Gigabyte Z97X-UD5H Socket LGA1150 VGA DVI HDMI 8 Channel Audio ATX Motherboard CPU Support for Intel Core i 7 processors/ Intel Core i 5 processors/ Intel Core i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1150 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel Z97 Express Chipset Memory 4 x DDR3 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 3200 (O.C.) / 3100 (O.C.) / 3000 (O.C.) / 2933 (O.C.) / 2800 (O.C.) / 2666 (O.C.) / 2600 (O.C.) / 2500 (O.C.) / 2400 (O.C.) / 2200 (O.C.) / 2133 (O.C.) / 2000 (O.C.) / 1866 (O.C.) / 1800 (O.C.) / 1600 / 1333 MHz memory modules Support for non-ECC memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor
- Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@24 Hz or 2560x 1600@60 Hz * Support for HDMI 1.4a version. Support for up to 3 displays at the same time Maximum shared memory of 512MB Audio Realtek ALC1150 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN 1 x Qualcomm Atheros Killer E2201 LAN chip (10/100/1000 Mbit) (LAN1) 1 x Intel Gb E LAN phy (10/100/1000 Mbit) (LAN2) * Teaming is not supported. Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x 16 slot, running at x 8 (PCIEX8) * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot will operate at up to x 8 mode. 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the PCIEX8 & PCIEX16 slots. When the PCIEX4 slot is populated, the PCIEX16 slot will operate at up to x 8 mode & the PCIEX8 will operate at up to x 4 mode. * When installing a x 8 or above card in the PCIEX4 slot, make sure to set PCIE Slot Configuration in BIOS Setup to x 4. (Refer to Chapter 2, BIOS Setup, Peripherals, for more information.) (The PCIEX16, PCIEX8 & PCIEX4 slots conform to PCI Express 3.0 standard.) 2 x PCI Express x 1 slots (The PCI Express x 1 slots conform to PCI Express 2.0 standard.) 2 x PCI slots Multi-Graphics Technology Support for 3-Way/2-Way AMD Cross Fire & 2-Way NVIDIA SLI Technology Storage Interface Chipset: 1 x M.2 PCIe connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe SSD support) 1 x SATA Express connector 6 x SATA 6 Gb/s connectors (SATA3 0~5) (M.2, SATA Express, & SATA3 4/5 connectors can only be used one at a time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is installed.) Support for RAID 0, RAID 1, RAID 5, & RAID 10 Marvell 88SE9172 chip: 2 x SATA 6 Gb/s connectors (GSATA3 6~7) Support for RAID 0 & RAID 1 * Due to system limitation, Intel RAID & Marvell RAID can only use either one. USB (Universal Serial Bus) Chipset: 4 USB (Universal Serial Bus) 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 6 USB (Universal Serial Bus) 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Chipset + Renesas u PD720210 USB (Universal Serial Bus) 3.0 Hub: 4 USB (Universal Serial Bus) 3.0/2.0 ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x PCIe power connector 1 x M.2 PCIe connector 1 x SATA Express connector 8 x SATA 6 Gb/s connectors 1 x CPU fan header 1 x water cooling fan header (CPU_OPT) 4 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB (Universal Serial Bus) 3.0/2.0 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper 1 x Trusted Platform Module (TPM) header 1 x power button 1 x reset button 1 x Clear CMOS button 2 x BIOS switches Voltage Measurement Points Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x optical S/PDIF Out connector 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 6 x USB (Universal Serial Bus) 3.0/2.0 ports 2 x USB (Universal Serial Bus) 2.0/1.1 ports 2 x RJ-45 ports 5 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection CPU/ System/ Chipset temperature detection CPU/CPU OPT/ System fan speed detection CPU/ System overheating warning CPU/CPU OPT/ System fan fail warning CPU/CPU OPT/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. @BIOS Easy Tune EZ Setup Fast Boot ON/OFF Charge Smart Time Lock Smart Recovery 2 System Information Viewer USB (Universal Serial Bus) Blocker Support for Q-Flash Support for Smart Switch Support for Xpress Install Bundle Software Norton Internet Security (OEM version) Intel Rapid Start Technology Intel Smart Connect Technology Intel Smart Response Technology Operating System Support for Windows 8.1/8/7 Form Factor ATX Form Factor; 30.5cm x 24.4cm
...

Gigabyte Z97X-UD5H-BK Socket LGA1150 VGA DVI HDMI Display Port 8 Channel Audio ATX Motherboard CPU Support for Intel Core i 7 processors/ Intel Core i 5 processors/ Intel Core i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1150 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel Z97 Express Chipset Memory 4 x DDR3 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 3000 (O.C.) / 2933 (O.C.) / 2800 (O.C.) / 2666 (O.C.) / 2600 (O.C.) / 2500 (O.C.) / 2400 (O.C.) / 2200 (O.C.) / 2133 (O.C.) / 2000 (O.C.) / 1866 (O.C.) / 1800 (O.C.) / 1600 / 1333 MHz memory modules Support for non-ECC memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor
- Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@24 Hz or 2560x 1600@60 Hz * Support for HDMI 1.4a version. Support for up to 3 displays at the same time Maximum shared memory of 512MB Audio Realtek ALC1150 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN 1 x Qualcomm Atheros Killer E2201 LAN chip (10/100/1000 Mbit) (LAN1) 1 x Intel Gb E LAN phy (10/100/1000 Mbit) (LAN2) Teaming is not supported. Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x 16 slot, running at x 8 (PCIEX8) The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot will operate at up to x 8 mode. 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) The PCIEX4 slot shares bandwidth with the PCIEX8 & PCIEX16 slots. When the PCIEX4 slot is populated, the PCIEX16 slot will operate at up to x 8 mode & the PCIEX8 will operate at up to x 4 mode. When installing a x 8 or above card in the PCIEX4 slot, make sure to set PCIE Slot Configuration in BIOS Setup to x 4. (Refer to Chapter 2, BIOS Setup, Peripherals, for more information.) (The PCIEX16, PCIEX8 & PCIEX4 slots conform to PCI Express 3.0 standard.) 2 x PCI Express x 1 slots (The PCI Express x 1 slots conform to PCI Express 2.0 standard.) 2 x PCI slots Multi-Graphics Technology Support for 3-Way/2-Way AMD Cross Fire & 2-Way NVIDIA SLI Technology Storage Interface Chipset: 1 x M.2 PCIe connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe SSD support) 1 x SATA Express connector 6 x SATA 6 Gb/s connectors (SATA3 0~5) (M.2, SATA Express, & SATA3 4/5 connectors can only be used one at a time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is installed.) Support for RAID 0, RAID 1, RAID 5, & RAID 10 Marvell 88SE9172 chip: 2 x SATA 6 Gb/s connectors (GSATA3 6~7) Support for RAID 0 & RAID 1 * Due to system limitation, Intel RAID & Marvell RAID can only use either one. USB (Universal Serial Bus) Chipset: 4 USB (Universal Serial Bus) 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 6 USB (Universal Serial Bus) 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Chipset + Renesas u PD720210 USB (Universal Serial Bus) 3.0 Hub: 4 USB (Universal Serial Bus) 3.0/2.0 ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x PCIe power connector 1 x M.2 PCIe connector 1 x SATA Express connector 8 x SATA 6 Gb/s connectors 1 x CPU fan header 1 x water cooling fan header (CPU_OPT) 4 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB (Universal Serial Bus) 3.0/2.0 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper 1 x Trusted Platform Module (TPM) header 1 x power button 1 x reset button 1 x Clear CMOS button 2 x BIOS switches Voltage Measurement Points Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x optical S/PDIF Out connector 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 6 x USB (Universal Serial Bus) 3.0/2.0 ports 2 x USB (Universal Serial Bus) 2.0/1.1 ports 2 x RJ-45 ports 5 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection CPU/ System/ Chipset temperature detection CPU/CPU OPT/ System fan speed detection CPU/ System overheating warning CPU/CPU OPT/ System fan fail warning CPU/CPU OPT/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. @BIOS Easy Tune EZ Setup Fast Boot ON/OFF Charge Smart Time Lock Smart Recovery 2 System Information Viewer USB (Universal Serial Bus) Blocker Support for Q-Flash Support for Smart Switch Support for Xpress Install Bundle Software Norton Internet Security (OEM version) Intel Rapid Start Technology Intel Smart Connect Technology Intel Smart Response Technology Operating System Support for Windows 8.1/8/7 Form Factor ATX Form Factor; 30.5cm x 24.4cm
...

Supports 4th & 5th Generation Intel Core processors Dual " Thunderbolt 2" technology support Extreme multi graphics support Precise digital CPU power design SATA Express support for 10 Gb/s data transfer Realtek ALC1150 115d B SNR HD Audio with Built-in rear audio amplifier Intel Gb E LAN with CFOS internet accelerator software 2x copper PCB design Long lifespan Durable Black solid caps APP Center including Easy Tune & Cloud Station utilities GIGABYTE UEFI Dual BIOS CPU Support for Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1150 package L3 cache varies with CPU (Please refer "CPU Support List" for more information) Chipset Intel Z97 Express Chipset Memory 4 x DDR3 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR3 3200 (O.C.) / 3100 (O.C.) / 3000 (O.C.) / 2933 (O.C.) / 2800 (O.C.) / 2666 (O.C.) / 2600 (O.C.) / 2500 (O.C.) / 2400 (O.C.) / 2200 (O.C.) / 2133 (O.C.) / 2000 (O.C.) / 1866 (O.C.) / 1800 (O.C.) / 1600 / 1333 MHz memory modules Support for non-ECC memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information) Onboard Graphics Integrated Graphics Processor: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter 1 x HDMI port, supporting a maximum resolution of 4096x 2160@24 Hz or 2560x 1600@60 Hz * Support for HDMI 1.4a version Intel DSL5520 Chip: 2 Thunderbolt ports (MDP1/MDP2) support for Mini-Display Port & Thunderbolt monitor (s), & supporting a maximum resolution of 3840x 2160@60 Hz. * If a monitor is connected to the MDP2 Thunderbolt port, the DVI port will become unavailable. * Because of the limited I/O resources of the PC architecture, the number of Thunderbolt devices that can be used is dependent on the number of the PCI Express & PCI devices being installed. (Refer to Chapter 1-7, Back Panel Connectors, for more information.) Support for up to 3 displays at the same time Maximum shared memory of 512MB Audio Realtek ALC1150 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Intel Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x 16 slot, running at x 8 (PCIEX8) * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot will operate at up to x 8 mode. 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the PCIEX8 & PCIEX16 slots. When the PCIEX4 slot is populated, the PCIEX16 slot will operate at up to x 8 mode & the PCIEX8 will operate at up to x 4 mode. * When installing a x 8 or above card in the PCIEX4 slot, make sure to set PCIE Slot Configuration (CPU) in BIOS Setup to x 4. (Refer to Chapter 2, BIOS Setup, Peripherals, for more information.) (The PCIEX16, PCIEX8 & PCIEX4 slots conform to PCI Express 3.0 standard) 3 x PCI Express x 1 slots (The PCI Express x 1 slots conform to PCI Express 2.0 standard) Multi-Graphics Technology Support for 3-Way/2-Way AMD Cross Fire™and 2-Way NVIDIA SLI™ Technology Storage Interface Chipset: 1 x SATA Express connector 6 x SATA 6 Gb/s connectors (SATA3 0~5) (SATA Express & SATA3 4/5 connectors can only be used one at a time) Support for RAID 0, RAID 1, RAID 5, & RAID 10 Marvell 88SE9172 chip: 2 x SATA 6 Gb/s connectors (GSATA3 6~7) Support for RAID 0 & RAID 1 * Due to system limitation, Intel RAID & Marvell RAID can only use either one USB (Universal Serial Bus) Chipset: 4 x USB (Universal Serial Bus) 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 6 x USB (Universal Serial Bus) 2.0/1.1 ports available through the internal USB (Universal Serial Bus) headers Chipset + Renesas u PD720210 USB (Universal Serial Bus) 3.0 Hub: 4 x USB (Universal Serial Bus) 3.0/2.0 ports on the back panel Thunderbolt Intel DSL5520 chip: 2 Thunderbolt ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x PCIe power connector 1 x SATA Express connector 8 x SATA 6 Gb/s connectors 1 x CPU fan header 1 x water cooling fan header (CPU_OPT) 4 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB (Universal Serial Bus) 3.0/2.0 header 3 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper 1 x Trusted Platform Module (TPM) header 1 x power button 1 x reset button 1 x Clear CMOS button 2 x BIOS switches Voltage Measurement Points Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 1 x optical S/PDIF Out connector 2 x Thunderbolt ports 6 x USB (Universal Serial Bus) 3.0/2.0 ports 1 x RJ-45 port 6 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring System voltage detection CPU/ System/ Chipset temperature detection CPU/CPU OPT/ System fan speed detection CPU/ System overheating warning CPU/CPU OPT/ System fan fail warning CPU/CPU OPT/ System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications. @BIOS Easy Tune EZ Setup Fast Boot ON/OFF Charge Smart Time Lock Smart Recovery 2 System Information Viewer USB (Universal Serial Bus) Blocker Support for Q-Flash Support for Smart Switch Support for Xpress Install Operating System Support for Windows 8.1/8/7 Form Factor ATX Form Factor; 30.5cm x 24.4cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website. ...

Gigabyte GB-BXi 3-4010 BRIX / Ultra Compact PC kit The BRIX from GIGABYTE is an ultra compact & versatile DIY PC kit available with a broad choice of processors covering a range of performance points. The BRIX redefines the desktop PC in terms of miniaturization with a form factor that sits in the palm of your h&. Ideal for compact HTPC builds or as a standard desktop in the home or office, the BRIX doesnt hold back in terms of display & peripheral connectivity, or raw performance. Supports dual display video output via HDMI & mini Display Port.

Includes:: IEEE 802.11b/g/n Wi-Fi / Bluetooth 4.0/3.0 Combo Mini PCIe module.

Includes:: VESA bracket for discreet display & wall mounting. Redefining the Desktop PC: Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a stylish design based around an anthracite aluminum frame & glass surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Dual Display: With support for HDMI & Display Port, the BRIX can power two displays simultaneously, making a perfect choice as a high productivity PC in professional & home environments, or in any number of industrial & commercial multi-display applications. Flexible Compact PC Kit: The BRIX is sold as a DIY PC kit, shipping with a Mini PCIe Wi-Fi module pre-installed, plus a power adapter & cable conforming to local standards. Requiring only system memory & m SATA SSD, the BRIX gives users the flexibility to independently choose integrated storage & system memory size, without the trouble of sourcing components that are not widely available on the retail market. VESA Support: Bundled with a VESA bracket, the BRIX can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This makes it simple & effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. Dimension
- 29.9 mm x 107.6 mm x 114.4 mm (1.18" x 4.24" x 4.5") Motherboard
- 100 x 105 mm CPU
- 4th generation Intel Core„¢ i 3-4010U 1.7 G Hz Memory 2 x SO-DIMM DDR3L slots (DDR3 1.35V) 1333 / 1600 MHz Max. 16GB LAN
- Gigabit LAN (Realtek RTL8111G) Audio
- Realtek ALC269 Graphics
- Intel HD 4400 graphics Expansion Slots 1 x m SATA slot 1 x Half-size mini-PCIe slot occupied by the Wi Fi+BT card Front I/O: 2 x USB (Universal Serial Bus) 3.0 1 x head phone jack with SPDIF Rear I/O: 1 x HDMI 1 x Mini Display Port 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Power Supply: Input: AC 100-240V Output: DC 19V 3.42A VESA: Bracket included Supports 75 x 75 & 100 x 100 mm









...

The BRIX from GIGABYTE is an ultra compact & versatile DIY PC kit available with a broad choice of processors covering a range of performance points. The BRIX redefines the desktop PC in terms of miniaturization with a form factor that sits in the palm of your h&. Ideal for compact HTPC builds or as a standard desktop in the home or office, the BRIX doesnt hold back in terms of display & peripheral connectivity, or raw performance. Supports dual display video output via HDMI & mini Display Port.

Includes:: IEEE 802.11b/g/n Wi-Fi / Bluetooth 4.0/3.0 Combo Mini PCIe module.

Includes:: VESA bracket for discreet display & wall mounting. Redefining the Desktop PC: Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a stylish design based around an anthracite aluminum frame & glass surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Dual Display: With support for HDMI & Display Port, the BRIX can power two displays simultaneously, making a perfect choice as a high productivity PC in professional & home environments, or in any number of industrial & commercial multi-display applications. Flexible Compact PC Kit: The BRIX is sold as a DIY PC kit, shipping with a Mini PCIe Wi-Fi module pre-installed, plus a power adapter & cable conforming to local standards. Requiring only system memory & m SATA SSD, the BRIX gives users the flexibility to independently choose integrated storage & system memory size, without the trouble of sourcing components that are not widely available on the retail market. VESA Support: Bundled with a VESA bracket, the BRIX can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This makes it simple & effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. Dimension
- 29.9 mm x 107.6 mm x 114.4 mm (1.18" x 4.24" x 4.5") Motherboard
- 100 x 105 mm CPU
- 4th generation Intel Core i 5-4200U 1.6 G Hz / 2.6 G Hz Memory: 2 x SO-DIMM DDR3L slots (DDR3 1.35V) 1333 / 1600 MHz Max. 16GB LAN
- Gigabit LAN (Realtek RTL8111G) Audio
- Realtek ALC269 Graphics
- Intel HD 4400 graphics Expansion Slots: 1 x m SATA slot 1 x Half-size mini-PCIe slot occupied by the Wi Fi+BT card Front I/O: 2 x USB (Universal Serial Bus) 3.0 1 x head phone jack with SPDIF Rear I/O: 1 x HDMI 1 x Mini Display Port 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Power Supply: Input: AC 100-240V Output: DC 19V 3.42A VESA: Bracket included Supports 75 x 75 & 100 x 100 mm









...

Gigabyte GB-BXi 7-4500 BRIX / Ultra Compact PC kit The BRIX from GIGABYTE is an ultra compact & versatile DIY PC kit available with a broad choice of processors covering a range of performance points. The BRIX redefines the desktop PC in terms of miniaturization with a form factor that sits in the palm of your h&. Ideal for compact HTPC builds or as a standard desktop in the home or office, the BRIX doesnt hold back in terms of display & peripheral connectivity, or raw performance. Supports dual display video output via HDMI & mini Display Port.

Includes:: IEEE 802.11b/g/n Wi-Fi / Bluetooth 4.0/3.0 Combo Mini PCIe module.

Includes:: VESA bracket for discreet display & wall mounting. Redefining the Desktop PC: Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a stylish design based around an anthracite aluminum frame & glass surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Dual Display: With support for HDMI & Display Port, the BRIX can power two displays simultaneously, making a perfect choice as a high productivity PC in professional & home environments, or in any number of industrial & commercial multi-display applications. Flexible Compact PC Kit: The BRIX is sold as a DIY PC kit, shipping with a Mini PCIe Wi-Fi module pre-installed, plus a power adapter & cable conforming to local standards. Requiring only system memory & m SATA SSD, the BRIX gives users the flexibility to independently choose integrated storage & system memory size, without the trouble of sourcing components that are not widely available on the retail market. VESA Support: Bundled with a VESA bracket, the BRIX can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This makes it simple & effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. Dimension
- 29.9 mm x 107.6 mm x 114.4 mm (1.18" x 4.24" x 4.5") Motherboard
- 100 x 105 mm CPU
- 4th generation Intel Core i 7-4500U 1.8 G Hz / 3.0 G Hz Memory: 2 x SO-DIMM DDR3L slots (DDR3 1.35V) 1333 / 1600 MHz Max. 16GB LAN
- Gigabit LAN (Realtek RTL8111G) Audio
- Realtek ALC269 Graphics
- Intel HD 4400 graphics Expansion Slots: 1 x m SATA slot 1 x Half-size mini-PCIe slot occupied by the Wi Fi+BT card Front I/O: 2 x USB (Universal Serial Bus) 3.0 1 x head phone jack with SPDIF Rear I/O: 1 x HDMI 1 x Mini Display Port 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA: Bracket included Supports 75 x 75 & 100 x 100 mm









...

Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a stylish design based around an anthracite aluminum frame & glass surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Specifications

Dimensions 29.9 mm x 107.9 mm x 114.6 mm (1.18" x 4.24" x 4.5") Motherboard 100 x 105 mm CPU 3rd generation Intel Core i 5-3337U 1.8 G Hz / 2.7 G Hz Chipset Intel HM77 Memory 2 x SO-DIMM DDR3 slots 1333 / 1600 MHz Max. 16GB (8GB x 2) LAN Gigabit LAN (Realtek RTL8111E) Graphics Intel HD 4000 graphics Expansion Slots 1 x m SATA slot 1 x Half-size mini-PCIe slot occupied by the Wi Fi card Front I/O 1 x USB (Universal Serial Bus) 3.0 Rear I/O 1 x HDMI 1 x Mini Display Port 1 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA Bracket included Supports 75 x 75 & 100 x 100 mm

...

Redefining the Desktop PC Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a stylish design based around an anthracite aluminum frame & glass surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that make it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Dual Display With support for HDMI & Display Port, the BRIX can power two displays simultaneously, making a perfect choice as a high productivity PC in professional & home environments, or in any number of industrial & commercial multi-display applications. Flexible Compact PC Kit The BRIX is sold as a DIY PC kit, shipping with a Wi-Fi Mini PCIe module pre-installed, plus a power adapter & cable conforming to local standards. Requiring only system memory & m SATA SSD, the BRIX gives users the flexibility to independently choose integrated storage & system memory size, without the trouble of sourcing components that are not widely available on the retail market. VESA Support Bundled with a VESA bracket, the BRIX can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This makes it simple & effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. Dimension
- 29.9 x 107.9 x 114.6 mm Motherboard
- 100 x 105 mm CPU
- Intel Celeron 1037U 1.8 G Hz Chipset
- Intel NM70 Memory
- 2 x SO-DIMM DDR3 slots 1333 / 1600 MHz Max. 16GB (8GB x 2) LAN
- Gigabit LAN (Realtek RTL8111E) Graphics
- Intel HD graphics Expansion Slots 1 x m SATA slot 1 x Half-size mini-PCIe slot occupied by the Wi Fi card Front I/O 1 x USB (Universal Serial Bus) 2.0 Rear I/O 1 x HDMI 1 x Mini Display Port 1 x USB (Universal Serial Bus) 2.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA: Bracket included Supports 75 x 75 & 100 x 100 mm UK Plug not included.






...

Gigabyte Ge Force GT 710 1GB DDR3 VGA Dual-Link DVI-D HDMI PCI-E Graphics card Ultra Durable 2 Technology Fitted with high quality components to deliver lower temperature, reliable operation & longer system lifespan. Ultra Cooling Low RDS (on) MOSFET Design Low Power Loss Ferrite Core Choke Design Longer Life All-Solid Capacitor Design OC GURU II Utility Adjust clock speeds, voltage, fan performance, power target, OSD setting can be monitored & tuned in real-time according to your own preference through this intuitive interface.

Specification Chipset GT 710 Core Clock 954 MHz (Standard: 954 MHz) Process Technology 28 nm Memory Clock 1800 MHz Memory Size 1GB Memory Bus 64-bit Memory Type DDR3 Card Bus PCI-E 2.0 x 8 Direct X 12 Open GL 4.5 PCB Form Low profile Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 2 I/O Dual-link DVI-D*1 / HDMI*1 / D-Sub*1 Card size H=24 L=147 W=106 mm (TBD) Power requirement 300W

...

Gigabyte Ge Force GT 710 2GB DDR3 VGA Dual-Link DVI-D HDMI PCI-E Graphics card Ultra Durable 2 Technology Fitted with high quality components to deliver lower temperature, reliable operation & longer system lifespan. Ultra Cooling Low RDS (on) MOSFET Design Low Power Loss Ferrite Core Choke Design Longer Life All-Solid Capacitor Design OC GURU II Utility Adjust clock speeds, voltage, fan performance, power target, OSD setting can be monitored & tuned in real-time according to your own preference through this intuitive interface.

Specification Chipset GT 710 Core Clock 954 MHz (Standard: 954 MHz) Process Technology 28 nm Memory Clock 1800 MHz Memory Size 2GB Memory Bus 64-bit Memory Type DDR3 Card Bus PCI-E 2.0 x 8 Direct X 12 Open GL 4.5 PCB Form Low profile Digital max resolution 4096 X 2160 Analog max resolution 2048 x 1536 Multi-view 2 I/O Dual-link DVI-D*1 / HDMI*1 / D-Sub*1 Card size H=24 L=147 W=106 mm (TBD) Power requirement 300W

...
