Assemble the perfect small form factor system for all your computing demands with yhe flexible ZOTAC H77-ITX Wi Fi Supreme mini-ITX platform. The ZOTAC H77-ITX Wi Fi Supreme supports socket LGA1155 Intel Core family processors & incorporates a discrete NVIDIA Ge Force GT 620 graphics processor to boost 3D performance, enable NVIDIA CUDA technology & drive two additional simultaneous independent displays. The ZOTAC H77-ITX Wi Fi Supreme packs unprecedented expansion capabilities with available one PCI Express x 4 slot, one mini-PCI Express & m SATA slot. A mix of 5 total SATA 6.0 Gb/s, SATA 3.0 Gb/s & e SATA ports with RAID 0, 1, & 5 support on the ZOTAC H77-ITX Wi Fi Supreme enable users to maximize storage connectivity & complete the ultimate home theatre PC or home file server. Model
- H77ITX-C-E Form Factor
- Mini-ITX Chipset
- Intel H77 Express CPU Socket
- LGA 1155 CPU Integrated
- 3rd Generation Intel Core i 3, i 5 & i 7 ready Onboard Video
- NVIDIA Ge Force GT 620 w/512MB DDR3 Onboard Audio
- 1 x HD Audio Port (7.1-channel)
- 1 x Digital Optical S/PDIF output
- 1 x Front panel audio header Onboard LAN
- 1 x 10/100/1000 Mbps Ethernet port Onboard WLAN
- 802.11n Memory Size
- Up to 16GB Memory Slots
- 2 x 240-pin SO-DIMM Memory Type
- DDR3-1600 SATA
- 2 x SATA 3 Gb/s;
- 2 x SATA 6 Gb/s;
- 1 x e SATA (SATA 3 Gb/s) RAID
- 0, 1, 0+1, 5 Video Ports DVI
- 2 HDMI
- 1 Display Port
- 1 USB (Universal Serial Bus) Ports
- 4 x USB (Universal Serial Bus) 3.0 ports (2 on back panel, 2 via header)
- 4 x USB (Universal Serial Bus) 2.0 ports (4 on back panel, 4 via header) PCI
- 1 x PCI Express x 4 (open-end)
- 1 x Mini PCI Express (occupied by Wi Fi module)
- 1 x m SATA Extra Features Bluetooth 4.0

Dimensions 6.7in x 6.7in
- 170mm x 170mm Weight
- 2.3400





























...

Experience a perfect synergy of performance & energy-efficiency with the ZOTAC M880G-ITX Wi Fi platform featuring AMD Vision„¢ technology. The ZOTAC M880G-ITX Wi Fi combines the power of a AMD Turion„¢ II Neo K625 dual-core processor with a ATI Radeon„¢ HD 4200 series graphics processor to deliver stunning high-definition video playback, excellent multi-tasking performance & superior energy-efficiency in a mini-ITX form factor. ATI Avivo„¢ HD technology delivers full-hardware decode of Blu-ray high-definition content for flawless playback & vivid visuals with the ZOTAC M880G-ITX Wi Fi. Expansion with the ZOTAC M880G-ITX Wi Fi is plentiful with one PCI Express x 1 slot, 6 SATA 6.0 Gb/s, 2 USB (Universal Serial Bus) 3.0 ports & up to 6 USB (Universal Serial Bus) 2.0 ports.

Specification Chipset Manufacturer AMD Chipset M880G + SB820M GPU ATI Radeon„¢ HD 4200 series CPU Compatibility Name AMD Turion„¢ II Neo K625 Dual-core, 1.5 GHz Socket NA (integrated CPU) Front-side bus Hyper Transport 3.0 Memory Memory Type DDR3 Memory Speed 800 MHz Slots 2 x 240-pin DIMM Capacity Up to 8GB Expansion Slots 1 x PCI Express x 1 1 x Mini PCI Express (Occupied by Wi Fi card) 3D API Direct X Direct X 10.1 Open GL Open GL 2.0 Networking Ethernet 10/100/1000 Mbps Wi Fi 802.11n/g/b Audio Analog 6-ch HD Digital S/PDIF Ports DVI 1 (HDCP) (Dual-Link DVI-I) HDMI 1 (HDCP w/7.1-channel Audio) VGA With included adapter SATA 6 (SATA 6.0 Gbps) PS/2 1 (Keyboard) Serial Port serial port header USB (Universal Serial Bus) Ports 2 x USB (Universal Serial Bus) 3.0 (back panel), 6 x USB (Universal Serial Bus) 2.0 (4 on back panel, 2 on pin header) Cooler Active (with fan) Form Factor mini-ITX OS Compatibility Windows Vista/7 premium ready Maximum Resolution 2048x 1536 Wake-On Support Overclocking features

...

Experience the power of high-performance 3rd Generation Intel Core processors with the palm-sized ZOTAC ZBOX nano with Intel HD Graphics 4000. By fusing an energy-efficient & powerful 3rd Generation Intel Core processor with the palm-sized form factor, the ZOTAC ZBOX nano with Intel HD Graphics 4000 delivers an unmatched combination of size & performance that is perfect for everyday work & casual use. Intel HD Graphics 4000 graphics processing enhances the ZOTAC ZBOX nano with Intel Quick Sync technology for lightning-fast video conversions & Intel Clear Video HD technology for smooth high-quality Blu-ray 3D playback capabilities. An exclusive ZOTAC nano RAID storage accessory included with the ZOTAC ZBOX nano with Intel HD Graphics 4000 enables users to harness the lightning-fast performance of two m SATA SSD* modules for superior performance in RAID 0 or enhanced data security with RAID 1. *m SATA SSDs not included. Product Name: Product Name
- ZBOX nano ID63 PLUS Chipset: Manufacturer
- Intel Chipset
- HM77 Express GPU
- Intel HD Graphics 4000 CPU Compatibility: Name
- Intel Core i 3 3227U (dual-core) (1.9 GHz) Socket
- NA (integrated CPU) Frontside Bus
- NA Memory: Memory Type
- DDR3 Memory Speed
- 1600 MHz Slots
- 1 x 204-pin SODIMM Capacity
- 4GB DDR3 (Up to 8GB) 3D API: Direct X
- Direct X 11 Open GL
- Open GL 3.1 Networking; Ethernet
- 10/100/1000 Mbps Wi Fi
- 802.11n/g/b + Bluetooth 4.0 Audio: Analog
- Combo Headphone / mini-Optical S/PDIF jack, Microphone jack Digital
- 8-ch HDMI Storage: Hard Drive
- 500GB 5400RPM HDD Optical Drive Memory Card Reader
- 7-in-1 (MMC/SD/SDHC/SDXC/MS/MS Pro/x D) Ports: DVI
- NA HDMI
- 1 Display Port
- 1 SATA
- NA e SATA
- 1 IDE
- NA PS2
- NA Serial Port
- NA USB (Universal Serial Bus) Ports
- 4 USB (Universal Serial Bus) 3.0 (on back panel) 2 USB (Universal Serial Bus) 2.0 (on front) Firewire
- NA Cooler: Cooler
- Smartfan Form Factor: Form Factor- mini-PC OS Compatibility Windows
- User installed (Windows 7/8 ready) Other: Graphics Output
- 1 x HDMI / 1 x Display Port































...

Zotac NVIDIA Ge Force GT 730 1GB DDR3 VGA DVI HDMI PCI-E Low Profile Graphics Card Upgrade to dedicated graphics & memory for unmatched high-definitionvisuals & performance with the ZOTAC Ge Force GT 730. Hardware accelerated Blu-ray 3D playback enables the ZOTAC Ge Force GT 730 to render stunning stereoscopic high-definition video with compatible displays & playback software. Advanced Dolby True HD & DTS-HD Audio lossless multi-channel HD audio bitstreaming ensures the ZOTAC Ge Force GT 730 delivers rich audiophile-class audio to match the beautiful visuals. NVIDIA Surround technology with tripledisplay support enables the ZOTAC Ge Force GT 730 to deliver unmatched gaming immersion & maximum productivity. FEATURES NVIDIA Adaptive Vertical Sync technology NVIDIA Surround technology NVIDIA Unified Architecture NVIDIA Phys X technology NVIDIA CUDA technology Hardware Video Decode Acceleration Blu-ray 3D ready HDMI xv YCC Color & Deep Color technologies Lossless audio bitstream capable SPECIFICATIONS NVIDIA Ge Force GT 730 GPU 384 processor cores 1GB DDR3 64-bit memory bus Engine clock: 902 MHz Memory clock: 1800 MHz PCI Express 2.0 (x 8 lanes) CONNECTORS 1 x DL-DVI-D 1 x VGA 1 x HDMI Triple simultaneous display capable HDCP compliant POWER REQUIREMENTS 300-watt power supply recommended 25-watt max power consumption HDTV READY ED 480p HD 720p HD 1080i Full HD 1080p Quad Full HD (4K) SOFTWARE COMPATIBILITY NVIDIA Ge Force driver Microsoft Direct X 12 (feature level 11_0) Open GL 4.4 Microsoft Windows Vista/7/8 x 86/x 64 ...

Zotac NVIDIA Ge Force GT 730 1GB DDR5 VGA DVI HDMI PCI-E Low Profile Graphics Card Upgrade to dedicated graphics & memory for unmatched high-definitionvisuals & performance with the ZOTAC Ge Force GT 730. Hardware accelerated Blu-ray 3D playback enables the ZOTAC Ge Force GT 730 to render stunning stereoscopic high-definition video with compatible displays & playback software. Advanced Dolby True HD & DTS-HD Audio lossless multi-channel HD audio bitstreaming ensures the ZOTAC Ge Force GT 730 delivers rich audiophile-class audio to match the beautiful visuals. NVIDIA Surround technology with tripledisplay support enables the ZOTAC Ge Force GT 730 to deliver unmatched gaming immersion & maximum productivity. FEATURES NVIDIA Adaptive Vertical Sync technology NVIDIA Surround technology NVIDIA Unified Architecture NVIDIA Phys X technology NVIDIA CUDA technology Hardware Video Decode Acceleration Blu-ray 3D ready HDMI xv YCC Color & Deep Color technologies Lossless audio bitstream capable SPECIFICATIONS NVIDIA Ge Force GT 730 GPU 384 processor cores 1GB DDR5 64-bit memory bus Engine clock: 902 MHz Memory clock: 5010 MHz PCI Express 2.0 (x 8 lanes) CONNECTORS 1 x DL-DVI 1 x VGA 1 x HDMI Triple simultaneous display capable HDCP compliant POWER REQUIREMENTS 300-watt power supply recommended 49-watt max power consumption HDTV READY ED 480p HD 720p HD 1080i Full HD 1080p Quad Full HD (4K) SOFTWARE COMPATIBILITY NVIDIA Ge Force driver Microsoft Direct X 12 (feature level 11_0) Open GL 4.4 Microsoft Windows Vista/7/8 x 86/x 64 ...

Easily view images, music & videos from your smartphone, tablet, laptop or PC with the ZOTAC Stream Box on a big-screen TV. The ZOTAC Stream Box instantly projects digital media stored on your device wirelessly to easily share precious memories on a big-screen TV with your friends & family Zotac Stream Box. Streaming Video/ Audio/ Picture to TV displays & monitors, supports Fire Streaming (DLNA/ Air Fun) & Miracast (Screen Capture), EU+UK+US plug ...

Assemble the perfect small form factor system for all your computing demands with the flexible ZOTAC Z68ITX Wi-Fi supreme mini-ITX platform. The ZOTAC Z68ITX Wi-Fi supreme boosts 3D performance, enables NVIDIA CUDA technology & drives two additional simultaneous independent displays. The ZOTAC Z68ITX Wi-Fi supreme packs unprecedented expansion capabilities with one PCI Express x 4 slot & one combination mini-PCI Express & m SATA slot that support mini-PCI Express cards & m SATA storage devices. Adventurous users can take advantage of the overclocking capabilities available on the ZOTAC Z68ITX Wi-Fi supreme beyond the stock limits for an extra performance kick. ...

Experience a completely new level of energy-efficient computing with the digital media friendly ZOTAC ZBOX Blu-ray AD03 mini-PC. Powered by the AMD E-350 APU Platform with AMD Radeon HD 6310 Discrete-Class Graphics, the ZOTAC ZBOX Blu-ray AD03 delivers outstanding CPU & GPU performance capable of handling streaming high-definition video, Blu-ray playback & day-to-day computing tasks with unprecedented energy-efficiency. Onboard 802.11n (300 Mb/s) Wi Fi & Gigabit Ethernet enables the ZOTAC ZBOX Blu-ray AD03 to deliver lightning-fast network connectivity with or without wires for instant access to the digital content available on the Internet or other networked sources. Customizing the ZBOX Blu-ray AD03 is simple with easy access to internal expansion including mini-PCI Express, two DDR3 SO-DIMM slots & space to accommodate a 2.5-inch SATA HDD or SSD ¢“ & plenty of external expansion via USB (Universal Serial Bus) 3.0, USB (Universal Serial Bus) 2.0 & e SATA ports. Product Name
- ZBOX Blu-ray AD03 Chipset: Manufacturer
- AMD Chipset
- M1 GPU
- AMD Radeon HD 6310 CPU Compatibility: Name
- AMD E-350 APU (1.6 GHz dual-core) Socket
- NA (integrated CPU) Memory: Memory Type
- DDR3 Memory Speed
- 1066 MHz Slots
- 2 x 204-pin SODIMM Capacity
- up to 8GB Expansions: Expansion Slots
- 1 Mini-PCI Express slot 3D API: Direct X
- Direct X 10.1 Open GL
- Open GL 3.2 Networking: Ethernet
- 10/100/1000 Mbps Wi Fi
- 802.11n/g/b (300 Mbps) Audio: Analog
- Stereo Output Digital
- 8-ch via HDMI Digital S/PDIF output Storage: Hard Drive
- Support 2.5-inch SATA 6.0 Gb/s HDD/SSD Optical Drive
- 4x Blu-ray read / 8x DVD / 24x CD read/write Memory Card Reader
- 6-in-1 (MMC/SD/SDHC/MS/MS Pro/x D) Ports: DVI
- 1 HDMI
- 1 (HDCP / LPCM & bitstream capable) SATA
- 1 (SATA 3.0 Gbps) e SATA
- e SATA 3.0 Gbps IDE
- na PS2
- na Serial Port
- na USB (Universal Serial Bus) Ports
- 2 x USB (Universal Serial Bus) 3.0 (1 back panel / 1 front panel) 2 x USB (Universal Serial Bus) 2.0 (1 Combo e SATA / USB (Universal Serial Bus) 2.0 back panel / 1 front panel) Cooler: Cooler
- Smartfan Form Factor: Form Factor
- mini-PC OS Compatibility: Windows
- User installed (Windows XP / Vista / 7 & Linux ready) Other: Graphics Output
- 1 DVI /1 HDMI































...

Enjoy eco-friendly computing with superior energy-efficiency & performance with the ZOTAC ZBOX ID42 mini-PC powered by an NVIDIA Ge Force GT 610 graphics processor & Intel Core Processor. NVIDIA Ge Force GT 610 graphics deliver unrivaled levels of performance & high definition video decode capabilities to the ZOTAC ZBOX ID42 mini-PC with NVIDIA CUDA, hardware-accelerated HD video decode & HDMI 1.4a technologies for eco-friendly computing with premium audio & video capabilities. High performance eco-friendly computing is only two thumb screws away with the ZOTAC ZBOX ID42 mini-PC thanks to a user friendly design that makes mastering the mini-PC quick & easy. Space for a 2.5-inch hard drive & 2 204-pin DDR3-1333 SO-DIMM slots enable users to customize the internals of the ZOTAC ZBOX ID42 to their own needs while USB (Universal Serial Bus) 3.0, USB (Universal Serial Bus) 2.0 ports & a 4-in-1 memory card reader (SD/SDHC/SDXC/MMC) provide greater external expansion capabilities for perfect eco-friendly computing. Assembly Configuration
- Barebone (no RAM, HDD, & OS) CPU Integrated
- Intel Core 1.1 GHz Dual-Core Chipset
- Intel NM70 Express Onboard Video
- NVIDIA Ge Force GT 610 w/512MB DDR3 Onboard Audio
- Onboard analog stereo high-definition audio/ 8-Channel LPCM digital audio (HDMI)/ Digital S/PDIF audio output Onboard LAN
- 2 x 10/100/1000 Mbps, 2 x Wi Fi 802.11n/g/b Memory Size
- Up to 16GB Memory Slots
- 2 x 204-pin SO-DIMM Memory Type
- DDR3 1333 SO-DIMM SATA
- 1 x SATA (6.0 Gbps) Hard Drive
- Support 2.5-inch SATA Video Ports
- 1 x HDMI 1.4a, 1 x DVI DVI
- 1 HDMI
- 1 USB (Universal Serial Bus) Ports
- 2 USB (Universal Serial Bus) 3.0 (1 on top, 1 front), 2 USB (Universal Serial Bus) 2.0 (2 on back panel) Power Connector
- DC19V Extra Features
- Bluetooth 4.0 Package Contents 1 x ZOTAC ZBOX ID42 1 x MCE compatible remote 2 x CR2032 batteries (for remote) 1 x USB (Universal Serial Bus) IR receiver 1 x Wi Fi antenna 1 x VESA mount 1 x AC adapter 1 x Power cord 1 x Warranty card 1 x User manual 1 x Driver disc

Dimensions 13.19in x 10.43in x 3.74in
- 335mm x 265mm x 95mm Weight 5.3100 Warranty 1-Year Standard



















...

Experience the power of Intel’s Sandy Bridge architecture in a compact form factor with the ZOTAC ZBOX ID81 mini-PC. Powered by an Intel Celeron Processor 857, the ZOTAC ZBOX ID81 takes CPU performance to the next level with desktop-class processing power that sips miniscule amounts of energy. Integrated Intel graphics enable the ZOTAC ZBOX ID81 mini-PC to simultaneously drive dual independent displays via HDMI & DVI for superior productivity capabilities from the mini-PC. Space for a 2.5-inch hard drive & 2 204-pin DDR3-1333 SO-DIMM slots enables users to customize the internals of the ZOTAC ZBOX ID81 to their own needs while USB (Universal Serial Bus) 3.0 & USB (Universal Serial Bus) 2.0 ports & a 6-in-1 memory card reader (SD/SDHC/MS/MS Pro/x D/MMC) provide greater external expansion capabilities for perfect energy-efficient computing. Model ZBOX ID81 Chipset Manufacturer Intel Chipset HM65 Express GPU Intel HD Graphics CPU Compatibility Name Intel Celeron 857 (dual-core 1.2 GHz) Socket NA (integrated CPU) Front-side bus na Memory Memory Type DDR3 Memory Speed 1333 MHz Slots 2 x 204-pin SODIMM Capacity up to 16GB Expansion Expansion Slots na 3D API Direct X Direct X 10.1 Open GL Open GL 3.1 Networking Ethernet 10/100/1000 Mbps Wi Fi 802.11n/g/b + Bluetooth 3.0 Audio Analog Stereo Output Digital 8-ch via HDMI S/PDIF Storage Hard Drive Support 2.5-inch SATA 6.0 Gb/s HDD/SSD Optical Drive na Memory Card Reader 6-in-1 (MMC/SD/SDHC/MS/MS Pro/x D) Ports DVI 1 HDMI 1 Display Port na SATA 1 (SATA 6.0 Gbps) e SATA na IDE na PS2 na Serial Port na USB (Universal Serial Bus) Ports 2 USB (Universal Serial Bus) 3.0 (on back panel) 4 USB (Universal Serial Bus) 2.0 (2 back panel / 1 front panel / 1 top panel) Firewire na Cooler Cooler Smartfan Form Factor Form Factor mini-PC OS Compatibility Windows User installed (Windows XP / Vista / 7 & Linux ready) General SLI Supported No Maximum Resolution na Other Wake-On Support Overclocking features Packaging Package Contents 1 x ZOTAC ZBOX ID81 1 x VESA mount 1 x Wi Fi antenna 1 x AC adapter 1 x Power cord 1 x Warranty card 1 x User manual 1 x Driver CD 1 x MCE compatible remote 2 x CR2032 batteries (for remote) 1 x USB (Universal Serial Bus) IR receiver Graphics Output 1DVI / 1 HDMI ...
