CPU 64bit AMD FX, Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 & Sempron CPU in AM3 / AM3+ package. Please refer to CPU Support for compatible CPU; the above description is for reference only. Hyper Transport Bus Hyper Transport 3.0 supporting speed up to 5200MT/s Chipset AMD 990FX & SB950 Chipset Main Memory Supports four unbuffered DIMM of 1.5 Volt DDR3 800/1066/1333/1600/1866*/2133* (OC) DRAM, 32GB Max Slots 2 PCI Express 2.0 x 16 slots 4 PCI Express 2.0 x 1 slots 1 PCI slot, support 3.3V/ 5V PCI bus Interface. On-Board SATA 6 SATA III (1~6) ports by AMD SB950
- Supports storage & data transfers at up to 6 Gb/s RAID Function
- SATA III 1~6 support RAID 0, 1, 5, 10 mode by AMD SB950 MSI Reminds You... The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk. USB (Universal Serial Bus) 3.0 2 USB (Universal Serial Bus) 3.0 ports by NEC D720200 Audio Chipset integrated by Realtek ALC892
- True Blu-ray Audio Support
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec LAN Realtek PCI-E Gb LAN controller 8111E
- Integrated Fast Ethernet MAC & PHY in single chip
- Supports 10 Mb/s, 100 Mb/s & 1000 Mb/s
- Compliance with PCI-Express Bus

Specification v 1.0a Internal I/O Connectors 1 x ATX 24-pin power connector 1 x ATX 8-pin 12V CPU power connector CPU x 1 / System x 4 FAN connectors 1 x Front panel audio connector 1 x Front panel connector 1 x Chassis intrusion switch connector 2 x USB (Universal Serial Bus) 2.0 connectors 6 x Serial ATA III connectors 1 x Serial port connector 1 x Clear CMOS jumper 1 x SPDIF-out connector 1 x TPM module connector Back Panel I/O Ports 1 x PS/2 Keyboard/ Mouse port 1 x Clear CMOS button 1 x Coaxial SPDIF-out 1 x Optical SPDIF-out 8 x USB (Universal Serial Bus) 2.0 ports 2 x USB (Universal Serial Bus) 3.0 ports (blue) 1 x RJ45 LAN Jacks 1 x 6 in 1 audio jack Dimension 30.5cm (L) x 24.4cm (W) ATX Form Factor Mounting 9 mounting holes









...

Fully support AMD AM3+ mutil-core processors In addition to upgrading all BIOS on the existing AM3 mainboards supporting AMD AM3+ multi-core processors before shipping to correspond to the upcoming AMD AM3+ processors, MSI has post the BIOS of corresponding mainboards with support for the new AMD AM3+ processors for consumers to upgrade their MSI AM3 mainboards in order to meet their demands for system upgrade & experiencing the powerful performance of the next-generation AMD processors. CPU 64bit AMD Phenom II X8/X6/X4/X3/X2, Athlon II X4/X3/X2 & Sempron CPU in AM3 / AM3+ package Please refer to CPU Support on MSI website for compatible CPU; the above description is for reference only Hyper Transport 3.0 supporting speed up to 5200MT/s Chipset AMD 990FX & SB950 Chipset Main Memory Supports four unbuffered DIMM of 1.5 Volt DDR3 800/1066/1333/1600/1800*/2133* (OC) DRAM, 32GB Max Slots 4 PCI Express 2.0 x 16 slots 2 PCI Express 2.0 x 1 slots 1 PCI slot, support 3.3V/ 5V PCI bus Interface On-Board SATA 6 SATA III (1~6) ports by AMD SB950
- Supports storage & data transfers at up to 6 Gb/s RAID Function
- SATA III 1~6 support RAID 0, 1, 5, 10 mode by AMD SB950 USB (Universal Serial Bus) 3.0 2 USB (Universal Serial Bus) 3.0 ports by NEC D720200 Audio Chipset integrated by Realtek ALC892
- True Blu-ray Audio Support
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec LAN Realtek PCI-E Gb LAN controller 8111E
- Integrated Fast Ethernet MAC & PHY in single chip
- Supports 10 Mb/s, 100 Mb/s & 1000 Mb/s
- Compliance with PCI-Express Bus

Specification v 1.0a IEEE1394 / Fire Wire VIA VT6315N chipset
- Supports up to two 1394 ports. (pinheader x 2)
- Transfer rate is up to 400 Mbps. Internal I/O Connectors 1 x ATX 24-pin power connector 1 x ATX 8-pin 12V CPU power connector CPU x 1 / System x 4 FAN connectors 1 x Front panel audio connector 1 x Front panel connector 1 x Chassis intrusion switch connector 2 x USB (Universal Serial Bus) 2.0 connectors 1 x USB (Universal Serial Bus) 3.0 connector 6 x Serial ATA III connectors 1 x IEEE1394 connector 1 x Serial port connector 1 x Power button 1 x Reset button 1 x OC Genie button 1 x Debug LED display 1 x Clear CMOS jumper 1 x SPDIF-out connector 1 x TPM module connector Back Panel I/O Ports 1 x PS/2 Keyboard port 1 x PS/2 Mouse port 1 x Claer CMOS button 1 x Coaxial SPDIF-out 1 x Optical SPDIF-out 4 x USB (Universal Serial Bus) 2.0 ports 2 x USB (Universal Serial Bus) 3.0 ports (blue) 2 x e SATA / USB (Universal Serial Bus) 2.0 Combo ports 1 x RJ45 LAN Jacks 1 x 6 in 1 audio jack

Dimensions 30.5cm (L) x 24.4cm (W) ATX Form Factor Mounting 9 mounting holes.













...

AMD 990FX chipset based • superb Stability: Military Class Components • OC Genie II: Easy Overclocking Technology ...

CPU • 64bit AMD FX, Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 & Sempron CPU in AM3 / AM3+ package. Please refer to CPU Support for compatible CPU; the above description is for reference only. Hyper Transport Bus • Hyper Transport 3.0 supporting speed up to 5200MT/s Chipset • AMD 990X & SB950 Chipset &12288; Main Memory • Supports four unbuffered DIMM of 1.5 Volt DDR3 800/1066/1333/1600/1866/2133* (OC) DRAM, 32GB Max &12288; Slots • 2 PCI Express 2.0 x 16 slots • 4 PCI Express 2.0 x 1 slots • 1 PCI slot, support 3.3V/ 5V PCI bus Interface. On-Board SATA • 6 SATA III (1~6) ports by AMD SB950
- Supports storage & data transfers at up to 6 Gb/s RAID Function
- SATA III 1~6 support RAID 0, 1, 5, 10 mode by AMD SB950 MSI Reminds You... • The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk. &12288; USB (Universal Serial Bus) 3.0 • 2 USB (Universal Serial Bus) 3.0 ports by NEC D720200 &12288; Audio • Chipset integrated by Realtek ALC892
- True Blu-ray Audio Support
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec LAN • Realtek PCI-E Gb LAN controller 8111E
- Integrated Fast Ethernet MAC & PHY in single chip
- Supports 10 Mb/s, 100 Mb/s & 1000 Mb/s
- Compliance with PCI-Express Bus

Specification v 1.0a &12288; Internal I/O Connectors
- 1 x ATX 24-pin power connector
- 1 x ATX 8-pin 12V CPU power connector
- CPU x 1 / System x 4 FAN connectors
- 1 x Front panel audio connector
- 1 x Front panel connector
- 1 x Chassis intrusion switch connector
- 2 x USB (Universal Serial Bus) 2.0 connectors
- 6 x Serial ATA III connectors
- 1 x Serial port connector
- 1 x Clear CMOS jumper
- 1 x SPDIF-out connector
- 1 x TPM module connector &12288; Back Panel I/O Ports
- 1 x PS/2 Keyboard/ Mouse port
- 1 x Claer CMOS button
- 1 x Coaxial SPDIF-out
- 1 x Optical SPDIF-out
- 8 x USB (Universal Serial Bus) 2.0 ports
- 2 x USB (Universal Serial Bus) 3.0 ports (blue)
- 1 x RJ45 LAN Jacks
- 1 x 6 in 1 audio jack &12288; Dimension • 30.5cm (L) x 24.4cm (W) ATX Form Factor Mounting • 9 mounting holes.





























...

Features Supports AMD Ryzen 1st & 2nd Generation/ Ryzen™ & Athlon™ with Radeon™ Vega Graphics / A-series & Athlon™ X4 Processors for Socket AM4 Supports DDR4 Memory, up to 3200 (OC) MHz Audio Boost: Reward your ears with studio grade sound quality. EZ Debug LED: Easiest way to troubleshoot. X-Boost: Software that auto-detects & means that you can boost the performance of any storage or USB (Universal Serial Bus) device. Core Boost: With premium layout & fully digital power design to support more cores & provide better performance. Overview DIY FRIENDLY MSI motherboards feature tons of convenient & smart design, such as convenient pin-header keep out zone, friendly SATA & USB (Universal Serial Bus) location & so on, so DIY users can pick & choose any gaming rig they want. STAY COOL FOR RELIABLE SYSTEM Cooling your PC is essential for reliable performance. MSI motherboards feature excellent power design with solid & heavy heatsink. Weve made sure to include enough fan headers with full control to allow you to cool your system any way you want. APPS TO GREATLY IMPROVE EFFICIENCY with many years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. Use these tools to get the most out of your motherboard & achieve victory when gaming. Moreover, we made sure our BIOS contains all the latest options & is easy to use for everyone. The extensive features let you fine-tune your system to deliver reliable maximum performance. ...

Features Supports AMD Ryzen 1st & 2nd Generation/ Ryzen™ & Athlon™ with Radeon™ Vega Graphics / A-series & Athlon™ X4 Processors for Socket AM4 Supports DDR4 Memory, up to 3200+ (OC) MHz Turbo M.2: Running at PCI-E Gen 3 x 4 maximizes performance for NVMe based SSDs. DDR4 Boost: Advanced technology to deliver pure data signals for the best performance & stability. Audio Boost: Reward your ears with studio grade sound quality. EZ Debug LED: Easiest way to troubleshoot X-Boost: Software that auto-detects & means that you can boost the performance of any storage or USB (Universal Serial Bus) device. Core Boost: With premium layout & fully digital power design to support more cores & provide better performance. PCI-E Steel Slot: Protecting VGA cards against bending for better performance, stability & strength. Overview DIY FRIENDLY MSI motherboards feature tons of convenient & smart design, such as convenient pin-header keep out zone, friendly SATA & USB (Universal Serial Bus) location & so on, so DIY users can pick & choose any gaming rig they want. STAY COOL FOR RELIABLE SYSTEM Cooling your PC is essential for reliable performance. MSI motherboards feature excellent power design with solid & heavy heatsink. Weve made sure to include enough fan headers with full control to allow you to cool your system any way you want. MAXIMUM COMPATIBILITY Every MSI motherboards are certified by strict mechanic that feature convenient pin-header keep out zone, friendly SATA & USB (Universal Serial Bus) location for compatibility with the widest range of components & devices, so DIY user can pick & choose the components they want. More than that, we offer a dedicated Qualified Vendor List (QVL) for the most critical part
- memory. Combining with MSI DDR4 Boost technology, we provide the maximum compatibility even over clocking, so you confirm & choose any gaming rig as you want. APPS TO GREATLY IMPROVE EFFICIENCY with many years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. Use these tools to get the most out of your motherboard & achieve victory when gaming. Moreover, we made sure our BIOS contains all the latest options & is easy to use for everyone. The extensive features let you fine-tune your system to deliver reliable maximum performance.
...

Features Supports AMD RYZEN series processors & 7th Gen A-series / Athlon™ Processors for socket AM4 Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency Audio Boost: Reward your ears with studio grade sound quality for a HI-FI experience EZ Debug LED: Easiest way to troubleshoot X-Boost: Great tool to boost your USB (Universal Serial Bus) & Storage performance Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection & efficiency Click BIOS 5: Award-winning BIOS with high resolution scalable font, favourites & search function WHQL certified for Windows 10 Overview STAY COOL Cooling your PC is essential for reliable performance. Weve made sure to include enough fan headers with full control to allow you to cool your system to the max. ENJOY THE LATEST VIDEO STANDARDS Supporting the latest display connectors for new technologies (OLED, HDR) & legacy connectors for beamers, MSI motherboards are designed to make life easier for any professional user. PROFESSIONAL SOUND QUALITY Get the most immersive sound experience. MSI Audio Boost delivers the highest sound quality through the use of premium quality audio components. This lets you enjoy breathtaking, game-changing sound to create the most dynamic soundscapes. BE THE FIRST TO BOOT UP IN THE MORNING This MSI product supports all the latest storage standards. This means that you can connect any ultra-fast storage device, giving you noticeable benefits. Start programs faster, load data faster & increase productivity.

Specification CPU • Supports AMD RYZEN series processors & 7th Gen A-series/ Athlon™ processors for Socket AM4 * This function will be supported depend on the CPU. Chipset • AMD A320 Chipset Main Memory • 2 x DDR4 memory slots, support up to 32GB • Support DDR4 1866/2133/2400/2667 (OC)/2933 (OC)/3200 (OC) Mhz* • Dual channel memory architecture • Supports ECC UDIMM memory (non-ECC mode) • Support non-ECC UDIMM memory * 7th Gen A-series/ Athlon processors support a maximum of DDR4 2400 Mhz. * Please refer www.msi.com for more information on compatible memory Slots • 1 x PCIe 3.0 x 16 slots
- RYZEN series processors support x 16 mode
- 7th Gen A-series/ Athlon™ processors support x 8 mode • 2 x PCIe 3.0 x 1 slots Onboard Graphics • 1 x DVI-D port, supports a maximum resolution of 1920x 1200@60 Hz • 1 x VGA port, supports a maximum resolution of 2048x 1280@60 Hz, 1920x 1200@60 Hz * Only support when using a 7th Gen A-series/ Athlon™ processor * Maximum shared memory of 2048 MB Storage • AMD A320 Chipset • 4 x SATA 6 Gb/s ports • Supports RAID 0, RAID1 & RAID 10 USB (Universal Serial Bus) • AMD A320 Chipset
- 6 USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connector)
- 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connector) Audio • Realtek ALC887 Codec
- 7.1-Channel High Definition Audio LAN • 1 x Realtek 8111H Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA 6 Gb/s connectors
- 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin system fan connector
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1 x PS/2 keyborard/ mouse combo port
- 2 x USB (Universal Serial Bus) 2.0 Type-A ports
- 1 x DVI-D port
- 1 x VGA port
- 1 x LAN (RJ45) port
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 3 x audio jacks Dimension • 9.6 in. x 8.1 in. (24.4 cm x 20.6 cm) • m-ATX Form Factor Mounting • 6 mounting holes


























...

Features Supports AMD RYZEN series processors & 7th Gen A-series / Athlon™ Processors for socket AM4 Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency Audio Boost: Reward your ears with studio grade sound quality for a HI-FI experience EZ Debug LED: Easiest way to troubleshoot X-Boost: Great tool to boost your USB (Universal Serial Bus) & Storage performance Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection & efficiency Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites & search function WHQL certified for Windows 10 Overview MAKING YOUR LIFE EASIER IS OUR BUSINESS Combining quality you can rely on with top performance & clever business solutions are key aspects of the MSI PRO SERIES motherboards. Engineered to gratify even the most demanding professional, these motherboards will fit in any PC. Making your life easier & supporting your business with super stable, reliable & long-lasting top performance. STAY COOL Cooling your PC is essential for reliable performance. Weve made sure to include enough fan headers with full control to allow you to cool your system to the max. ENJOY THE LATEST VIDEO STANDARDS Supporting the latest display connectors for new technologies (OLED, HDR) & legacy connectors for beamers, MSI motherboards are designed to make life easier for any professional user. PROFESSIONAL SOUND QUALITY Get the most immersive sound experience. MSI Audio Boost delivers the highest sound quality through the use of premium quality audio components. This lets you enjoy breathtaking, game-changing sound to create the most dynamic soundscapes.

Specification CPU • Supports AMD RYZEN series processors & 7th Gen A-series/ Athlon™ processors for Socket AM4 * This function will be supported depend on the CPU. Chipset • AMD A320 Chipset Main Memory • 2 x DDR4 memory slots, support up to 32GB • Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz* • Dual channel memory architecture • Supports ECC UDIMM memory (non-ECC mode) • Support non-ECC UDIMM memory * 7th Gen A-series/ Athlon processors support a maximum of DDR4 2400 Mhz. * Please refer www.msi.com for more information on compatible memory Slots • 1 x PCIe 3.0 x 16 slots
- RYZEN series processors support x 16 mode
- 7th Gen A-series/ Athlon™ processors support x 8 mode • 2 x PCIe 3.0 x 1 slots Onboard Graphics • 1 x HDMI™ port, supports a maximum resolution of 4096x 2160@24 Hz* • 1 x VGA port, supports a maximum resolution of 2048x 1280@60 Hz, 1920x 1200@60 Hz * Only support when using a 7th Gen A-series/ Athlon™ processor * Maximum shared memory of 2048 MB Storage • AMD A320 Chipset • 4 x SATA 6 Gb/s ports • Supports RAID 0, RAID1 & RAID 10 USB (Universal Serial Bus) • AMD A320 Chipset
- 6 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connector)
- 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connector) Audio • Realtek ALC887 Codec
- 7.1-Channel High Definition Audio LAN • 1 x Realtek 8111H Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA 6 Gb/s connectors
- 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin system fan connector
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 2 x Serial port connector
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1 x PS/2 keyborard/ mouse combo port
- 2 x USB (Universal Serial Bus) 2.0 Type-A ports
- 1 x HDMI™ port
- 1 x VGA port
- 1 x LAN (RJ45) port
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 3 x audio jacks Dimension • 9.3 in. x 7.4 in. (23.6 cm x 18.7 cm) • m-ATX Form Factor Mounting • 6 mounting holes


























...

Main Features Supports 1st, 2nd & 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics & 2nd Gen AMD Ryzen™ with Radeon™ Graphics / Athlon™ with Radeon™ Vega Graphics & A-series / Athlon X4 Desktop Processors for Socket AM4 Supports DDR4 Memory, up to 3200 (OC) MHz Audio Boost: Reward your ears with studio grade sound quality. DDR4 Boost: Advanced technology to deliver pure data signals for the best performance & stability Core Boost: With premium layout & fully digital power design to support more cores & provide better performance. DIY FRIENDLY MSI motherboards feature tons of convenient & smart design, such as convenient pin-header keep out zone, friendly SATA & USB (Universal Serial Bus) location & so on, so DIY users can pick & choose any gaming rig they want. ENHANCED PERFORMANCE MSI motherboards featured all the latest solution for enthusiast gamers & prosumers. CPU & memory enhancement & fast storage & USB (Universal Serial Bus) transfer speed are ready to be on the battlefield. IN-STUDIO ADVANTAGE MSI motherboards provide the most fascinating in-studio advantages, designed to satisfy any professional workflow. Elevate your listening pleasure & network connection with MSI Audio & LAN. Enjoy extreme sound quality & uninterrupted online experience. EXHILARATING & INSPIRING Each MSI motherboard is built based on the specific topic in order to match different tastes & favors. Furthermore, MSI also adopts the modern style to design the heatsink through huge surface & sleek but simple cuts in order to make the heatsink & appearance looks ripped & powerful. Combined with neutral color, such as black, grey & silver, as the main background, MSI motherboard can perfect fit different RGB LED effects & strongly shows the gamers tunes. LOYAL COMRADE with many years of experience, MSI is no stranger to building high-performance motherboards. Our R&D & engineering teams have reviewed countless designs, evaluated a wide selection of high quality components, & developed products for reliability even under extreme conditions. ...
