*EX Display*Biostar TA75M+ Llano Socket FM1 VGA DVI HDMI 8 Channel
Audio MATX Motherboard (Includes Back Plate Only)

Product Description

*EX Display* Biostar TA75M+ Llano Socket FM1 VGA DVI HDMI 8 Channel Audio m ATX Motherboard (
Includes: back plate only) * No driver cd/cables or manual included* * Only

Includes:: Back plate* Chipset AMD A75 CPU Support AMD A8 Processor AMD A6 Processor AMD A4 Processor AMD E2 Processor Maximum CPU TDP (Thermal Design Power): 100 Watt Check Biostar website for list of compatible processors, the above is for reference only Memory Support Dual Channel DDR3 2000 (OC)/1866/1600/1333/1066/800 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory Expansion Slots 1 x PCI Slots 1 x PCI-E x 1 2.0 Slot 2 x PCI-E x 16 2.0 Slot (x 16 + x 4) Storage 6 x SATA3 6 Gb/s Connector Support SATA RAID: 0, 1, 10 USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 3 x USB (Universal Serial Bus) 2.0 Header Gb E Realtek RTL8111E
- 10/100/1000 Controller Integrated Video By CPU model Maximum resolution: VGA:1920x 1600, DVI-D:1920x 1200, HDMI:1920x 1200 Audio Realtek ALC892 8-Channel HD Audio Rear I/O 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector Internal I/O 1 x USB (Universal Serial Bus) 3.0 Header 3 x USB (Universal Serial Bus) 2.0 Header 6 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header

Dimensions Micro ATX Form Factor Dimension: 24.4cm x 22.5cm (W x L ) OS Support Support Windows XP / Vista / 7
