GIGABYTE HD Experience Series
- Powered by NVIDIA Ge Force GT 640 GPU Integrated with industrys best 2048MB DDR3 memory & 128-bit
...

Gigabyte Ge Force GT 710 2GB DDR3 VGA Dual-Link DVI-D HDMI PCI-E Graphics card Ultra Durable 2 Technology Fitted with high quality components to deliver lower temperature, reliable operation & longer system lifespan. Ultra Cooling Low RDS (on) MOSFET Design Low Power Loss Ferrite Core Choke Design Longer Life All-Solid Capacitor Design OC GURU II Utility Adjust clock speeds, voltage, fan performance, power target, OSD setting can be monitored & tuned in real-time according to your own preference through this intuitive interface.

Specification Chipset GT 710 Core Clock 954 MHz (Standard: 954 MHz) Process Technology 28 nm Memory Clock 1800 MHz Memory Size 2GB Memory Bus 64-bit Memory Type DDR3 Card Bus PCI-E 2.0 x 8 Direct X 12 Open GL 4.5 PCB Form Low profile Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 2 I/O Dual-link DVI-D*1 / HDMI*1 / D-Sub*1 Card size H=24 L=147 W=106 mm (TBD) Power requirement 300W

...

Features Powered by NVIDIA Ge Force GT 710 GPU Integrated with the first 1024MB DDR3 memory & 64-bit memory interface Core Clock: 954 M Hz Features Dual-link DVI-D / D-Sub / HDMI Support PCI Express 2.0 x 8 bus interface Recommended system power supply requirement: 300W

Specification Graphics Processing Ge Force GT 710 Core Clock 954 MHz (Standard: 954 MHz) Memory Clock v 2.0 1600 MHz v 1.0 1800 MHz Memory Size 1 GB Memory Type DDR3 Memory Bus 64 bit Card Bus PCI-E 2.0 Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 3 Card size H=35 L=151 W=69 mm PCB Form Low Profile Direct X 12 Open GL 4.5 Recommended PSU 300W I/O Dual-link DVI-D*1 / HDMI*1 / D-Sub*1 Accessories HDMI+DVI low profile bracket x 1 D-SUB low profile bracket x 1

...

Your whole PC experience
- a whole lot faster Accelerate your entire PC experience with a new NVIDIA Ge Force GT 740 graphics card.
...

Powered by NVIDIA Ge Force GT 220 GPU Supports PCI Express 2.0 Microsoft Direct X 10.1 & Open GL 3.1 support Integrated with industrys best 1GB DDR3 memory & 128-bit memory interface Supports NVIDIA Pure Video HD technology Features Dual link DVI-I / D-sub / HDMI with HDCP protection Chipset NVIDIA Gigabyte GT220 Core Clock 720 MHz Mem Clock 1600 MHz Memory 1 GB Memory Bus 128 bit Memory Type DDR 3 Card dimension ATX Bus Type PCI-E 2.0 Bus Speed 16 D-SUB Yes DVI Port Yes Multi View Yes Shader Clock 1566 MHz Maximum Digital Resolution 2560x 1600 Maximum VGA Resolution 2048x 1536 ...

Features Powered by Ge Force GTX 1050 Integrated with 2GB GDDR5 128bit memory WINDFORCE 2X with Blade Fan Design Protection Back Plate Core Boost: 1531 MHz/ Base: 1417 MHz in OC Mode Boost: 1506 MHz/ Base: 1392 MHz in Gaming GIGABYTE custom-designed 90 mm fan cooler, with air flow optimized cover & aluminum base. The cooler can dissipate heat effectively from the GPU while keeping the fan at lower speed & noise. Unique Blade Fan Design The airflow is spilt by the triangle fan edge, & guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the air flow by 23% over traditional fans. Alternate Spinning Fan Design Optimize air flow by the alternate spinning fans that reduce air turbulence & effectively dissipate the heat. 3D Active Fan with LED Indicators The semi-passive fans will remain off when the GPU is under a set loading or temperature for low power gaming. The LED fan indicator on the top of the graphics card provides an instant display of the fan status. One-click Super overclocking With a simple click on XTREME engine utility, gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge, while saving the hassle of manual adjustment. Specification Graphics Processing- Ge Force GTX 1050 Ti Boost: 1531 MHz/ Base: 1417 MHz in OC Mode Boost: 1506 MHz/ Base: 1392 MHz in Gaming Process Technology- 16 nm Memory Clock- 7008 MHz Memory Size- 2 GB Memory Type- GDDR5 Memory Bus- 128 bit Card Bus- PCI-E 3.0 x 16 Output- Dual-link DVI-D *1 HDMI-2.0b*3 (Max Resolution: 4096x 2160 @60 Hz) Display Port-1.4 *1 (Max Resolution: 7680x 4320 @60 Hz) Digital max resolution- 7680x 4320 Multi-view- 3 Card size- H=40 L=229 W=118 mm PCB Form- ATX Direct X- 12 Open GL- 4.5 Recommended PSU- 300W Power Connectors- NA ...

Promotional keys for Fortnite gear will be sent out via email. These will be sent up to 5 working days after the invoice date. Features Powered by Ge Force GTX 1060 Integrated with 6GB GDDR5 192bit memory WINDFORCE 2X with Blade Fan Design Support up to 8K display @60 Hz 16.8M Customizable Colour RGB Lighting Overview GIGABYTE G1 Gaming Series graphics cards are crafted for perfection in pursuit of the ultimate graphics experience for gaming enthusiasts. Based on the revolutionary NVIDIA Pascal™ GPU architecture, G1 gaming graphics card brings you incredible gaming experience. Pascal-powered graphics card give you superior performance & power efficiency Support up to 8K display @60 Hz Outstanding performance for Virtual Reality gaming Displays Supports DVI-D, HDMI 2.0 & Display Port 1.4 connections. Allowing up to 4 independent screens to be displayed at once. Cooling The WINDFORCE 2X cooling system features two 90mm unique blade fans, 2 pure copper composite heat-pipes, alternate spinning fan design, & heat pipes direct touch technology, together delivering an effective heat dissipation capacity for higher performance at lower temperatures. Alternate Spinning Fan Design Optimize air flow by the alternate spinning fans that reduce air turbulence & effectively dissipate the heat. 16.8M Customizable Colour Lighting With 16.8M customizable colour options & numerous lighting effects, you could now choose the right scheme for your gaming rig through XTREME Engine utility.

Specification Graphics Processing Ge Force GTX 1060 Core Clock Boost: 1847 MHz/ Base: 1620 MHz in OC Mode Boost: 1809 MHz/ Base: 1594 MHz in Gaming Process Technology 16 nm Memory Clock 8008 MHz Memory Size 6 GB Memory Type GDDR5 Memory Bus 192 bit Card Bus PCI-E 3.0 x 16 Output Dual-link DVI-D *1 HDMI-2.0b*1 (Max Resolution: 4096x 2160 @60 Hz) Display Port-1.4 *3 (Max Resolution: 7680x 4320 @60 Hz) Digital max resolution 7680x 4320 Multi-view 4 Card size H=40 L=278 W=114 mm PCB Form ATX Direct X 12 Open GL 4.5 Recommended PSU 400W Power Connectors 8 pin*1

...

Promotional keys for Fortnite gear will be sent out via email. These will be sent up to 5 working days after the invoice date. Features Powered by Ge Force GTX 1060 Integrated with 3GB GDDR5 192bit memory WINDFORCE 2X with Blade Fan Design Support up to 8K display @60 Hz 16.8M Customizable Color RGB Lighting Core Clock Boost: 1847 MHz/ Base: 1620 MHz in OC Mode Boost: 1809 MHz/ Base: 1594 MHz in Gaming Overview WINDFORCE 2X Cooling System The WINDFORCE 2X cooling system features two 90mm unique blade fans, 2 pure copper composite heat-pipes, alternate spinning fan design, & heat pipes direct touch technology, together delivering an effective heat dissipation capacity for higher performance at lower temperatures. Alternate Spinning Fan Design Optimize air flow by the alternate spinning fans that reduce air turbulence & effectively dissipate the heat. Unique Blade Fan Design The airflow is spilt by the triangle fan edge, & guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the air flow by 23% over traditional fans. Composite heat-pipes The composite heat-pipes combines both thermal conductivity & phase transition for efficiently managing the transfer of heat between two solid interfaces which increases 29% of cooling capacity. 16.8M Customizable Color Lighting With 16.8M customizable color options & numerous lighting effects, you could now choose the right scheme for your gaming rig through XTREME Engine utility. Intuitive XTREME Engine Utility Adjust clock speeds, voltage, fan performance, RGB lighting effect, power target can be monitored & tuned in real-time according to your own preference through this intuitive interface.

Specification Graphics Processing Ge Force GTX 1060 Core Clock Boost: 1847 MHz/ Base: 1620 MHz in OC Mode Boost: 1809 MHz/ Base: 1594 MHz in Gaming CUDA Cores 1280 Process Technology 16 nm Memory Clock 8008 MHz Memory Size 3 GB Memory Type GDDR5 Memory Bus 192 bit Card Bus PCI-E 3.0 x 16 Output Dual-link DVI-D *1 HDMI-2.0b*1 (Max Resolution: 4096x 2160 @60 Hz) Display Port-1.4 *3 (Max Resolution: 7680x 4320 @60 Hz) Digital max resolution 7680x 4320 Multi-view 4 Card size H=40 L=278 W=114 mm PCB Form ATX Direct X 12 Open GL 4.5 Recommended PSU 400W Power Connectors 8 pin*1

...

Gigabyte Ge Force GTX 1060 Mini ITX OC 6GB GDDR5 Dual_LInk DVI-D HDMI Display Port PCI-E Graphics Card Custom-designed Cooling System Equipped with 2 pure copper heat-pipes & 90 mm unique-blade fan with 3D active functionality, & heat pipes direct touch technology, the cooler can dissipate heat effectively from the GPU while keeping the fan at lower speed & noise. Cooling System-Fan Unique Blade Fan Design The airflow is spilt by the triangle fan edge, & guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the air flow by 23% over traditional fans. 3D Active Fan The semi-passive fans will remain off when the GPU is under a set loading or temperature for low power gaming. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle. Cooling System- Heat Pipes Composite heat-pipes The composite heat-pipes combines both thermal conductivity & phase transition for efficiently managing the transfer of heat between two solid interfaces which increases 29% of cooling capacity. Heat Pipe Direct Touch The pure copper heat pipes are shaped to maximize the direct contact area to the GPU. Compact Card Size Measuring merely 17cm in length, the card, perfectly compatible for building most of the PCs from ATX to mini-ITX. Specifications Graphics Processing Ge Force GTX 1060 Core Clock Boost: 1771 M Hz/ Base: 1556 MHz in OC Mode Boost: 1746 MHz/ Base: 1531 MHz in Gaming Mode Process Technology 16 nm Memory Clock 8008 MHz Memory Size 6 GB Memory Type GDDR5 Memory Bus 192 bit Card Bus PCI-E 3.0 x 16 Output Dual-link DVI-D *2 HDMI-2.0b*1 (Max Resolution: 4096x 2160 @60 Hz) Display Port-1.4 *1 (Max Resolution: 7680x 4320 @60 Hz) Digital max resolution 7680x 4320 Multi-view 4 Card size H=37 L=169 W=131 mm PCB Form ATX Direct X 12 Open GL 4.5 Recommended PSU 400W Power Connectors 6 pin*1 ...

Features Power by Ge Force GTX 1070 Integrated with 8GB GDDR5 256bit memory 90mm cooler with 3D active fan One-click Super Overclocking 17cm compact card size Core Clock Boost: 1746 MHz/ Base: 1556 MHz in OC Mode Boost: 1721 MHz/ Base: 1531 MHz in Gaming Overview The Ultimate Gaming PC Platform Get game ready with Ge Force GTX. Ge Force GTX delivers the fastest performance, with the most advance gaming technologies (NVIDIA Game Works™) & the best gaming ecosystem (Ge Force Experience™) Performance Built with all-new NVIDIA pascal™ architecture & using ultra-fast Fin FET manufacturing process, Ge Force GTX 10 series is a quantum leap in performance & power efficiency. Next-Gen Gaming Technologies Get all the power & performance you need to drive the latest displays, including VR, ultra-high-resolution, & multiple monitors. NVIDIA Game Works™ technologies give you the smoothest gameplay & cinematic experiences, as well as revolutionary 360-degree image capture—even in VR. VR Ready Discover next-generation VR performance, the lowest latency, & plug-&-play compatability leading headsets
- driven by NVIDIA VRWorks™ technologies. VR audio, physics, & haptics let you hear & feel every moment. Xtreme Engine Adjust clock speeds, voltage, fan performance, power target can be monitored & tuned in real-time according to your own preference through this intuitive interface. Download (* The interface & functionality of the software is subject to each model.)

Specification Graphics Processing Ge Force GTX 1070 Core Clock Boost: 1746 MHz/ Base: 1556 MHz in OC Mode Boost: 1721 MHz/ Base: 1531 MHz in Gaming Process Technology 16 nm Memory Clock 8008 MHz Memory Size 8 GB Memory Type GDDR5 Memory Bus 256 bit Card Bus PCI-E 3.0 x 16 Output Dual-link DVI-D *2 HDMI-2.0b*1 (Max Resolution: 4096x 2160 @60 Hz) Display Port-1.4 *1 Digital max resolution 7680x 4320 Multi-view 4 Card size H=37 L=169 W=131 mm PCB Form ATX Direct X 12 Open GL 4.5 Recommended PSU 500W Power Connectors 8 pin*1 SLI support 2-way SLI HB


...
