Low Profile Serial Card &pipe; Full Profile Brackets Incl &pipe; 921.4 Kbps &pipe; Windows & Linux\n\n Add eight RS-232 DB9 serial ports to your desktop computer, through two PCIe expansion card slots. This PCI express serial card, with two breakout cables, provides you with multiple ports to connect a wide variety of serial peripherals, at speeds of up to 921.4 Kbps. Connect your Peripherals with 8 Serial Ports The PCI express serial port card makes it easy to add serial ports to connect your peripherals including printers, scanners, credit/debit card readers, PIN pads & modems, industrial controls & more. The 8 port PCIe serial card
Includes:: 2 breakout cables
- each with 4 DB9 connectors. Versatile Use The low profile PCIe serial card is the ideal choice for adding serial ports, even when space is at a premium. The DB9 serial card is designed to fit into small form factor & standard computer cases. The card comes pre-configured with a low-profile bracket, &
Includes:: two optional full-profile brackets, so installation is easy regardless of the case form factor. Maximum Compatibility With broad OS support, including for Windows & Linux, this PCI Express card is easy to integrate into mixed environments.PEX8S1050LP&175;is backed by a Star Tech.com lifetime warranty & free lifetime technical support.\n\n The Star Tech.com Advantage\n\n- 8 PORT SERIAL CARD: Serial controller card w/ 16C1050 UART based on the Systembase SB16C1058PCI, w/15k V ESD, 8x DB9 ports, bi-directional RS232 speeds up to 921.6 Kbps per port & 256 byte FIFO buffer\n- OPTIONAL CONFIGURABLE POWER: Multiport serial card provides 12v/5v, or none on pin 9 w/up to 3A total shared; 2 (1x DB44 to 4x DB9) breakout cables incl; Hex nuts incl for opt screw or nut DB9 interface\n- COMPATABILITY: 2 low profile brackets for PCI-e 1x card; Fully compliant w/ PCI Express Base Spec, Revision 1.0a/1.1; Supports Windows (incl. XP & up) & Linux; For low profile desktop/servers\n\n\n\n Product ID: PEX8S1050LP\n\n\n\n\n\n Model: 8-Port PCI Express RS232 Serial Adapter Card
- PCIe RS232 Serial Card
- 16C1050 UART
- Low Profile Serial DB9 Controller/ Expansion Card
- 15k V ESD Protection
- Windows/ Linux\n\n Datasheet: http://objects.icecat.biz/objects/mmo_76455154_1593700791_4374_19663.pdf\n\n\n\n Manual: http://objects.icecat.biz/objects/mmo_76455154_1593700789_3011_32023.pdf\n\n\n\n\n\n\n\n
