Specification Display Number of Screens: 1 Screen

Size: 61cm (24”) Screen Mode:



...

XFXs unique, continuous Easy Rail technology enables you to maximize available power & make setup easy. Stack numerous power-hungry components, such as your GPU, CPU & other components, without fear of crashing. Its also a perfect solution for hardcore gamers. XFXForce Hybrid Fan Control Hybrid mode allows the PSU to operate silently until it reaches 20% load. Quiet Hybrid Fan Control Conserves Power Hybrid Fan Mode allows your fan to stay off when your computer is idle but turns on automatically when the PSU needs it. Hybrid mode, when activated, allows the PSU to operate silently until it reaches 20% load or 25 degrees C. Then it switches to Quiet Mode (only 16d BA) until reaching 50% load which then switches to Cooling Mode to cool the PSU appropriately. XFXForce Easy Rail XFXForce Easy Rail Stack numerous power-hungry components, such as your GPU, CPU & other components, without fear of crashing. Real Gamers Choose Easy Rail Multi-rail PSUs are safe & often preferred, but its just not equipped to handle the power-hungry components of todays gaming systems--especially if its a multi-GPU or multi-CPU setup. Multi-Rail PSUs breakdown power bands into smaller, individual rails so its possible for over-current & system shutdowns to occur. Whats needed is one, big, reliable rail for all of your components. For real high-power gaming needs, XFX Easy Rail is the only choice. Solid Link Technology Maximizes Efficiency Solid Link technology allows XFX PSUs to drastically reduce the wires inside. Other PSUs have numerous wired internal components, which generate heat, wasting energy & decreasing efficiency. Solid Link Technology replaces traditional wired connections with direct pin to port connections. This reduces heat generated by wires which in turn reduces lost wattage giving you clean, consistent high quality voltage. XFXForce Solid Link Technology XFXForce Solid Link Technology Solid Link Technology replaces traditional wired connections with direct pin to port connections. Traditional Full Modular PSUs tend to have a bundle of cables which generate heat causing wattage loss. This means the PSU has to actually pull in more wattage to make up for the loss to give you the wattage your computer needs. Solid Link Full Modular PSUs dont have all these primary wires, instead using pin lag that directly connect to the connector daughter board which drastically reduces the lost wattage--meaning youll draw less wall power which saves you money. Extreme Heat Tested Capacitors Internal PC operating temperature is around 35 degrees C but the internal PSU temperature can be much higher. XFX uses all high-quality Japanese brand capacitors rated to withstand up to 105 degrees C. While some competitors claim to use Japanese capacitors, they may only be rated for 85 degrees C, which can shorten the usable life of a PSU. Automatic Protection Sensors All XFX PSUs come with automatic output protection systems to protect you & your computer. This

Includes:: Total Power Protection (OPP), Over Voltage Protection (OVP), Over Current Protection (OCP), Short Circuit Protection (SCP), & Over Temperature Protection (OTP). Clean Power Power drawn from your AC outlet is typically dirty with voltage spikes & fluctuations, which can harm vital PC components. XFX PSUs are designed to deliver tight DC voltage regulation with minimal AC ripple, giving you safer, cleaner power.

...

Designed specifically for the high performance gamer, the XFX 750W Black Edition PSU supports multiple high-end graphics cards. Offering an array of unparalleled features, the XFX 750W PSU delivers exceptional performance. Benefits Specifically designd to support multiple, high-end graphic adapters Single, high-power +12V rail eliminates the problems associated with multiple +12V power distribution Industrial grade components insure high reliability & long life High efficiency not only helps protect the environment but also allows the XFX 750W PSU to run cool & quiet Combining both fixed & modular cables delivers superior performance & flexibility KEY FEATURES 750W of continuous power at 50°C Tight voltage regulation (±3%) High efficiency operation up to 88% (80 Plus Silver) Single, high power +12V rail (up to 62A/744W) DC to DC voltage Regulator modules for +3.3V & +5V High quality Japanese brand capacitors (105°C) Solid polymer caps provide enhanced reliability & stability Quiet 135mm ball bearing fan provides superior cooling Supports multiple high-end graphic adapters (NVIDIA SLI & ATI Cross Fire Ready) Supports the latest ATX12V & EPS12V standards Active PFC with Universal AC input Detachable modular cables Energy Star 4.0 & Ro HS compliant Cables & Connectors Fixed Cables/ Connectors (1) Main Power ATX 20+4-pin (1) ATX 12V 4+4-pin (1) EPS12V 8-pin (2) PCI-E 6+2-pin Modular Cables/ Connectors (2) PCI-E 6+2-pin (4) Serial ATA 15-pin up to 11 conectors (3) Peripheral 4-pin up to 8 connectors (1) FDD 4-pin up to 2 connectors ...

Actively converts a Display Port signal to a single-link DVI signal Supports resolutions up to 1920 x 1200 No USB (Universal Serial Bus) connection needed Draws less power Compatible with all supported Eyefinity configurations AMD Eyefinity multi-display validated ensures compatibility for all Eyefinity configurations ...

XFX AMD Radeon R9 280 3GB DDR5 Dual DVI HDMI Mini Display Port PCI-E Graphics Card General Product Description: BLACK DD RADEON R9 280 1000M 3GB D5 2 Xm DP HDMI 2XDVI Processor & Bus Bus Type: PCI-E 3.0 Chipset version: Tahiti Pro 2 GPU Bus (bit): 384 GPU Clock: 1000 MHz Performance Category: Performance Stream Processors: 1792 Memory Memory Bus: 384 bit Memory Clock: 5.2 GHz Memory Size: 3 GB Memory Type: DDR5 Feature Technologies AMD Cross Fire Technology: Y AMD Eyefinity Technology: Y AMD HD3D Technology: Y AMD Hybrid Graphics Technology: 1 AMD Power Play Technology: Y AMD Stream Technology: Y Environmental Ro HS: Y Display Output Display Port ready: 1.2 Dual link Support: Y HDMI Ready: 1.4a Max Supported Resolution (ANALOG): 2048 x 1536 Max Supported Resolution (DIGITAL): 2560 x 1600 (DVI);4096 x 2160 (HDMI;DP) Output
- DL-DVI-I: 1 Output
- HDMI: 1 Output
- mini DP: 1 Output
- SL-DVI-D: 1 Physical Card Profile: Dual Thermal Solution: DD Fansink Thermal Type: Dual Slot Card Dimension (cm): 29.5 x 14.3 x 4.2 Card Dimension (inch): 11.61 x 5.63 x 1.65



...

The XFX Black Edition 850 watt modular power supply gives you the power you need with a brilliant combination of form & function. Giving more than just life to your PC, this power supply allows easy cable management with modular connectors which helps increase airflow. With tight voltage regulation & high efficiency operation up to 90% (80 Plus Gold) this power supply will give you exactly what you need to keep your gaming charged & ready. Input Voltage Range AC 100
- 240 V Frequency Required 47
- 63 Hz Power Output Connectors Details 1 x 4 PIN mini-power connector, 5 x 4 PIN internal power, 10 x 15 pin Serial ATA power, 6 x 8 pin PCI Express power with detachable 2 pin section, 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section, 1 x power 24 pin ATX with detachable 4 pin section, 1 x power 8 pin EPS12V Output Voltage +3.3, +5, ±12 V ± 3% Power Capacity 850 Watt Output Current +12V1
- 70 A, +3.3V
- 25 A, +5V
- 25 A, +5VSB
- 3 A, -12V
- 0.8 A 80 PLUS Certification 80 PLUS Gold






...

Easy Rail Technology Provides Maximum Power. Unique, continuous Easy Rail technology enables you to maximize available power & make set-up easy. Stack numerous power-hungry components without fear of crashing. It's also a perfect solution for hardcore gamers. Product Features 450W of continuous power at 50°C Tight voltage regulation (±5%) High efficiency operation up to 85% (80 Plus Bronze) Single, high power +12V rail (up to 53A/636W) High quality Japanese brand capacitor (105°C) Quiet 135mm ball bearing fan provides superior cooling Supports multiple high-end graphic adaptors (AMD Cross Fire Ready) Supports the latest ATX12V & EPS12V standards Active PFC with Universal AC input Energy Star 40 & Ro HS compliant 5-Year Limited Warranty ...

Unique, continuous Easy Rail™ technology enables you to maximize available power & make set-up easy. Stack numerous power-hungry components without fear of crashing. It's also a perfect solution for hardcore gamers. 2 year standard warranty with all PSUs
- simply register your PSU when purchased at http://xfxforce.com/en-gb/ Help/ Support.aspx to obtain a 5 year warranty. Register within 30 days of purchase, & provide proof of purchase for any warranty actions. General +12V Rail Outputs: Single ATX12V 2.2 & ESP12V 2.91 Compliant: Yes Maximum Wattage (W):850 Performance Category: Enthusiast UPC Number:778656058811 Technologies Cross Fire Ready: Yes SLI Ready: Yes Ratings & Efficiencies AC Input Current (Arms):11A
- 5.5A AC Input Frequency (Hz):50/60 Hz AC Input Voltage (Vac):100
- 240 Active Power Factor Correction (PFC): Yes DC Output Voltage Regulation:±3% Efficiency @ Typical Load:up to 90% Energy-Efficiency:80 Plus Bronze Certified Other Features DC to DC Converters (+3.3 & +5V): Yes EZ Grip Connectors: Yes High Reliable 105°C Japanese Capacitors: Yes Solid State Capacitors: Yes Load Range +12V1 (m W):TBA Max +12V1 Output Current (A):70 Max +12V1 Power (W):840 Max +3.3V & +5V combined power (W):125 Max +3.3V Output Current (A):25 Max +5V Output Current (A):25 Max +5VSB Output Current (A):3 Max +5VSB Power (W):15 Max -12V Output Current (A):0.8 Max -12V Power (W):6 Wattage (W):850W Cable Connectors Modular 6+2-pin PCI-E:6 Modular ATX12V / EPS12V: One 4+4-pin, One EPS 12V 8-pin Modular FDD:1 Modular Motherboard Connector:20+4 pin Modular Peripheral: Up to 5 Modular SATA: Up to 10 Safety & Protection Over Current Protection (OCP): Yes Over Power Protection (OPP): Yes Over Temperature Protection: Yes Over Voltage Protection (OVP): Yes Short Circuit Protection (SCP): Yes Under Voltage Protection (UVP): Yes Physical Cooling Fan Size (mm):120 Intake Fan: Airflow (CFM/min):80.5 Intake Fan: Diameter (mm):120 x 120 x 25 mm Intake Fan: Speed:2050 rpm Package

Dimensions (cm):31.9 x 21.0 x 16.3 Package

Dimensions (inch):12.55 x 8.26 x 6.42 Package Weight (Kg):2.76 est. Package Weight (lb):6.08 est. PSU Dimension (cm):8.6 x 14.0 x 16.0 PSU Dimension (inch):3.4 x 5.5 x 6.3 Certifications & Standards C-tick: Yes CB: Yes TUV: Yes






...

Essays. Spreadsheets. Letters. Photo archiving. Gaming. You want to do it all. & you want to do it now. Here at XFX, XFX calls that classic Computer Split Personality Disorder. & XFX has the prescription: the XFX ATI Radeon HD 5450 Graphics Card. GPU
- AMD HD 5450 Memory Size
- 1GB Memory Type
- s DDR3 Core Clock
- 650 M Hz Memory Clock
- 1066 M Hz Memory Bus
- 64bit Bus
- PCI-Express






...

The XFX AMD Radeon HD 6400 graphics card delivers discrete graphics performance thats perfect for every day computing. Multitask with AMDs Eye Speed technology & accelerate applications. With Direct X 11, the XFX AMD Radeon HD 6400 graphics card gets a performance boost, delivering advance technologies with superb Direct X 11 support. ...
