Featuring an AMD Ryzen&132;&162; V1000 series V1500B quad-core processor that delivers great system performance with up to quad-core / 8 threads & Turbo Core up to 2.2 GHz. The TS-473A features two 2.5 Gb E RJ45 ports & two PCIe Gen 3 slots for you to flexibly deploy 5 Gb E/10 Gb E networks. Two M.2 NVMe SSD slots for Qtier Technology & SSD Caching enable constant storage optimization. The TS-473A supports QTS & Qu TS hero, allowing users to flexibly switch operating system based on their requirements. High performance AMD Ryzen&132;&162; processor The TS-473A is powered by an AMD Ryzen&132;&162; V1000 series V1500 quad-core 2.2 GHz processor with up to 64GB RAM (ECC memory is supported) & features USB (Universal Serial Bus) 3.2 Gen 2 ports for speeds up to 10 Gb/s. The TS-473A also provides one USB (Universal Serial Bus) Type-C port for supporting more devices to transfer large media files across devices, providing you with a more efficient workflow. Transform your network with a wallet-friendly 2.5 Gb E switch Upgrading your network shouldn&153;t break the bank, & 2.5 Gb E connectivity provides immediately noticeable improvements compared to standard 1 Gb E. QNAP offers 2.5 Gb E switches that supports Multi-Gigabit NBASE-T&132;&162; & means that you can use existing CAT5e cables to connect multiple computers & NAS, assisting organizations in implementing high-speed, secure & scalable network environments without going over budget. Switch operating systems for optimal data integrity & reliability The TS-473A also supports Qu TS hero
- QNAP&153;s ZFS-based NAS operating system. Providing end-to-end data integrity, data reduction (inline data deduplication, compression & compaction), & much more, Qu TS hero uses additional system resources to ensure an optimal environment for protecting business data. Obtain performance benefits from M.2 SSD caching The TS-473A features 2 M.2 NVMe SSD slots for you to enjoy SSD caching or Qtier auto tiering Technology Improve random data access speeds with an SSD cache SSD caches accelerate IOPS performance & reduce latency for storage volumes. They are perfect for IOPS-demanding applications (including databases & virtualization) & can significantly improve overall workflows. Maximize the value of SSDs with Qtier Technology Qtier&132;&162; Technology empowers the TS-473A with auto tiering that helps continuously optimize storage efficiency by automatically moving data between M.2 SSDs, 2.5-inch SSDs, & high-capacity HDDs based on the data's access frequency. Qtier&132;&162; 2.0 features IO-awareness that empowers SSD-tiered storage with a cache-like reserved space to handle burst I/O in real time, greatly maximizing the advantages of SSDs. Upgrade to 10 Gb E & abundant capability with PCIe expansion The TS-473A features two PCIe Gen 3 x 4 slots that allows for various expansion cards for expanding application potential. Easy & Secure File Management File Station allows direct management of files stored on the TS-473A & in the cloud. Users can easily upload files from their PC, drag/drop files between folders, rename/delete files, & configure file/folder permissions to prevent unauthorized access. Microsoft Office Online can also be used to directly view/edit Microsoft Office documents stored on the TS-473A. Confidential/sensitive data can be encrypted to add extra security. Install a graphics card for GPU-accelerated computing Graphics cards are optimized for graphical calculations & transformations, but require significantly more power than other hardware. The TS-473A features PCIe slots to support low-profile graphics cards that do not need power cables, including NVIDIA&174; Ge Force&174; GTX1650 graphics cards to boost performance of applications such as video editing, 4K UHD transcoding, imaging processing in QTS & performance of virtual machines via GPU passthrough. Build an affordable Fibre Channel SAN environment Common Fibre Channel Storage Area Networks (SAN) devices are often costly. By installing a QNAP 16 Gb Fibre Channel card (QXP-16G2FC 16 Gb) in the TS-473A, you can set a Fibre Channel Target using the i SCSI & Fibre Channel app. Moreover, the LUN Masking & Port Binding features provide an additional layer of data security. High-speed 2.5 Gb E VM Backup Solution With Hyper Data Protector, the TS-473A becomes an agentless backup tool for unlimited VMware&174; v Sphere & Microsoft&174; Hyper-V VM backup. Hyper Data Protector features incremental backup, global deduplication, backup scheduling & recovery compression. With 2.5 Gb E connectivity, backup & restoration times are greatly reduced, providing a cost-effective solution for disaster recovery. QNAP Backup & Data Protection Solutions: Complete Apps & Utilities at Your Fingertips QNAP provides comprehensive solutions for virtually all data protection requirements. Discover an array of apps/utilities to help you back up various sources, including:
- Boxafe " Google Workspace (G Suite) / Microsoft 365 Saa S backup
- Hyper Data Protector " VMware v Sphere/ Microsoft Hyper-V VM backup
- Hybrid Backup Sync " QNAP NAS/file server/mac OS backup
- Net Bak Replicator " Windows backup
- Snapshot " QNAP NAS protection/backup Flexible & economical storage expansion QNAP provides easy storage capacity expansion solutions. Here are several ways to expand your TS-473A storage as needed to accommodate data & business growth. Upgrade RAID Capacity Hot-swap lower-capacity drives with larger-capacity drives to expand your NAS capacity so it can grow with your business. Attach Expansion Enclosures Connect two TR-004 RAID expansion enclosures, or one 8-bay TL-D800S SATA 6 Gb/s JBOD, & use the QTS Storage & Snapshots Manager to easily handle NAS capacity expansion. Migrate to a New NAS Install your NAS hard drives into a larger QNAP NAS & retain all your existing data & configurations.\n\n\n\n Storage Total installed storage capacity 16 TBOnline RAID migration Yes Online RAID expansion Yes Storage drives installed Yes Installed storage drive type HDDNumber of storage drives installed 4 Supported storage drive types HDD & SSDNumber of storage drives supported 4 Storage drive interface Serial ATA II, Serial ATA IIIStorage drive capacity 4000 GBStorage drive size 2.5/3.5" Hot-swap drive bays Yes RAID support Yes RAID levels 0, 1, 5, 6, 10, JBODSupported storage drive interfaces M.2, Serial ATA II, Serial ATA IIIStorage drive sizes supported 2.5, 3.5, M.2 Number of M.2 (M & B) slots 2RAID rebuild Yes Number of system drives installed 1 System drive capacity 5 GBProcessor Processor manufacturer AMDProcessor threads 8 Processor frequency 2.2 GHz Processor family Ryzen Embedded Processor model V1500 B Processor cores 4 Memory Internal memory type DDR4 Internal memory 8 GBMaximum RAM supported 64 GBMemory slots 2 Flash memory 5000 MBMemory form factor SO-DIMMNetwork Dynamic DNS (DDNS) Yes Ethernet LANYes Ethernet LAN data rates 100, 1000, 2500 Mbit/s Wake-on-LAN ready Yes Jumbo frames support Yes DHCP server Yes WLAN adapter supported Yes Ports & interfaces USB port Yes PCI Express x 4 (Gen 3.x) slots 2 Ethernet LAN (RJ-45) ports 2USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 3 Hard drive RAID support Yes RAID levels 0, 1, 5, 6, 10, JBODDesign Fan diameter 26 cm Cooling type Active Fan diameter 12 cm Drive bay locking Yes Product colour Black Number of fans 2 fan (s)LED indicators Yes Chassis type Tower Technical details Type NASDevice class Small & Medium Business Backup function Yes Backup features Cloud, USB (Universal Serial Bus) drive, i SCSI LUNProduct colour Black Noise level 21.4 d BLED indicators Yes Chassis type Tower Buzzer Yes Number of fans 2 fan (s) Performance Built-in FTP server Yes S.M.A.R.T. support Yes Password authentication Yes Disk scan Yes Browser supported Mozilla Firefox, Microsoft Edge, Google Chrome, Apple Safari Remotely operated Yes Type NASDevice class Small & Medium Business Backup function Yes Backup features Cloud, USB (Universal Serial Bus) drive, i SCSI LUNOn/off switch Yes Windows operating systems supported Windows 10, Windows 7, Windows 8 Server operating systems supported Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 Mac operating systems supported Mac OS X 10.10 Yosemite Linux operating systems supported Yes Security algorithms 256-bit AES, FIPS 140-2, SSH, SSL/TLSReset button Yes Operating system installed QNAP Turbo System Noise level 21.4 d B Buzzer Yes Snapshot Yes USB copy function Yes Cooling Cooling type Active Fan diameter 12 cm Fan voltage 12 VNumber of fans 2 fan (s) Security Drive bay locking Yes Security algorithms 256-bit AES, FIPS 140-2, SSH, SSL/TLSSoftware Windows operating systems supported Windows 10, Windows 7, Windows 8 Server operating systems supported Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 Mac operating systems supported Mac OS X 10.10 Yosemite Linux operating systems supported Yes Operating system installed QNAP Turbo System Management features On/off switch Yes Reset button Yes Power Power consumption (HDD standby)19.576 WPower supply location Built-in Power supply unit (PSU) capacity 250 WFan voltage 12 VAC input voltage 100
- 240 VAC input frequency 50/60 Hz Power consumption (typical)29.792 WNumber of power supply units 1 Weight & dimensions Width 199.3 mm Depth 280.8 mm Height 188.2 mm Packaging content Number of screws 24 Cables included AC, LAN (RJ-45) Power cables quantity 1 System requirements Windows operating systems supported Windows 10, Windows 7, Windows 8 Server operating systems supported Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 Mac operating systems supported Mac OS X 10.10 Yosemite Linux operating systems supported Yes Operational conditions Storage temperature (T-T)-20
- 70 &176;CStorage relative humidity (H-H)5
- 95% Operating temperature (T-T)0
- 40 &176;COperating relative humidity (H-H)5
- 95% Packaging data Cables included AC, LAN (RJ-45)\n\n\n\n Datasheet: https://d 5bm 31en 4blvo.cloudfront.net/uploads/pdf/mmo_91030646_1617948532_5443_30948.pdf
