POWER\n Direct 6+2 Phases Digital VRM Solution with Low RDS (on) MOSFETs\n\n Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n- Digital PWM Controller to deliver appropriate voltage to the CPU.\n- Direct 6+2 Phases Low RDS (on) MOSFETs without PWM Doublers, each power phase connects directly to the CPU.\n- All-solid capacitors to improve transient response & minimize oscillation.\n- 8-pin Solid Pin CPU Power Connector.\n\n PERFORMANCE\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n High Current Support\n Each fan headers support PWM & DC fan & Water cooling Pump, & up to 24W (12V x 2A) with Over-Current Protection\n Precision Control\n Up to 7 temperature/fan speed control points for precise fan curve\n Dual Curve Mode\n Slope/ Stair dual mode for different user scenario\n Fan Stop\n Fan can stop completely below users' specified temperature point\n\n Smart Fan 6 BIOS UI\n Improve fan curve UI\n We increase control points from 5 to 7 & larger fan speed graph for precise & easier fan curve control.\n Slope/ Stair dual graph mode\n Fan curve can be quickly switch with Slope & Stair modes for different user scenario. Slope is traditional & intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.\n Manual Input\n For advanced users, we provide fan speed manual input for more precise control.\n EZ Tuning\n Use can place 4 EZ Tuning points at rough temperature/fan speed, & Smart Fan 6 can quickly generate a fan curve.\n Fan curve profile\n Fan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.\n\n Support for DDR4 XMP Up to 4600 M Hz & Beyond\n GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 4600 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard.\n\n Memory Layout
- Daisy Chain Design\n With the optimized daisy-chain routing, the B560 Ultra Duable motherboard provides a proven speed of up to DDR4-4600+ MHz with high-density Memory module. Optimized daisy-chained routing eliminates the stub effect, pushes the one DIMM per channel in dual channel interleaving mode to hit higher memory frequencies, providing professional gamers a denser & faster system memory experience.\n\n Single 32GB Support\n The maximum memory capacity on the B560 motherboard is 128GB. After Intel updated the memory reference code, a single slot can support up to 32GB. Therefore with populated 2 DIMM per channel on both channel, total memory capacity is 128GB, which was only available on High End Desktop (HEDT) platforms. For users who always run out of memory capacity, there is more bandwidth now for memory-intensive application such as rendering & video editing.\n\n High-End Audio Capacitors\n GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers.\n\n Audio Noise Guard\n GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level.\n\n Dual PCIe 4.0/3.0 x 4 M.2 Connectors\n GIGABYTE Ultra Durable Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their Systems&153; potential.\n\n Exclusive Realtek 8118 Gaming LAN\n High Speed Gigabit LAN with Automatic Bandwidth Allocation\n Realtek 8118 LAN is a high performance & friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features & the fastest & smoothest Internet experience.\n\n High Definition Digital Outputs\n Enjoy true HD display capability using the most commonly integrated digital output technologies on today&153;s HD displays & TVs.\n\n LIGHTING\n RGB FUSION 2.0\n With B560 Motherboard, RGB Fusion 2.0 is even better with Addressable LEDs. RGB Fusion 2.0 offers users the option to control onboard RGB & external RGB / Addressable LED light strips for their PC. Already feature filled with colors & patterns, RGB Fusion 2.0 on B560 Series Motherboards are now upgraded with Addressable LED support. With external Addressable LED strips, where each LED is digitally addressable, users can experience even more patterns, styles, & illuminations.\n\n With B560 Motherboard will support either 5v or 12v Addressable LED lighting strips & up to 300 LED lights. RGB Fusion 2.0 with Addressable LEDs comes with new patterns & various speed settings with more to come.\n\n With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style & show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.\n\n GIGABYTE RGB Fusion APP\n Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try & adjust colors & speeds for different modes, all this can be achieved away from the keyboard & monitor of their PC.\n\n ULTRA DURABLE\n Solid Pin Power Connectors\n B560 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n START SULFURIZATION PROTECTION\n Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change & causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new meaning.\n\n SOFTWARE\n Refreshed BIOS\n The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system.\n\n APP CENTER\n GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities & drivers, you can choose any utility you want to install from APP CENTER & keep updated with the latest utilities & drivers version.\n\n Easy Tune&132;&162;\n GIGABYTE's Easy Tune&132;&162; is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n\n\n Product Model: B560 HD3\n\n\n
...

Direct 12+1 Phases Digital VRM Solution with Low RDS (on) MOSFET\n Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n\n Benefits of Lower RDS (on) MOSFETs\n- Optimized gate charge to minimize switching losses.\n- Lower temperature, smaller size, better thermal characteristics.\n\n ADVANCED THERMAL SOLUTION\n B560M AORUS uses high performance Fully Covered thermal design with high coverage MOSFET Heatsinks & thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers & gamers.\n\n 2X larger Surface\n Increased surface area up to 2X larger compared to traditional heatsinks. It improves heat dissipation from the MOSFETs.\n\n Real One-piece Build\n TMOS is a TRUE single piece heatsink. Its one-piece design & larger surface drastically improve the cooling performance against competitors&153; multi-piece design.\n\n Multi-cut Design\n TMOS features several channels & inlets on the heatsink. This design allows for the air flow to go through which leads to a great improvement of the heat transfer performance.\n\n AORUS M.2 Thermal Guard\n GIGABYTE Ultra-Efficient M.2 Thermal Guard\n With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling & bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.\n\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n Cooling Features\n High Current Support\n Each fan headers support PWM & DC fan & Water cooling Pump, & up to 24W (12V x 2A) with Over-Current Protection\n Precision Control\n Up to 7 temperature/fan speed control points for precise fan curve\n Dual Curve Mode\n Slope/ Stair dual mode for different user scenario\n\n Smart Fan 6 BIOS UI\n Improve fan curve UI\n We increase control points from 5 to 7 & larger fan speed graph for precise & easier fan curve control.\n Slope/ Stair dual graph mode\n Fan curve can be quickly switch with Slope & Stair modes for different user scenario. Slope is traditional & intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.\n Manual Input\n For advanced users, we provide fan speed manual input for more precise control.\n EZ Tuning\n Use can place 4 EZ Tuning points at rough temperature/fan speed, & Smart Fan 6 can quickly generate a fan curve.\n Fan curve profile\n Fan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.\n\n PERFORMANCE\n With the best quality components & GIGABYTE R&D design capability, the B560M AORUS is a true beast among motherboards.\n\n Shielded Memory Routing\n All memory routing is under the PCB inner layer shielded by a large ground layer to protect from external interference.\n\n Dual PCIe 4.0/3.0 x 4 M.2\n GIGABYTE AORUS Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system's potential.\n\n 2.5 Gb E LAN Onboard\n 2X Faster than ever\n- Adoption of 2.5G LAN provide up to 2.5 Gb E network connectivity, with at least 2 times faster transfer speeds compared to general 1 Gb E networking, perfectly designed for gamers with ultimate online gaming experience.\n- Support Multi-Gig (10/100/1000/2500 Mbps) RJ-45 ethernet\n\n Intel&174; USB (Universal Serial Bus) 3.2 Gen 2 Type-C&132;&162; Controller\n Intel's native USB (Universal Serial Bus) 3.2 Gen 2 host controller provides USB (Universal Serial Bus) 3.2 Gen 2 ports with speeds up to 10 Gbps. With twice the bandwidth compared to its previous generation as well as backwards compatibility with USB (Universal Serial Bus) 2.0 & USB (Universal Serial Bus) 3.2 Gen 1, the much enhanced USB (Universal Serial Bus) 3.2 Gen 2 protocol is available over the new reversible USB (Universal Serial Bus) Type-C&132;&162; & the traditional USB (Universal Serial Bus) Type-A connector for better compatibility over a wider range of devices.\n\n USB Type-C&174; Front Panel Connector\n Equipped with next generation connectivity AORUS Motherboards already support the chassis of the future. The onboard USB (Universal Serial Bus) Type-C&174; header for USB (Universal Serial Bus) 3.2 Gen 1 makes access convenient when connecting a USB (Universal Serial Bus) 3.2 Gen 1 drive or charging your new mobile device.\n\n High Quality Onboard Audio Design\n Delivers high quality sound resolution & sound expansion to create the most realistic sound effects for professional gamers.\n\n DEFINITIVE AESTHETICS\n B560M AORUS ELITE features RGB FUSION 2.0 & offers users the option to control onboard, external light strips, and/or AORUS devices with RGB/ Addressable RGB LEDs to make their PC more unique & stylish.\n\n Multi-Zone Light Show Design\n Now offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support & a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs which surround the motherboard.\n\n With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style & show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.\n\n GIGABYTE RGB Fusion APP\n Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try & adjust colors & speeds for different modes, all this can be achieved away from the keyboard & monitor of their PC.\n\n ULTRA DURABLE\n GIGABYTE is reputable for its product durability & high quality manufacturing process. Needless to say, we use the best components we can find for the B560M AORUS motherboard & reinforce every slot to make each of them solid & durable.\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n Ultra Durable&132;&162; PCIe Armor\n Industry Leading Ultra Durable&132;&162; PCIe Armor\n The innovative one piece stainless steel shielding design from GIGABYTE reinforces the PCIe connectors to provide the extra strength required to support heavy graphics cards.\n\n Solid Pin Power Connectors\n AORUS motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n GIGABYTE BIOS & APP CENTER\n Good software goes hand in hand with perfect hardware. GIGABYTE motherboard bundled several useful & intuitive software to help users to control every aspect of motherboard.\n\n BIOS\n New User Interface\n All new EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan.\n My Favorites\n Add constantly used items into the favorite menu for quick access.\n Storage Information\n Show all kinds of storage information including SATA, PCIE & M.2 interface.\n Changelog\n List all changes before saving & exiting bios. Quickly review overall settings modification.\n Intuitive Load Line Curve\n Clearly show each loadline calibration setting in an intuitive curve graph.\n\n APP CENTER\n GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities & drivers, you can choose any utility you want to install from APP CENTER & keep updated with the latest utilities & drivers version.\n\n Easy Tune&132;&162;\n GIGABYTE's Easy Tune&132;&162; is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n\n\n Product Model: B560M AORUS ELITE\n\n\n ...

Direct 12+1 Phases Digital VRM Solution with Low RDS (on) MOSFET\n Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n\n Benefits of Lower RDS (on) MOSFETs\n- Optimized gate charge to minimize switching losses.\n- Lower temperature, smaller size, better thermal characteristics.\n\n ADVANCED THERMAL SOLUTION\n B560M AORUS uses high performance Fully Covered thermal design with high coverage MOSFET Heatsinks & thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers & gamers.\n\n 2X larger Surface\n Increased surface area up to 2X larger compared to traditional heatsinks. It improves heat dissipation from the MOSFETs.\n\n Real One-piece Build\n TMOS is a TRUE single piece heatsink. Its one-piece design & larger surface drastically improve the cooling performance against competitors&153; multi-piece design.\n\n Multi-cut Design\n TMOS features several channels & inlets on the heatsink. This design allows for the air flow to go through which leads to a great improvement of the heat transfer performance.\n\n AORUS M.2 Thermal Guard\n GIGABYTE Ultra-Efficient M.2 Thermal Guard\n With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling & bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.\n\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n Cooling Features\n High Current Support\n Each fan headers support PWM & DC fan & Water cooling Pump, & up to 24W (12V x 2A) with Over-Current Protection\n Precision Control\n Up to 7 temperature/fan speed control points for precise fan curve\n Dual Curve Mode\n Slope/ Stair dual mode for different user scenario\n\n Smart Fan 6 BIOS UI\n Improve fan curve UI\n We increase control points from 5 to 7 & larger fan speed graph for precise & easier fan curve control.\n Slope/ Stair dual graph mode\n Fan curve can be quickly switch with Slope & Stair modes for different user scenario. Slope is traditional & intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.\n Manual Input\n For advanced users, we provide fan speed manual input for more precise control.\n EZ Tuning\n Use can place 4 EZ Tuning points at rough temperature/fan speed, & Smart Fan 6 can quickly generate a fan curve.\n Fan curve profile\n Fan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.\n\n PERFORMANCE\n With the best quality components & GIGABYTE R&D design capability, the B560M AORUS is a true beast among motherboards.\n\n Shielded Memory Routing\n All memory routing is under the PCB inner layer shielded by a large ground layer to protect from external interference.\n\n Dual PCIe 4.0/3.0 x 4 M.2\n GIGABYTE AORUS Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system's potential.\n\n 2.5 Gb E LAN Onboard\n 2X Faster than ever\n- Adoption of 2.5G LAN provide up to 2.5 Gb E network connectivity, with at least 2 times faster transfer speeds compared to general 1 Gb E networking, perfectly designed for gamers with ultimate online gaming experience.\n- Support Multi-Gig (10/100/1000/2500 Mbps) RJ-45 ethernet\n\n Intel&174; USB (Universal Serial Bus) 3.2 Gen 2 Type-C&132;&162; Controller\n Intel's native USB (Universal Serial Bus) 3.2 Gen 2 host controller provides USB (Universal Serial Bus) 3.2 Gen 2 ports with speeds up to 10 Gbps. With twice the bandwidth compared to its previous generation as well as backwards compatibility with USB (Universal Serial Bus) 2.0 & USB (Universal Serial Bus) 3.2 Gen 1, the much enhanced USB (Universal Serial Bus) 3.2 Gen 2 protocol is available over the new reversible USB (Universal Serial Bus) Type-C&132;&162; & the traditional USB (Universal Serial Bus) Type-A connector for better compatibility over a wider range of devices.\n\n USB Type-C&174; Front Panel Connector\n Equipped with next generation connectivity AORUS Motherboards already support the chassis of the future. The onboard USB (Universal Serial Bus) Type-C&174; header for USB (Universal Serial Bus) 3.2 Gen 1 makes access convenient when connecting a USB (Universal Serial Bus) 3.2 Gen 1 drive or charging your new mobile device.\n\n High Quality Onboard Audio Design\n Delivers high quality sound resolution & sound expansion to create the most realistic sound effects for professional gamers.\n\n DEFINITIVE AESTHETICS\n B560M AORUS ELITE features RGB FUSION 2.0 & offers users the option to control onboard, external light strips, and/or AORUS devices with RGB/ Addressable RGB LEDs to make their PC more unique & stylish.\n\n Multi-Zone Light Show Design\n Now offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support & a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs which surround the motherboard.\n\n With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style & show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.\n\n GIGABYTE RGB Fusion APP\n Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try & adjust colors & speeds for different modes, all this can be achieved away from the keyboard & monitor of their PC.\n\n ULTRA DURABLE\n GIGABYTE is reputable for its product durability & high quality manufacturing process. Needless to say, we use the best components we can find for the B560M AORUS motherboard & reinforce every slot to make each of them solid & durable.\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n Ultra Durable&132;&162; PCIe Armor\n Industry Leading Ultra Durable&132;&162; PCIe Armor\n The innovative one piece stainless steel shielding design from GIGABYTE reinforces the PCIe connectors to provide the extra strength required to support heavy graphics cards.\n\n Solid Pin Power Connectors\n AORUS motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n GIGABYTE BIOS & APP CENTER\n Good software goes hand in hand with perfect hardware. GIGABYTE motherboard bundled several useful & intuitive software to help users to control every aspect of motherboard.\n\n BIOS\n New User Interface\n All new EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan.\n My Favorites\n Add constantly used items into the favorite menu for quick access.\n Storage Information\n Show all kinds of storage information including SATA, PCIE & M.2 interface.\n Changelog\n List all changes before saving & exiting bios. Quickly review overall settings modification.\n Intuitive Load Line Curve\n Clearly show each loadline calibration setting in an intuitive curve graph.\n\n APP CENTER\n GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities & drivers, you can choose any utility you want to install from APP CENTER & keep updated with the latest utilities & drivers version.\n\n Easy Tune&132;&162;\n GIGABYTE's Easy Tune&132;&162; is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n\n\n Product Model: B560M AORUS ELITE\n\n\n ...

Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n- Digital PWM Controller to deliver appropriate voltage to the CPU.\n- Direct 6+2 Phases Low RDS (on) MOSFETs without PWM Doublers, each power phase connects directly to the CPU.\n- All-solid capacitors to improve transient response & minimize oscillation.\n- 8-pin Solid Pin CPU Power Connector.\n\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n Cooling Features\n- High Current Support\n Each fan headers support PWM & DC fan & Water cooling Pump, & up to 24W (12V x 2A) with Over-Current Protection\n- Precision Control\n Up to 7 temperature/fan speed control points for precise fan curve\n- Dual Curve Mode\n Slope/ Stair dual mode for different user scenario\n- Fan Stop\n Fan can stop completely below users' specified temperature point\n\n Support for DDR4 XMP Up to 4600 M Hz & Beyond\n GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 4600 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard.\n\n High-End Audio Capacitors\n GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers.\n\n Audio Noise Guard\n GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level.\n\n Dual PCIe 4.0/3.0 x 4 M.2 Connectors\n GIGABYTE Ultra Durable Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their Systems&153; potential.\n\n Intel Gb E LAN with c Fos Speed Internet Accelerator Networking\n Intel Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments.\n\n Connecting the Future
- USB (Universal Serial Bus) Type-C\n The World's Next Universal Connector Reversible USB (Universal Serial Bus) Type-C with USB (Universal Serial Bus) 3.2 Gen 1\n The USB (Universal Serial Bus) Type-C is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.2 Gen 1 support for 10 Gb/s transfer speed. Powered by the Intel&174; USB (Universal Serial Bus) 3.2 Gen 1 controller, this little port provides the best USB (Universal Serial Bus) Type-C experience possible.\n\n High Definition Digital Outputs\n Enjoy true HD display capability using the most commonly integrated digital output technologies on today&153;s HD displays & TVs.\n* Maximum support of 3 independent display at one time.\n\n RGB FUSION 2.0\n With B560 Motherboard, RGB Fusion 2.0 is even better with Addressable LEDs.* RGB Fusion 2.0 offers users the option to control onboard RGB & external RGB / Addressable LED light strips for their PC. Already feature filled with colors & patterns, RGB Fusion 2.0 on B560 Series Motherboards are now upgraded with Addressable LED support. With external Addressable LED strips, where each LED is digitally addressable, users can experience even more patterns, styles, & illuminations.\n\n With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style & show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.\n\n GIGABYTE RGB Fusion APP\n Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try & adjust colors & speeds for different modes, all this can be achieved away from the keyboard & monitor of their PC.\n\n Solid Pin Power Connectors\n B560 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n START SULFURIZATION PROTECTION\n Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change & causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new meaning.\n\n Refreshed BIOS\n The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system.\n\n APP CENTER\n GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities & drivers, you can choose any utility you want to install from APP CENTER & keep updated with the latest utilities & drivers version.\n\n Easy Tune\n GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n\n\n Product Model: B560M D3H\n\n\n
...

Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n- Digital PWM Controller to deliver appropriate voltage to the CPU.\n- Direct 6+2 Phases Low RDS (on) MOSFETs without PWM Doublers, each power phase connects directly to the CPU.\n- All-solid capacitors to improve transient response & minimize oscillation.\n- 8-pin Solid Pin CPU Power Connector.\n\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n Cooling Features\n- High Current Support\n Each fan headers support PWM & DC fan & Water cooling Pump, & up to 24W (12V x 2A) with Over-Current Protection\n- Precision Control\n Up to 7 temperature/fan speed control points for precise fan curve\n- Dual Curve Mode\n Slope/ Stair dual mode for different user scenario\n- Fan Stop\n Fan can stop completely below users' specified temperature point\n\n Support for DDR4 XMP Up to 4600 M Hz & Beyond\n GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 4600 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard.\n\n High-End Audio Capacitors\n GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers.\n\n Audio Noise Guard\n GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level.\n\n Dual PCIe 4.0/3.0 x 4 M.2 Connectors\n GIGABYTE Ultra Durable Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their Systems&153; potential.\n\n Intel Gb E LAN with c Fos Speed Internet Accelerator Networking\n Intel Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments.\n\n Connecting the Future
- USB (Universal Serial Bus) Type-C\n The World's Next Universal Connector Reversible USB (Universal Serial Bus) Type-C with USB (Universal Serial Bus) 3.2 Gen 1\n The USB (Universal Serial Bus) Type-C is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.2 Gen 1 support for 10 Gb/s transfer speed. Powered by the Intel&174; USB (Universal Serial Bus) 3.2 Gen 1 controller, this little port provides the best USB (Universal Serial Bus) Type-C experience possible.\n\n High Definition Digital Outputs\n Enjoy true HD display capability using the most commonly integrated digital output technologies on today&153;s HD displays & TVs.\n* Maximum support of 3 independent display at one time.\n\n RGB FUSION 2.0\n With B560 Motherboard, RGB Fusion 2.0 is even better with Addressable LEDs.* RGB Fusion 2.0 offers users the option to control onboard RGB & external RGB / Addressable LED light strips for their PC. Already feature filled with colors & patterns, RGB Fusion 2.0 on B560 Series Motherboards are now upgraded with Addressable LED support. With external Addressable LED strips, where each LED is digitally addressable, users can experience even more patterns, styles, & illuminations.\n\n With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style & show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.\n\n GIGABYTE RGB Fusion APP\n Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try & adjust colors & speeds for different modes, all this can be achieved away from the keyboard & monitor of their PC.\n\n Solid Pin Power Connectors\n B560 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n START SULFURIZATION PROTECTION\n Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change & causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new meaning.\n\n Refreshed BIOS\n The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system.\n\n APP CENTER\n GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities & drivers, you can choose any utility you want to install from APP CENTER & keep updated with the latest utilities & drivers version.\n\n Easy Tune\n GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n\n\n Product Model: B560M D3H\n\n\n
...

POWER\n 6+2 Phases Digital Power Design\n Direct 6+2 Phases Digital VRM Solution with Low RDS (on) MOSFETs\n\n Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n- Digital PWM Controller to deliver appropriate voltage to the CPU.\n- Direct 6+2 Phases Low RDS (on) MOSFETs without PWM Doublers, each power phase connects directly to the CPU.\n- All-solid capacitors to improve transient response & minimize oscillation.\n- 8-pin Solid Pin CPU Power Connector.\n\n PERFORMANCE\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n High Current Support\n Each fan headers support PWM & DC fan & Water cooling Pump, & up to 24W (12V x 2A) with Over-Current Protection\n Precision Control\n Up to 7 temperature/fan speed control points for precise fan curve\n Dual Curve Mode\n Slope/ Stair dual mode for different user scenario\n Fan Stop\n Fan can stop completely below users' specified temperature point\n\n Smart Fan 6 BIOS UI\n Improve fan curve UI\n We increase control points from 5 to 7 & larger fan speed graph for precise & easier fan curve control.\n Slope/ Stair dual graph mode\n Fan curve can be quickly switch with Slope & Stair modes for different user scenario. Slope is traditional & intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.\n Manual Input\n For advanced users, we provide fan speed manual input for more precise control.\n EZ Tuning\n Use can place 4 EZ Tuning points at rough temperature/fan speed, & Smart Fan 6 can quickly generate a fan curve.\n Fan curve profile\n Fan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.\n\n High-End Audio Capacitors\n GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers.\n Audio Noise Guard\n GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level.\n\n Dual PCIe 4.0/3.0 x 4 M.2 Connectors\n GIGABYTE Ultra Durable Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their Systems&153; potential.\n\n LIGHTING\n RGB FUSION 2.0\n With B560 Motherboard, RGB Fusion 2.0 is even better with Addressable LEDs. RGB Fusion 2.0 offers users the option to control onboard RGB & external RGB / Addressable LED light strips for their PC. Already feature filled with colors & patterns, RGB Fusion 2.0 on B560 Series Motherboards are now upgraded with Addressable LED support. With external Addressable LED strips, where each LED is digitally addressable, users can experience even more patterns, styles, & illuminations.\n\n With B560 Motherboard will support either 5v or 12v Addressable LED lighting strips & up to 300 LED lights. RGB Fusion 2.0 with Addressable LEDs comes with new patterns & various speed settings with more to come.\n\n With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style & show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.\n\n GIGABYTE RGB Fusion APP\n Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try & adjust colors & speeds for different modes, all this can be achieved away from the keyboard & monitor of their PC.\n\n ULTRA DURABLE\n Solid Pin Power Connectors\n B560 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n START SULFURIZATION PROTECTION\n Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change & causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new meaning.\n\n SOFTWARE\n Refreshed BIOS\n The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system.\n\n APP CENTER\n GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities & drivers, you can choose any utility you want to install from APP CENTER & keep updated with the latest utilities & drivers version.\n\n Easy Tune&132;&162;\n GIGABYTE's Easy Tune&132;&162; is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n\n\n Product Model: B560M H\n\n\n ...

POWER\n 6+2 Phases Digital Power Design\n Direct 6+2 Phases Digital VRM Solution with Low RDS (on) MOSFETs\n\n Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n- Digital PWM Controller to deliver appropriate voltage to the CPU.\n- Direct 6+2 Phases Low RDS (on) MOSFETs without PWM Doublers, each power phase connects directly to the CPU.\n- All-solid capacitors to improve transient response & minimize oscillation.\n- 8-pin Solid Pin CPU Power Connector.\n\n PERFORMANCE\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n High Current Support\n Each fan headers support PWM & DC fan & Water cooling Pump, & up to 24W (12V x 2A) with Over-Current Protection\n Precision Control\n Up to 7 temperature/fan speed control points for precise fan curve\n Dual Curve Mode\n Slope/ Stair dual mode for different user scenario\n Fan Stop\n Fan can stop completely below users' specified temperature point\n\n Smart Fan 6 BIOS UI\n Improve fan curve UI\n We increase control points from 5 to 7 & larger fan speed graph for precise & easier fan curve control.\n Slope/ Stair dual graph mode\n Fan curve can be quickly switch with Slope & Stair modes for different user scenario. Slope is traditional & intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.\n Manual Input\n For advanced users, we provide fan speed manual input for more precise control.\n EZ Tuning\n Use can place 4 EZ Tuning points at rough temperature/fan speed, & Smart Fan 6 can quickly generate a fan curve.\n Fan curve profile\n Fan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.\n\n High-End Audio Capacitors\n GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers.\n Audio Noise Guard\n GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level.\n\n Dual PCIe 4.0/3.0 x 4 M.2 Connectors\n GIGABYTE Ultra Durable Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their Systems&153; potential.\n\n LIGHTING\n RGB FUSION 2.0\n With B560 Motherboard, RGB Fusion 2.0 is even better with Addressable LEDs. RGB Fusion 2.0 offers users the option to control onboard RGB & external RGB / Addressable LED light strips for their PC. Already feature filled with colors & patterns, RGB Fusion 2.0 on B560 Series Motherboards are now upgraded with Addressable LED support. With external Addressable LED strips, where each LED is digitally addressable, users can experience even more patterns, styles, & illuminations.\n\n With B560 Motherboard will support either 5v or 12v Addressable LED lighting strips & up to 300 LED lights. RGB Fusion 2.0 with Addressable LEDs comes with new patterns & various speed settings with more to come.\n\n With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style & show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.\n\n GIGABYTE RGB Fusion APP\n Don't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try & adjust colors & speeds for different modes, all this can be achieved away from the keyboard & monitor of their PC.\n\n ULTRA DURABLE\n Solid Pin Power Connectors\n B560 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n START SULFURIZATION PROTECTION\n Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change & causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design GIGABYTE gives Ultra Durable Motherboards a whole new meaning.\n\n SOFTWARE\n Refreshed BIOS\n The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system.\n\n APP CENTER\n GIGABYTE APP CENTER is a useful portal of all GIGABYTE MB utilities & drivers, you can choose any utility you want to install from APP CENTER & keep updated with the latest utilities & drivers version.\n\n Easy Tune&132;&162;\n GIGABYTE's Easy Tune&132;&162; is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n\n\n Product Model: B560M H\n\n\n ...

Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.
- 8+2+1 Phases Low RDS (on) MOSFETs
- Solid capacitors to improve transient response & minimize oscillation
- 8-pin Solid Pin CPU Power Connector Support for DDR4 XMP Up to 5333 M Hz & Beyond GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 5333 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard. GIGABYTE B660 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience triple bandwidth than the current PCIe 3.0 devices. To reach the high speed & maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance. Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface. Hybrid Cores Optimization With new Intel Hybrid technology, GIGABYTE exclusively creates two new " CPU Upgrade " in BIOS profiles to meet different users&153; scenarios by adjusting P-Core & E-Core activation & voltage policy. Exclusive Realtek 8118 Gaming LAN High Speed Gigabit LAN with Automatic Bandwidth Allocation Realtek 8118 LAN is a high performance & friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features & the fastest & smoothest Internet experience. WIFI 6E Advantage Spectrum congestion is huge problem in current WIFI environment nowadays because too many devices all use existing 2.4 G Hz & 5 G Hz spectrum, & it cause unreliable connection & slower speed. WIFI 6E is extended standard to WIFI 6, & it use dedicated 6 G Hz band that it provides not only brand new frequency to transfer data, but also spacious spectrum for future more devices. With WIFI 6E, users can enjoy faster connection & stronger signal than before. Connecting the Future
- USB (Universal Serial Bus) 3.2 Gen 2x 2 Type-C Featuring the USB (Universal Serial Bus) 3.2 Gen 2x 2 design which is doubled the performance than previous generation of USB (Universal Serial Bus) 3.2 Gen 2. It works up to 20 Gbps ultra-fast data transfer while connecting to USB (Universal Serial Bus) 3.2 compliant peripherals. Through the USB (Universal Serial Bus) Type-C connector, users can enjoy the flexibility of reversible connection to access & store massive amounts of data rapidly. HDMI 2.0 for 4K UHD Display & HDCP 2.2 supported HDMI 2.0, which is backwards compatible with HDMI 1.4, offers 18 Gb/s of bandwidth " nearly twice that of the previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), offering the best visual experience for viewers. High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level. Update the BIOS easily without installing the CPU, memory & graphics card. With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go! Solid Pin Power Connectors B660 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading. Solid Pin Power connector advantages
- Larger contact area for electricity
- More metal quantity to sustain higher power & generated heat
- Ultra durable & longer lifespan RGB FUSION 2.0 B660 motherboards feature RGB FUSION 2.0 to offer lighting effected options & customized settings with outstanding aesthetics, & able to let enthusiasts building a stylish & unique gaming PC. Refreshed BIOS The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system. * Photos are for reference only. Product features may vary by model. Easy Tune GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most. System Information Viewer GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n Internal I/ONumber of M.2 (M) slots 2 Thunderbolt headers 2USB 3.2 Gen 2 (3.1 Gen 2) connectors 1 Front panel connector Yes 12V power connector Yes Supported storage drive interfaces M.2, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 1TPM connector Yes Serial port headers 1S/PDIF out connector Yes Number of SATA III connectors 4 Number of chassis fan connectors 3 Front panel audio connector Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family Intel Motherboard chipset Intel B660 Serial port headers 1PC health monitoring CPU, Fan, Temperature, Voltage HDMI version 2.1 Motherboard form factor ATXComponent for PCAudio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660RAID levels 0, 1, 5, 10PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel Core i 5, Intel Core i 7, Intel Core i 9, Intel&174; Pentium&174; Maximum number of SMP processors 1 Processor socket LGA 1700 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMECCYes Non-ECCYes Supported memory clock speeds 2133, 2400, 2666, 2933, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4500, 4600, 4700, 4800, 4933, 5000, 5133, 5333 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, SATA IIIRAID levels 0, 1, 5, 10RAID support Yes Graphics Maximum resolution 4096 x 2160 pixels HDCPYes Rear panel I/O ports USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1 Display Port version 1.2USB 2.0 ports quantity 4 Wi Fi-AP antenna jack 2PS/2 ports quantity 1HDMI version 2.1HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1USB 3.2 Gen 2x 2 Type-C ports quantity 1 Network Ethernet LANYes Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Ethernet interface type Gigabit Ethernet Bluetooth Yes Bluetooth version 5.2 Top Wi-Fi standard Wi-Fi 6E (802.11ax)WLAN controller model RZ608 Features Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCExpansion slots Number of M.2 (M) slots 2PCI Express x 16 slots 2BIOSBIOS type UEFI AMIClear CMOS jumper Yes BIOS memory size 256 Mbit ACPI version 5.0 System Management BIOS (SMBIOS) version 2.7 Desktop Management Interface (DMI) version 2.7 Video Maximum resolution 4096 x 2160 pixels HDCPYes Software Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Drivers included Yes Weight & dimensions Width 305 mm Depth 244 mm Packaging content Drivers included Yes Cables included SATA\n\n\n\n






...

Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.
- 8+2+1 Phases Low RDS (on) MOSFETs
- Solid capacitors to improve transient response & minimize oscillation
- 8-pin Solid Pin CPU Power Connector Support for DDR4 XMP Up to 5333 M Hz & Beyond GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 5333 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard. GIGABYTE B660 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience triple bandwidth than the current PCIe 3.0 devices. To reach the high speed & maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance. Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface. Hybrid Cores Optimization With new Intel Hybrid technology, GIGABYTE exclusively creates two new " CPU Upgrade " in BIOS profiles to meet different users&153; scenarios by adjusting P-Core & E-Core activation & voltage policy. Exclusive Realtek 8118 Gaming LAN High Speed Gigabit LAN with Automatic Bandwidth Allocation Realtek 8118 LAN is a high performance & friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features & the fastest & smoothest Internet experience. Connecting the Future
- USB (Universal Serial Bus) 3.2 Gen 2x 2 Type-C Featuring the USB (Universal Serial Bus) 3.2 Gen 2x 2 design which is doubled the performance than previous generation of USB (Universal Serial Bus) 3.2 Gen 2. It works up to 20 Gbps ultra-fast data transfer while connecting to USB (Universal Serial Bus) 3.2 compliant peripherals. Through the USB (Universal Serial Bus) Type-C connector, users can enjoy the flexibility of reversible connection to access & store massive amounts of data rapidly. HDMI 2.0 for 4K UHD Display & HDCP 2.2 supported HDMI 2.0, which is backwards compatible with HDMI 1.4, offers 18 Gb/s of bandwidth " nearly twice that of the previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), offering the best visual experience for viewers. High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level. Q-Flash Plus Update the BIOS easily without installing the CPU, memory & graphics card. With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go! Solid Pin Power Connectors B660 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading. Solid Pin Power connector advantages
- Larger contact area for electricity
- More metal quantity to sustain higher power & generated heat
- Ultra durable & longer lifespan RGB FUSION 2.0 B660 motherboards feature RGB FUSION 2.0 to offer lighting effected options & customized settings with outstanding aesthetics, & able to let enthusiasts building a stylish & unique gaming PC. Refreshed BIOS The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system. * Photos are for reference only. Product features may vary by model. Easy Tune GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most. System Information Viewer GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n\n\n Internal I/ONumber of M.2 (M) slots 2USB 3.2 Gen 2 (3.1 Gen 2) connectors 1 Front panel connector Yes 12V power connector Yes Supported storage drive interfaces M.2, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 1TPM connector Yes Serial port headers 1S/PDIF out connector Yes Number of SATA III connectors 4 Number of chassis fan connectors 3 Front panel audio connector Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family Intel Motherboard chipset Intel B660 Serial port headers 1PC health monitoring CPU, Fan, Temperature, Voltage HDMI version 2.1 Motherboard form factor ATXComponent for PCAudio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660RAID levels 0, 1, 5, 10PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel Core i 5, Intel Core i 7, Intel Core i 9, Intel&174; Pentium&174; Maximum number of SMP processors 1 Processor socket LGA 1700 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMECCYes Non-ECCYes Supported memory clock speeds 3466, 3600, 3666, 3733, 3800, 3866, 4000, 4133, 4266, 4300, 4400, 4500, 4600, 4700, 4800, 4933, 5000, 5133, 5333 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, SATA IIIRAID levels 0, 1, 5, 10RAID support Yes Graphics Maximum resolution 4096 x 2160 pixels HDCPYes Rear panel I/O ports USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1 Display Port version 1.2USB 2.0 ports quantity 4PS/2 ports quantity 1HDMI version 2.1HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1USB 3.2 Gen 2x 2 Type-C ports quantity 1 Network Ethernet LANYes Wi-Fi No Ethernet interface type Gigabit Ethernet Features Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660PC health monitoring CPU, Fan, Temperature, Voltage Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCExpansion slots Number of M.2 (M) slots 2PCI Express x 16 slots 5BIOSBIOS type UEFI AMIBIOS memory size 256 Mbit ACPI version 5.0 System Management BIOS (SMBIOS) version 2.7 Desktop Management Interface (DMI) version 2.7 Video Maximum resolution 4096 x 2160 pixels HDCPYes Software Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Drivers included Yes Weight & dimensions Width 305 mm Depth 244 mm Packaging content Drivers included Yes Cables included SATA\n\n\n\n






...

UNPARALLELED PERFORMANCE\n With technology moving so fast, GIGABYTE still keep up with the latest trends & provide our customers with advanced features & latest technology. GIAGBYTE B660 Series motherboards come with upgraded power solution, latest storage standards & outstanding connectivity to enable optimize performance for gaming.\n\n Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading.\n- 8+1+1 Phases Dr MOS\n- Solid capacitors to improve transient response & minimize oscillation\n- 8-pin Solid Pin CPU Power Connector\n\n GIGABYTE B660 Motherboards are ready to work with the PCIe 4.0 devices which are expected to experience twice bandwidth than the current PCIe 3.0 devices. To reach the high speed & maintain good signal integrity, GIGABYTE R&D uses the low impedance PCB to provide the maximum performance.\n\n Support for DDR4 XMP Up to 4400 M Hz & Beyond\n GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 4400 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE otherboard.\n\n Hybrid Cores Optimization\n With new Intel Hybrid technology, GIGABYTE exclusively creates two new " CPU Upgrade " in BIOS profiles to meet different users&153; scenarios by adjusting P-Core & E-Core activation & voltage policy.\n\n M.2 Thermal Guard\n With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling & bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.\n\n 3% Cooler by implementing&227;&227;&227;&227;&227;&227;&227;\n 2x copper PCB Design\n By adopting 2x copper on PCB inner layer, it lowers the components' temperature at least 3% by turning the PCB into a super thin PCB size copper heatsink to dissipate the heat from the components effectively, due to it&153;s high thermal conductivity & lower impedance.\n\n Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.\n\n NEXT GENERATION CONNECTIVITY\n GIGABYTE B660 Series Motherboards let you experience ultimate connection flexibility & blazing data-transfer speed with next generation network, storage, & WIFI connectivity.\n\n First adopter on 2.5 Gb E LAN onboard\n\n 2X Faster than ever\n- Adoption of 2.5G LAN provide up to 2.5 Gb E network connectivity, with at least 2 times faster transfer speeds compared to general 1 Gb E networking, perfectly designed for gamers with ultimate online gaming experience.\n- Support Multi-Gig (10/100/1000/2500 Mbps) RJ-45 Ethernet\n\n 802.11ax WIFI 6E\n Latest Wireless solution 802.11ax WIFI 6E with new dedicated 6 G Hz b&, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections & speeds up to 2.4 Gbps*. Moreover, Bluetooth 5 provides 4X range over BT 4.2 & with faster transmission.\n\n Benefit of WIFI 6E\n Dedicated spectrum in 6 G Hz band for less interference\n 5.5X throughput than 802.11ac 1x 1\n 4X better network capacity, no traffic jams especially in those dense area with lots of devices\n Network efficiency increase for better user experience\n\n Connecting the Future
- USB (Universal Serial Bus) Type-C\n The World's Next Universal Connector\n The USB (Universal Serial Bus) Type-C is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.2 Gen 2 support for 10 Gb/s transfer speed. Powered by the Intel USB (Universal Serial Bus) 3.2 Gen 2 controller, this little port provides the best USB (Universal Serial Bus) Type-C experience possible.\n\n High-End Audio Capacitors\n GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers.\n\n Audio Noise Guard\n GIGABYTE motherboards feature an audio noise guard that essentially separates the board&153;s sensitive analog audio components from potential noise pollution at the PCB level.\n\n DEFINITIVE AESTHETICS\n GIGABYTE motherboards bundle several useful & intuitive software to help users to control every aspect of motherboard & provide customizable lighting effect with outstanding aesthetics to fit your unique personality.\n\n RGB FUSION 2.0\n B660 motherboards feature RGB FUSION 2.0 to offer lighting effected options & customized settings with outstanding aesthetics, & able to let enthusiasts building a stylish & unique gaming PC.\n\n New User Interface\n All new EASY MODE shows important hardware information in one page including CPU clock, Memory, Storage, Fan.\n My Favorites\n Add constantly used items into the favorite menu for quick access.\n Storage Information\n Show all kinds of storage information including SATA, PCIE & M.2 interface.\n Changelog\n List all changes before saving & exiting bios. Quickly review overall settings modification.\n Intuitive Load Line Curve\n Clearly show each loadline calibration setting in an intuitive curve graph.\n\n Easy Tune\n GIGABYTE's Easy Tune is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most.\n\n System Information Viewer\n GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System Information Viewer.\n\n ULTRA DURABLE\n GIGABYTE Ultra Durable features its product durability & high-quality manufacturing process. GIGABYTE motherboards use the best components & reinforce every slots to make each of them solid & durable.\n\n Q-Flash Plus\n Update the BIOS easily without installing the CPU, memory & graphics card.\n With GIGABYTE Q-Flash Plus, you don&153;t need to install the CPU, memory & graphics card nor enter the BIOS menu to flash the BIOS. Just download & save a new BIOS file (rename to gigabyte.bin) on the USB (Universal Serial Bus) flash drive, then press the dedicated Q-Flash Plus button & you&153;re good to go!\n\n Solid Pin Power Connectors\n B660 motherboards feature solid plated ATX 12V 8 pin power connectors to offer a stable power supply during CPU overloading.\n\n Solid Pin Power connector advantages\n- Larger contact area for electricity\n- More metal quantity to sustain higher power & generated heat\n- Ultra durable & longer lifespan\n\n\n\n\n\n\n\n Model: B660 GAMING X AX DDR4\n\n\n\n Manual: https://d 5bm 31en 4blvo.cloudfront.net/uploads/pdf/mmo_96597934_1642596209_5529_24567.pdf\n\n\n\n
...
