The Matrox M9120 Plus LP x 1 low-profile, quad-upgradeable, dual monitor graphics card renders pristine images on either two displays (natively), or four displays (via an aftermarket upgrade cable) at resolutions up to 1920x 1200 (digital), or 2048x 1536 (analog). Armed with 512MB of graphics memory & advanced desktop management, the M9120 Plus drives business, government, & industrial applications with extraordinary performance on in both independent & stretched desktop modes. Its low-profile form factor makes it easy to integrate into a wide variety of systems, it offers optimal Windows Vista Aero support (WDDM mode), & it can be paired with another Matrox graphics card if additional outputs are required. The M9120 Plus card builds upon the reliability & stability of previous Matrox products & retains core Matrox benefits such as long life-cycles, top-to-bottom manufacturing, & unified display driver models for easy deployment across multiple systems. ...

The Matrox M9140 LP PCIe x 16 quad head graphics card renders pristine images across four monitors at resolutions up to 1920x 1200 per output (digital or analog) for an exceptional multi-display user experience. With 512 MB of memory & advanced desktop management features such extending the Windows Taskbar to span multiple displays & support of independent or stretched modes, the M9140 drives business, industrial, & government applications with extraordinary performance. Its low-profile form factor makes it easy to integrate into a wide variety of systems, it offers optimal Windows Vista Aero support (WDDM mode), & it can be paired with another M9140 graphics card to support up to eight displays from a single system. The M9140 graphics card builds upon the reliability & stability of previous Matrox products, & retains core Matrox benefits such as long life-cycles, top-to-bottom manufacturing & unified display driver models for easy deployment across multiple systems. ...

The Matrox M9148 LP PCIe x 16 four monitor graphics card renders pristine images across four Display Port monitors at resolutions up to 2560 x 1600 per output for an exceptional multi-monitor user experience. With 1 GB of memory & advanced desktop management features such extending the Windows Taskbar to span multiple displays & support of independent or stretched modes, the M9148 drives business, industrial, & government applications with extraordinary performance. Its low-profile form factor makes it easy to integrate into a wide variety of systems, it offers optimal Windows Vista Aero support (WDDM mode), & it can be paired with another M9148 graphics card to support up to eight Display Port monitors from a single system. Part Number
- M9148-E1024LAF Bus Type
- PCIe x 16 Graphics Memory
- 1024MB Card Form Factor (PCB / bracket)
- LP / ATX Extra bracket in the box
- LP Card

Dimensions
- 6.6" (L) x 2.7" (H) On-board Connectors
- 4 x Mini Display Port Adapters
- 4 x Mini Display Port to Display Port Connector Adapters
- 4 x Display Port to DVI Max Display Outputs per Card
- 4 Supported Display Output Types
- Display Port, DVI SL Max Display Port Resolution per Output
- 2560x 1600 Max DVI Resolution per Output
- 1920x 1200 Independent Desktop Mode
- Yes Stretched Desktop Mode
- Yes Joined Adapter Mode
- Yes (Not available under Microsoft Windows 7 & Vista when M9188 is the additional card, except under Windows 7 XDDM mode) Matrox Clone
- Yes Pivot Support
- Yes Passive Cooling
- Yes Unified Driver Package
- Yes Power Desk Software
- Yes EMC Certifications
- Class B Supported Operating Systems
- Windows 7 (32/64bit), Windows Vista (32/64bit), Windows XP (32/64bit), Windows Server 2003/2008 (32/64bit), & Linux Open GL support
- 2.0

























...

PRODUCT
Features: Matrox Dual Head to use 2 monitors at a time (in "independent" or "stretched" mode)PCI
...

Reliable, ultra-low power graphics solution with wide enterprise flexibility The Matrox P690 PCIe x 16 offers 128MB of graphics memory & full Dual Head support for using two digital or analog monitors at high resolution & pristine image quality. With ultra-low power consumption, fanless cooling & unified display drivers for easy deployment across multiple systems, the P690 PCIe x 16 is suitable for a wide range of professional applications. This graphics card builds upon the reliability, stability, & features of the proven P-Series product line, making it an ideal choice for use in long-life environments. Matrox Dual Head technology with support for two digital or analog monitors at a time Independent resolutions & stretched desktop both supported Native PCI Express x 16 support Passive cooling (heat sink with no fan) for silent operation & extra reliability Ultra low power consumption: 10 watts Unified driver package also compatible with other products in P-Series, G-Series, QID Series, MMS Series, Parhelia Series, & Extio Series Display drivers for Windows XP & XP x 64, Windows 2000, Windows Vista (XDDM) & Vista x 64 (XDDM), Windows Server 2003 & Server 2003 x 64* Easy-to-use Matrox Power Desk desktop management software Support for customizable unattended installation of drivers for multi-system set-up Compatible with Matrox Power Space for augmented multi-display desktop functionality including multiple workspace configuration support, program autostart, desktop recall, RDP recognition support, & multi-system workspace import/export Joined graphics card mode enables an additional Matrox Dual Head& Dagger; or Triple Head± graphics card to work in tandem in one system to drive up to four displays using advanced multi-card features† Widescreen resolution support & additional functionality via Matrox Power Res Display pivoting (rotation) support Global sales & technical support Ro HS & WEEE compliant 3-year warranty * Drivers for Windows Server 2003, Windows XP x 64 (64-bit) & Windows Vista XDDM available online. For other possible operating systems, contact Matrox. With Joined graphics card mode, some Dual Head graphics cards can be joined with a second compliant Dual Head or Triple Head graphics card to drive up to four displays. In Joined graphics card mode, compliant Triple Head graphics cards are supported in Dual Head mode only. Joined graphics card mode multi-display configurations can be obtained by downloading the Matrox Power Desk-SE version 2.04 display driver & above. Hardware included Matrox P690 PCIe x 16 graphics card Two DVI-I-to-HD15 connector adapters Software included Matrox display drivers for Microsoft Windows XP & Windows 2000* Matrox Power Desk desktop management software Part Number
- P69-MDDE128F Card type
- PCIe x 16 (PCI Express x 16) Graphics Memory
- 128 MB DDR2 Bracket connectors
- DVI x 2 Card form factor
- ATX Bracket form factor
- ATX EMC certifications
- Class B – ACA, CE, CSA, FCC, VCCI Card size
- 6.6" x 4.38" / 16.76 x 11.13 cm (Card size = length, not including bracket & bracket connectors x height, including slot connector. Card width is within specifications for a single card of the given type.) Maximum resolutions (per display) Digital, 1-2 monitors: 1920 x 1200 Analog, 1-2 monitor: 2048 x 1536







...

The low-profile Matrox Millennium P690 LP PCIe x 16 128MB offers Dual Head support for two digital or analog monitors at high resolution & pristine image quality. Designed with native PCI Express x 16 support, it can accommodate both ATX & low-profile systems, making it ideal for small form factor PCs & docking stations. The P690 LP PCIe x 16 builds upon the reliability, stability, & features of the proven Millennium P-Series product line, & is suitable for a wide range of professional applications. Ultra-low power consumption, fanless cooling, & unified display drivers make it easy to deploy across multiple systems in long-life environments. ...

Matrox P690 256 MB DDR2 DVI PCI-E Low Profile Graphics Card Reliable, ultra-low power graphics solution with wide enterprise flexibility The Matrox P690 Plus LP PCIe x 16 offers 256MB of graphics memory & full Dual Head support for using two digital or analog monitors at high resolution & pristine image quality, & can be upgraded (via a Quad-HD15 cable). With ultra-low power consumption, fanless cooling & unified display drivers for easy deployment across multiple systems, the P690 Plus LP PCIe x 16 is suitable for a wide range of professional applications. This graphics card builds upon the reliability, stability, & features of the proven P-Series product line, making it an ideal choice for use in long-life environments. Matrox Dual Head technology with support for two digital or analog monitors at a time Independent resolutions & stretched desktop both supported Native PCI Express x 16 support Passive cooling (heat sink with no fan) for silent operation & extra reliability Aftermarket upgrade to quad analog display Upgrade to quad head output via cable (CAB-L60-4XAF) Ultra low power consumption: 10.7 watts Unified driver package also compatible with other products in P-Series, G-Series, QID Series, MMS Series, Parhelia Series, & Extio Series Display drivers for Windows XP & XP x 64, Windows 2000, Windows Vista (XDDM) & Vista x 64 (XDDM), Windows Server 2003 & Server 2003 x 64* Easy-to-use Matrox Power Desk desktop management software Support for customizable unattended installation of drivers for multi-system set-up Compatible with Matrox Power Space for augmented multi-display desktop functionality including multiple workspace configuration support, program autostart, desktop recall, RDP recognition support, & multi-system workspace import/export Joined graphics card mode enables an additional Matrox Dual Head& Dagger; or Triple Head± graphics card to work in tandem in one system to drive up to four displays using advanced multi-card features† Widescreen resolution support & additional functionality via Matrox Power Res Display pivoting (rotation) support Global sales & technical support Ro HS & WEEE compliant 3-year warranty Part Number
- P69-MDDE256LAUF Card type
- PCIe x 16 (PCI Express x 16) Graphics Memory
- 256 MB DDR2 Bracket connectors
- LFH60 Card form factor
- LP (Low-Profile) Bracket form factor
- ATX Extra bracket in the box
- LP Adapter Cables
- LFH-60 to 2 x DVI Connector Adapters
- 2 DVI-to-HD15 EMC certifications
- Class A – ACA, CE, CSA, FCC, VCCI Card size
- 6.6" x 2.71" / 16.76 x 6.88 cm (Card size = length, not including bracket & bracket connectors x height, including slot connector. Card width is within specifications for a single card of the given type.) Maximum resolutions (per display) Digital, 1-2 monitors: 1920 x 1200 Analog, 1-2 monitor: 2048 x 1536 Analog, 3-4 monitors: 1920 x 1200










...
