Product description
- Intended for use with microphones mounted on lecterns, pulpits, conference tables & other surfaces Suspended
...

Audio-Technica’s second-generation 2000 Series is a 10-channel frequency-agile UHF wireless system designed to suit a variety of applications, including MI/live performance, fixed installation, public address, A/V rental houses & places of worship. It offers all the advantages of a high-quality, professional wireless system at an extremely affordable price. New professional features include two available frequency bands & switchable antenna power. Also new to the 2000 Series, the optional ATW-CHG2 two-bay recharging station provides power to recharge Ni MH batteries in two ATW-T220a handheld transmitters and/or ATW-T210a Uni Pak transmitters in any combination. Offering 10 selectable channels in one of two UHF frequency ranges & True Diversity UHF wireless technology, the 2000 Series features automatic frequency scanning. At the touch of a button, this function automatically determines & sets the best available frequency. Any of the 2000 Series’ 10 channels may be used together without any frequency coordination problems or group selection issues. The 2000 Series also incorporates Audio-Technica’s Tone Lock squelch plus an easy-to-read LCD information display. Features Serious advances in affordable professional wireless Clear sound quality & rock-solid, dependable performance Automatic frequency scanning 10 compatible user-switchable channels in one of two UHF frequency ranges Antenna power available for powered antennas & other in-line RF devices True Diversity operation selects the better signal from the two receiver sections, reducing dropouts Tone Lock tone squelch system fights interference Rugged metal half-rack receiver with soft-touch controls & LCD display Balanced XLR & unbalanced 1/4” output jacks enable use with a wide variety of audio gear Switchable transmitter power output with high & low settings offered

Includes:: rack-mount kit & detachable UHF antennas Ground-lift switch helps eliminate audible hum caused by ground loops between the sound system & receiver ATW-T220a Handheld Microphone/ Transmitter features PRO 41 Capsule for maximum feedback rejection & consistent sound New charger (ATW-CHG2 ) available for ATW-T220a & ATW-T210a transmitters Handheld Transmitter RF Power Output: 10 m W Spurious Emissions: According to National Regulations Microphone Element: Dynamic cardioid Batteries: Two 1.5V AA alkaline (not included) Current Consumption: 150 m A typical Battery Life: Approx. 9 hours (depending on battery type & use pattern) Dimensions: 9.02" (229.0 mm) long x 2.11" (53.5 mm) maximum diameter Net Weight: 7.8 oz (221 g) Accessory Included: AT8456a Quiet-Flex™ Stand Clamp

...

Audio-Technica’s second-generation 2000 Series is a 10-channel frequency-agile UHF wireless system designed to suit a variety of applications, including MI/live performance, fixed installation, public address, A/V rental houses & places of worship. It offers all the advantages of a high-quality, professional wireless system at an extremely affordable price. New professional features include two available frequency bands & switchable antenna power. Also new to the 2000 Series, the optional ATW-CHG2 two-bay recharging station provides power to recharge Ni MH batteries in two ATW-T220a handheld transmitters and/or ATW-T210a Uni Pak transmitters in any combination. Offering 10 selectable channels in one of two UHF frequency ranges & True Diversity UHF wireless technology, the 2000 Series features automatic frequency scanning. At the touch of a button, this function automatically determines & sets the best available frequency. Any of the 2000 Series’ 10 channels may be used together without any frequency coordination problems or group selection issues. The 2000 Series also incorporates Audio-Technica’s Tone Lock squelch plus an easy-to-read LCD information display. Features Serious advances in affordable professional wireless Clear sound quality & rock-solid, dependable performance Automatic frequency scanning 10 compatible user-switchable channels in one of two UHF frequency ranges Antenna power available for powered antennas & other in-line RF devices True Diversity operation selects the better signal from the two receiver sections, reducing dropouts Tone Lock tone squelch system fights interference Rugged metal half-rack receiver with soft-touch controls & LCD display Balanced XLR & unbalanced 1/4” output jacks enable use with a wide variety of audio gear Switchable transmitter power output with high & low settings offered

Includes:: rack-mount kit & detachable UHF antennas Ground-lift switch helps eliminate audible hum caused by ground loops between the sound system & receiver ATW-T220a Handheld Microphone/ Transmitter features PRO 41 Capsule for maximum feedback rejection & consistent sound New charger (ATW-CHG2 ) available for ATW-T220a & ATW-T210a transmitters

...

The Audio-Technica Lavalier Microphone Clip AT8434 is a simple lavalier microphone clip that offers you the ability to perfectly position your Audio-Technica microphone. This unit is black & is designed to work with Audio-Technica case style M8. Perfect Microphone Positioning Place your microphone exactly where you need it with this convenient clip designed to work with Audio-Technica microphones. ...

The AT8646QM shock-mount plate effectively isolates mounted microphones from impact vibration & mechanical noise normally transmitted from the mounting surface. It is intended for use with microphones mounted on lecterns pulpits conference tables & similar surfaces. Designed especially for Uni Point¨ & Engineered Sound gooseneck microphones they may be used with other lightweight plug-in microphones with XLRM-type outputs. The AT8646QM can be mounted in any smooth horizontal surface. All connections exit the bottom of the mount & are via screw terminal strips. Weight 64 g.

Dimensions W x D x H78.0 mm (3.07) wide 78.0 mm (3.07) deep mm.

...

The Audio-Technica AT829c W is a cardioid lavalier microphone terminated with a locking 4-pin connector. The microphone is intended for use with A-T Uni Pak body-pack wireless transmitters. The microphone cable measures 55" in length (1.4 m). Miniature unobtrusive profile Cardioid polar pattern rejects off-axis signal & feedback 55" cable terminated for use with Uni Pak transmitters Transducer
- Condenser Polar Pattern
- Cardioid Cable
- 55" (1.4m), terminated for use with Uni Pak transmitters


...

This double-gooseneck cardioid condenser microphone with integral power module & 5/8"-27 adapter-mount is ideal for boardroom, school, government, house of worship & other installed applications. Featuring a wide-range condenser element with low-mass diaphragm for superior performance, the microphone's self-contained electronics eliminate need for external power modules. Available in two lengths: 15.79" (PRO47TL) & 12.40" (PRO47T). Features Wide-range condenser element with low-mass diaphragm for superior performance Self-contained electronics eliminate need for external power modules Flat, smooth frequency response Quiet, fixed-placement, long-life gooseneck Direct mounts to any 5/8"-27 st&, or to included threaded mounting stud 9.8' (3.0 m) cable permanently attached between microphone & XLRM-type connector Overall length of 15.79" (401.0 mm) Also available in a 12.40" (315.0 mm)-long version as PRO47T ...

This low-profile cardioid condenser boundary microphone is recommended for unobtrusive table-, ceiling-, or panel-mount applications in high-quality sound reinforcement, professional recording & teleconferencing. Designed for permanent installation, the microphone is equipped with a self-contained power module with an XLRM-type output connector, eliminating the need for an external power module. Protected by a rugged all-metal case with a two-layer steel mesh grille, the microphone has a cardioid pattern for enhanced gain before feedback & enhanced signal-to-noise ratio. It is available in two
Colours: black (ES947) & white (ES947W). Features Designed for surface-mount applications such as high-quality sound reinforcement, professional recording & teleconferencing Low-profile element provides uniform cardioid polar pattern with 120 degrees acceptance angle Mounts unobtrusively in table-tops, ceilings & wall panels Self-contained power module with XLRM-type output connector Rugged all-metal case with a two-layer steel mesh grille Isolators provide mechanical dampening of mounting-surface vibration Requires 11V to 52V DC phantom power Uni Guard RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI) Available in two
Colours: black (ES947) & white (ES947W) Ro HS compliant-free from all substances specified in the EU directive on hazardous substances

...

This low-profile cardioid condenser boundary microphone is recommended for unobtrusive table-, ceiling-, or panel-mount applications in high-quality sound reinforcement, professional recording & teleconferencing. Designed for permanent installation, the microphone is equipped with a self-contained power module with an XLRM-type output connector, eliminating the need for an external power module. Protected by a rugged all-metal case with a two-layer steel mesh grille, the microphone has a cardioid pattern for enhanced gain before feedback & enhanced signal-to-noise ratio. It is available in two
Colours: black (ES947) & white (ES947W). Features Designed for surface-mount applications such as high-quality sound reinforcement, professional recording & teleconferencing Low-profile element provides uniform cardioid polar pattern with 120 degrees acceptance angle Mounts unobtrusively in table-tops, ceilings & wall panels Self-contained power module with XLRM-type output connector Rugged all-metal case with a two-layer steel mesh grille Isolators provide mechanical dampening of mounting-surface vibration Requires 11V to 52V DC phantom power Uni Guard RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI) Available in two
Colours: black (ES947) & white (ES947W) Ro HS compliant—free from all substances specified in the EU directive on hazardous substances

...

The PRO49QL quick-mount double-gooseneck cardioid condenser microphone is designed to plug into any standard XLRF-type surface or cable connector. With a flat, smooth frequency response & self-contained electronics, this mic features a quiet, fixed-placement, long-life gooseneck & wide-range condenser element with low-mass diaphragm for superior performance. Available in two lengths: 13.07" (PRO49Q); 16.46" (PRO49QL). Wide-range condenser element with low-mass diaphragm for superior performance Self-contained electronics eliminate need for external power modules Flat, smooth frequency response Quiet, fixed-placement long-life gooseneck Plugs into any standard XLRF-type surface or cable connector Overall length of 16.46" (418.0 mm) Element: Fixed-charge back plate, permanently polarized condenser Polar Pattern: Cardioid Frequency Response: 70-16, 000 Hz Open Circuit Sensitivity: -37 d B (14.1 m V) re 1V at 1 Pa Impedance: 100 ohms Maximum Input Sound Level: 134 d B SPL, 1 k Hz at 1% T.H.D. Dynamic Range: 106 d B, 1 k Hz at Max SPL Signal to Noise Ratio: 66 d B, 1 k Hz at 1 Pa Phantom Power Requiremens: 9-52V DC, 2 m A typical Weight: 3.0 oz (84 g) Dimensions: 16.46" (418.0 mm) long, 0.47" (12.0 mm) head diameter, 0.74" (18.9 mm) base diameter Output Connector: Integral 3-pin XLRM-type ...
