Features
- The Worlds first Direct X 11 PCIe 1x graphics solution with Eyefinity technology (through Display Port output) Bringing
...

292 million 40nm transistors Tera Scale 2 unified processing architecture Compliant with Direct X 11 & earlier revisions ATI Stream technology Designed for Direct Compute 11 & Open CLAccelerated Video Transcoding (AVT) Compliant with Direct X 11 & earlier revisions Supports Open GL 3.2ATI Avivo HD video & display technology ATI Power Play technology ATI Cross Fire X multi-GPU technology PCI Express 2.1 support ...

Chipset
- Radeon HD 6450 PCI-e Series ASIC
- Radeon TM HD 6450 GPU Manu. Process (Micron)
- 40nm Memory Size (MB)
- 1024



...

Chipset
- Radeon HD 6750 PCIe Series Manu. Process (Micron)
- 40nm Memory Size (MB)
- 1024 Memory Type
- GDDR5 Engine



...

Ice Q X Cooling Technology Faster Make your Overclocking dream comes true! The HIS Ice Q X Turbo models are bios-overclocked out of the box, & thus brings the immersive gamers the best over-clocking potential. Cooler HIS 6770 Ice Q X is cooler than the Reference Cooler. Thanks to the 9.2cm silent fan, massive amount of cool air is drawn from the central fan to cool down the GPU & graphics card directly. 2 heatpipes optimize cooling performance by removing heat from the core area, providing ultimate solution for professional gamers & HTCP users. Quieter HIS 6770 Ice Q X is quieter than the Reference Cooler. High Quality Components High-end components & techniques reinforce stability & durability. Specifications Chipset
- Radeon HD 6770 PCIe Series Manu. Process (Micron)
- 40nm Memory Size (MB)
- 1024 Memory Type
- GDDR5 Engine Clock (MHz)
- 880 Mhz Memory Clock (Gbps)
- 5 Gbps Memory Interface (bit)
- 128 Power Supply Requirement
- 450 Watt or greater power Max. Resolution
- 2560*1600 Bus Interface
- PCI Express x 16 Display Port
- Yes HDMI
- Yes DVI
- 2x Dual-link DVI-I HD 6770 System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 450 Watt or greater power supply with one 75W 6-pin PCI Express power connectors recommended (600 Watt & two 6-pin connectors for AMD Cross Fire X technology in dual mode). Minimum 1GB of system memory Installation software requires CD-ROM drive or DVD-ROM drive, a keyboard, a mouse, & a display DVD playback requires DVD drive & a DVD Blu-ray playback requires Blu-ray drive For an AMD Cross Fire X system, a second AMD Radeon HD 6770 Graphics card, an AMD Cross Fire X Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable is required Use of 3 or more displays with AMD Eyefinity technology requires a Display Port-capable panel or an AMD Eyefinity validated dongle












...

Ice Q X Cooling Technology Cooler HIS 6950 Ice Q X is cooler than the Reference Cooler. Thanks to the 9.2cm silent fan, massive amount of cool air is drawn from the central fan to cool down the GPU & graphics card directly. 4 heatpipes optimize cooling performance by removing heat from the core area, providing ultimate solution for professional gamers & HTCP users. Quieter HIS 6950 Ice Q X is quieter than the Reference Cooler. High Quality Components High-end components & techniques reinforce stability & durability. Dynamic Phase Control PWM IC
- A significant energy saving technique for reducing power consumption. Solid State Choke (SSC)
- Durable Iron that can maximize current capacity, power efficiency & stability. Full Solid State Capacitors
- Extend the lifespan & storage capabilities. Specifications Chipset
- Radeon HD 6950 PCIe Series ASIC
- Radeon HD 6950 GPU Manu. Process (Micron)
- 40nm Memory Size (MB)
- 2048 Memory Type
- GDDR5 Engine CLK (MHz)
- 800 Mhz Memory CLK (Gbps)
- 5 Gbps Memory Interface (bit)
- 256 Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 2560*1600 (Single Display) Bus Interface
- PCI Express x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Upper Single-link DVI-D + Bottom Dual-link DVI-I HD 6950 System Requirement PCI Express based PC is required with one X16 lane graphics slot with 2 slots space available on the motherboard 500 Watt or greater power supply with two 750W 6-pin PCI Express power connectos recommended Certified power supplies are recommended Minimum 1GB of system memory Installation software requires CD-ROM drive, a keyboard, a mouse, & a display DVD playback requires DVD drive & a DVD Blu-ray playback requires Blu-ray drive & a Blu-ray disc For an AMD Cross Fire X system, a second AMD Radeon HD 6900 Series graphics card, an AMD Cross Fire X Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable is required
















...

The HIS 6970 Ice Q is over 23 Degrees C Cooler than the reference cooler. Quieter than the reference cooler. 4 heatpipes optimise cooling performance by removing heat from the core area, providing the ultimate solution for professional gamers & HTPC users. Cool air is drawn from both sides of the fan to therby enhance the cooling efficiency. Directly exhausts hot air out of the PC case. Chipset
- Radeon HD 6970 PCIe Series ASIC
- Radeon HD 6970 GPU Manu. Process (Micron)
- 40nm Memory Size (MB)
- 2048 Memory Type
- GDDR5 Engine CLK (MHz)
- 900 Mhz Memory CLK (Gbps)
- 5.6 Gbps Memory Interface (bit)
- 256 Power Supply Requirement
- 550 Watt or greater power Max. Resolution
- 2560*1600 (Single Display) Bus Interface
- PCI Express x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Upper Single-link DVI-D + Bottom Dual-link DVI-I HD 6970 System Requirement PCI Express based PC is required with one X16 lane graphics slot with 2 slots space available on the motherboard 550 Watt or greater power supply with one 75W 6-pin PCI Express power connector & one 150W 8-pin PCI Expresss power connector recommended Certified power supplies are recommended Minimum 1GB of system memory Installation software requires CD-ROM drive, a keyboard, a mouse, & a display DVD playback requires DVD drive & a DVD Blu-ray playback requires Blu-ray drive & a Blu-ray disc For an AMD Cross Fire X system, a second AMD Radeon HD 6900 Series graphics card, an AMD Cross Fire X Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable is required













...

The card offers outstanding graphics quality & an effective cooling solution for mid-high end HTPC users. Good Graphics Power for HTPC Users With core & memory clocks at 800 M Hz & 4500 M Hz, the card ensures the highest graphics enjoyment for movies & various applications, perfect for HTPC users. With HIS high quality component, the card has higher stability & longer life span. The card also comes with the innovative overclocking software by HIS – i Turbo. User can control the temperature, speed & power in their hands! The card has low power consumption, requiring only 400W power supply & no external power! It is also loaded with AMD latest power saving technologies such as AMD Power Play™ & AMD Power Tune technologies! Model Name
- HIS 7750 i Cooler 1GB GDDR5 PCI-E DVI/HDMI/VGA Chipset
- Radeon HD 7750 PCIe Series ASIC
- Radeon TM HD 7750 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 1024 Memory Type
- GDDR5 Engine CLK (MHz)
- 800 M Hz Memory CLK (Gbps)
- 1.6 Gbps Memory Interface (bit)
- 128bit Power Supply Requirement
- 400 Watt or greater power Max. Resolution
- 2560x 1600 per display (Dual-link DVI) 2048x 1536 per display (VGA) Bus Interface
- PCI Express 3.0 x 16 Display Port
- No HDMI
- Yes DVI
- Dual-link DVI-I VGA
- Yes HD 7750 System Requirements
- PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 400W (or greater) power supply recommended. 500W power supply (or greater) recommended for AMD Cross Fire™ technology in dual mode Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx for a list of Certified products Minimum 1GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray™ playback requires Blu-ray drive
















...

Introducing the HIS 7750 i Cooler 2GB! The card offers outstanding graphics quality & an effective cooling solution for mid-high end HTPC users. The card has 2GB memory, i Cooler, i Turbo, high quality components & low power consumption! With core & memory clocks at 800 M Hz & 1600 M Hz & the additional 2GB memory, the card ensures the highest graphics enjoyment for movies & various applications. With HIS high quality component, the card has higher stability & longer life span. The card also comes with the innovative overclocking software by HIS – i Turbo. User can control the temperature, speed & power in their hands! The card has low power consumption, requiring only 400W power supply & no external power! It is also loaded with AMD latest power saving technologies such as AMD Power Play™ & AMD Power Tune technologies! Model Name
- HIS 7750 i Cooler 2GB DDR3 PCI-E DVI/HDMI/VGA Chipset
- Radeon HD 7750 PCIe Series ASIC
- Radeon TM HD 7750 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 2048 Memory Type
- DDR3 Engine CLK (MHz)
- 800 M Hz Memory CLK (Gbps)
- 1.6 Gbps Memory Interface (bit)
- 128bit Power Supply Requirement
- 400 Watt or greater power Max. Resolution
- 2560x 1600 per display (Dual-link DVI) 2048x 1536 per display (VGA) Bus Interface
- PCI Express 3.0 x 16 Display Port
- No HDMI
- Yes DVI
- Dual-link DVI-I VGA
- Yes HD 7750 System Requirements
- PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 400W (or greater) power supply recommended. 500W power supply (or greater) recommended for AMD Cross Fire™ technology in dual mode Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx for a list of Certified products Minimum 1GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray™ playback requires Blu-ray drive
















...

The card is equipped with the widely acclaimed HIS i Cooler – certified by HIS that generates less than 28 d B in 2D mode. HIS i Cooler provides an outstanding cooling performance & quiet environment. With HIS i Cooler, the life span of the card is maximized while the noise level is minimized! Model Name
- HIS 7770 i Cooler 1GB GDDR5 PCI-E DVI/HDMI/VGA Chipset
- Radeon HD 7770 PCIe Series ASIC
- Radeon TM HD 7770 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 1024 Memory Type
- GDDR5 Engine CLK (MHz)
- 1000 M Hz Memory CLK (Gbps)
- 4.5 Gbps Memory Interface (bit)
- 128bit Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 2560x 1600 per display (Dual-link DVI) 2048x 1536 per display (VGA) Bus Interface
- PCI Express 3.0 x 16 Mini Display Port
- No HDMI
- Yes DVI
- Dual-link DVI-D VGA
- Yes HD 7770 System Requirements
- PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 500W (or greater) power supply with one 75W 6-pin PCI Express power connector recommended 600W power supply (or greater) with two 75W 6-pin PCI Express power connectors recommended for AMD Cross Fire™ technology in dual mode. Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx for a list of Certified products Minimum 4GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray™ playback requires Blu-ray drive For AMD Cross Fire™ system, a second AMD Radeon™ HD7770 GPU, & AMD Cross Fire™ Ready motherboard is required.
















...
