The AMD Fusion family of Accelerated Processing Units (APUs) is coming. Working in conjunction with the advanced x 86 processor cores, an APUs multiple vector cores enable software developers to create innovative new applications that expand usage models & make PCs fast, easy to use, & more intuitive. The recent introduction of new tools for thread-level & data-parallel applications development simplifies the task of creating these applications. The development platforms & tools are scheduled to be widely available. The rest is up to entrepreneurial developers & PC manufacturers. Specifications Socket
- AMD FM1 Cache
- 3MB L2 Cores
- 3 CPU Clock
- 2100 M Hz (2.10 G Hz)



...

Systems powered by AMD A-Series APUs with discrete-level graphics deliver up to 3X the visual performance of competing Intel Systems. Boost visual performance by at least 120% when you combine an AMD A-Series APU with select AMD Radeon HD 6000 Series graphics cards. AMD Turbo CORE Technology dynamically adjusts to users’ various workloads, delivering up to 300 M Hz of additional frequency on select AMD A-Series APUs. The APU Enables the graphics features & performance users demand with full Direct X 11 support. Socket
- AMD FM1 Cache
- 4MB L2 Cores
- 4 CPU Clock
- 2600 M Hz (2.60 G Hz) Radeon Cores
- 320 GPU Clock
- 443 M Hz Max DDR3
- 1866 M Hz Dual Graphics
- Yes







...

Systems powered by AMD A-Series APUs with discrete-level graphics deliver up to 3X the visual performance of competing Intel Systems. Boost visual performance by at least 120% when you combine an AMD A-Series APU with select AMD Radeon HD 6000 Series graphics cards. AMD Turbo CORE Technology dynamically adjusts to users’ various workloads, delivering up to 300 M Hz of additional frequency on select AMD A-Series APUs. The APU Enables the graphics features & performance users demand with full Direct X11 support. Socket
- FM1 Cache
- 4MB L2 Cores
- 4 CPU Clock
- 2900 M Hz Radeon Cores
- 400 GPU Clock
- 600 M Hz Max DDR3
- 1866 M Hz Dual Graphics
- Yes







...

Ebuyer bundle deals are designed to give you the best components & peace of mind with component compatability. In this bundle are included the following components:- Asus Motherboard
- F1A55-M LE AMD Processor
- AMD Llano A6 A3500 2.1 G Hz Socket FM1 3MB L2 Cache Retail Boxed Processor Patriot Memory
- 4GB G2 Series DDR3 PG234G1600ELKA (2 x 2GB Kit) Memory Details 4GB (2 x 2GB) PC3-12800 (1600 M Hz) Enhanced Latency Kit The G2 Series, AMD Edition memory kits are designed for AMD platforms. They are perfectly matched for enthusiasts & gamers looking to seek out every ounce of performance available from their system while being easy on your wallet. The low-profile Patriot G2 series, AMD Edition modules incorporate heat-spreaders that provide excellent heat dissipation capabilities without interfering with large CPU coolers for the perfect balance of CPU & memory cooling performance while adding a touch of style to your AMD platform. Extreme Performance PC3-12800 (1600 M Hz) Enhanced Latency (9-9-9-24) Voltage: 1.65 ~ 1.7V Equipped with an extruded aluminum shield to provide enhanced cooling Tested on AM3 7/8/9 series platforms Processor Details The AMD Fusion family of Accelerated Processing Units (APUs) is coming. Working in conjunction with the advanced x 86 processor cores, an APUs multiple vector cores enable software developers to create innovative new applications that expand usage models & make PCs fast, easy to use, & more intuitive. The recent introduction of new tools for thread-level & data-parallel applications development simplifies the task of creating these applications. The development platforms & tools are scheduled to be widely available. The rest is up to entrepreneurial developers & PC manufacturers. Specifications Socket
- AMD FM1 Cache
- 3MB L2 Cores
- 3 CPU Clock
- 2100 M Hz (2.10 G Hz) Motherboard Details This motherboard supports AMD A-& E2- series Accelerated Processor with AMD Radeon HD 6000 Series Graphics. This revolutionary APU (Accelerated Processing Unit) combines processing power & advanced Direct X 11 graphics in one small, energy-efficient design to enable accelerated performance & an industry-leading visual experience. It features Dual-channel DDR3 memory support & accelerates data transfer rate up to 5GT/s. CPU AMD Socket FM1 A- Series/E2- Series Accelerated Processors Supports CPU up to 4 cores Supports AMD Turbo Core 2.0 Technology * The AMD Turbo Core 2.0 Technology Support depends on the APU types Chipset AMD A55 FCH (Hudson D2) Memory 2 x DIMM, Max. 32GB, DDR3 2250 (O.C.)/1866/1600/1333/1066 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Graphics Integrated AMD Radeon HD 6000 Series Graphics in Llano APU Multi-VGA output support: DVI/RGB ports
- Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
- Supports RGB with max. resolution 1920 x 1600 @ 60 Hz AMD Dual Graphics technology support *1 Supports Direct X 11 Multi-GPU Support Supports AMD Cross Fire X Technology Expansion Slots 1 x PCIe 2.0 x 16 (blue) 1 x PCIe 2.0 x 16 (x 4 mode, black) 1 x PCIe 2.0 x 1 1 x PCI Storage AMD A55 FCH (Hudson D2) chipset: 6 x SATA 3 Gb/s port (s), blue Support Raid 0, 1, 10, JBOD LAN Realtek 8111E, 1 x Gigabit LAN Controller (s) Audio Realtek ALC887 8-Channel High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking USB (Universal Serial Bus) Ports AMD A55 FCH (Hudson D2) chipset: 12 x USB (Universal Serial Bus) 2.0 port (s) (6 at back panel, , 6 at mid-board) Back I/O Ports 1 x PS/2 keyboard (violet) 1 x PS/2 mouse (green) 1 x DVI-D 1 x D-Sub 1 x LAN (RJ45) port (s) 6 x USB (Universal Serial Bus) 2.0 3 x Audio jack (s) Internal I/O Ports 3 x USB (Universal Serial Bus) 2.0 connector (s) support (s) additional 6 USB (Universal Serial Bus) 2.0 port (s) 1 x COM port (s) connector (s) 6 x SATA 3 Gb/s connector (s) 1 x CPU Fan connector (s) 1 x Chassis Fan connector (s) 1 x Power Fan connector (s) 1 x S/PDIF out header (s) 1 x 24-pin EATX Power connector (s) 1 x 4-pin ATX 12V Power connector (s) 1 x parallel port connector (s) 1 x Front panel connector (s) 1 x Front panel audio connector (s) (AAFP) 1 x Internal speaker connector (s) Form Factor m ATX Form Factor 9.6 inch x 9 inch (24.4 cm x 22.9 cm )









...

Unbeatable multi-core value with AMD Phenom II processors. They deliver The Ultimate Visual Experience for high definition ...

EBUYER has done the testing for you
- EBUYER has now launched pre-built & fully tested bundles consist of Motherboard, memory
...

Overview GPU Acceleration EPYC enables up to 6 dedicated GPUs in a single-socket servers with peer-to-peer communication through the CPU. 2-socket and/or PCI switches are no longer needed to get the lanes required to achieve this level of GPU density. Scale-Out Storage Solutions • Fast Storage With EPYC’s 128 PCIe lanes, you no longer need 2 sockets to get the high-bandwidth PCI lanes to allow dense NVMe storage solutions. • Cold Storage Attach up to 32 SATA devices without the cost of an HBA. Enterprise Business Applications EPYC means that you can buy only what you need to support your enterprise business application requirements. No more second sockets need to go unused. EPYC HIGH PERFORMANCE COMPUTING EPYC strikes the perfect balance of cores/threads, memory, I/O bandwidth & security to deliver excellent performance for many High Performance Computing (HPC) workloads. AMD’s state-of-the-art GPUs combined with EPYC provide excellent solutions for your most demanding HPC applications. EPYC VIRTUALIZATION & CLOUD With its industry-leading core count, EPYC can enable more VMs & more robustly configured VMs per server than previously possible. Whether you are deploying a single server, implementing a private cloud or enabling a hybrid cloud, EPYC provides the perfect balance of compute, memory, I/O & security for your virtualized environment.

Specification Number of CPU Cores 16 Number of Threads 32 Base Clock Speed 2.1 G Hz Max Turbo Core Speed 2.7 G Hz All Core Boost Speed 2.7 G Hz Total L3 Cache 32MB Socket Count 1P/2P PCI Express Version x 128 Default TDP / TDP 155/170W Max System Memory Speed 2400 M Hz/2666 M Hz Memory Channels 8 Mem BW (2S Theo) 307 GB/s/341 GB/s Key Features Workload Affinity:
- License cost optimized
- General Purpose Foundation Product Family: AMD EPYC Product Line: AMD EPYC 7000 Series Platform: Server Item Dimension (L inchx W inchx H inch) 5 x 5 x 3 Weight 1.00 lb Warranty Information 3 Years



...

Overview GPU Acceleration EPYC enables up to 6 dedicated GPUs in a single-socket servers with peer-to-peer communication through the CPU. 2-socket and/or PCI switches are no longer needed to get the lanes required to achieve this level of GPU density. Scale-Out Storage Solutions • Fast Storage With EPYC’s 128 PCIe lanes, you no longer need 2 sockets to get the high-bandwidth PCI lanes to allow dense NVMe storage solutions. • Cold Storage Attach up to 32 SATA devices without the cost of an HBA. Enterprise Business Applications EPYC means that you can buy only what you need to support your enterprise business application requirements. No more second sockets need to go unused. EPYC HIGH PERFORMANCE COMPUTING EPYC strikes the perfect balance of cores/threads, memory, I/O bandwidth & security to deliver excellent performance for many High Performance Computing (HPC) workloads. AMD’s state-of-the-art GPUs combined with EPYC provide excellent solutions for your most demanding HPC applications. EPYC VIRTUALIZATION & CLOUD With its industry-leading core count, EPYC can enable more VMs & more robustly configured VMs per server than previously possible. Whether you are deploying a single server, implementing a private cloud or enabling a hybrid cloud, EPYC provides the perfect balance of compute, memory, I/O & security for your virtualized environment.

Specification Number of CPU Cores 16 Number of Threads 32 Base Clock Speed 2.2 G Hz Max Turbo Core Speed 2.7 G Hz All Core Boost Speed 2.7 G Hz Total L1 Cache 0KB Total L3 Cache 64MB Socket Count 1P/2P PCI Express Version x 128 Default TDP / TDP 155/170W Max System Memory Speed 2400 M Hz/2666 M Hz Memory Channels 8 Mem BW (2S Theo) 307 GB/s/341 GB/s Key Features Workload Affinity:
- License cost optimized
- General Purpose Foundation Product Family: AMD EPYC Product Line: AMD EPYC 7000 Series Platform: Server Item Dimension (L inchx W inchx H inch) 5 x 5 x 3 Weight 1.00 lb Warranty Information 3 Years



...

Overview GPU Acceleration EPYC enables up to 6 dedicated GPUs in a single-socket servers with peer-to-peer communication through the CPU. 2-socket and/or PCI switches are no longer needed to get the lanes required to achieve this level of GPU density. Scale-Out Storage Solutions • Fast Storage With EPYC’s 128 PCIe lanes, you no longer need 2 sockets to get the high-bandwidth PCI lanes to allow dense NVMe storage solutions. • Cold Storage Attach up to 32 SATA devices without the cost of an HBA. Enterprise Business Applications EPYC means that you can buy only what you need to support your enterprise business application requirements. No more second sockets need to go unused. EPYC HIGH PERFORMANCE COMPUTING EPYC strikes the perfect balance of cores/threads, memory, I/O bandwidth & security to deliver excellent performance for many High Performance Computing (HPC) workloads. AMD’s state-of-the-art GPUs combined with EPYC provide excellent solutions for your most demanding HPC applications. EPYC VIRTUALIZATION & CLOUD With its industry-leading core count, EPYC can enable more VMs & more robustly configured VMs per server than previously possible. Whether you are deploying a single server, implementing a private cloud or enabling a hybrid cloud, EPYC provides the perfect balance of compute, memory, I/O & security for your virtualized environment.

Specification Number of CPU Cores 16 Number of Threads 32 Base Clock Speed 2.4 G Hz Max Turbo Core Speed 2.9 G Hz All Core Boost Speed 2.9 G Hz Total L1 Cache 0KB Total L3 Cache 64MB Socket Count 1P/2P PCI Express Version x 128 Default TDP / TDP 155/170W Max System Memory Speed 2400 M Hz/2666 M Hz Memory Channels 8 Mem BW (2S Theo) 307 GB/s/341 GB/s Key Features Workload Affinity:
- GPU/FPGA Accelerated
- General Purpose
- Storage Foundation Product Family: AMD EPYC Product Line: AMD EPYC 7000 Series Platform: Server Item Dimension (L inchx W inchx H inch) 5 x 5 x 3 Weight 1.00 lb Warranty Information 3 Years




...

GPU Acceleration EPYC enables up to 6 dedicated GPUs in a single-socket servers with peer-to-peer communication through the CPU. 2-socket and/or PCI switches are no longer needed to get the lanes required to achieve this level of GPU density. Scale-Out Storage Solutions • Fast Storage With EPYC’s 128 PCIe lanes, you no longer need 2 sockets to get the high-bandwidth PCI lanes to allow dense NVMe storage solutions. • Cold Storage Attach up to 32 SATA devices without the cost of an HBA. Enterprise Business Applications EPYC means that you can buy only what you need to support your enterprise business application requirements. No more second sockets need to go unused. EPYC HIGH PERFORMANCE COMPUTING EPYC strikes the perfect balance of cores/threads, memory, I/O bandwidth & security to deliver excellent performance for many High Performance Computing (HPC) workloads. AMD’s state-of-the-art GPUs combined with EPYC provide excellent solutions for your most demanding HPC applications. EPYC VIRTUALIZATION & CLOUD With its industry-leading core count, EPYC can enable more VMs & more robustly configured VMs per server than previously possible. Whether you are deploying a single server, implementing a private cloud or enabling a hybrid cloud, EPYC provides the perfect balance of compute, memory, I/O & security for your virtualized environment.

Specification Number of CPU Cores 16 Number of Threads 32 Base Clock Speed 2.4 G Hz Max Turbo Core Speed 2.9 G Hz All Core Boost Speed 2.7 G Hz Total L3 Cache 64MB Socket Count 1P PCI Express Version x 128 Default TDP / TDP 155/170W Max System Memory Speed 2400 M Hz/2666 M Hz Memory Channels 8 Mem BW (2S Theo) 307 GB/s/341 GB/s Key Features Workload Affinity:
- License cost optimized
- General Purpose
- Storage Foundation Product Family: AMD EPYC Product Line: AMD EPYC 7000 Series Platform: Server Item Dimension (L inchx W inchx H inch) 5 x 5 x 3 Weight 1.00 lb Warranty Information 3 Years




...
