The Broadcom Net Xtreme II 57711 dual-port SFP+ adapter card with TCP/IP Offload Engine (TOE) & i SCSI offload is the fourth-generation of Convergence Network Interface Cards (C-NIC). The BCM57711 is the next-generation in C-NIC, combining offload technology with standard Ethernet functionality. Together, these features provide the necessary performance & bandwidth critical to I/O intensive applications such as virtualization & High Performance Computing (HPC). ...

Designed for today's enterprise & data center environments, Broadcom's Net Xtreme 1G Ethernet Adapters are the ideal solution for multicore servers, delivering full line-rate throughput across all ports. The BCM5719 PCIe NIC is a 13th-generation 10/100/1000BASE-T & 10/100/1000BASE-X Ethernet LAN controller solution for high-performance server & networking applications. The host interface supports a separate PCI Express function for each LAN interface. The BCM5719

Includes:: I/O Virtualization (IOV) features such as 17 receive & 16 transmit queues, & 17 MSI-X vectors with flexible vector-to-queue association. These IOV features enable the BCM5719 to support VMWare Net Queue & Microsoft VMQ technologies. The BCM5719

Includes:: A superbly comprehensive set of hardware features that the system may use to implement IEEE 1588 or IEEE 802.1AS-based time synchronization. These hardware features include a high-precision clock, timestamp registers for receive/transmit packets, & programmable trigger inputs & watchdog outputs.



...

The Broadcom BCM957414A4142CC is a dual-port 25 Gb/s or 10 Gb/s, PCI-Express Gen 3 x 8 Network Interface Card that supports both SFP28/SFP+ optical modules & copper-direct attach cable. The card uses the Broadcom BCM57414 25 Gb E MAC controller with the integrated dual-channel 25 Gb E SFI transceiver. Dual-port pluggable media interface, which may be equipped with 25 Gb E or 10 Gb E SFP28/SFP+ optical transceiver or with copper direct-attach cable Fully compliant to the SFF-8402 standard X8 PCI Express v 3.0 compliant SR-IOV with up to 128 VFs Function Level Reset (FLR) support Tru Flow flow processing engine Virtual Network Termination
- VXLAN, NVGRE, Geneve, GRE encap/decap VSwitch acceleration Tunnel-aware stateless offloads DCB support: PFC, ETS, QCN, DCBx RDMA over converged Ethernet (Ro CE) SMBus 2.0 MCTP over SMBus PCIe-based UART & KCS Jumbo frames up to 9 KB Advanced Congestion Avoidance Multiqueue, Net Queue, & VMQ IPv 4 & IPv 6 offloads TCP, UDP, & IP checksum offloads Large Send Offload (LSO) Large Receive Offload (LRO) TCP Segmentation Offload (TSO) Receive-side Scaling (RSS) Transmit-side Scaling (TSS) VLAN insertion/removal Interrupt coalescing Network boot-PXE, UEFI ISCSI boot MSI & MSI-X Conforms to the PCI Express Card Electromechanical

Specification Rev. 3.0


...

IBM offers the Broadcom 10 Gb E SFP+ network adapter family that is based on the Broadcom BCM57811S & BCM57810S controllers for IBM System x servers. This adapter uses Broadcom's controller technology, which provides outstanding performance, efficiency, and scalability for the enterprise data center. The adapter connects to SFP+ multimode fiber SR optical modules & direct-attach copper (DAC) cables. Designed For Ne Xt Scale nx 360 M4; System x i Data Plex dx 360 M4; System x 3100 M4;x 3250 M4;x 3300 M4;x 3500 M4;x 3530 M4;x 3550 M4;x 3630 M4;x 3650 M4;x 3650 M4 BD;x 3650 M4 HD;x 3690 X5;x 3850 X5;x 3950 X5 ...

The Emulex LPe 35000 Gen 7 Fibre Channel (FC) Host Bus Adapters (HBAs) by Broadcom are designed for demanding mission-critical workloads & emerging applications. Applications continue to grow in size & scale &, to support them, enterprises are increasingly turning to new server technologies that contain hundreds of processor cores as well as high-performance storage solutions including low-latency NVMe all-flash arrays (AFAs). NVMe can significantly increase the performance of storage area networks (SANs), making the selection of high-speed networking technology the critical element for achieving maximum system-wide performance. Fibre Channel is purpose-built for storage networks, meeting the requirements for high availability, scalability, predictable performance & low latency. Compared to the previous generation, Emulex Gen 7 FC HBAs offer up to 2x higher bandwidth, 3x better latency, enhanced security, & operational efficiency for 32GFC & 64GFC SANs. ...

Enables endless design flexibility with the ability to operate NVMe, SAS, or SATA storage devices in a single drive bay Designed for high-end servers utilizing internal storage, the 9400-8i Tri-Mode Storage Adapter is ideal for increased connectivity & maximum performance for data center flexibility. With increased bandwidth & IOPS performance compared to previous generations, the 9400-8i adapter delivers the performance & scalability needed by critical applications.
- Connects up to 1024 SAS/SATA devices or 24* NVMe devices
- Provides maximum connectivity & performance for high-end servers & applications
- Support critical applications with the bandwidth of PCIe 3.1 connectivity


...

Designed for large-scale external storage enclosures & internal storage, the 9400-8i 8e Tri-Mode Storage Adapter is ideal for increased connectivity & maximum performance for data center flexibility. With increased bandwidth & IOPS performance compared to previous generations, the 9400-8i 8e adapter delivers the performance & scalability needed by critical applications.
- Connects up to 1024 SAS/SATA devices; & up 24 (internal only) NVMe devices per controller
- Provides maximum connectivity & performance for high-end servers & applications
- Support critical applications with the bandwidth of PCIe 3.1 connectivity
- Ideal for connecting large-scale external storage enclosures & internal storage



...

The high-port 9500-16i Tri-Mode, PCIe Gen 4.0 HBA is ideal for increased connectivity & maximum performance for enterprise data center flexibility. With increased bandwidth & IOPS performance compared to previous generations, the 9500-16i adapter delivers the performance & scalability needed by critical applications. Connects up to 1024 SAS/SATA devices or 32 NVMe devices Provides maximum connectivity & performance for high-end servers & applications Support critical applications with the bandwidth of PCIe 4.0 connectivity Universal Bay Management (UBM) Ready ...

The 9500-8e Tri-Mode, PCIe Gen 4.0 HBA with eight external ports is ideal for increased connectivity & maximum performance for enterprise data center flexibility. The HBA features the SAS3808 x 8, Gen 4.0 I/O Controller (IOC), making it part of the industry's first HBA family to offer both PCIe Gen 4.0 host & storage interfaces. With increased bandwidth & IOPS performance compared to previous generations, the 9500-8e adapter delivers the performance & scalability needed by critical applications. Connects up to 1024 SAS/SATA devices or 32 NVMe devices Provides maximum connectivity & performance for high-end servers & applications Support critical applications with the bandwidth of PCIe 4.0 connectivity Universal Bay Management (UBM) Ready ...

The high-port 9500-16i Tri-Mode, PCIe Gen 4.0 HBA is ideal for increased connectivity & maximum performance for enterprise data center flexibility. With increased bandwidth & IOPS performance compared to previous generations, the 9500-16i adapter delivers the performance & scalability needed by critical applications. Connects up to 1024 SAS/SATA devices or 32 NVMe devices Provides maximum connectivity & performance for high-end servers & applications Support critical applications with the bandwidth of PCIe 4.0 connectivity Universal Bay Management (UBM) Ready ...
