Features Features Powered by Ge Force GT 1030 Integrated with 2GB GDDR5 64bit memory Supports HDMI 4K@60 Hz Smooth 4K video playback & HTML5 web browsing One-click overclocking via AORUS Graphics Engine Core Clock Boost: 1544 MHz/ Base: 1290 MHz in OC Mode Boost: 1518 MHz/ Base: 1265 MHz in Gaming Mode Overview GIGABYTE CUSTOM-DESIGNED COOLER The custom-designed cooler introduced a 80mm fan along with the aluminum base, together delivering an effective heat dissipation capacity for higher performance at lower temperatures ULTRA DURABLE COMPONENTS Engineered with the high-quality chokes & capacitors, this graphic card delivers outstanding performance & durable system lifespan. SMOOTH & CRISP VISUAL Equipped with one DVI-D, & one gold-plated HDMI ports, the card can deliver smooth 4K video playback. Intuitive AORUS Graphics Engine Utility The cutting edge intuitive interface means that you can tune the clock speeds, voltage, fan performance, & power target in real-time according to your own gaming requirement. One-click Super overclocking With a simple click on AORUS Graphics Engine utility, gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge.

Specification Graphics Processing Ge Force GT 1030 Core Clock Boost: 1544 MHz/ Base: 1290 MHz in OC Mode Boost: 1518 MHz/ Base: 1265 MHz in Gaming Mode CUDA Cores 384 Memory Clock 6008 MHz Memory Size 2 GB Memory Type GDDR5 Memory Bus 64 bit Output DVI-D *1 HDMI-2.0b*1 (Max Resolution: 4096x 2160 @60 Hz) Digital max resolution 4096 X 2160 Multi-view 2 Card size H=26.8 L=167.7 W=111.2 mm PCB Form ATX Direct X 12 Open GL 4.5 Recommended PSU 300W

...

Features Powered by Ge Force GT 1030 Integrated with 2GB GDDR5 64bit memory Low profile design with passive cooler One-click overclocking via AORUS Graphics Engine Core Clock Boost: 1506 MHz/ Base: 1252 MHz in OC Mode Boost: 1468 MHz/ Base: 1227 MHz in Gaming Mode Product Overview ABSOLUTE SILENT Introducing the exclusive passive thermal design, the card covered with large heat sink provides great cooling capacity under silent 0d B environment. LOW PROFILE DESIGN Low profile design saves more spaces to fit slim or smaller system. Equipped with a DVI-D & a HDMI port, the card supports up to 4K high resolution. SMOOTH & CRISP VISUAL Equipped with a DVI-D & a HDMI port, the card can deliver beautiful & smooth 4K video playback. ULTRA DURABLE COMPONENTS Engineered with the high-quality chokes & capacitors, this graphic card delivers outstanding performance & durable system lifespan. Intuitive AORUS Graphics Engine Utility The cutting edge intuitive interface means that you can tune the clock speeds, voltage, fan performance, & power target in real-time according to your own gaming requirement. One-click Overclocking With a simple click on AORUS Graphics Engine utility, gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge Specifications Graphics Processing Ge Force GT 1030 Core Clock Boost: 1506 MHz/ Base: 1252 MHz in OC Mode Boost: 1468 MHz/ Base: 1227 MHz in Gaming Mode Memory Clock 6008 MHz Memory Size 2 GB Memory Type GDDR5 Memory Bus 64 bit Output DVI-D *1 HDMI-2.0b*1 (Max Resolution: 4096x 2160 @60 Hz) Digital max resolution 4096 X 2160 Multi-view 2 Card size H=35.9 L=174.9 W=68.9 PCB Form Low Profile Direct X 12 Open GL 4.5 Recommended PSU 300W ...

GIGABYTE HD Experience Series Powered by NVIDIA Ge Force GT 430 GPU Integrated with industrys best 1GB DDR3 memory 128-bit memory interface Features Dual link DVI-I/ D-SUB/HDMI with HDCP protection GIGABYTE UD2 material GIGABYTE custom-designed 80mm fan Support NVIDIA CUDA™ Technology Support NVIDIA Phy X™ Technology * Minimum 400W or greater system power supply with Chipset
- Ge Force GT 430 Core Clock
- 700 MHz Shader Clock
- 1400 MHz Memory Clock
- 1600 MHz Process Technology
- 40 nm Memory Size
- 1 GB Memory Bus
- 128 bit Card Bus
- PCI-E 2.0 Memory Type
- DDR3 Direct X
- 11 Open GL
- 4.2 PCB Form
- ATX Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Tools
- N/A I/O
- HDMIx 1, DVI-Ix 1, D-subx 1 Card size
- 187 mm x 127 mm x 34 mm Power requirement
- 400W


















...

GIGABYTE HD Experience Series Powered by NVIDIA Ge Force GT 430 GPU Integrated with industrys best 2GB DDR3 memory 128-bit memory interface Features Dual link DVI-I/ D-SUB/HDMI with HDCP protection GIGABYTE UD2 material GIGABYTE custom-designed 80mm fan Support NVIDIA CUDA™ Technology Support NVIDIA Phy X™ Technology * Minimum 400W or greater system power supply with

Specification
- Chipset
- Ge Force GT 430 Core Clock
- 700 MHz Shader Clock
- 1400 MHz Memory Clock
- 1600 MHz Process Technology 40 nm Memory Size
- 2 GB Memory Bus
- 128 bit Card Bus
- PCI-E 2.0 Memory Type
- DDR3 Direct X
- 11 Open GL
- 4.2 PCB Form
- ATX Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Tools
- N/A I/O
- HDMIx 1, DVI-Ix 1, D-subx 1 Card size
- 187 mm x 127 mm x 34 mm Power requirement
- 400W




















...

10% performance better than generic HD 5570 GIGABYTE Low profile Dual Fan Native Golden Plated HDMI Powered by NVIDIA Ge Force GT 430 GPU 96 Stream Processors Microsoft Direct X 11 & Open GL 3.2 support Supports PCI Express 2.0 interface Features Dual Link DVI-I/ D-Sub/ HDMI Supports NVIDIA Pure Video HD Technology Support NVIDIA Phys X / CUDA Technology

Specification Core Clock 730 MHz (std 700 MHz) Memory Clock 1800 MHz Shader Clock 1460 MHz Memory Size 1 GB DDR3 Bus Type PCI Express 2.0 Memory Bus 128-bit Stream Processors 96 Memory type 64 Mx 16 GV-N430OC-1GL

Specification Table Direct X 11 Yes DVI Port DVI-I (Support Dual-link DVI-I) HDMI Yes D-sub Yes HDCP Yes



...

33 % performance better than GT 240 With DX11 support Gold plated HDMI 40 nm, No external power connector needed Features Powered by NVIDIA Ge Force GT 440 GPU 96 Stream Processors Microsoft Direct X 11 & Open GL 4.0 support Supports PCI Express 2.0 interface Features Dual Link DVI-I/ D-Sub/ HDMI Supports NVIDIA Pure Video HD Technology Support NVIDIA Phys X / CUDA Technology

Specification Core Clock 830 MHz (std 810 MHz) Memory Clock 1800 MHz Shader Clock 1660 MHz Memory Size 1GB DDR3 memory Bus Type PCI Express 2.0 Memory Bus 128-bit Stream Processors 96 Memory type 64 Mx 16 GV-N440D3-1GI

Specification Table Direct X 11 Yes DVI Port DVI-I (Support Dual-link DVI-I) HDMI Yes D-sub Yes HDCP Yes 400 Watt or greater power supply recommended



...

Specifications Chipset
- Ge Force GT 610 PCB Form
- Low Profile Core Clock
- 810 MHz Shader Clock
- 1620 MHz Memory Clock
-




...

Chipset
- Ge Force GT 610 PCB Form
- Low Profile Core Clock
- 810 MHz Shader Clock
- 1620 MHz Memory Clock
- 1333 MHz




...

GIGABYTE HD Experience Series Powered by NVIDIA Ge Force GT 610 GPU Core Clock: 810 M Hz Integrated with 2GB DDR3 memory & 64-bit memory interface Features Dual link DVI-I/ D-SUB/HDMI PCI-E 2.0 interface Support NVIDIA 3D Vision Surround Support NVIDIA CUDA Technology Support NVIDIA Phys X Technology System power supply requirement: 300W Specifications Chipset
- Ge Force GT 610 Core Clock
- 810 MHz Shader Clock
- 1620 MHz Memory Clock
- 1333 MHz Process Technology
- 40 nm Memory Size
- 2048MB Memory Bus
- -64 bit Card Bus
- PCI-E 2.0 Memory Type
- DDR3 Direct X
- 11.1 Open GL
- 4.3 I/O
- HDMIx 1, DVI-Ix 1, D-subx 1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Card size
- 158*121.5*22mm Power requirement
- 300W
















...

GIGABYTE HD Experience Series Powered by NVIDIA Ge Force GT 620 GPU Integrated with 1GB DDR3 memory & 64-bit memory interface Features Dual link DVI-I/ D-SUB/HDMI PCI-E 2.0 interface Support NVIDIA CUDA™ Technology Support NVIDIA Phys X™ Technology Support NVIDIA FXAA Technology Support NVIDIA Adaptive Vertical Sync Technology System power supply requirement: 350W

Specification
- Chipset
- Ge Force GT 620 PCB Form
- Low Profile Core Clock
- 700 MHz Shader Clock
- 1400 MHz Memory Clock
- 1200 MHz Process Technology
- 40 nm Memory Size
- 1024 MB Memory Bus
- 64 bit Card Bus
- PCI-E 2.0 Memory Type
- DDR3 Direct X
- 11.1 Open GL
- 4.3 I/O
- HDMIx 1, DVI-Ix 1, D-subx 1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Tools
- N/A Card size
- 175mm * 121.5mm * 22mm Power requirement
- 350W





















...
