Unique, continuous Easy Rail™ technology enables you to maximize available power & make set-up easy. Stack numerous power-hungry components without fear of crashing. It's also a perfect solution for hardcore gamers. 2 year standard warranty with all PSUs
- simply register your PSU when purchased at http://xfxforce.com/en-gb/ Help/ Support.aspx to obtain a 5 year warranty. Register within 30 days of purchase, & provide proof of purchase for any warranty actions. General +12V Rail Outputs: Single ATX12V 2.2 & ESP12V 2.91 Compliant: Yes Maximum Wattage (W):850 Performance Category: Enthusiast UPC Number:778656058811 Technologies Cross Fire Ready: Yes SLI Ready: Yes Ratings & Efficiencies AC Input Current (Arms):11A
- 5.5A AC Input Frequency (Hz):50/60 Hz AC Input Voltage (Vac):100
- 240 Active Power Factor Correction (PFC): Yes DC Output Voltage Regulation:±3% Efficiency @ Typical Load:up to 90% Energy-Efficiency:80 Plus Bronze Certified Other Features DC to DC Converters (+3.3 & +5V): Yes EZ Grip Connectors: Yes High Reliable 105°C Japanese Capacitors: Yes Solid State Capacitors: Yes Load Range +12V1 (m W):TBA Max +12V1 Output Current (A):70 Max +12V1 Power (W):840 Max +3.3V & +5V combined power (W):125 Max +3.3V Output Current (A):25 Max +5V Output Current (A):25 Max +5VSB Output Current (A):3 Max +5VSB Power (W):15 Max -12V Output Current (A):0.8 Max -12V Power (W):6 Wattage (W):850W Cable Connectors Modular 6+2-pin PCI-E:6 Modular ATX12V / EPS12V: One 4+4-pin, One EPS 12V 8-pin Modular FDD:1 Modular Motherboard Connector:20+4 pin Modular Peripheral: Up to 5 Modular SATA: Up to 10 Safety & Protection Over Current Protection (OCP): Yes Over Power Protection (OPP): Yes Over Temperature Protection: Yes Over Voltage Protection (OVP): Yes Short Circuit Protection (SCP): Yes Under Voltage Protection (UVP): Yes Physical Cooling Fan Size (mm):120 Intake Fan: Airflow (CFM/min):80.5 Intake Fan: Diameter (mm):120 x 120 x 25 mm Intake Fan: Speed:2050 rpm Package
Dimensions (cm):31.9 x 21.0 x 16.3 Package
Dimensions (inch):12.55 x 8.26 x 6.42 Package Weight (Kg):2.76 est. Package Weight (lb):6.08 est. PSU Dimension (cm):8.6 x 14.0 x 16.0 PSU Dimension (inch):3.4 x 5.5 x 6.3 Certifications & Standards C-tick: Yes CB: Yes TUV: Yes
