Internal Mini Serial Attached SCSI x 4 to (4) x 1 Serial ATA fan-out cable with SFF-8448 sideband signals. Key Features Storage Cable Type
- Serial ATA / SAS cable
- with Sidebands SAS Lane Qty
- 4-Lane Length
- 1 m Connector (s)
- 1 x 36 pin 4i Mini Multi Lane SAS (SFF-8087) Connector (s) (Other Side) 4 x 7 pin Serial ATA ¦ 1 x SAS sideband connector The ACK-I-m SASx 4-4SATAx 1-SB-1m R is an internal Mini Serial Attached SCSI x 4 (SFF-8087) to (4) x 1 Serial ATA (adapter based) fan-out cable with SFF-8448 sideband signals. It measures 1 meter & is used for connecting a SATA/SAS adapter (SFF-8087) to SATA disks, or a SATA/SAS backplane.




...

Reliable PCIe connectivity for SCSI tape drives & SCSI hard drives Key Features Form Factor
- MD2 low-profile Number of devices
-

...

Series 5Z family of SAS/SATA adapters offers full cache protection without battery installation, monitoring, or replacement costs. Key Features Zero-Maintenance Cache Protection Intelligent Power Management MD2 Â- Low profile form factor 1.2 G Hz Dual Core RAID on Chip (ROC) 8-Lane PCI-Express bus interface The Series 5Z family of high-performance Adaptec SAS/SATA RAID adapters offers both high I/O transaction & high bandwidth processing for use with cost-effective, high-capacity SATA drives or high-performance SAS drives. The Adaptec RAID Series 5Z adapters utilize industry-leading dual core RAID on Chip (ROC), 512MB of DDR2 write cache, & connectivity with the latest x 8 PCI-Express to deliver over 250, 000 I/ Os 1.2 G Bs. Using SAS expanders, they can connect up to 256 SATA/SAS devices. The Adaptec RAID Series 5Z adapters supports a broad range of operating systems, compatibility with more than 300 third-party devices, & full integration with Adaptec Storage Manager™ for centralized management of all Adaptec raid adapters on the network. Zero-Maintenance Cache Protection Â- Save Thousands of Dollars in Data Center Costs Adaptec Series 5Z adapters introduce Zero-Maintenance Cache Protection, a revolutionary advancement that maximizes performance & extends power savings by protecting adapter cache without battery backup units & without incurring monitoring, maintenance, replacement or disposal costs. During a system power loss, the flash memory-based cache protection can preserve data for up to 10 years. Intelligent Power Management
- Reduce Power by up to 70% Adaptec Intelligent Power Management slashes storage power & cooling costs by spinning down idle disks & providing a lower power mode for active disks. Benefits Performance Unified Serial RAID adapter supports both SATA & SAS devices. Ideal for bandwidth intensive storage applications; NAS, OLTP servers, web servers, & digital surveillance. Offers Zero-Maintenance Cache Protection & Intelligent Power Management. Key RAID Features Supports 4 (5405Z) or 8 (5805Z) direct-attached or up to 256 SATA or SAS disk drives using SAS expanders RAID levels 0, 1, 1E, 5, 5EE, 6, 10, 50 & 60 Quick initialization Online Capacity Expansion Copyback Hot Spare Dynamic caching algorithm Native Command Queuing (NCQ) Background initialization Hot-plug drive support RAID Level Migration Hot spares Â- global, dedicated, & pooled Automatic/manual rebuild of hot spares SAF-TE enclosure management Configurable stripe size S.M.A.R.T. support Up to 512TB array sizes Multiple arrays per disk drive Bad stripe table Dynamic sector repair Staggered drive spin-up Bootable array support Optimized Disk Utilization Data Transfer Rate
- 3 Gb/s per port Bus System Interface
- 8-lane PCIe Form Factor
- Low-Profile MD2 Cache Memory
- 512MB of DDR2 memory Connector Configuration
- 5405Z: 1 internal (SFF-8087) Mini SAS Package Contents Adaptec RAID 5405Z adapter Pre-installed Flash Backup Module with Supercapacitor card Additional low profile vented bracket





...

Series 6 family of SAS/SATA adapters offer superior bandwidth & full cache protection without battery installation, monitoring, or replacement costs Key Features 6 Gb/s throughput at each port PMC-Sierra PM8013 Dual Core RAID on Chip (ROC) SAS 2.0 interfaces & PCIe Gen 2 Host Connection Low Profile, MD2 Form Factor Supports up to 256 SAS/SATA drives Adaptec RAID 6805 8 internal port, low profile, SAS 2.0 & Gen 2 PCI-Express (PCIe) Unified Serial RAID controller with Zero-Maintenance Cache Protection & Intelligent Power Management delivers exceptional performance, advanced data protection, maximum scalability & the lowest total cost of ownership for enterprise-class, high-density server applications The Series 6 & 6T high-performance Adaptec SAS/SATA RAID adapters offer maximum performance, scalability & reliability. With the enhanced bandwidth of its 6 Gb/s SAS 2.0 interfaces & the PCIe Gen 2 host connection they offer up to 60% higher sustained sequential throughput than previous generation adapters. Based on PMC-Sierra's market-leading, multi-core SRC 8x 6G RAID-on-Chip (Ro C) the Adaptec Series 6 & Series 6T can deliver up to 2 GB/s sustained data transfer rate to the host. Peak performance is up to 4.8GB/s through the SAS 2.0 interfaces & 4.0GB/s through the PCIe Gen 2 host interface. Using SAS expanders, it can connect up to 256 SAS/SATA. The Adaptec Series 6 & Series 6T support a broad range of operating systems, compatibility with more than 300 third-party devices, & full integration with Adaptec Storage Manager™ for centralized management of all Adaptec RAID adapters on the network. Zero-Maintenance Cache Protection Kit Option Â- Maximum protection & Savings Adaptec Series 6 is the industry's first adapter which offers Zero-Maintenance Cache Protection (ZMCP) that eliminates Battery Backup Units (BBUs) in favor of 4GB of NAND flash memory to protect cached data & eliminate the installation, monitoring, maintenance, disposal & replacement costs associated with BBUs. Available as a separate Kit: Adaptec Flash Module 600 (AFM-600). Hybrid RAID With Hybrid RAID 1 & 10 Series 6 & 6T adapters offer maximum performance & reliability by combining Solid State Drives (SSDs) & Hard Disk Drives (HDDs) in a single array. Performing read operations from the faster SSD & write operations on both the SSDs & HDD results in tremendous performance gains over standard HDD RAID arrays. Hybrid RAID offers the benefits of both technologies & allows a better cost-per-operation. Specifications Operating System Microsoft Windows Red Hat Linux SUSE Linux Fedora Debian Linux Ubuntu Linux Sun Solaris Free BSD VMware ESX Benefits Performance Unified Serial RAID controller supports both SATA & SAS devices. Ideal for bandwidth intensive storage applications; NAS, OLTP servers, web servers, & digital surveillance. Offers Zero-Maintenance Cache Protection & Intelligent Power Management. Key Differentiators Zero-Maintenance Cache Protection Intelligent Power Management Customer Needs High I/O transaction & high bandwidth processing. Form Factor
- MD2 Low-Profile Cache Memory
- 512MB of DDR2 667 M Hz cache memory RAID Levels
- RAID levels 0, 1, 1E, 5, 5EE, 6, 10, 50, 60 & JBOD Key RAID Features Supports up to 256 SATA or SAS devices using SAS expanders RAID levels 0, 1, 1E, 5, 5EE, 6, 10, 50, 60 & JBOD Quick initialization Online Capacity Expansion Copyback Hot Spare Dynamic caching algorithm Native Command Queuing (NCQ) Background initialization Hot-plug drive support RAID Level Migration Hot spares Â- global, dedicated, & pooled Automatic/manual rebuild of hot spares SES & SAF-TE enclosure management Configurable stripe size S.M.A.R.T. support Multiple arrays per disk drive Dynamic sector repair Staggered drive spin-up Bootable array support Optimized Disk Utilization Bus System Interface Type
- 8-lane PCIe Gen 2 Internal Connectors
- 2 internal (SFF-8087) Mini SAS Data Transfer Rate
- 6 Gb/s per port Management Utilities Adaptec Storage Manager™ (ASM) Java-based GUI Management Utility Remote configuration, monitoring & notification ASM OS Support: Windows, Linux, SCO, Solaris Free BSD Microsoft VDS Support SNMP, SMTP Remote firmware updates ARCCONF Command Line Interface SMI-S support for VMware Adaptec BIOS Configuration Utility (ACU) BIOS level configuration utility Flashable BIOS support Physical Size
- 2.5" H x 6.6" L (64mm x 167mm) Operating Temperature 0°C to 55°C* (with 200 LFM airflow; without flash module) 0°C to 50°C* (with 200LFM airflow; with flash module) Note: This Adaptec card contains a powerful RAID processor which requires adequate airflow to operate reliably. Please install this card only into server or PC chassis with recommended airflow (200 LFM). * Ambient temperature measured 1" away from the RAID processor Operating Voltage 0.17 amp @ 3.3V 1.25 amp @ 12V measured on PCIe Gen 2 systems with 6G drives Regulatory Certification
- CE, FCC, UL, C-tick, VCCI, KCC Environmental Compliance
- Ro HS, REACH Mean Time Before Failure (MTBF)
- 860, 953 hours at 40 degree C. Package Contents Adaptec RAID 6805 Controller Additional low profile vented bracket Quick Installation Guide (English/ French/ German/ Italian/ Spanish/ Japanese) Adaptec RAID Installation DVD (bootable, incl. documentation, drivers & software) Cables: Two m SASx 4-4SATA x 1-SB (2272300-R), 0.7m * Singles do not contain cable









...

Adaptec RAID 6405E 4 internal port, low-profile MD2
- Low Profile (2.535"H x 5.115"L) with PCIe x 1, SAS 2.0 & Gen 2 PCI-Express
...

Adaptec Series 8 RAID Adapters
- Unmatched connectivity, performance & data protection Key Features 8 internal ports 12 Gb/s
...

Adaptec Series 8 RAID Adapters
- Unmatched connectivity, performance & data protection Key Features 16 ports (8 internal,
...

Adaptec 12 Gb/s SAS HD Cables for Series 8/8Q Adapters The Adaptec ACK-I-HDm SAS-HDm SAS-.5M is an internal Mini Serial Attached SCSI HD x 4 (SFF-8643) to Mini Serial Attached SCSI HD (SFF-8643) cable. It measures 0.5 meter & is used for connecting a SAS/SATA adapter to a SAS/SATA backplane. ...

Internal Mini Serial Attached SCSI HD x 4 (SFF-8643) to Mini Serial Attached SCSI x 4 (SFF-8087) cable Key Features Type: Adaptec 6 Gb/s SAS HD Cables Compatibility: Series 7/7Q Adapters Dimension: 1 Meter The Adaptec ACK-I-HDm SAS-m SAS-1M is an internal Mini Serial Attached SCSI HD x 4 (SFF-8643) to Mini Serial Attached SCSI x 4 (SFF-8087) cable. It measures 1 meter & is used for connecting a SAS/SATA adapter to a SAS/SATA backplane. ...

The Adaptec RAID 1220SA card is a two-port, PCI Express x 1 controller featuring Adaptec Host RAID
- an integrated RAID technology
...
