Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.
- 8+2+1 Phases Low RDS (on) MOSFETs
- Solid capacitors to improve transient response & minimize oscillation
- 8-pin Solid Pin CPU Power Connector Support for DDR4 XMP Up to 5333 M Hz & Beyond GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 5333 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard. GIGABYTE B660 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience triple bandwidth than the current PCIe 3.0 devices. To reach the high speed & maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance. Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface. Hybrid Cores Optimization With new Intel Hybrid technology, GIGABYTE exclusively creates two new " CPU Upgrade " in BIOS profiles to meet different users&153; scenarios by adjusting P-Core & E-Core activation & voltage policy. Exclusive Realtek 8118 Gaming LAN High Speed Gigabit LAN with Automatic Bandwidth Allocation Realtek 8118 LAN is a high performance & friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features & the fastest & smoothest Internet experience. WIFI 6E Advantage Spectrum congestion is huge problem in current WIFI environment nowadays because too many devices all use existing 2.4 G Hz & 5 G Hz spectrum, & it cause unreliable connection & slower speed. WIFI 6E is extended standard to WIFI 6, & it use dedicated 6 G Hz band that it provides not only brand new frequency to transfer data, but also spacious spectrum for future more devices. With WIFI 6E, users can enjoy faster connection & stronger signal than before. Connecting the Future
- USB (Universal Serial Bus) 3.2 Gen 2x 2 Type-C Featuring the USB (Universal Serial Bus) 3.2 Gen 2x 2 design which is doubled the performance than previous generation of USB (Universal Serial Bus) 3.2 Gen 2. It works up to 20 Gbps ultra-fast data transfer while connecting to USB (Universal Serial Bus) 3.2 compliant peripherals. Through the USB (Universal Serial Bus) Type-C connector, users can enjoy the flexibility of reversible connection to access & store massive amounts of data rapidly. HDMI 2.0 for 4K UHD Display & HDCP 2.2 supported HDMI 2.0, which is backwards compatible with HDMI 1.4, offers 18 Gb/s of bandwidth " nearly twice that of the previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), offering the best visual experience for viewers. High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level. Update the BIOS easily without installing the CPU, memory & graphics card. With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go! Solid Pin Power Connectors B660 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading. Solid Pin Power connector advantages
- Larger contact area for electricity
- More metal quantity to sustain higher power & generated heat
- Ultra durable & longer lifespan RGB FUSION 2.0 B660 motherboards feature RGB FUSION 2.0 to offer lighting effected options & customized settings with outstanding aesthetics, & able to let enthusiasts building a stylish & unique gaming PC. Refreshed BIOS The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system. * Photos are for reference only. Product features may vary by model. Easy Tune GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most. System Information Viewer GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n Internal I/ONumber of M.2 (M) slots 2 Thunderbolt headers 2USB 3.2 Gen 2 (3.1 Gen 2) connectors 1 Front panel connector Yes 12V power connector Yes Supported storage drive interfaces M.2, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 1TPM connector Yes Serial port headers 1S/PDIF out connector Yes Number of SATA III connectors 4 Number of chassis fan connectors 3 Front panel audio connector Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family Intel Motherboard chipset Intel B660 Serial port headers 1PC health monitoring CPU, Fan, Temperature, Voltage HDMI version 2.1 Motherboard form factor ATXComponent for PCAudio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660RAID levels 0, 1, 5, 10PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel Core i 5, Intel Core i 7, Intel Core i 9, Intel&174; Pentium&174; Maximum number of SMP processors 1 Processor socket LGA 1700 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMECCYes Non-ECCYes Supported memory clock speeds 2133, 2400, 2666, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4500, 4600, 4700, 4800, 4933, 5000, 5133, 5333 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, SATA IIIRAID levels 0, 1, 5, 10RAID support Yes Graphics Maximum resolution 4096 x 2160 pixels HDCPYes Rear panel I/O ports USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1 Display Port version 1.2USB 2.0 ports quantity 4 Wi Fi-AP antenna jack 2PS/2 ports quantity 1HDMI version 2.1HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1USB 3.2 Gen 2x 2 Type-C ports quantity 1 Network Ethernet LANYes Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Ethernet interface type Gigabit Ethernet Bluetooth Yes Bluetooth version 5.2 Top Wi-Fi standard Wi-Fi 6E (802.11ax)WLAN controller model RZ608 Features Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCExpansion slots Number of M.2 (M) slots 2PCI Express x 16 slots 2BIOSBIOS type UEFI AMIClear CMOS jumper Yes BIOS memory size 256 Mbit ACPI version 5.0 System Management BIOS (SMBIOS) version 2.7 Desktop Management Interface (DMI) version 2.7 Video Maximum resolution 4096 x 2160 pixels HDCPYes Software Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Drivers included Yes Weight & dimensions Width 305 mm Depth 244 mm Packaging content Drivers included Yes Cables included SATA\n\n\n\n






...

Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.
- 8+2+1 Phases Low RDS (on) MOSFETs
- Solid capacitors to improve transient response & minimize oscillation
- 8-pin Solid Pin CPU Power Connector Support for DDR4 XMP Up to 5333 M Hz & Beyond GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 5333 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard. GIGABYTE B660 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience triple bandwidth than the current PCIe 3.0 devices. To reach the high speed & maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance. Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface. Hybrid Cores Optimization With new Intel Hybrid technology, GIGABYTE exclusively creates two new " CPU Upgrade " in BIOS profiles to meet different users&153; scenarios by adjusting P-Core & E-Core activation & voltage policy. Exclusive Realtek 8118 Gaming LAN High Speed Gigabit LAN with Automatic Bandwidth Allocation Realtek 8118 LAN is a high performance & friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features & the fastest & smoothest Internet experience. Connecting the Future
- USB (Universal Serial Bus) 3.2 Gen 2x 2 Type-C Featuring the USB (Universal Serial Bus) 3.2 Gen 2x 2 design which is doubled the performance than previous generation of USB (Universal Serial Bus) 3.2 Gen 2. It works up to 20 Gbps ultra-fast data transfer while connecting to USB (Universal Serial Bus) 3.2 compliant peripherals. Through the USB (Universal Serial Bus) Type-C connector, users can enjoy the flexibility of reversible connection to access & store massive amounts of data rapidly. HDMI 2.0 for 4K UHD Display & HDCP 2.2 supported HDMI 2.0, which is backwards compatible with HDMI 1.4, offers 18 Gb/s of bandwidth " nearly twice that of the previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), offering the best visual experience for viewers. High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level. Q-Flash Plus Update the BIOS easily without installing the CPU, memory & graphics card. With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go! Solid Pin Power Connectors B660 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading. Solid Pin Power connector advantages
- Larger contact area for electricity
- More metal quantity to sustain higher power & generated heat
- Ultra durable & longer lifespan RGB FUSION 2.0 B660 motherboards feature RGB FUSION 2.0 to offer lighting effected options & customized settings with outstanding aesthetics, & able to let enthusiasts building a stylish & unique gaming PC. Refreshed BIOS The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system. * Photos are for reference only. Product features may vary by model. Easy Tune GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most. System Information Viewer GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n Internal I/ONumber of M.2 (M) slots 2USB 3.2 Gen 2 (3.1 Gen 2) connectors 1 Front panel connector Yes 12V power connector Yes Supported storage drive interfaces M.2, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 1TPM connector Yes Serial port headers 1S/PDIF out connector Yes Number of SATA III connectors 4 Number of chassis fan connectors 3 Front panel audio connector Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family Intel Motherboard chipset Intel B660 Serial port headers 1PC health monitoring CPU, Fan, Temperature, Voltage HDMI version 2.1 Motherboard form factor ATXComponent for PCAudio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660RAID levels 0, 1, 5, 10PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel Core i 5, Intel Core i 7, Intel Core i 9, Intel&174; Pentium&174; Maximum number of SMP processors 1 Processor socket LGA 1700 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMECCYes Non-ECCYes Supported memory clock speeds 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4500, 4600, 4700, 4800, 4933, 5000, 5133, 5333 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, SATA IIIRAID levels 0, 1, 5, 10RAID support Yes Graphics Maximum resolution 4096 x 2160 pixels HDCPYes Rear panel I/O ports USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1 Display Port version 1.2USB 2.0 ports quantity 4PS/2 ports quantity 1HDMI version 2.1HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1USB 3.2 Gen 2x 2 Type-C ports quantity 1 Network Ethernet LANYes Wi-Fi No Ethernet interface type Gigabit Ethernet Features Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCExpansion slots Number of M.2 (M) slots 2PCI Express x 16 slots 5BIOSBIOS type UEFI AMIBIOS memory size 256 Mbit ACPI version 5.0 System Management BIOS (SMBIOS) version 2.7 Desktop Management Interface (DMI) version 2.7 Video Maximum resolution 4096 x 2160 pixels HDCPYes Software Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Drivers included Yes Weight & dimensions Width 305 mm Depth 244 mm Packaging content Drivers included Yes Cables included SATA\n\n\n\n






...

UNPARALLELED PERFORMANCE\n With technology moving so fast, GIGABYTE still keep up with the latest trends & provide our customers with advanced features & latest technology. GIAGBYTE B660 Series motherboards come with upgraded power solution, latest storage standards & outstanding connectivity to enable optimize performance for gaming.\n\n Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n- 8+1+1 Phases Dr MOS\n- Solid capacitors to improve transient response & minimize oscillation\n- 8-pin Solid Pin CPU Power Connector\n\n GIGABYTE B660 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience twice bandwidth than the current PCIe 3.0 devices. To reach the high speed & maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance.\n\n Support for DDR4 XMP Up to 4400 M Hz & Beyond\n GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 4400 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE otherboard.\n\n Hybrid Cores Optimization\n With new Intel Hybrid technology, GIGABYTE exclusively creates two new " CPU Upgrade " in BIOS profiles to meet different users&153; scenarios by adjusting P-Core & E-Core activation & voltage policy.\n\n M.2 Thermal Guard\n With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling & bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.\n\n 3% Cooler by implementing&227;&227;&227;&227;&227;&227;&227;\n 2x copper PCB Design\n By adopting 2x copper on PCB inner layer, it lowers the components' temperature at least 3% by turning the PCB into a super thin PCB size copper heatsink to dissipate the heat from the components effectively, due to it&153;s high thermal conductivity & lower impedance.\n\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n NEXT GENERATION CONNECTIVITY\n GIGABYTE B660 Series Motherboards let you experience ultimate connection flexibility & blazing data-transfer speed with next generation network, storage, & WIFI connectivity.\n\n First adopter on 2.5 Gb E LAN onboard\n\n 2X Faster than ever\n- Adoption of 2.5G LAN provide up to 2.5 Gb E network connectivity, with at least 2 times faster transfer speeds compared to general 1 Gb E networking, perfectly designed for gamers with ultimate online gaming experience.\n- Support Multi-Gig (10/100/1000/2500 Mbps) RJ-45 Ethernet\n\n 802.11ax WIFI 6E\n Latest Wireless solution 802.11ax WIFI 6E with new dedicated 6 G Hz b&, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections & speeds up to 2.4 Gbps*. Moreover, Bluetooth 5 provides 4X range over BT 4.2 & with faster transmission.\n\n Benefit of WIFI 6E\n Dedicated spectrum in 6 G Hz band for less interference\n 5.5X throughput than 802.11ac 1x 1\n 4X better network capacity, no traffic jams especially in those dense area with lots of devices\n Network efficiency increase for better user experience\n\n Connecting the Future
- USB (Universal Serial Bus) Type-C\n The World's Next Universal Connector\n The USB (Universal Serial Bus) Type-C is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.2 Gen 2 support for 10 Gb/s transfer speed. Powered by the Intel USB (Universal Serial Bus) 3.2 Gen 2 controller, this little port provides the best USB (Universal Serial Bus) Type-C experience possible.\n\n High-End Audio Capacitors\n GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers.\n\n Audio Noise Guard\n GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level.\n\n DEFINITIVE AESTHETICS\n GIGABYTE motherboards bundle several useful & intuitive software to help users to control every aspect of motherboard & provide customizable lighting effect with outstanding aesthetics to fit your unique personality.\n\n RGB FUSION 2.0\n B660 motherboards feature RGB FUSION 2.0 to offer lighting effected options & customized settings with outstanding aesthetics, & able to let enthusiasts building a stylish & unique gaming PC.\n\n New User Interface\n All new EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan.\n My Favorites\n Add constantly used items into the favorite menu for quick access.\n Storage Information\n Show all kinds of storage information including SATA, PCIE & M.2 interface.\n Changelog\n List all changes before saving & exiting bios. Quickly review overall settings modification.\n Intuitive Load Line Curve\n Clearly show each loadline calibration setting in an intuitive curve graph.\n\n Easy Tune\n GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n ULTRA DURABLE\n GIGABYTE Ultra Durable features its product durability & high-quality manufacturing process. GIGABYTE motherboards use the best components & reinforce every slots to make each of them solid & durable.\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n Solid Pin Power Connectors\n B660 motherboards feature solid plated ATX 12V 8 pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n\n\n\n\n\n\n Model: B660 GAMING X AX DDR4\n\n\n\n Manual: https://d 5bm 31en 4blvo.cloudfront.net/uploads/pdf/mmo_96597934_1642596209_5529_24567.pdf\n\n\n\n
...

B660I AORUS PRO DDR4 PERFORMANCE UNLEASHED Rule supreme with the B660 AORUS gaming motherboards. The new king of gaming platform continues the legendary AORUS bloodline with the most robust power delivery & dominant thermal design, glorified with the complete memory overclocking technology to crown your PC with the best Alder Lake's performance in all its gaming glory. UNPARALLELED PERFORMANCE With technology moving so fast, GIGABYTE still keep up with the latest trends & provide our customers with advanced features & latest technology. GIGABYTE B660 Series motherboards come with upgraded power solution, latest storage standards & outstanding connectivity to enable optimize performance for gaming. To ensure maximum Turbo Boost & performance of Intel's new generation CPU, GIGABYTE B660 series equip the best VRM design ever built with the highest quality components. Support for DDR4 XMP Up to 5333 M Hz & Beyond AORUS is offering a tested & proven platform that ensures proper compatibility with profiles up to 5333 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their AORUS motherboard. PCIe 4.0 x 4 M2 AORUS motherboards offer the industry's best compatibility in terms of NVMe storage for users who demand high capacity & seek the best performance. Upgrade with the latest 2nd generation Gen 4 SSD, the performance is up to 7000MB/s which is up to 2x faster than PCIe 3.0 SSD. Hybrid Cores Optimization With new Intel Hybrid technology, GIGABYTE exclusively creates two new "CPU Upgrade" in BIOS profiles to meet different users&153; scenarios by adjusting P-Core & E-Core activation & voltage policy. 3% Cooler by implementing 2X copper PCB Design By adopting 2X copper on PCB inner layer, it lowers the components' temperature at least 3% by turning the PCB into a super thin PCB size copper heatsink to dissipate the heat from the components effectively, due to it's high thermal conductivity & lower impedance. Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface. CONNECTIVITY GIGABYTE B660 Series Motherboards let you experience ultimate connection flexibility & blazing data-transfer speed with next generation network, storage, & WIFI connectivity. First adopter on 2.5 Gb E LAN onboard 2X Faster than ever
- Adoption of 2.5G LAN provide up to 2.5 Gb E network connectivity, with at least 2X faster transfer speeds compared to general 1 Gb E networking, perfectly designed for gamers with ultimate online gaming experience.
- Support Multi-Gig (10/100/1000/2500 Mbps) RJ-45 Ethernet WIFI 6 802.11ax + BT 5 Module Wireless solution 802.11ax WIFI 6 with new dedicated 6 G Hz b&, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections & speeds up to 2.4 Gbps*. Moreover, Bluetooth 5 provides 4X range over BT 4.2 & with faster transmission. Benefit of WIFI 6
- 5.5X throughput than 802.11ac 1x 1
- 4X better network capacity, no traffic jams especially in those dense area with lots of devices
- Network efficiency increase for better user experience HDMI 2.0 for 4K UHD Display & HDCP 2.2 supported HDMI 2.0, which is backwards compatible with HDMI 1.4, offers 18 Gb/s of bandwidth " nearly twice that of the previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), offering the best visual experience for viewers. USB (Universal Serial Bus) Type-C Front Panel Connector Equipped with next generation connectivity AORUS Motherboards already support the chassis of the future. The onboard USB (Universal Serial Bus) Type-C header for USB (Universal Serial Bus) 3.2 Gen 1 makes access convenient when connecting a USB (Universal Serial Bus) 3.2 Gen 1 drive or charging your new mobile device. High Quality Onboard Audio Design Delivers high quality sound resolution & sound expansion to create the most realistic sound effects for professional gamers. PERSONALIZATION GIGABYTE motherboards bundle several useful & intuitive software to help users to control every aspect of motherboard & provide customizable lighting effect with outstanding aesthetics to fit your unique personality. Multi-Zone Light Show Design Now offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support & a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs which surround the motherboard. New User Interface All new EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan. My Favorites Add constantly used items into the favorite menu for quick access. Storage Information Show all kinds of storage information including SATA, PCIE & M.2 interface. Changelog List all changes before saving & exiting bios. Quickly review overall settings modification. Intuitive Load Line Curve Clearly show each loadline calibration setting in an intuitive curve graph. GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most. System Information Viewer GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer. ULTRA DURABLE GIGABYTE Ultra Durable features its product durability & high-quality manufacturing process. GIGABYTE motherboards use the best components & reinforce every slots to make each of them solid & durable.&1 Q-Flash Plus Update the BIOS easily without installing the CPU, memory & graphics card. With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go! Solid Pin Power Connectors AORUS motherboards feature solid plated ATX 24pin & ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading. Solid Pin Power connector advantages
- Larger contact area for electricity
- More metal quantity to sustain higher power & generated heat
- Ultra durable & longer lifespan\n\n\n\n Internal I/ONumber of M.2 (M) slots 1USB 3.2 Gen 2 (3.1 Gen 2) connectors 1 Front panel connector Yes 12V power connector Yes Supported storage drive interfaces M.2, SATA IIIUSB 2.0 connectors 1USB 3.2 Gen 1 (3.1 Gen 1) connectors 1TPM connector Yes Serial port headers 1 Number of SATA III connectors 4 Number of chassis fan connectors 1 Front panel audio connector Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family Intel Motherboard chipset Intel B660 Serial port headers 1PC health monitoring CPU, Fan, Temperature, Voltage Parallel processing technology support Not supported HDMI version 2.1 Motherboard form factormini ITXComponent for PCAudio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660RAID levels 0, 1, 5, 10PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factormini ITXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel&174; Core&132;&162; i 5, Intel&174; Core&132;&162; i 7, Intel&174; Core&132;&162; i 9, Intel&174; Pentium&174; Maximum number of SMP processors 1 Processor socket LGA 1700 Memory Number of memory slots 2 Memory slots type DIMMSupported memory types DDR4-SDRAMECCYes Non-ECCYes Supported memory clock speeds 2133, 2400, 2666, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4500, 4600, 4700, 4800, 4933, 5000, 5133, 5333 MHz Maximum internal memory 64 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, SATA IIIRAID levels 0, 1, 5, 10RAID support Yes Graphics Parallel processing technology support Not supported Maximum resolution 4096 x 2160 pixels HDCPYes Rear panel I/O ports USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1 Display Port version 1.2USB 2.0 ports quantity 2 Wi Fi-AP antenna jack 2S/PDIF out port Yes HDMI version 2.1HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1 Digital audio optical out 1 Network Ethernet LANYes Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Ethernet interface type 2.5 Gigabit Ethernet Bluetooth Yes Bluetooth version 5.2 Top Wi-Fi standard Wi-Fi 6 (802.11ax) Features Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factormini ITXComponent for PCExpansion slots Number of M.2 (M) slots 1PCI Express x 16 slots 1BIOSBIOS type UEFI AMIBIOS memory size 256 Mbit ACPI version 5.0 System Management BIOS (SMBIOS) version 2.7 Desktop Management Interface (DMI) version 2.7 Video Maximum resolution 4096 x 2160 pixels HDCPYes Software Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Drivers included Yes Weight & dimensions Width 170 mm Depth 170 mm Packaging content Drivers included Yes Cables included SATA\n\n\n\n







...

Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading. 6+2+1 Phases Low RDS (on) MOSFETs Solid capacitors to improve transient response & minimize oscillation 8-pin Solid Pin CPU Power Connector GIGABYTE B660 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience twice bandwidth than the current PCIe 3.0 devices. To reach the high speed & maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance. Support for DDR4 XMP Up to 5333 M Hz & Beyond GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 5333 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard. Hybrid Cores Optimization With new Intel Hybrid technology, GIGABYTE exclusively creates two new " CPU Upgrade " in BIOS profiles to meet different users&153; scenarios by adjusting P-Core & E-Core activation & voltage policy. M.2 Thermal Guard GIGABYTE Ultra-Efficient M.2 Thermal Guard With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling & bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue. Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface. High Current Support Each fan headers support PWM & DC fan & Water cooling Pump, & up to 24W (12V x 2A) with Over-Current Protection Precision Control Up to 6 temperature/fan speed control points for precise fan curve Dual Curve Mode Slope/ Stair dual mode for different user scenario Fan Stop Fan can stop completely below users' specified temperature point First adopter on 2.5 Gb E LAN onboard 2X Faster than ever Adoption of 2.5G LAN provide up to 2.5 Gb E network connectivity, with at least 2 times faster transfer speeds compared to general 1 Gb E networking, perfectly designed for gamers with ultimate online gaming experience. Support Multi-Gig (10/100/1000/2500 Mbps) RJ-45 Ethernet WIFI 6 802.11ax + BT 5 Module Wireless solution supports 802.11ax, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections & speeds up to 2.4 Gbps*. Moreover, Bluetooth 5 provides 4X range over BT 4.2 & with faster transmission. HDMI 2.0 for 4K UHD Display & HDCP 2.2 supported HDMI 2.0, which is backwards compatible with HDMI 1.4, offers 18 Gb/s of bandwidth " nearly twice that of the previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), offering the best visual experience for viewers. High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level. Q-Flash Plus Update the BIOS easily without installing the CPU, memory & graphics card. With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go! Solid Pin Power Connectors B660 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.\n\n\n\n Technical details Motherboard chipset family Intel Motherboard chipset Intel B660 Supported processor sockets LGA 1700 Motherboard form factormicro ATXComponent for PCAudio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660RAID levels 0, 1, 5, 10 Supported processor sockets LGA 1700 Audio output channels 7.1 channels Motherboard form factormicro ATXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel&174; Core&132;&162; i 5, Intel&174; Core&132;&162; i 7, Intel&174; Core&132;&162; i 9, Intel&174; Pentium&174; Gold Supported processor sockets LGA 1700 Processor socket LGA 1700 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMMemory channels Dual-channel Non-ECCYes Supported memory clock speeds 2133, 2400, 2666, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4500, 4600, 4700, 4800, 4933, 5000, 5133, 5333 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, PCI Express 4.0, SATA IIIRAID levels 0, 1, 5, 10RAID support Yes Internal I/OFront panel connector Yes Supported storage drive interfaces M.2, PCI Express 4.0, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 1S/PDIF out connector Yes Number of SATA III connectors 4 Number of chassis fan connectors 3 Front panel audio connector Yes EPS power connector (8-pin) Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Rear panel I/O ports USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1USB 2.0 ports quantity 2PS/2 ports quantity 1 Microphone in Yes HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1 Network Ethernet LANYes Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Ethernet interface type 2.5 Gigabit Ethernet Bluetooth Yes Bluetooth version 5.2 Top Wi-Fi standard Wi-Fi 6 (802.11ax) Features Power source type ATXWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660 Supported processor sockets LGA 1700 Audio output channels 7.1 channels Motherboard form factormicro ATXComponent for PCExpansion slots PCI Express x 1 (Gen 3.x) slots 2PCI Express x 16 (Gen 4.x) slots 1BIOSBIOS type UEFIBIOS memory size 256 Mbit ACPI version 5.0 System Management BIOS (SMBIOS) version 2.7 Desktop Management Interface (DMI) version 2.7 Power Power source type ATXSoftware Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Weight & dimensions Width 244 mm Depth 244 mm\n\n\n\n ...

- Features latest Intel 4th generation Core processors
- Support 2.5" Hard Drives (1 x 6 Gbps SATA3)
- Ultra compact PC design

...

Redefining the Desktop PC Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a stylish design based around an anthracite aluminum frame & glass surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Dual Display With support for HDMI & Display Port, the BRIX can power two displays simultaneously, making a perfect choice as a high productivity PC in professional & home environments, or in any number of industrial & commercial multi-display applications. Flexible Compact PC Kit The BRIX is sold as a DIY PC kit, shipping with a Mini PCIe Wi-Fi module pre-installed, plus a power adapter & cable conforming to local standards. Requiring only system memory & m SATA SSD, the BRIX gives users the flexibility to independently choose integrated storage & system memory size, without the trouble of sourcing components that are not widely available on the retail market. VESA Support Bundled with a VESA bracket, the BRIX can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This makes it simple & effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. ...

- Features latest Intel 4th generation Core processors
- Support 2.5" Hard Drives (1 x 6 Gbps SATA3)
- Ultra compact PC design

...

Redefining the Desktop PC Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a stylish design based around an anthracite aluminum frame & glass surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Dual Display With support for HDMI & Display Port, the BRIX can power two displays simultaneously, making a perfect choice as a high productivity PC in professional & home environments, or in any number of industrial & commercial multi-display applications. Flexible Compact PC Kit The BRIX is sold as a DIY PC kit, shipping with a Mini PCIe Wi-Fi module pre-installed, plus a power adapter & cable conforming to local standards. Requiring only system memory & m SATA SSD, the BRIX gives users the flexibility to independently choose integrated storage & system memory size, without the trouble of sourcing components that are not widely available on the retail market. VESA Support Bundled with a VESA bracket, the BRIX can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This makes it simple & effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. ...

- Features latest Intel 4th generation Core processors
- Support 2.5" Hard Drives (1 x 6 Gbps SATA3)
- Ultra compact PC design

...
