The Worlds first Direct X 11 PCI graphics solution with native HDMI output Bringing upgrade possibilities to motherboard with PCI slots only Multi-monitoring solution High Profile Form Factor with interchangeable low profile brackets Best for Business & Multimedia application Model Name
- HIS 5450 Silence 512MB DDR3 PCI HDMI/DVI/VGA Chipset
- Radeon HD 5450 PCI Series ASIC
- Radeon TM HD 5450 GPU Pixel fill rate
- 2.6 Gigapixels/sec Stream Processing Units
- 80 Manu. Process (Micron)
- 40nm Memory Size (MB)
- 512 Memory Type
- DDR3 Engine CLK (MHz)
- 650 M Hz Memory CLK (Gbps)
- 1000 M Hz Memory Interface (bit) -64 Power Supply Requirement
- 400 Watt or greater power supply recommended Max. Resolution
- 2560*1600 (Dual dual-link) Bus Interface
- PCI Display Port
- No HDMI
- Yes DVI
- Yes VGA
- Yes
















...

Model Name
- HIS 9250 128MB (64bit) PCI Chipset
- Radeon 9250 Series ASIC
- RV280 Pixel Pipelines
- 4 Vertex Engines
-




...

Display Port to Single Link-DVI Eyefinity Adapter Enables ATI Eyefinity multiple-display, supports up to 6 displays Connects Display Port output to a DVI-Enabled HDTV, Monitor or Projector Simply connect the Display Port end of the connector to ATI Eyefinity-compliant graphics card, & plug your existing display into the DVI adapter. The built-in USB (Universal Serial Bus) connection provides power to the cable adapter. Resolution
- Up to 1920x 1200 & 1080p AMD Eyefinity Ready
- Yes HDCP
- Yes


...

Mini isplay Port to Single Link-DVI Eyefinity Adapter Enables ATI Eyefinity multiple-display, supports up to 6 displays Connects Mini Display Port output to a DVI-Enabled HDTV, Monitor or Projector Simply connect the Mini Display Port end of the connector to ATI Eyefinity-compliant graphics card, & plug your existing display into the DVI adapter. ATI Eyefinity Technology
- Experience the Power of 6! To enable more than two displays, additional panels with native Display Port connectors, and/or certified Display Port adapters to convert your monitor˜s native input to your cards Display Port or Mini-Display Port connector (s), are required. ATI Eyefinity technology requires one panel with a Display Port connector to enable the third display. Display Port to DVI dongle is required for panel with DVI connector. ATI Eyefinity technology can support up to 6 displays using a single enabled ATI Radeon„¢ graphics card with Windows Vista or Windows 7 operating systems
- the number of displays may vary by board design & you should confirm exact specifications with the applicable manufacturer before purchase. ATI Eyefinity technology works with games that support non-standard aspect ratios, which is required for panning across multiple displays. Specifications Resolution
- Up to 1920x 1200 & 1080p AMD Eyefinity Ready
- Yes HDCP
- Yes




...

Features
- The Worlds first Direct X 11 PCIe 1x graphics solution with Eyefinity technology (through Display Port output) Bringing
...

292 million 40nm transistors Tera Scale 2 unified processing architecture Compliant with Direct X 11 & earlier revisions ATI Stream technology Designed for Direct Compute 11 & Open CLAccelerated Video Transcoding (AVT) Compliant with Direct X 11 & earlier revisions Supports Open GL 3.2ATI Avivo HD video & display technology ATI Power Play technology ATI Cross Fire X multi-GPU technology PCI Express 2.1 support ...

Chipset
- Radeon HD 6450 PCI-e Series ASIC
- Radeon TM HD 6450 GPU Manu. Process (Micron)
- 40nm Memory Size (MB)
- 1024



...

Chipset
- Radeon HD 6750 PCIe Series Manu. Process (Micron)
- 40nm Memory Size (MB)
- 1024 Memory Type
- GDDR5 Engine



...

Ice Q X Cooling Technology Faster Make your Overclocking dream comes true! The HIS Ice Q X Turbo models are bios-overclocked out of the box, & thus brings the immersive gamers the best over-clocking potential. Cooler HIS 6770 Ice Q X is cooler than the Reference Cooler. Thanks to the 9.2cm silent fan, massive amount of cool air is drawn from the central fan to cool down the GPU & graphics card directly. 2 heatpipes optimize cooling performance by removing heat from the core area, providing ultimate solution for professional gamers & HTCP users. Quieter HIS 6770 Ice Q X is quieter than the Reference Cooler. High Quality Components High-end components & techniques reinforce stability & durability. Specifications Chipset
- Radeon HD 6770 PCIe Series Manu. Process (Micron)
- 40nm Memory Size (MB)
- 1024 Memory Type
- GDDR5 Engine Clock (MHz)
- 880 Mhz Memory Clock (Gbps)
- 5 Gbps Memory Interface (bit)
- 128 Power Supply Requirement
- 450 Watt or greater power Max. Resolution
- 2560*1600 Bus Interface
- PCI Express x 16 Display Port
- Yes HDMI
- Yes DVI
- 2x Dual-link DVI-I HD 6770 System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 450 Watt or greater power supply with one 75W 6-pin PCI Express power connectors recommended (600 Watt & two 6-pin connectors for AMD Cross Fire X technology in dual mode). Minimum 1GB of system memory Installation software requires CD-ROM drive or DVD-ROM drive, a keyboard, a mouse, & a display DVD playback requires DVD drive & a DVD Blu-ray playback requires Blu-ray drive For an AMD Cross Fire X system, a second AMD Radeon HD 6770 Graphics card, an AMD Cross Fire X Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable is required Use of 3 or more displays with AMD Eyefinity technology requires a Display Port-capable panel or an AMD Eyefinity validated dongle












...
