Next-Gen Firewall for SMBs\n The Zyxel Zy WALL ATP100/200/500/800 is an Advanced Threat Protection Firewall Series dedicated for small & medium businesses, empowered by cloud intelligence to level up network protection, especially in tackling unknown threats. The Zy WALL ATP Firewall Series not only supports all Zyxel security service such as Web security, Application Security, Malware Blocker, Reputation Filter, etc., but also sandboxing & Secu Reporter, &, last but not least, an infographic dashboard, delivering high performance & ensuring comprehensive protection as a self-evolving solution.\n\n class="generic"> Technical details Concurrent users 10 user (s) Concurrent connections 300000 Heat dissipation 42.65 BTU/h Data transmission Maximum data transfer rate 1000 Mbit/s Firewall throughput 1000 Mbit/s VPN throughput 300 Mbit/s Performance Mean time between failures (MTBF)989810.8 h Concurrent users 10 user (s) Concurrent connections 300000 Certification FCC Part 15 (Class B), CE (Class B), RCM (Class B), BSMI, LVDHeat dissipation 42.65 BTU/h Networking VPN tunnels quantity 40 Security VPN support IKEv 2, IPSec, SSL, L2TP/IPSec Ports & interfaces SFP module slots quantity 1 Connectivity technology Wired WAN connection Ethernet (RJ-45) Ethernet LAN (RJ-45) ports 4 Ethernet LAN data rates 10, 100, 1000 Mbit/s Console port RJ-45 Number of console ports 1 Certificates Certification FCC Part 15 (Class B), CE (Class B), RCM (Class B), BSMI, LVDEndurance Mean time between failures (MTBF)989810.8 h Power Power consumption (max)12.5 WOperational conditions Operating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-30
- 70 &176;COperating relative humidity (H-H)10
- 90% Storage relative humidity (H-H)10
- 90% Weight & dimensions Dimensions (Wx Dx H)216 x 143 x 33 mm Weight 850 g Packaging data Package width 284 mm Package height 190 mm Package depth 100 mm Package weight 1.4kg Packaging content Cables included LAN (RJ-45), RS-232\n\n\n\nhttp://objects.icecat.biz/objects/mmo_75660224_1574413871_7488_30656.pdf



...

Advanced Protection for Evolving Threat\n Cyber attacks of today are multiplying in large volumes along with more diverse forms of threats including " crypto jacking, malware, surging ransomware variants, & many more! Zy WALL ATP Firewall is empowered with smart cloud intelligence giving seamless protection against all those Advanced Persistent Threats, achieving ultimate in-depth defense of future unknown attacks.\n\n Block it. Learn it. Prevent it.\n\n Block Unknown Threats\n Multi-Layer Protection from default bundled security service can block malicious & suspicious traffic, ensuring wellbeing of your business network.\n\n Learn Unknown Threats\n Cloud Intelligence identifies every incoming threats so the Cloud Threat Database keeps learning, evolving, & growing stronger after each attack.\n\n Prevent Unknown Threats\n Cloud Intelligence extracts top ranked threat information & gives all ATP firewalls constant updates. This global sharing synergy empowers ATP firewalls to prevent all hidden threats.\n\n Cloud Machine Learning\n Zyxel Cloud intelligence identifies unknown files from all ATP Firewalls, accumulates results in database & gives all ATP a daily update, effectively turning every new threat into a new piece of intelligence & continuously grow with self-evolving security ecosystem that adapt to new advanced attacks at all times.\n\n Sandboxing\n Sandboxing is an isolated cloud environment that contains unknown files to identify new malware types that conventional static security mechanism cannot detect, ensuring protection against zero-day attacks.\n\n Reporting & Analytics\n ATP Firewall dashboard gives user-friendly infographic traffic summary & threat statistics. Users can also utilize Secu Reporter for further comprehensive threat analysis.\n\n ATP Dashboard\n ATP Firewall dashboard displays traffic summary since-reboot & in-depth seven-day threat statistics with hit counts. Feature Feature Value Firewall throughput 2000 Mbit/s VPN throughput 500 Mbit/s Heat dissipation 45.38 BTU/h Mean time between failures (MTBF)529688.2 h Certification FCC Part 15 (Class B), CE EMC (Class B), C-Tick (Class B), BSMI, LVD (EN60950-1), BSMINumber of VLANs 16 Active TCP connections (max)600000 Content filtering 1 Connectivity technology Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2 Ethernet LAN (RJ-45) ports 4 Ethernet LAN data rates 10, 100, 1000 Mbit/s WAN connection Ethernet (RJ-45)SFP module slots quantity 1 Rack mounting Y Form factor Desktop Built-in fan N Input current 2.5 APower consumption (max)13.3 WOperating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-30
- 70 &176;COperating relative humidity (H-H)10
- 90% Storage relative humidity (H-H)10
- 90% Dimensions (Wx Dx H)272 x 187 x 36 mm Weight 1.4kg Package width 427 mm Package height 73 mm Package depth 247 mm Package weight 2.42kg



...

Advanced Protection for Evolving Threat\n Cyber attacks of today are multiplying in large volumes along with more diverse forms of threats including " crypto jacking, malware, surging ransomware variants, & many more! Zy WALL ATP Firewall is empowered with smart cloud intelligence giving seamless protection against all those Advanced Persistent Threats, achieving ultimate in-depth defense of future unknown attacks.\n\n Block it. Learn it. Prevent it.\n\n Block Unknown Threats\n Multi-Layer Protection from default bundled security service can block malicious & suspicious traffic, ensuring wellbeing of your business network.\n\n Learn Unknown Threats\n Cloud Intelligence identifies every incoming threats so the Cloud Threat Database keeps learning, evolving, & growing stronger after each attack.\n\n Prevent Unknown Threats\n Cloud Intelligence extracts top ranked threat information & gives all ATP firewalls constant updates. This global sharing synergy empowers ATP firewalls to prevent all hidden threats.\n\n Cloud Machine Learning\n Zyxel Cloud intelligence identifies unknown files from all ATP Firewalls, accumulates results in database & gives all ATP a daily update, effectively turning every new threat into a new piece of intelligence & continuously grow with self-evolving security ecosystem that adapt to new advanced attacks at all times.\n\n Sandboxing\n Sandboxing is an isolated cloud environment that contains unknown files to identify new malware types that conventional static security mechanism cannot detect, ensuring protection against zero-day attacks.\n\n Reporting & Analytics\n ATP Firewall dashboard gives user-friendly infographic traffic summary & threat statistics. Users can also utilize Secu Reporter for further comprehensive threat analysis.\n\n ATP Dashboard\n ATP Firewall dashboard displays traffic summary since-reboot & in-depth seven-day threat statistics with hit counts. Feature Feature Value Firewall throughput 2000 Mbit/s VPN throughput 500 Mbit/s Heat dissipation 45.38 BTU/h Mean time between failures (MTBF)529688.2 h Certification FCC Part 15 (Class B), CE EMC (Class B), C-Tick (Class B), BSMI, LVD (EN60950-1), BSMINumber of VLANs 16 Active TCP connections (max)600000 Content filtering 1 Connectivity technology Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2 Ethernet LAN (RJ-45) ports 4 Ethernet LAN data rates 10, 100, 1000 Mbit/s WAN connection Ethernet (RJ-45)SFP module slots quantity 1 Rack mounting Y Form factor Desktop Built-in fan N Input current 2.5 APower consumption (max)13.3 WOperating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-30
- 70 &176;COperating relative humidity (H-H)10
- 90% Storage relative humidity (H-H)10
- 90% Dimensions (Wx Dx H)272 x 187 x 36 mm Weight 1.4kg Package width 427 mm Package height 73 mm Package depth 247 mm Package weight 2.42kg



...

Fast, reliable 11n technology for future-proof access networks Undoubtedly, mobility is the key to improve employee productivity & efficiency in all modern businesses as more & more bandwidth-consuming Web applications & mobile devices are involved in daily operations today. Beyond mobility, the ratified 11n technology allows faster (up to 300 Mbps) data rates & better network reliability that supports more users to accommodate business needs. As performance of 11n Wireless LAN has exceeded the speed of basic wired Ethernet, it turns out to be a more cost-effective option for businesses building or expanding access networks over investing on a large number of wired LAN switches. No extra cost converting standalone AP into management WLAN architecture The Zy XEL NWA3560-N is a "hybrid" AP that acts as a standalone AP infrastructure or a centralized management structure with controller mode & managed AP. The hybrid feature has full flexibility to deploy secure & reliable WLAN networks. In the initial phase constructing a WLAN, the NWA3560-N can be configured as a fully functional standalone AP; with more APs installed, the NWA3560-N can be set to the WLAN controller mode to manage the rest of APs. The scalability is able to manage up to 24 APs & it is also suitable for companies with a staff of 300-500. Effortless deployment with Po E, auto-discovery & auto-provisioning In order to eliminate complicated configuration & installation processes, the NWA3560-N AP provides a variety of features to allow quick network deployments. All ranges of NWA3560-N APs comes with standard 802.3af or 802.3at Po E support that enables the APs to utilize the existing cabling & receive power from Po E switches. Once installed & powered up, the NWA3560-N AP automatically discovers the controller AP & join the management group; & secure automatic provisioning is established between the controller AP & the managed APs effortlessly. SMB networks with best security, resilience & effective features Small & medium-sized businesses usually have tighter equipment budgets & limited IT staff. With the NWA3560-N, the SMBs can take advantage of the flexibility to meet growing needs while building a future-proof office network. More than just WPA/WPA2 personal & enterprise certification, the NWA3560-N also features an embedded RADIUS server that saves expense & maintenance efforts by eliminating standalone RADIUS servers; the NWA3560-N also supports device HA to provide stable & reliable connections for non-stop productivity. All indoor units of the NWA3560-N adopt LSOH material for plenum spaces; in case of fire, the material would produce the least amount of toxic or corrosive smoke to avoid harming people around. With all the considerate design along with business AP features such as multiple SSID, the NWA3560-N AP is the smart & pragmatic choice for growing SMBs. ...

To maintain our competitive advantage & market leadership, Zy XEL has taken across-the-board reengineering initiatives such as a customer-centric business model redefinition, sales & support efficiency streamlining, modernization of product lifecycle management processes, & the implementation of our &156;service excellence&157; mechanism. Zy XEL is committed to staying ahead of the networking trends & providing the best solutions & services for our customers.\n\n Technological Expertise\n Zy XEL prides itself on products & solutions built with leading-edge technology advancements. Our uncompromising investment in R&D has enabled us to maximize our expertise of advanced technologies & develop application-specific requirements for customized products.\n\n Global Experience\n With 20 years of experience with the world&153;s major telecommunication & service providers & over 400, 000 enterprise customers, our global experience & success allows us to deliver benefits such as shorter time-to-market directly adoptable by customers.\n\n Product Performance\n High quality & reliability are two essential criteria driving all of our products. Green is the fundamental protocol embedded into not only our products but also culture & discipline.\n\n Local-touch Services\n In partnership with our worldwide business & service partners, our customers talk to knowledgeable staff, not machines or untrained contractors. Sophisticated resources & human services are offered throughout all our contact points. Feature Feature Value Software type Upgrade Compatibility NXC2500 ...

Connect Multiple Devices with High Speed & Reliability\n The Zy XEL ES-105A v 3, a five port desktop switch with plug-&-play design, can easily connect devices including PCs, network storage devices & print servers to your home network. The ES-105A v 3 offers advanced High Priority ports to boost performance & user experience for Internet surfing, online gaming, multimedia or any application you prefer with prioritized bandwidth.\n\n Compliant with the IEEE 802.3az Energy Efficient Ethernet standard, the ES-105A v 3 provides power-saving benefits without compromising performance.\n\n Compact, sturdy design with wall-mount alternative\n The Zy XEL ES-105A v 3 fits any working environment. The stylish, compact metal housing with wall-mount installation design provides more flexibility for wired home networks. The affordable, reliable series comes with five ports to meet home network expansion needs.\n\n Optimal bandwidth for media traffics through high priority ports\n The Zy XEL ES-105A v 3 v 3 comes with two high priority ports. With the port-based Qo S feature, the ES-105A v 3 provides considerably enhanced download quality. Users can experience better performance for Internet surfing, online gaming & multimedia streaming through prioritized bandwidth settings. The ES-105A v 3 features increased buffer memory to maintain smooth network transmission while the switch is handling heavy loads.\n\n Easy to connect multiple devices\n The Zy XEL ES-105A v 3 is designed to boost your home network with better performance & efficiency. With the N-way auto-negotiation function, the ES-105A v 3 connects to network devices with the highest possible speed & activates full-duplex mode automatically, while the store-&-forward service offers low latency & error-free packet delivery.\n\n The plug-&-play design means that you can easily connect devices such as PCs, network storage servers & print servers to the home network without manual configuration.\n\n To protect the network from broadcast storms, the ES-105A v 3 can immediately locate a port experiencing loop errors & then blink the appropriate LED light. Feature Feature Value Switch type Unmanaged Quality of Service (Qo S) support Y Basic switching RJ-45 Ethernet ports quantity 5 Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100) Power connector DC-in jack Networking standards IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x 10G support N Full duplex Y Flow control support Y Auto MDI/MDI-XYVLAN support YMAC address table 1000 entries Switching capacity 1 Gbit/s Store-&-forward Y Authentication Auto VLAN, MAC-based authentication Stackable N Product colour Silver Reset button YLED indicators Y Certification FCC, CE, C-Tick, BSMIBuffer size 56 KBAC input voltage 100
- 240 VAC input frequency 50
- 60 Hz Output voltage 5 VOutput current 1 APower consumption (typical)0.92 WOperating temperature (T-T)0
- 50 &176;CStorage temperature (T-T)-40
- 70 &176;COperating relative humidity (H-H)10
- 90% Storage relative humidity (H-H)10
- 95% Width 121 mm Depth 75 mm Height 26 mm Weight 248 g User guide YAC adapter included Y Package width 127 mm Package depth 82 mm Package height 95 mm Package weight 373.5 g





...

Connect Multiple Devices with High Speed & Reliability The Zy XEL ES-105A v 2, a five port desktop switch with plug-&-play design, can easily connect devices including PCs, network storage devices & print servers to your home network. The ES-105A v 2 offers advanced High Priority ports to boost performance & user experience for Internet surfing, online gaming, multimedia or any application you prefer with prioritized bandwidth. Compliant with the IEEE 802.3az Energy Efficient Ethernet standard, the ES-105A v 2 provides power-saving benefits without compromising performance. Easy to connect multiple devices The Zy XEL ES-105A v 2 is designed to boost your home network with better performance & efficiency. With the N-way auto-negotiation function, the ES-105A v 2 connects to network devices with the highest possible speed & activates full-duplex mode automatically, while the store-&-forward service offers low latency & error-free packet delivery. The plug-&-play design means that you can easily connect devices such as PCs, network storage servers & print servers to the home network without manual configuration. To protect the network from broadcast storms, the ES-105A v 2 can immediately locate a port experiencing loop errors & then blink the appropriate LED light. Optimal bandwidth for media traffics through High Priority ports The Zy XEL ES-105A v 2 comes with two high priority ports. With the port-based Qo S feature, the ES-105A v 2 provides considerably enhanced download quality. Users can experience better performance for Internet surfing, online gaming & multimedia streaming through prioritized bandwidth settings. The ES-105A v 2 features increased buffer memory to maintain smooth network transmission while the switch is handling heavy loads. ...

Connect Multiple Devices with High Speed & Reliability The Zy XEL ES-108A v 2, a eight port desktop switch with plug-&-play design, can easily connect devices including PCs, network storage devices & print servers to your home network. The ES-108A v 2 offers advanced High Priority ports to boost performance & user experience for Internet surfing, online gaming, multimedia or any application you prefer with prioritized bandwidth. Compliant with the IEEE 802.3az Energy Efficient Ethernet standard, the ES-108A v 2 provides power-saving benefits without compromising performance. Easy to connect multiple devices The Zy XEL ES-108A v 2 is designed to boost your home network with better performance & efficiency. With the N-way auto-negotiation function, the ES-108A v 2 connects to network devices with the highest possible speed & activates full-duplex mode automatically, while the store-&-forward service offers low latency & error-free packet delivery. The plug-&-play design means that you can easily connect devices such as PCs, network storage servers & print servers to the home network without manual configuration. To protect the network from broadcast storms, the ES-108A v 2 can immediately locate a port experiencing loop errors & then blink the appropriate LED light. Optimal bandwidth for media traffics through High Priority ports The Zy XEL ES-108A v 2 comes with three high priority ports. With the port-based Qo S feature, the ES-108A v 2 provides considerably enhanced download quality. Users can experience better performance for Internet surfing, online gaming & multimedia streaming through prioritized bandwidth settings. The ES-108A v 2 features increased buffer memory to maintain smooth network transmission while the switch is handling heavy loads. ...

Robust Design Zy XEL's ES-1552 Extra Smart Switch comes with 52 Fast Ethernet copper ports plus four Gigabit uplinks (two 1000 Base-T ports & two SFP slots) that power the non-blocking connection power to SMB/SB networks, & the multi-function design fits into copper or fiber networks easily. By utilising 4G uplinks & port aggregation, bandwidth on critical paths can be expanded flexibly by merging multiple traffic pipelines into one to dramatically improve network stability. Extra Smart™ Evolution While many legacy web smart switches improve manageability they can often be complex to use. For most small businesses, inadequate IT expertise & complicated configurations are the major pains to overcome. Powered by a new hardware platform with smart ACL technology; " Auto Do S Attack Prevention" & " Auto Vo IP" features provides hassle-free operation. In addition, Zy XEL ES-1552 comes with a streamlined intuitive Web-GUI for features such as 802.1Q VLAN, 802.1p traffic priority & static port aggregation. Extra Secure
- Auto Do S Attack Prevention Security is a top priority for SMB/SB networks. Equipped with Auto Do S Attack Prevention, the ES-1552 Extra Smart Switch is capable of fighting against ubiquitous Do S attacks. A few mouse clicks is all it takes to initiate the protection & complete the once-complicated ACL setting, reducing the time required with switch setup & management. ES-1552 supports 802.1Q VLAN for traffic isolation, as well as static MAC forwarding & dynamic ARP to establish a robust protected network. Auto Vo IP Telephony without the Configuration headaches Vo IP is becoming more popular within businesses, but it usually requires IT expertise to optimise a network for Vo IP applications. The " Auto Vo IP" feature of the ES-1552 Extra Smart Switch can identify Vo IP packet patterns & approve the highest priority to Vo IP-friendly communications. Auto Vo IP offers IP telephony without the configuration headaches. Features like four priority queues & a WFQ scheduling algorithm allows users to optimise network bandwidth usage & quality of services. In terms of bandwidth management, users can choose from several options & pick the most appropriate.
...

The Zy XEL Switch ES1100 Series is designed for SMBs to boost business network performance & efficiency. It enables businesses to enter the world of networking connectivity without the need for complicated management. The Series provides not only plug-&-play simplicity for high-bandwidth connectivity but also the N-way Auto-negotiation functions to connect its network counterparts with the highest possible data speed as well as to activate the duplex mode automatically. The ES1100 Series is Ideal for typical noise-sensitive office environments for its superior energy efficiency & Ethernet connectivity. Green networking The environment-aware ES1100 Series offers 10/100M Ethernet speeds critical to the next-generation network applications, & it also provides power-saving functions to reduce energy consumption for lower operating cost.
- Traffic detection ? IEEE Energy Efficient Ethernet (EEE) compliance (ES1100-16/24/24E)
- The feature automatically detects network traffics & adjusts power consumption accordingly in a dynamic manner. It reduces power consumption during the low link utilization periods.
- Inactive link detection
- The power usage adjustment feature automatically reduces power usage when any shut down network device or inactive link is detected. That is, power consumption of the Series can be adjusted according to the link status or the number of active network devices when possible.
- Cable length detection
- The devices equipped with this green feature can automatically detect the length of connected Ethernet cables & adjust power usage accordingly. The shorter the cable length, the less power it consumes. Best-in-class solution for Fast Ethernet environments The ES1100 Series comprises of unmanaged Fast Ethernet switches that provide an inexpensive solution for Fast Ethernet connections to the desktop with outstanding performance. The ES1100 Series is an ideal solution for bandwidth-intensive applications such as high-resolution photo delivery, video/audio streaming & downloading as well as server farm connections. Better performance & efficiency The full ES1100 range of 8/16/24-port Fast Ethernet switches has been designed to boost your network with better performance & efficiency. With the N-Way Auto-negotiation function, the ES1100 Series connects the network counterparts with the highest possible data speed & activates the duplex mode automatically. Transmission reliability Unlike shared 10/100 Mbps networks, the ES1100 Series eliminates congestion by providing dedicated bandwidth; & its duplex mode doubles the effective bandwidth by enabling two-way communications. The store-&-forward service brings low latency & error-free packet delivering, while the plug-&-play & multiple network protocol compatibility of the ES1100 Series makes installation & management easier & faster than ever. Desktop size with flexible rackmount & wallmount design fits your working environments With embedded rackmount brackets, the desktop size devices can fits into your rack environment easily. No matter how intense your network demand is, the ES1100 Series supports your needs with an affordable & reliable network solution designed especially for small businesses. Freedom of installation by Po E (ES1100-8P/16P) The ES1100-8P & ES1100-16P support IEEE 802.3af Po E to ease installation in challenging spaces such as ceiling or wall mounting. It works with devices such as WLAN APs, Vo IP phones & IP surveillance cameras that can be powered by Ethernet connectivity over CAT-5 cables less than 100 meters (300 feet) in length; so there is no need for extra power adapters, & powering the devices installed on the ceiling is no longer a headache. This feature helps enterprises to reduce installation time & cost when many new devices are needed.





...
