Kolink gave the Inspire K3 something that helps it stand out from the crowd: the front is equipped with a striking "X" design as well as two RGB-LED strips which can be controlled via the motherboard (4 Pin) or I/O panel. The side cutouts serve as air inlets & dust filters. The tempered glass side panel offers owners a view of the interior, specifically of the Micro-ATX or Mini-ITX motherboard that has been installed. The Micro-ATX case offers support for powerful hardware & plenty of drives to make creating your perfect gaming system a breeze. This makes the Kolink Inspire K3 one of the best cases out there for gamers on the lookout for a deal but that have an eye for exceptional design. The Kolink Inspire K3 Micro-ATX Case at a Glance:
- Striking front panel with RGB lighting
- Tempered glass side panel & PSU slot in the top
- Space for 1x 120 mm fan at the front & 1x 92mm fan in the back - Space for GPUs up to 320 mm long & CPU coolers 150 mm tall
- I/O Panel with one USB (Universal Serial Bus) 3.0, one USB (Universal Serial Bus) 2.0 & RGB-LED controls
- Light & easy to carry at just 3, 9kg Affordable Micro-ATX Case from Kolink for Gamers The Kolink Inspire K3 is an extremely affordable Micro-ATX case that is, in style terms, oriented more towards gamers. It can fit graphics cards up to 32cm in length. What stands out about it in particular is the use of transparent strips in the shape of an "X" that is illuminated via two RGB-LED strips. The side-mounted vents help ensure your components receive plenty of airflow, & at the top towards the front lie the USB (Universal Serial Bus) 2.0- & USB (Universal Serial Bus) 3.0 connections as well as RGB lighting controls
- although this can also be controlled via a 4-pin cable to the motherboard if needed. A tinted, tempered glass side panel rounds out the stylish design of the Kolink Inspire K3. The interior offers support for a Micro-ATX- or Mini-ITX motherboard. The case also supports graphics cards up to 320 mm long, & CPU coolers up to 150 mm in height
- more than enough space for most common models. The right side offers plenty of space for cable management due to its shape. The front allows for a 120 mm fan. The back has space for a 92 mm fan. Towards the top/front of the case lie two slots, the top one can hold a 3, 5- or 2, 5" drive. Under this, in the second slot, there is space for a 2, 5" SSD. At the bottom, users have the option of installing another 3, 5- or 2, 5" drive.






...

The Kolink KL series are 80 Plus Bronze certified power supply units aimed at the budget system build, offering reliable power without a hefty price tag. The KL-400 is able to deliver 400w of continuous power at 80 Plus Bronze efficiency over a single rail, & features multiple protections such as OVP, UVP, SCP, OPP & OTP. The KL series all meet the necessary EU requirements for standby wattage & efficiency. They all contain a low noise 12cm fan & have 1 x (400W) or 2 x (500W/600W) PCI-E 6+2 pin connectors for GPU support. The Kolink KL series PSU are a perfect combination of reliability & functionality, backed up with a 2 year warranty for peace of mind. SPECIFICATIONS
- Power supply: 200V
- 240V / 50-60 Hz
- Wattage: 400W
- Compliance: AMD, INTEL ATX 2.92 2.3/EPS, 80 Plus Bronze Certified
- Silent 12cm fan cooling
- High performance components for enhanced reliability
- Eco-friendly design to meet Elot 3
- Support PCI express
- 1 x (400W) & 2 x (500W/600W)
- Intelligent temperature control, Noise: <26d B
- Multi-Protection OVP, UVP, SCP, OPP, OTP
- Time MTBF: 100, 000 hours minimum
- 80+ Bronze APFC high efficiency: minimum 85% efficiency at 50% load, 82% efficiency at a load of 20% & 100%
- Power consumption in standby <0.5 W
- Temperature: 40 ° C
- Dimensions: 86mm (H) x 150mm (W) x 150mm (D)
- CE/ Ro HS approved CONNECTORS
- 1 x 20+4-Pin ATX12V/EPS12V
- 1 x 4+4-Pin ATX12V/EPS12V
- 1 x 6+2-Pin-PCIe
- 3 x SATA
- 2 x 4-Pin-Molex
- 1 x FDD
- Warranty: 2yr * Does not come with kettle lead























...

The Kolink KL series are 80 Plus Bronze certified power supply units aimed at the budget system build, offering reliable power without a hefty price tag. The KL-500 is able to deliver 500w of continuous power at 80 Plus Bronze efficiency over a single rail, & features multiple protections such as OVP, UVP, SCP, OPP & OTP. The KL series all meet the necessary EU requirements for standby wattage & efficiency. They all contain a low noise 12cm fan & have 1 x (400W) or 2 x (500W/600W) PCI-E 6+2 pin connectors for GPU support. The Kolink KL series PSU are a perfect combination of reliability & functionality, backed up with a 2 year warranty for peace of mind. SPECIFICATIONS
- Power supply: 200V
- 240V / 50-60 Hz
- Wattage: 500W
- Compliance: AMD, INTEL ATX 2.92 2.3/EPS, 80 Plus Bronze Certified
- Silent 12cm fan cooling
- High performance components for enhanced reliability
- Eco-friendly design to meet Elot 3
- Support PCI express
- 1 x (400W) & 2 x (500W/600W)
- Intelligent temperature control, Noise: <26d B
- Multi-Protection OVP, UVP, SCP, OPP, OTP
- Time MTBF: 100, 000 hours minimum
- 80+ Bronze APFC high efficiency: minimum 85% efficiency at 50% load, 82% efficiency at a load of 20% & 100%
- Power consumption in standby <0.5 W
- Temperature: 40 ° C
- Dimensions: 86mm (H) x 150mm (W) x 150mm (D)
- CE/ Ro HS approved CONNECTORS
- 1 x 20+4-Pin ATX12V/EPS12V
- 1 x 4+4-Pin ATX12V/EPS12V
- 2 x 6+2-Pin-PCIe
- 4 x SATA
- 3 x 4-Pin-Molex
- 1 x FDD
- Warranty: 2yr *does not come with kettle lead























...

The Kolink KL series are 80 Plus Bronze certified power supply units aimed at the budget system build, offering reliable power without a hefty price tag. The KL-600 is able to deliver 600w of continuous power at 80 Plus Bronze efficiency over a single rail, & features multiple protections such as OVP, UVP, SCP, OPP & OTP. The KL series all meet the necessary EU requirements for standby wattage & efficiency. They all contain a low noise 12cm fan & have 1 x (400W) or 2 x (500W/600W) PCI-E 6+2 pin connectors for GPU support. The Kolink KL series PSU are a perfect combination of reliability & functionality, backed up with a 2 year warranty for peace of mind. SPECIFICATIONS
- Power supply: 200V
- 240V / 50-60 Hz
- Wattage: 600W
- Compliance: AMD, INTEL ATX 2.92 2.3/EPS, 80 Plus Bronze Certified
- Silent 12cm fan cooling
- High performance components for enhanced reliability
- Eco-friendly design to meet Elot 3
- Support PCI express
- 1 x (400W) & 2 x (500W/600W)
- Intelligent temperature control, Noise: <26d B
- Multi-Protection OVP, UVP, SCP, OPP, OTP
- Time MTBF: 100, 000 hours minimum
- 80+ Bronze APFC high efficiency: minimum 85% efficiency at 50% load, 82% efficiency at a load of 20% & 100%
- Power consumption in standby <0.5 W
- Temperature: 40 ° C
- Dimensions: 86mm (H) x 150mm (W) x 150mm (D)
- CE/ Ro HS approved CONNECTORS
- 1 x 20+4-Pin ATX12V/EPS12V
- 1 x 4+4-Pin ATX12V/EPS12V
- 2 x 6+2-Pin-PCIe
- 4 x SATA
- 3 x 4-Pin-Molex
- 1 x FDD
- Warranty: 2yr *does not come with kettle lead























...

Kolink is steadily becoming renowned for their ability to create quality cases at very competitive prices. Now they have released the extremely stylish KLA-002 Midi-Tower. In terms of functionality, the case offers something that has almost become a rarity these days: two externally accessible 5.25" drive bays. The front is manufactured from premium quality plastic with the look of brushed aluminium. The tidy & well-designed interior of the KLA-002 offers plenty of space for hardware as well as watercooling
- & the cable management options only add to the premium feel of the case as a whole. Despite focusing on value for your money, Kolinks refusal to compromise on quality makes their cases an excellent choice for gamers. The Features of the Kolink KLA-002 Designer case for motherboards up to ATX form factor 1x Pre-installed 80 mm fan in the back I/O Panel with 2x USB (Universal Serial Bus) 2.0 / 1x USB (Universal Serial Bus) 3.0 & HD Audio In/ Out Supports a 240 mm radiator 3x 3.5 & 2x 2.5" drive slots Supports graphics cards up to 35 cm long & CPU coolers up to 15 cm in height The robust chassis is made from one millimetre-thick SECC steel & has a stylish plastic front section that takes after brushed aluminium in its appearance. The power supply would be placed at the top of the case towards the rear, while also offering space for up to two hard drives in front beneath the HDD cage. An additional HDD can be installed onto the reverse side of the motherboard tray. Alternatively, should you prefer, two 2.5" SDDs be installed. The case also reserves plenty of space for cable management. 5.25" drives have become somewhat of a rarity in recent years, but the KLA-002 offers two of them. This has the knock-on effect of allowing users to potentially enjoy the benefits of external fan controllers or optical drives. In order to keep the hardware installed in the case cool, the case

Includes:: a pre-installed 80 mm fan that exhausts warm air out of the spacious case. The front of the case allows for two 120 mm fans. Those who prefer watercooling on the other hand will appreciate the cases ability to support a 240 mm radiator. Large air vents in the front cover also help ensure the interior is kept well-supplied with fresh air. The left side of the case also supports an 80- or 120 mm fan.


...

Kolink is expanding their range of cases with the addition of a new, compact, as well as high-performance case that is designed for use in schools as well as offices. Get ready for the Micro-ATX KLM-002: in terms of pure flexibilty bearing in mind the

Dimensions, this case is a force to be reckoned with. Depending on your space requirements, the case is designed for horizontal or vertical use. The interior allows for up to three 2.5" drives to be installed. A pre-installed 80mm fan helps ensure more than adequate cooling. Features Compact mini case: 35.5 x 9.5 x 28.5cm For motherboards up to Micro-ATX, processors with integrated GPU Horizontal or vertical orientation, stand included with case Slots for a 3.5- & 2.5" drive or up to three 2.5" drives One pre-installed 80mm fan Supports SFX power supplies I/O Panel with 1x USB (Universal Serial Bus) 3.0, 2x USB (Universal Serial Bus) 2.0, Audio In/ Out Kolink KLM-002: The Compact Case for Schools & Offices With a height/width of just 9.5cm the Kolink KLM-002 is exceptionally compact & can be set to the orientation you prefer depending on the space available with the help of an included st&. All told, this makes the KLM-002 an outstanding choice for use in spaces with large numbers of systems such as offices & schools. Despite the compact

Dimensions however, the KLM-002 is built to support a large amount of hardware regardless. The case supports Micro-ATX- & Mini-ITX form factor motherboards. As for graphics cards, 9.5cm of space is available, although the case is ideally suited for use with CPUs that include & integrated GPU. If you do require the extra gaming horsepower however, a low-profile GPU with a max length of approx. 150mm can be installed. Hard Drives & SFX Power Supply Support With air vents on the back, sides & roof, the case is designed from the ground up with airflow in mind, helped by the presence of a pre-installed 80mm fan. On the interior, a total of three 2.5" drives can be installed, & alternatively a 3.5"- & a 2.5" drive are also supported. A compact SFX-form factor power supply is required due to the

Dimensions of the case, this points outwards from the bottom of the case when set vertically. An angled kettle cable must be used so that the cable can be guided out towards the rear. Functionality aside, the appearance of the KLM-002 cuts no corners either. The front has the appearance of brushed aluminium. The I/O panel is also located on the front, offerings a USB (Universal Serial Bus) 3.0- & two USB (Universal Serial Bus) 2.0 ports. Two 3.5" jacks for headphones & microphones are available. The power switch is mounted to the side along the edge of the cases front cover.





...

Featuring a compact size & cost effective design, the Kolink KLM-003 Micro-ATX Case provides a strong solution for business & home office use. The KLM-003 features an attractive brushed aluminium effect front panel with side venting & a 5.25& Prime; drive bay, with internal support for up to a 300mm VGA card & 150mm CPU cooler, alongside ATX power supplies. Features For motherboards up to M-ATX form factor 5.25& Prime; Drive Bay, with space for 2 x 3.5& Prime; HDDs or 3 x 2.5& Prime; SSDs One pre-installed 80mm fan Supports ATX Power Supplies All black coated interior I/O Panel with 1x USB (Universal Serial Bus) 3.0, 1x USB (Universal Serial Bus) 2.0, Audio In/ Out Supports 300mm VGA Cards & 150mm CPU Coolers Kolink KLM-003: Compact yet functional The KLM-003 Micro-ATX case is designed to provide a small footprint within your office or home setup. The

Dimensions are just 365 x 184 x 345 mm in total, however there is plenty of room for your hardware. Graphics cards up to 300mm can be installed, alongside 150mm CPU Coolers & ATX Power supplies. Both Micro-ATX & Mini-ITX motherboards are supported. Storage & cooling covered The KLM-003 Micro-ATX case is designed to provide a small footprint within your office or home setup. The

Dimensions are just 365 x 184 x 345 mm in total, however there is plenty of room for your hardware. Graphics cards up to 300mm can be installed, alongside 150mm CPU Coolers & ATX Power supplies. Both Micro-ATX & Mini-ITX motherboards are supported. Storage & cooling covered The KLM-003 has space for either 2 x 3.5& Prime; HDDs or 3 x 2.5& Prime; SSDs. Theres up to 16mm of cable management space available behind the motherboard tray for more effective routing of power supply cables & theres also space for a 5.25& Prime; device such as an optical drive. A 80mm fan is installed at the rear as standard, with space for a 120mm fan available on the side panel. Functionality aside, the KLM-003 offers a simple yet attractive look with solid steel side panels & a brushed aluminium effect front panel design. The I/O panel is located on the top panel & sports a USB3.0 port, alongside a USB2.0 port. Two 3.5& Prime; jacks for headphones & microphones are available, along with the power button.



...

The Kolink Levante features a striking mesh front panel that subtly covers, although still leaves visible, three pre-installed RGB rainbow fans. The combination of RGB lighting & the mesh panel creates an impressive visual effect. The Kolink Levante also

Includes:: fully dual tempered glass panels on the cases left & right sides. The look is completed by a further pre-installed RGB rainbow fan mounted at the rear of the case. An overview of: Midi Tower case 440 x 206.5 x 475mm (Hx Wx D) Can hold up to E-ATX form factor motherboards Tempered glass right & left side panels

Includes:: 4x 120mm Ring Rainbow RGB fans Dedicated RGB lighting controller & remote control both bundled with case The Kolink Levante in detail: The Kolink Levante has an extraordinary design & is a highly functional Midi Tower case. It features a mesh front panel & dual tempered glass side panels. These enable users to prominently display the four bundled 120mm RGB fans as well as any other components they want to show the world. Not only do the fans look great but ensure excellent airflow for top performance. Three are fitted to the front panel while the last one goes in the back panel. Combined they create a striking effect. Kolink have included an RGB controller that can sync RGB lighting components within the case. This controller can manage up to 6 x fans & 2 x RGB strips & offers over 350 different lighting effects & modes. Theres even a remote control included to make switching between effects hassle-free. The Kolink Levante has many options for connectivity with the possibility of installing up to three 2.5"/3.5" HDD/SSD drives & a further two 2.5" HDD/SSD drives. The case features useful ports too, including a USB (Universal Serial Bus) 3.0 port on the front, individual audio ports for mics & headphones, an RGB control button & two USB (Universal Serial Bus) 2.0 ports. A bundled PSU shroud helps considerably in maintaining a neat & tidy look thanks to excellent cable management.



...

The Luminosity RGB Midi-Tower is another highly refined case from Kolink built with great looks & maximum hardware compatibility in mind. With a stylish appearance & an emphasis on lighting to showcase it all, Kolink has gone above & beyond to design something special. This case not only looks spectacular in its standard configuration, it is also designed in such a way that the lighting you select to customise this case with looks even better. Whilst Kolinks reputation for attractive pricing also shines through, the Luminosity shines in other aspects as well. The Perfect Midi-Tower to Showcase Your Lighting A large full acrylic side window & two RGB 12 cm 15 LED fans on the front panel & a 12 cm fan on the rear offer the perfect lighting to show off the components you have chosen to build into your PC, especially if those components themselves utilise RGB lighting e.g. Ai O coolers or graphics cards. The tinted & partially transparent front panel also reduces glare from RGB components which helps to ensure lighting is evenly balanced around the inside of the case as well as making the included RGB LED fans even more eye-catching. The Features of the Kolink Luminosity Gaming Case at a Glance However maximising the visual effect of your gaming PC extends further than RGB lighting alone. Kolink knows that it is the combination of good cable management with attractive RGB lighting that separates the attractive gaming PCs from the stunning. For this reason Kolink has chosen to include a PSU shroud whose effects are two-fold: firstly it optimises the airflow to your CPU & GPU, which is vital for the smooth running of your PC in the long term, but secondly the placement of the PSU behind a shroud on the bottom of the case also means a large proportion of cabling is instantly concealed without having to resort to time-consuming cable management. Kolinks attention to detail extends further than the appearance of the case however. In terms of optical drives & storage options, the front of the case is capable of holding two 5, 25" drives in the upper slots, while the area below is occupied by two large RGB LED fans. Two further 3.5" drive bays as well as two 2.5" bays are available internally. This expandability means that with a Kolink case your upgrade options in the future are equally broad. The I/O panel in the front of the case offers one USB (Universal Serial Bus) 3.0 port (with USB (Universal Serial Bus) 2.0 converter), two USB (Universal Serial Bus) 2.0 ports, HD Audio & a microphone input. ...

The Modular Power PSUs from Kolink boast an enhanced circuit design & an associated performance increase. These features offer a significant enhancement of voltage regulation & meet the needs of modern powerful computers. In addition, the extremely quiet 120mm fan, with a fined-tuned RPM curve, has been optimized for airflow. This makes the Modular Power the quietest power supply of its kind. The Modular Power PSUs looks amazing in any high-end gaming system due to its modern design & the flexible, flat & semi-modular cables use for connections across the system. Features 444W & 37A on a 12V rail 80 PLUS bronze certificate for high efficiency ATX form factor with a length of 160 mm Semi-modular cable management, modern look with flat black cables Connectors: 1x 24-pin, 1x 4+4-pin, 2x 6+2-pin, 4x SATA, 2x Molex Kolink Modular Power: Full performance & high efficiency The 500 Watt model of the Modular Power series offered here has enough connections & performance for fast gaming computers with basic equipment. The PSU delivers up to 444W & 37A on the +12V rail while providing 100W & 15A each on the +3.3V & +5V rails. This especially high efficiency meets the requirements of 80 Plus Bronze 230V EU & exceeds 85/82/82 percent at 50/20/100 percent load (at 230 Volt input voltage). The PSUs highly efficient circuit design features independent DC-to-DC converters for the 3.3V & 5V outputs, ensuring extremely precise voltage regulation. Each example of Modular Power series is cooled by a 120 mm fan with durable & quiet sleeve bearings that offer a fine-tuned RPM curve. Thanks to the optimized airflow, the fan & thus the entire PSU remain quiet as a whisper. Besides the 20+4 pin for the motherboard, the Kolink Modular Power has a 4+4 pin connector for the CPU & two 6+2 pin connectors for dedicated graphics cards. Four SATA & two Molex connectors are available for additional components. The flat, flexible, completely & semi-modular black cables have a modern look & fit into almost any up-to-date gaming setup. Note: For environmental reasons the manufacturer does not supply a power cord for connection to the mains. ...
