Choose the AMD CPU or APU that’s right for you. Build your own system with an AMD processor-in-a-box (PIB) & get exactly what you want from an innovative AMD A-Series Accelerated Processor Unit (APU). Specifications Model
- A10-7800 Socket
- AMD FM2+ CPU Clock Speed
- 3.5GHZ / 3.9 G Hz Turbo Totel L2 Cache
- 4MB DDR3 Speed
- 2133 M Hz Radeon Brand
- Radeon R7 Graphics Compute Cores
- 12 (4 CPU + 8 GPU) GPU Clock Speed
- 720 Mhz TDP
- 65 Watt








...

AMD A10-7870K 4.1 GHz Socket FM2+ 4MB Cache Retail Boxed Processor AMD A10-7870K specifications General information Type CPU / Microprocessor Market segment Desktop Family AMD A10-Series Model number A10-7870K CPU part number: AD787KXDJCSBX is a boxed microprocessor with low-noise fan & heatsink (125W) Frequency 3900 MHz Turbo frequency 4100 MHz Boosted P states [1] 1: 4100 MHz, 1.45V Package 906-pin lidded micro-PGA package Socket Socket FM2+ Size 1.57" x 1.57" / 4cm x 4cm Architecture / Microarchitecture Microarchitecture Steamroller Processor core Godavari Core stepping A1 CPUID 630F81 Manufacturing process 0.028 micron Data width 64 bit The number of CPU cores 4 The number of threads 4 Floating Point Unit Integrated Level 1 cache size 2 x 96 KB 3-way set associative shared instruction caches 4 x 16 KB 4-way set associative data caches Level 2 cache size 2 x 2 MB 16-way set associative shared caches Level 3 cache size None Multiprocessing Uniprocessor Features MMX instructions Extensions to MMX SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 SSE4a AES / Advanced Encryption Standard instructions AVX / Advanced Vector Extensions BMI1 / Bit Manipulation instructions 1 F16C / 16-bit Floating-Point conversion instructions FMA3 / 3-operand Fused Multiply-Add instructions FMA4 / 4-operand Fused Multiply-Add instructions TBM / Trailing Bit Manipulation instructions XOP / e Xtended Operations instructions AMD64 / AMD 64-bit technology AMD-V / AMD Virtualization technology EVP / Enhanced Virus Protection Turbo Core 3.0 technology Low power features Power Now! Low power P states [1] 1: 3800 MHz, 1.4V 2: 3700 MHz, 1.325V 3: 3500 MHz, 1.2V 4: 3000 MHz, 0.9V 5: 2400 MHz, 0.6V 6: 1700 MHz, 0.325V Integrated peripherals / components Integrated graphics GPU Type: Radeon R7 series Shader cores: 512 Base frequency (MHz): 866 The number of supported displays: 4 Memory controller The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-2133 Maximum memory bandwidth (GB/s): 34.1 ...

AMD’s most advanced desktop APU technology challenges the very definition of a processor. Arm yourself against the obstacles that impede the performance of today’s applications & games with up to 12 Compute Cores (4 CPU + 8 GPU) & innovative Graphics Core Next (GCN) Architecture. AMD
- A10-7870K 3900 MHz Socket FM2+ Processor Family
- AMD A10-Series Model number
- A10-7870K Frequency
- 3900 MHz Turbo frequency
- 4100 MHz Package
- 906-pin lidded micro-PGA package Socket
- FM2+ Microarchitecture
- Steamroller Processor core
- Godavari Core stepping
- A1 Manufacturing process
- 0.028 micron Data width
- 64 bit The number of cores
- 4 The number of threads
- 4 Level 1 cache size
- 2 x 96 KB 3-way set associative shared instruction caches 4 x 16 KB 4-way set associative data caches Level 2 cache size
- 2 x 2 MB 16-way set associative shared caches Features AMD64 / AMD 64-bit technology EVP / Enhanced Virus Protection Turbo Core 3.0 technology VT / Virtualization technology Low power features Power Now! Integrated graphics
- GPU Type: Radeon R7 series Shader cores
- 512 Base frequency (MHz)
- 867 The number of supported displays
- 4 Memory controller The number of controllers
- 1 Memory channels
- 2 Supported memory
- DDR3






















...

AMD A10-7890K 4.3 GHz Socket FM2+ 4MB Cache Retail Boxed Processor AMD A10-7890K is an upcoming AMD Accelerated Processing Unit for socket FM2+ platform. It is rumored to replace the A10-7870K, which is a current AMD flagship APU. Partial specifications of the A10-7890K surfaced in August 2015, & later they were confirmed by CPU support listings, published by Biostar. According to those, the processor will utilize AMD Godavari design, & will have the same core stepping as the A10-7870K. The processor will be clocked at 4.1 GHz, which gives it a 200 MHz or up to 5% frequency advantage over its predecessor. The maximum Turbo Core & GPU frequencies are not known at this time. Similar to older A10-Series models, the A10-7890K will have 4 CPU cores, 4 MB of level 2 cache & it will lack L3 cache. The processor will fit into 95 Watt TDP. We do not have information on the release date of this model. AMD A10-7890K specifications General information Type CPU / Microprocessor Market segment Desktop Family AMD A10-Series Model number A10-7890K CPU part number: AD789KXDJCHBX is a boxed microprocessor with low-noise fan & heatsink (Wraith cooler) Frequency 4100 MHz Turbo frequency 4300 MHz Package 906-pin lidded micro-PGA package Socket Socket FM2+ Size 1.57" x 1.57" / 4cm x 4cm Architecture / Microarchitecture Microarchitecture Steamroller Processor core Godavari Core stepping A1 CPUID 630F81 Manufacturing process 0.028 micron Data width 64 bit The number of CPU cores 4 The number of threads 4 Floating Point Unit Integrated Level 1 cache size 2 x 96 KB 3-way set associative shared instruction caches 4 x 16 KB 4-way set associative data caches Level 2 cache size 2 x 2 MB 16-way set associative shared caches Level 3 cache size None Multiprocessing Uniprocessor Features MMX instructions Extensions to MMX SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 SSE4a AES / Advanced Encryption Standard instructions AVX / Advanced Vector Extensions BMI1 / Bit Manipulation instructions 1 F16C / 16-bit Floating-Point conversion instructions FMA3 / 3-operand Fused Multiply-Add instructions FMA4 / 4-operand Fused Multiply-Add instructions TBM / Trailing Bit Manipulation instructions XOP / e Xtended Operations instructions AMD64 / AMD 64-bit technology AMD-V / AMD Virtualization technology EVP / Enhanced Virus Protection Turbo Core 3.0 technology Low power features Power Now! Integrated peripherals / components Integrated graphics GPU Type: Radeon R7 series Shader cores: 512 Base frequency (MHz): 866 Memory controller The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-2133 Maximum memory bandwidth (GB/s): 34.1 ...

AMD A10-Series A10-7860K 3600 MHz Socket FM2+ Retail Boxed Processor AMD A10-7860K specifications General information Type CPU / Microprocessor Market segment Desktop Family AMD A10-Series Model number A10-7860K Frequency 3600 MHz Turbo frequency 4000 MHz Package 906-pin lidded micro-PGA package Socket Socket FM2+ Size 1.57" x 1.57" / 4cm x 4cm Architecture / Microarchitecture Microarchitecture Steamroller Processor core Godavari Manufacturing process 0.028 micron Die size 245mm Data width 64 bit The number of CPU cores 4 The number of threads 4 Floating Point Unit Integrated Level 1 cache size 2 x 96 KB 3-way set associative shared instruction caches 4 x 16 KB 4-way set associative data caches Level 2 cache size 2 x 2 MB 16-way set associative shared caches Level 3 cache size None Multiprocessing Uniprocessor Features MMX instructions Extensions to MMX SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ? SSE4a AES / Advanced Encryption Standard instructions AVX / Advanced Vector Extensions BMI1 / Bit Manipulation instructions 1 F16C / 16-bit Floating-Point conversion instructions FMA3 / 3-operand Fused Multiply-Add instructions FMA4 / 4-operand Fused Multiply-Add instructions TBM / Trailing Bit Manipulation instructions XOP / e Xtended Operations instructions AMD64 / AMD 64-bit technology AMD-V / AMD Virtualization technology EVP / Enhanced Virus Protection Turbo Core 3.0 technology Low power features Power Now! Integrated peripherals / components Integrated graphics GPU Type: Radeon R7 series Shader cores: 512 Base frequency (MHz): 757 The number of supported displays: 4 Memory controller The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-2133 Maximum memory bandwidth (GB/s): 34.1 Other peripherals PCI Express 3.0 (16 lanes) Unified Video Decoder 4.0 Video Coding Engine 2.0 True Audio accelerator ...

Specifications Family
- AMD A4 Series Model Number
- A4-4020 Core Frequency
- 3200 M Hz Turbo Frequency
- 3400 M Hz Socket
-




...

Specifications Family
- AMD A4 Series Model Number
- A4-6300 Core Frequency
- 3700 M Hz Turbo Frequency
- 3900 M Hz Socket
-




...

&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203; Get more of what you want with an AMD A-Series APU Changing the game for PCs by revolutionizing the accelerated desktop processor that combines the power of a multicore CPU with AMD Radeon™ graphics all in one energy-efficient chip. Unlock your system’s full potential with HSA-enabled APUs Experience a new level of immersion with AMD True Audio technology Blaze through apps with AMD Turbo Core technology Specifications Model
- AMD A4-7300 Core Frequency
- 3.8 G Hz Turbo Core Frequency
- 4 G Hz Number of Cores
- 2 L2 shared Cache
- 1MB AMD Radeon Graphics Brand
- HD 8470D AMD Radeon Cores
- 192 GPU Clock Speed
- 800 M Hz Max DDR3
- 1600 M Hz TDP
- 65 Watts









...

Now you can create exactly what you want using a top-of-the-line AMD processor or the innovative AMD Accelerated Processor Unit (APU). Processor
- AMD A6-3670K Socket
- FM1 Cores
- 4 Clock
- 2.7 G Hz Cache
- 4MB L2 Cache (4 x 1MB) Graphics
- HD 6530D Graphics Cores on Die
- 320 GPU Clock speed
- 444 M Hz Direct X Version
- DX11








...

Choose the AMD CPU or APU that’s right for you. Build your own system with an AMD processor-in-a-box (PIB) & get exactly what you want from an innovative AMD A-Series Accelerated Processor Unit (APU). Specifications Model
- A6-7400K Radeon Brand
- Radeon R5 Graphics Compute Cores
- 6 (2 CPU + 4 GPU) CPU Clock Speed
- 3.5 G Hz / 3.9 G Hz Turbo Totel L2 Cache
- 1MB DDR3 Speed
- 1866 M Hz GPU Clock Speed
- 756 Mhz TDP
- 65 Watt







...
