Designed for large-scale external storage enclosures, the 9400-8e Tri-Mode Storage Adapter is ideal for increased connectivity & maximum performance for data center flexibility. With increased bandwidth & IOPS performance compared to previous generations, the 9400-8e adapter delivers the performance & scalability needed by critical applications. Connects up to 1024 SAS/SATA devices Provides maximum connectivity & performance for high-end servers & applications Support critical applications with the bandwidth of PCIe 3.1 connectivity Ideal for connecting large-scale external storage enclosures ...

RAID controller cards temporarily cache data from the host system until it is successfully written to the storage media. While cached, data can be lost if system power fails, jeopardizing the data’s permanent integrity. RAID caching is a cost-effective way to improve I/O performance by writing data to a controller’s cache before it is written to disk. However, in the event of a power or server failure, the writes in cache may be lost. Cache Vault flash cache protection modules & battery backup units (BBUs) protect the integrity of cached data by storing cached data in non-volatile flash cache storage or by providing battery power to the controller. Cache Vault technology prevents data loss by powering critical components of the card long enough to automatically transfer the cached data to NAND flash. Once power returns, the data is restored to the cache & normal operation resumes. By using a super-capacitor instead of Lithium-ION batteries, Cache Vault technology virtually eliminates hardware maintenance costs associated with batteries, lowers total cost of ownership over the life of the controller card & provide more environmentally friendly cache protection, all while maintaining optimal RAID performance. ...

The Broadcom dual-port 10GBASE-T Ethernet network adapter for Dell Power Edge rack servers is based on the Net Xtreme E-series BCM57406 Controller ASIC. As application workloads & virtualization technologies drive increased demands on server performance, network performance requirements scale accordingly. This growth demands an advanced breed of Ethernet connectivity solutions. Broadcom Net Xtreme E-series adapters in Dells Power Edge servers deliver high throughput, low latency & key features to enable optimal performance for a variety of workloads. Whether in a native bare-metal platform or in a virtualized environment, Net Xtreme-E series solutions are designed to deliver the networking performance & flexibility needed to ensure optimal application performance. Features like SRIOV with 128 virtual functions (VFs) & VMQ hardware support give IT administrators the tools to address any networking challenge. ...

The Broadcom 57412 10 Gb Network Interface Card from Dell is ideal for connecting your server to your network. The Dual Port PCIe Adapter proven to be reliable & standards-based solutions. ...

The Broadcom Net Xtreme II 57711 dual-port SFP+ adapter card with TCP/IP Offload Engine (TOE) & i SCSI offload is the fourth-generation of Convergence Network Interface Cards (C-NIC). The BCM57711 is the next-generation in C-NIC, combining offload technology with standard Ethernet functionality. Together, these features provide the necessary performance & bandwidth critical to I/O intensive applications such as virtualization & High Performance Computing (HPC). ...

The Broadcom BCM957414A4142CC is a dual-port 25 Gb/s or 10 Gb/s, PCI-Express Gen 3 x 8 Network Interface Card that supports both SFP28/SFP+ optical modules & copper-direct attach cable. The card uses the Broadcom BCM57414 25 Gb E MAC controller with the integrated dual-channel 25 Gb E SFI transceiver. Dual-port pluggable media interface, which may be equipped with 25 Gb E or 10 Gb E SFP28/SFP+ optical transceiver or with copper direct-attach cable Fully compliant to the SFF-8402 standard X8 PCI Express v 3.0 compliant SR-IOV with up to 128 VFs Function Level Reset (FLR) support Tru Flow flow processing engine Virtual Network Termination
- VXLAN, NVGRE, Geneve, GRE encap/decap VSwitch acceleration Tunnel-aware stateless offloads DCB support: PFC, ETS, QCN, DCBx RDMA over converged Ethernet (Ro CE) SMBus 2.0 MCTP over SMBus PCIe-based UART & KCS Jumbo frames up to 9 KB Advanced Congestion Avoidance Multiqueue, Net Queue, & VMQ IPv 4 & IPv 6 offloads TCP, UDP, & IP checksum offloads Large Send Offload (LSO) Large Receive Offload (LRO) TCP Segmentation Offload (TSO) Receive-side Scaling (RSS) Transmit-side Scaling (TSS) VLAN insertion/removal Interrupt coalescing Network boot-PXE, UEFI ISCSI boot MSI & MSI-X Conforms to the PCI Express Card Electromechanical

Specification Rev. 3.0


...

IBM offers the Broadcom 10 Gb E SFP+ network adapter family that is based on the Broadcom BCM57811S & BCM57810S controllers for IBM System x servers. This adapter uses Broadcom's controller technology, which provides outstanding performance, efficiency, and scalability for the enterprise data center. The adapter connects to SFP+ multimode fiber SR optical modules & direct-attach copper (DAC) cables. Designed For Ne Xt Scale nx 360 M4; System x i Data Plex dx 360 M4; System x 3100 M4;x 3250 M4;x 3300 M4;x 3500 M4;x 3530 M4;x 3550 M4;x 3630 M4;x 3650 M4;x 3650 M4 BD;x 3650 M4 HD;x 3690 X5;x 3850 X5;x 3950 X5 ...

The Emulex LPe 35000 Gen 7 Fibre Channel (FC) Host Bus Adapters (HBAs) by Broadcom are designed for demanding mission-critical workloads & emerging applications. Applications continue to grow in size & scale &, to support them, enterprises are increasingly turning to new server technologies that contain hundreds of processor cores as well as high-performance storage solutions including low-latency NVMe all-flash arrays (AFAs). NVMe can significantly increase the performance of storage area networks (SANs), making the selection of high-speed networking technology the critical element for achieving maximum system-wide performance. Fibre Channel is purpose-built for storage networks, meeting the requirements for high availability, scalability, predictable performance & low latency. Compared to the previous generation, Emulex Gen 7 FC HBAs offer up to 2x higher bandwidth, 3x better latency, enhanced security, & operational efficiency for 32GFC & 64GFC SANs. ...

For applications needing external storage connectivity, the LSI SAS host bus adapter allows servers of any size to attach to multiple SAS or SATA end devices in external enclosures. Scale storage to support performance & capacity-intensive applications with SAS & the flexibility to support SATA drives. Eight ports of 12 Gb/s SAS + SATA ports Eight lanes of PCI Express 3.0 Low-profile form factor Mini-SAS HD connectors LSI SAS 3008 12 Gb/s SAS+SATA controller Supports SSDs, HDDs, & tape drives Provides connectivity in a low-profile form factor 8 lanes of PCI Express 3.0 provides fast signaling for high bandwidth applications High performance with 12 Gb/s SAS data transfer rates ...

Enables endless design flexibility with the ability to operate NVMe, SAS, or SATA storage devices in a single drive bay Designed for high-end servers utilizing internal storage, the 9400-8i Tri-Mode Storage Adapter is ideal for increased connectivity & maximum performance for data center flexibility. With increased bandwidth & IOPS performance compared to previous generations, the 9400-8i adapter delivers the performance & scalability needed by critical applications.
- Connects up to 1024 SAS/SATA devices or 24* NVMe devices
- Provides maximum connectivity & performance for high-end servers & applications
- Support critical applications with the bandwidth of PCIe 3.1 connectivity


...
