This 2-port 10GBASE-T module provides 2 dual-speed 1000BASE-T or 10GBASE-T RJ-45 ports. Can also be used for low cost stacking. For use with HPE Flex Network 5130 HI & HPE Flex Network 5510 HI switches. ...

HPE 524SFP+ 10 Gigabit Ethernet Card
- PCI Express 3.0 x 8
- 2 Port (s)
- Optical Fiber Improve CPU Utilization with Lower


...

The HPE Ethernet 10 Gb 2-port 530T Adapter is a dual-port 10GBASE-T adapter, featuring the BCM57810S 10 Gb Ethernet solution from Broadcom in a PCIe 2.0 compliant form factor designed for HPE Pro Liant Gen 8 rack & tower servers. The HPE 530T Adapter delivers full line-rate performance across all ports with low power consumption, utilizing CAT 6A UTP cabling with distances up to 100 meters. Providing high performance Ethernet connectivity, it is ideal for virtual server & cloud computing environments. It supports enterprise class features (VLAN tagging, adaptive interrupt coalescing, MSI-X, NIC teaming (bonding), Receive Side Scaling (RSS), jumbo frames, PXE boot) & virtualization features (VMware Net Queue & Microsoft VMQ). The adapter's support for HPE Sea of Sensors 3D Technology enhances server performance by reducing energy consumption & expense. ...

HPE 535T 10 Gigabit Ethernet Card for Server
- PCI Express 3.0 x 8
- 2 Port (s)
- 2
- Twisted Pair Are you looking for



...

Do you need an adapter that is big on capability & small on CPU utilization? The HPE Ethernet 10 Gb 2-port 537SFP+ Adapter has been designed to efficiently deliver high performance, low latency & minimal CPU utilization by offloading many I/O processing within the adapter. Low latency dramatically improves application performance & frees up CPU resources in the host allowing it to do more important tasks Features Improve Application Performance
- HPE Ethernet 10 Gb 2-port 537SFP+ Adapters offload packet processing to reduce CPU utilization with tunnel offloads (VXLAN & NVGRE). Now you can distribute network traffic across CPU cores in your data center.
- Speed up packet processing to service more I/O requests by utilizing data plane development kit (DPDK) feature. Increase I/O Bandwidth for Workload Intensive Applications
- HPE Ethernet 10 Gb 2-port 537SFP+ Adapters deliver single root I/O virtualization (SR-IOV) which increases virtual network performance while decreasing CPU utilization.


...

Designed For Aruba 5406R zl 2, 5406R-44G-Po E+/2SFP+ v 2 zl 2, 5406R-44G-Po E+/4SFP v 2 zl 2, 5406R-8XGT/8SFP+ v 2 zl 2 ...

Designed For HPE Aruba 5406R zl 2, 5406R-44G-Po E+/2SFP+ v 2 zl 2, 5406R-44G-Po E+/4SFP v 2 zl 2, 5406R-8XGT/8SFP+ v 2 zl 2 ...

Flexible, Scalable & SDN Ready for the Campus Network The HP 5400 zl Switch Series provides flexibility, scalability & ease of use for enterprise edge, SMB, & branch office core deployments. This modular switch has license free software with an advanced Layer 2 & 3 feature set; IPv 4 BGP, policy based routing, IPv 4/IPv 6 OSPF, & robust Qo S. Purpose-built HP Networking ASIC delivers wire-speed classification & policy enforcement. This hardware-based control of access & traffic allows protection, detection & response to network threats with no network performance degradation. Flexible connectivity options with 6 or 12 slot chassis with support for 10/100, Gigabit Ethernet & 10 Gigabit Ethernet (10GBASE-T & SFP+), & Po E+. Robust virtualization with versatile HP Alliance One service modules. Software-defined Network (SDN) ready with Open Flow support for future proofing your network. Security & Quality of Service The HP 5400 zl Switch Series

Includes:: security & quality of services features so your network can more securely deliver the performance your users require. Flexible authentication options include Local MAC Authentication, 802.1X, MAC & Web Authentication, for enhanced security & policy-driven application authentication. Advanced distributed denial of service (DDOS) protection, such as DHCP Snooping, IP Source Guard, & ARP Protection, & flexible traffic controls, such as policy-based routing, Qo S, & ACLs, to manage end-to-end application priorities. Powerful multilevel-access security controls, such as varying security management login, RADIUS/TACACS+, & SSH to enhance security & control change management access. Defend the edge of your IPv 6 network with DHCPv 6 Protection & Dynamic IPv 6 Lockdown. Single View of the Network The HP 5400 zl Switch Series can be seamlessly managed with HP Intelligent Management Center (IMC) Software Platform to provide end-to-end network transparency with consistent network experience through comprehensive configuration, compliance & policy management. RMON, XRMON & s Flow provide advanced monitoring & reporting capabilities for statistics, history, alarms & events. Performance High-speed, high-capacity architecture: 1 Tbps crossbar switching fabric provides intra-module & inter-module switching with 585.6 million pps throughput on the purpose-built Pro Vision ASICs Selectable queue configurations: allows for increased performance by selecting the number of queues & associated memory buffering that best meet the requirements of the network applications Resiliency & high availability Virtual Router Redundancy Protocol: allows groups of two routers to dynamically back each other up to create highly available routed environments IEEE 802.1s Multiple Spanning Tree Protocol: provides high link availability in multiple VLAN environments by allowing multiple spanning trees; encompasses IEEE 802.1D Spanning Tree Protocol & IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.3ad Link Aggregation Control Protocol (LACP) & HP port trunking: support up to 144 trunks, each with up to eight links (ports) per trunk Distributed trunking: enables loop-free & redundant network topology without using Spanning Tree Protocol; allows a server or switch to connect to two switches using one logical trunk for redundancy & load sharing Optional redundant power supply (HP 5400 series): provides uninterrupted power & allows hot-swapping of the redundant power supplies when installed Layer 2 switching VLAN support & tagging: supports the IEEE 802.1Q standard & 2, 048 VLANs simultaneously IEEE 802.1v protocol VLANs: isolate select non-IPv 4 protocols automatically into their own VLANs GARP VLAN Registration Protocol: allows automatic learning & dynamic assignment of VLANs IEEE 802.1ad Q-in-Q: increases the scalability of an Ethernet network by providing a hierarchical structure; connects multiple LANs on a high-speed campus or metro network MAC-based VLAN: provides granular control & security; uses RADIUS to map a MAC address/user to specific VLANs (requires v 2 modules)

...

Power & innovation to converge your mobile campus The HP 5400R zl 2 Switch Series is an industry leading mobile campus access solution with HP smart rate multi-gigabit ports for high speed connectivity for next wave 802.11ac devices. It brings enterprise-class resiliency & true flexibility, security & scalability to converged campus networks. Resiliency & high availability at the edge The HP 5400R zl 2 Switch Series utilizing the 6th generation HP networking ASIC delivers wire-speed classification & policy enforcement. This hardware-based control of access & traffic allows protection, detection & response to network threats with no network performance degradation. Main Specifications
- Product Description: HPE 5406R 44GT Po E+ / 4SFP+ (No PSU) v 3 zl 2 Switch
- switch
- 44 ports
- Managed
- rack-mountable
- Device Type: Switch
- 44 ports
- Managed
- Enclosure Type: Rack-mountable 4U
- Subtype: Gigabit Ethernet
- Ports: 44 x 10/ 100/ 1000 (Po E+) + 4 x 1 Gigabit / 10 Gigabit SFP+
- Power Over Ethernet (Po E): Po E+
- Performance: Routing/ switching capacity:960 Gbps Throughput:up to 571.4 Mpps Switching fabric band
Width:1015 Gbps
- Capacity: IPv 4 routing table entries:10000 IPv 6 routing table entries:5000
- MAC Address Table

Size: 64K entries
- Jumbo Frame Support: Yes
- Routing Protocol: RIP-1, RIP-2, BGP, IGMP, VRRP, OSPFv 2, PIM-SM, static IP routing, PIM-DM, IGMPv 3, OSPFv 3, static IPv 6 routing, MLDv 2, MLD
- Remote Management Protocol: SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SMON, CLI, XRMON
-

Features: Flow control, routing, DHCP support, BOOTP support, ARP support, trunking, VLAN support, auto-uplink (auto MDI/ MDI-X), IGMP snooping, Diff Serv support, IPv 6 support, half duplex mode, full duplex mode, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, tunnelling, Access Control List (ACL) support, Quality of Service (Qo S), MLD snooping, Non-Stop Routing (NSR), bandwidth control, STP Root Guard, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv 4 support, DHCP relay, Port Security, fan tray, DHCP client, Energy Efficient Ethernet, Management Information Base (MIB), dynamic ARP protection, DHCP protection, dual firmware images, Class of Service (Co S), s Flow v 5, GARP VLAN Registration Protocol (GVRP), Type of Service (To S), MACsec support
- Compliant Standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX
- Dimensions: (Wx Dx H) 44.45 cm x 45.09 cm x 17.53 cm
- Weight: 12.75kg
- Manufacturer Warranty: Limited lifetime warranty



























...

- Product Description: HPE 5412R-92G-Po E+/ 4SFP v 2 zl 2 Switch
- switch
- 92 ports
- Managed
- rack-mountable
- Device




...
