160 @ 50 Hz Maximum Displays
- Up to 6 displays with the use of a DP MST Hub Features Direct X Version Support
- 11.2 API (feature 11_0) Open GL Version Support
- 4.3 Multi-GPU Technology
- Cross Fire, 4-way (SW) Interface
- PCI Express x 16 3.0 Card

Dimensions Card Dimension (mm)
- 276x 127x 39mm Power Requirements Power consumption (W)
- 250 Recommended Power Supply (W)
- 750 Power Connectors
- 1x 6-Pin, 1x 8-Pin























...

MSI R9 290X 4GB GDDR5 Dual DVI HDMI Display Port Graphics Card Gaming App: OC Mode “ Tune up core clock & fan speed to gain a best performance. Gaming Mode “ Provide a stable gaming experience with higher core clock. Silent Mode “ The best operating environment with extremely low noise. Product

Specification Product Name
- R9 290X GAMING 4G GPU
- AMD Radeon R9 290X Codename
- Hawaii XT Processors
- 2816 Units Core Clock (OC Mode)
- 1040 MHz Memory Clock
- 5000 MHz Memory Size
- 4G GDDR5 Memory Bus
- 512 bits Outputs Display Port / HDMI DL DVI-D*2 Card Dimension
- 276 x 127 x 39 mm Form Factor
- ATX Technology Support: Afterburner OC
- GPU/VDDCI Direct X
- 11.2 Open GL
- 4.3 Multi-GPU Technology
- Cross Fire, 4-way (SW) Multi-Display Technology
- Eyefinity 3D Technology
- HD3D Power Saving Tech.
- Power Tune HDCP Capable
- Y Accessory Driver CD
- Y Installation Guide
- Y Power Cable
- 6pin*1, 8pin*1






















...
